Use only the power adapter supplied with this
product.
Make sure the electrical outlet is not controlled
by a wall switch.
The power adapter is intended to be correctly
oriented in a vertical or floor mount position. The
prongs are not designed to hold the plug in place
if they are plugged into a ceiling, under-the-table
or cabinet outlet.
Make sure the baby unit and the power adapter
cord are out of reach of children.
•
•
•
•
Overview 1Light sensor
2Camera
3Infrared LEDs
4-/VOLUME/+
Press to adjust the speaker volume.
It determines the talkback volume
transmitted from your parent unit.
•
5Microphone
6ON/OFF LED light
On when the baby unit is turned on
and is paired to the parent unit.
Flashes when the baby unit is not
being viewed; or when the link to the
parent unit is lost.
•
•
7ON/OFF switch
Slide to turn on or off the baby unit.•
8Temperature sensor
9Speaker
10 Threaded socket
For wall mount installation use.•
11 Power jack
12 PAIR
Press and hold to pair the parent unit.•
Before use
Pair new baby unit
Each newly purchased baby unit (VM3211)
must be paired to your video monitor system
(VM3251/VM3251-2).
You can pair a maximum of four baby units to your
parent unit. Each new baby unit must be paired to
the parent unit before use.
Make sure you power on the parent unit before
pairing.
Press MENU when the parent unit is idle.
Press or to choose , then press to
select.
Press or to choose an empty baby
unit slot ( , , or ), then press
SELECT. The parent unit screen displays
.
Use a narrow-pointed object, such as a
pen, to press PAIR on the bottom of the
baby unit.
The ON/OFF LED light at the side of
baby unit flashes quickly when pairing.
•
•
1.
2.
3.
4.
•
When pairing is successful, the parent unit
screen displays and the LINK light turns
on. The view of the newly paired baby unit
in SINGLE-CAM mode will be shown on the
parent unit. The ON/OFF LED light on the new
baby unit remains on.
Check for reception strength and camera angle
before drilling the holes.
Place the wall mount bracket on a wall and
then use a pencil to mark the top and the
bottom holes as shown. Remove the wall
mount bracket and drill two holes in the wall
(7/32 inch drill bit).
If you drill the holes into a stud, go to step 3.
-OR-
If you drill the holes into an object other than
a stud, insert the wall anchors into the holes.
1.
2.
•
-
-
•
1.
2.
Tap gently on the ends with a hammer until
the wall anchors are flush with the wall.
Align the wall mount bracket and screws
with the holes in the wall as shown. Tighten
the screw in the middle hole first, so that
the wall mount bracket position is fixed.
You can tighten the other screw in the top
hole.
Place the baby unit on the wall mount
bracket. Tighten the screw into the threaded
socket at the bottom to secure the baby unit.
-OR-
Insert the screws into the holes and tighten
the screws until only 1/4 inch of the screws
are exposed.
Place the baby unit on the wall mount
bracket. Tighten the screw into the
threaded socket at the bottom to secure the
baby unit. Align the holes on the wall mount
bracket with the screws on the wall, and
slide the wall mount bracket down until it
locks into place.
3.
Operating range
The operating range of the baby monitor is
up to 300 meters (1,000 feet) outdoors or
50 meters (160 feet) indoors. The actual
operating range may vary depending on
the environmental conditions and other
interferences such as walls, doors and other
obstructions.
General product care
To keep this product working well and looking good,
follow these guidelines:
Avoid putting it near heating appliances and
devices that generate electrical noise (for
example, motors or fluorescent lamps).
DO NOT expose it to direct sunlight or moisture.
Avoid dropping the product or treating it roughly.
Clean with a soft cloth.
DO NOT immerse the baby unit in water and do
not clean them under the tap.
DO NOT use cleaning spray or liquid cleaners.
Make sure the baby unit is dry before you connect
them to the mains again.
•
•
•
•
•
•
•
Important safety instructions
When using your equipment, basic safety
precautions should always be followed to reduce
the risk of fire, electric shock and injury, including
the following:
Follow all warnings and instructions marked on
the product.
Adult setup is required.
This product is intended as an aid. It is not
a substitute for responsible and proper adult
supervision and should not be used as such.
This product is not intended for use as a
medical monitor.
Do not use this product near water. For
example, do not use it next to a bath tub, wash
bowl, kitchen sink, laundry tub or swimming
pool, or in a wet basement or shower.
Use only the adapters included with this
product. Incorrect adapter polarity or voltage
can seriously damage the product.
Baby unit power adapter:
Output: 5V DC 1000mA
The power adapters are intended to be correctly
oriented in a vertical or floor mount position.
The prongs are not designed to hold the plug
in place if it is plugged into a ceiling, under-the-
table or cabinet outlet.
For pluggable equipment, the socket-outlet
shall be installed near the equipment and shall
be easily accessible.
Unplug this product from the wall outlet before
cleaning. Do not use liquid or aerosol cleaners.
Use a damp cloth for cleaning.
Do not cut off the power adapters to replace them
with other plugs, as this causes a hazardous
situation.
Do not allow anything to rest on the power
cords. Do not install this product where the
cords may be walked on or crimped.
This product should be operated only from the
type of power source indicated on the marking
label. If you are not sure of the type of power
supply in your home, consult your dealer or
local power company.
Do not overload wall outlets or use an extension
cord.
Do not place this product on an unstable table,
shelf, stand or other unstable surfaces.
This product should not be placed in any area
where proper ventilation is not provided. Slots
and openings in the back or bottom of this
product are provided for ventilation. To protect
them from overheating, these openings must
not be blocked by placing the product on a soft
surface such as a bed, sofa or rug. This product
should never be placed near or over a radiator
or heat register.
