V-ZUG 31038 Series User manual

Operating instructions
Induction multi slider
Glas ceramic hob

Thank you for choosing to buy one of our products. Your appliance is made to
high standards and is easy to use. Nevertheless, please take the time to read
these operating instructions in order to familiarize yourself with the appliance
and get the best use out of it.
Please follow the safety precautions.
Modifications
Text, diagrams and data correspond to the technical standard of the appliance
at the time these operating instructions went to press. The right to make tech-
nical modifications for the purpose of the further development of the appliance
is reserved.
Validity
The product family (model number) corresponds to the first alphanumerics on
the identification plate. These operating instructions apply to:
Type Product family
GK37TIMPS/C/F/F spec. 31038
GK46TIABS/C/F/U/.1F 028, 31017
GK47TIMPS/C/F 31036
GK47TIMAS/C/F 31037
GK36TIPS/C/F/F spec. 975
GK46TIPS/C/F/F spec. 973
GK46TIAS/C/F/U/.1F 974, 31019
Variations depending on the model are noted in the text.
© V-ZUG Ltd, CH-6301 Zug, 2015
2

Contents
1 Safety precautions 5
1.1 Symbols used..............................................................................................5
1.2 General safety precautions.......................................................................6
1.3 Appliance-specific safety precautions ....................................................7
1.4 Instructions for use.....................................................................................8
2 Disposal 10
3 Using for the first time 11
4 Your appliance 12
4.1 Appliance overview..................................................................................12
4.2 Operating and display elements ...........................................................14
4.3 How induction hobs function .................................................................15
4.4 Pan detection............................................................................................16
4.5 Cookware...................................................................................................16
4.6 Flexible cooking .......................................................................................17
5 Operating the appliance 18
5.1 Switching the appliance on and off ......................................................18
5.2 Selecting a cooking zone.......................................................................18
5.3 Overview of power levels........................................................................19
5.4 Switching a cooking zone off.................................................................19
5.5 Residual heat indicator ...........................................................................19
5.6 Keep warm setting...................................................................................19
5.7 PowerPlus..................................................................................................20
5.8 Automatic boost .......................................................................................27
5.9 Operating time..........................................................................................28
5.10 Timer...........................................................................................................30
5.11 Childproof lock .........................................................................................31
5.12 Restore function .......................................................................................32
5.13 Pause cooking..........................................................................................33
5.14 Wipe protection ........................................................................................33
6 User settings 34
6.1 Changing user settings...........................................................................35
6.2 Cancelling user settings .........................................................................35
7 Care and maintenance 36
8 Trouble-shooting 37
9 Technical data 40
3

9.1 Product fiche.............................................................................................40
10 Index 42
11 Notes 44
12 Service & Support 47
4

1 Safety precautions
1.1 Symbols used
Denotes important safety precautions.
Failure to observe said precautions can result in injury or in damage
to the appliance or fittings!
Information and precautions that should be observed.
Information on disposal
Information about the operating instructions
►Indicates step-by-step instructions.
–Describes how the appliance reacts to the steps taken.
•Indicates a list.
5

1 Safety precautions
1.2 General safety precautions
•Read the operating instructions before using the appliance for
the first time!
•This appliance can be used by children aged 8 and above
and by persons with reduced physical, sensory or mental cap-
abilities, or lack of experience and/or knowledge, provided
they are supervised or have been instructed on the safe use
of the appliance and have understood the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be undertaken by children without su-
pervision.
•If an appliance is not equipped with a mains cable and a plug
or other means for disconnecting from the mains with a con-
tact opening on each pole complying with the conditions of
overvoltage category III for full isolation, an isolating device
must be incorporated into the permanently installed electrical
installation in accordance with the installation regulations.
•If the mains cable of this appliance is damaged, it must be re-
placed by the manufacturer or its Customer Services or a sim-
ilarly qualified person in order to avoid hazard.
6

