V-ZUG DF-SLG6 User manual

Range hood
DF-SLG5 / DF-SLG6
DF-SLG8 / DF-SLG9
Operating instructions
V-ZUG Ltd

2
Thank you for choosing to buy one of our products. Your appliance is made
to high standards and is easy to use. Nevertheless, please take the time to
read these operating instructions in order to familiarize yourself with the
appliance and get the best use out of it.
Please follow the safety precautions.
Modifications
Text, diagrams and data correspond to the technical standard of the appli-
ance at the time these operating instructions went to press. The right to make
technical modifications for the purpose of the further development of the
appliance is reserved.
Symbols used
AIndicates step-by-step instructions.
– Describes how the appliance reacts to the steps taken.
䡲Indicates a list.
Validity
The model number corresponds to the first 3 digits on the identification plate.
These operating instructions apply to the models:
Variations depending on the model are noted in the text.
© V-ZUG Ltd, CH-6301 Zug, 2009
Denotes important safety precautions. Failure to observe said pre-
cautions can result in injury or damage to the appliance or fittings!
Denotes useful tips for the user.
Type Model no.
DF-SLG5 377
DF-SLG6 384
DF-SLG8 378
DF-SLG9 385

3
Contents
Safety precautions 4
Before using for the first time . . . . . . . . . . . . . . . . . . . . . . . . 4
Correct use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Children in the home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Note on use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Appliance description 8
Extraction model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Recirculation model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Construction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Operating and display elements . . . . . . . . . . . . . . . . . . . . . 11
Use 12
Care and maintenance 17
Cleaning the housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cleaning the grease filter . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Replacing the standard activated charcoal filter . . . . . . . . . 20
Cleaning and replacing the long-life activated charcoal
filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Replacing halogen spotlights . . . . . . . . . . . . . . . . . . . . . . . 22
Trouble-shooting 23
What to do if ... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Accessories and spare parts 24
Technical data 25
Disposal 26
Notes 27
Index 29
Repair service 31
Quick instructions 32

4
Safety precautions
In accordance with the requirements of IEC 60335-1:
䡲This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless supervised or unless they have been given instruction
concerning the use of the appliance by a person responsible for their
safety.
Before using for the first time
䡲The appliance must be installed and connected up to the electricity supply
according to the separate installation instructions. The necessary work
should be carried out by a qualified fitter or electrician.
䡲Dispose of the packaging material in accordance with local regulations.
The appliance corresponds to recognised technology standards
and the relevant safety regulations. Proper use of the appliance is
however essential to avoid damage and accidents. Please there-
fore follow the precautions given in these operating instructions.

… Safety precautions
5
Correct use
䡲The appliance is designed for use in the home for extracting cooking fumes
and smells from above the cooking surface.
䡲Any repairs, modifications or manipulations to the appliance, especially
any electrically live parts, should only be carried out by the manufacturer,
its Customer Services or similarly qualified persons. Repairs if carried out
incorrectly may cause serious injury, damage to the appliance and fittings,
as well as affect the functioning of the appliance. If the appliance is not
working properly or in case of a repair order, follow the instructions given
in the 'Repair service' section. Please contact our Customer Services if
necessary.
䡲Use original spare parts only.
䡲Retain these operating instructions for future reference. If you sell or pass
the appliance on to a third party, please ensure these operating instruc-
tions, together with the installation instructions, accompany the appliance.
In this way, the new owner can inform themselves about how to use the
appliance correctly and read the pertinent safety precautions.
Children in the home
䡲Packaging material e.g. plastic and polystyrene can be dangerous for
children. Danger of suffocation! Please keep packaging material away from
children.
䡲The appliance is designed for use by adults who are familiar with these
operating instructions. Children are often unable to recognise the danger
of electrical appliances. Ensure proper supervision and do not allow
children to play with the appliance – there is a danger that children could
hurt themselves.

… Safety precautions
6
Note on use
䡲If the