1 Safety precautions
1.3 Appliance-specific safety precautions
•WARNING: If the surface is cracked or there is damage to the
material thickness, the appliance must be switched off and
disconnected from the electricity supply in order to avoid a
possible electric shock.
•WARNING: During use, the appliance and its exposed parts
become hot. Please be careful to avoid the exposed parts of
the heating elements.
•Never use a steam cleaner.
•Objects made of metal, e.g. knives, forks, spoons, covers or
aluminium foil, should not be put on the hob as they can be-
come hot.
•WARNING: Leaving fat or oil unattended on the hob can be
dangerous and can lead to fires. NEVER try to extinguish a
fire with water. Instead, switch the appliance off and then care-
fully cover the flames with an object such as a cover or a fire
blanket.
•WARNING: Never leave objects on the hob as they pose a fire
hazard.
•The appliance must not be operated with an external time
switch or a separate remote control system.
7

1 Safety precautions
1.4 Instructions for use
Before using for the first time
•The appliance must be installed and connected to the electricity supply in
accordance with the separate installation instructions. Have a qualified fitter/
electrician carry out the necessary work.
Correct use
•The appliance is designed for use in the home for preparing food. No liabil-
ity is assumed for any damage caused by improper use or incorrect hand-
ling.
•Any repairs, modifications or manipulations to the appliance, especially any
electrically live parts, may only be carried out by the manufacturer, its Cus-
tomer Services or a similarly qualified person. Repairs if carried out incor-
rectly may cause serious injury, damage to the appliance and fittings, as
well as affect the functioning of the appliance. If the appliance is not work-
ing properly or in case of a repair order, follow the instructions given in the
repair service section. Please contact Customer Services if necessary.
•Use original spare parts only.
•Retain these operating instructions for future reference. If you sell the appli-
ance or pass it on to a third party, include these operating instructions as
well as the installation instructions.
•The appliance corresponds to recognised technology standards and the rel-
evant safety regulations. Proper use of the appliance is, however, essential
to avoid damage and accidents. Please therefore follow the precautions
given in these operating instructions.
•The heated surface will remain hot for some time after it is switched off and
will only cool down slowly to room temperature. Leave a sufficient amount of
time before you carry out work such as cleaning the appliance.
Caution: Risk of burns!
•Overheated fat and oil can easily catch fire. Never attempt to extinguish
burning oil or fat with water. Danger of explosion! Smother the flames with a
fire blanket. Keep doors and windows closed.
Caution: Risk of injury!
•Keep pets away from the device.
8

1 Safety precautions
Caution: Risk to life!
•Packaging materials, e.g. plastic film and polystyrene, can be dangerous for
children. Danger of suffocation! Keep packaging material away from chil-
dren.
How to avoid damaging the appliance
•In the case of thermal failure, switch the solid plate off and allow to cool
down completely. Do not put any dishes on it. Do not cool with cold water
under any circumstances.
•Do not climb onto the appliance.
•To avoid damaging the silicon grouting, do not put hot cookware on the
frame.
•Do not cut or prepare food on the surface or drop hard objects onto it. Do
not drag cookware across the surface.
•Make sure than no sugary foods or juices end up on the hot cooking zones.
This can damage the surface. If sugary foods or juices do end up on the
hot cooking zones, remove these immediately with a glass ceramic hob
scraper (while the hob is still hot).
•Do not leave the appliance unattended during operation.
•Pots with pure copper or aluminium bases should not be used for cooking
as they leave behind traces that can be difficult to clean. If the traces are
not removed immediately after cooking with a suitable cleaning agent, they
can be permanently burned on and therefore permanently ruin the visual ap-
pearance of the appliance.
•Sliding pots and cookware across the glass ceramic causes scratches. You
can largely avoid these by lifting pots and cookware when putting them into
place.
•The hob is an item for daily use: signs of usage such as scratches or visible
material abrasion from pots or cookware are normal. Intensive use leads to
more distinctive signs of usage. In such cases, the appliance continues to
function perfectly and a complaint is not justified. Safety is always guaran-
teed.
•There is no such thing as completely scratch-proof glass; scratches can
even develop on sapphire glass, which is used in watches. The glass
ceramic used is of the best quality available on the market.
9

2 Disposal
Packaging
•All packaging materials (cardboard, plastic film (PE) and polystyrene (EPS))
are marked and should, if possible, be collected for recycling and disposed
of in an environmentally friendly way.
Disconnection
•Disconnect the appliance from the mains. With a fixed appliance, this is to
be carried out by a qualified electrician!
Safety
•Disable the appliance to prevent accidents caused by improper use, espe-
cially through children playing.
•Pull the plug out of the mains socket or have the appliance disconnected
from the mains by an electrician. Then cut the mains cable off flush with the
appliance.
•Remove or disable the lock on the appliance door.
Disposal
•The old appliance should not be discarded as worthless rubbish. If dis-
posed of correctly, the raw materials can be recovered for recycling.
•The symbol on the identification plate warns that the appliance may not
be disposed of in normal household waste.
•The appliance must be disposed of in accordance with local regulations on
waste disposal. For more information on the handling, disposal and recyc-
ling of the product, please contact the local authorities, the local recycling
facilities for household waste or the retailer from whom you purchased the
appliance.
10

3 Using for the first time
The appliance must be installed and connected to the electricity sup-
ply in accordance with the separate installation instructions. Have a
qualified fitter/electrician carry out the necessary work.
Unpleasant odours can develop during the initial operating hours of a
cooking zone. This is a normal occurrence with brand-new appliances.
Ensure the quality of the ambient air is good.
Where is the identification plate located?
The identification plate and connection plate are located on the underside of
the hob.
1 2
1Identification plate with serial number (FN)
2Connection plate
A second identification plate is enclosed and should be affixed to the built-in
cabinet under the hob.
Make a note of the serial number (FN) of your appliance on the last page of
these operating instructions.
The serial number is required for identifying the appliance. Only then
can customer services guarantee a faultless service.
11

4 Your appliance
4.1 Appliance overview
GK37TIMPS, GK37TIMPSC, GK37TIMPSF, GK37TIMPSF spec.
•3 cooking zones Ø 210mm
GK46TIABS, GK46TIABSC, GK46TIABSF, GK46TIABSU, GK46TIABS.1F
•1 frying zone Ø 180/280mm
•1 cooking zone Ø 210mm
•1 cooking zone Ø 180mm
•1 cooking zone Ø 145mm
GK47TIMPS, GK47TIMPSC, GK47TIMPSF
•2 cooking zones Ø 210mm (back)
•2 cooking zones Ø 180mm (front)
12

4 Your appliance
GK47TIMAS, GK47TIMASC, GK47TIMASF
•2 cooking zones Ø 210mm (back)
•2 cooking zones Ø 180mm (front)
GK36TIPS, GK36TIPSC, GK36TIPSF, GK36TIPSF spec.
•1 dual ring cooking zone
Ø 180/260mm
•1 cooking zone Ø 210mm
•1 cooking zone Ø 145mm
GK46TIPS, GK46TIPSC, GK46TIPSF, GK46TIPSF spec.
•1 cooking zone Ø 210mm
•2 cooking zones Ø 180mm
•1 cooking zone Ø 145mm
GK46TIAS, GK46TIASC, GK46TIASF, GK46TIASU, GK46TIAS.1F
•1 cooking zone Ø 210mm
•2 cooking zones Ø 180mm
•1 cooking zone Ø 145mm
13

4 Your appliance
4.2 Operating and display elements
GK36TI… / GK37TI …
12346
5
GK46TI … / GK47TI …
12346 5
Buttons
Device ON/OFF
Slider (to set the power level)
PowerPlus
Pause cooking ON/OFF and restore function
Operating time/timer
Wipe protection ON/OFF
14

4 Your appliance
Displays
1Power level of the cooking zone
2Operating time activated
3Pause activated/restoration of saved settings possible
4Cooking zone indicator light for the operating time
5Operating time/timer
6Wipe protection activated
4.3 How induction hobs function
Induction hobs function considerably differently to conventional hobs or solid
plates. The induction coil under the glass ceramic creates a magnetic field
that alternates quickly and which directly heats the magnetisable base of the
cookware.
The glass ceramic is only heated by the hot cookware. If the cookware is re-
moved from the cooking zone, the power supply is interrupted immediately.
Induction hobs:
•react very quickly
•can be adjusted with great precision
•are powerful
•are energy efficient
•are safe
Cookware with a fully magnetisable base is required for cooking with
an induction hob.
15

4 Your appliance
4.4 Pan detection
Every cooking zone is equipped with pan detection. This recognises cookware
with a magnetisable base that is suitable for use with induction hobs.
•If the cookware is removed during operation or unsuitable cookware is
used,
– the selected power level flashes alternately with .
•If there is no cookware placed on the cooking zone during the pan detec-
tion time of 10minutes:
– The cooking zone switches off automatically.
– The display changes from to .
– The appliance switches off after 10seconds if no other cooking zone is
switched on.
4.5 Cookware
Suitable cookware
Only cookware with a fully magnetisable base is suitable for cooking on the in-
duction hob.
You can check this in the following way:
•A magnet adheres to every point on the entire base of the cookware.
•The selected power level for the hob is illuminated, not alternating with
the power level.
Do not heat unsuitable cookware using auxiliary parts such as metal
discs or similar. This can damage the hob.
Energy-efficient cooking
For the most efficient energy consumption and even heat distribution, please
observe the following:
•The base of the cookware must be clean, dry and smooth.
•Place the cookware in the centre of the cooking zone.
•Use a lid that fits correctly.
•Adapt the size of the cookware to the load capacity.
16

4 Your appliance
Coated cookware
•Coated cookware when empty may never be heated at a higher power level
than .
– The coating may otherwise become overheated and damaged.
•For frying, do not use a higher power level than .
Never use PowerPlus with coated frying pans.
Noise during cooking
Cookware can make noise during cooking. This does not indicate any mal-
function, nor does it affect the functioning of the appliance in any way.
4.6 Flexible cooking
Only applicable for GK37TIMPS, GK47TIMPS and GK47TIMAS.
For flexible cooking, there are no marked cooking zones.
Pots of different sizes can be placed on every zone. However, for pan detec-
tion, must be covered.
If both circles are covered by a large pot, both heating areas can be
operated together with the bridge function.
For even frying, the pan must be centred on .
17

5 Operating the appliance
5.1 Switching the appliance on and off
Operation is roughly the same for all appliances.
►Switching on the appliance: Hold button down for 1second.
–If there is no further input, the appliance switches off after 10seconds
for safety reasons.
►Switching the appliance off: Press the button.
5.2 Selecting a cooking zone
►Touch the slider of the required cooking zone or swipe it to set the
power level.
18

5 Operating the appliance
5.3 Overview of power levels
Power level Cooking method Use
LKeeping warm Sauces, keeps food ready for serving
at around 65 °C
1Melting, gentle
warming
Butter, chocolate, gelatine, sauces
2
3Swelling Rice
4Continued cooking,
reducing, stewing
Vegetables, potatoes, sauces, fruit,
fish
5
6Continued cooking,
braising
Pasta, soup, braised meat
7Gentle frying Rösti (hash browns), omelettes,
breaded fried foods, sausages
8Frying, deep frying Meat, chips
9Flash frying Steak
PFast heating Boiling water
5.4 Switching a cooking zone off
►Touch on the slider.
–If there is no further input and the other cooking zones are switched
off, the appliance switches off after 10seconds.
5.5 Residual heat indicator
After a cooking zone is switched off, remains illuminated as long as there is
a risk of burns.
5.6 Keep warm setting
The keep warm setting keeps ready-cooked foods warm at approx. 65°C. It
can be found between power levels and .
19

5 Operating the appliance
5.7 PowerPlus
All the cooking zones are equipped with the PowerPlus booster.
When PowerPlus is switched on, the cooking zone selected works at extra
high power for 10minutes. PowerPlus can be used, for instance, to heat a
large quantity of water quickly.
Switching PowerPlus on
►Press the slider .
– is illuminated in the display.
–After 10minutes, it automatically reverts to power level .
If the cookware is removed, PowerPlus is interrupted. PowerPlus con-
tinues as soon as the cookware is placed back on the cooking zone.
Switching PowerPlus on
►Touch the required power level on the slider.
20
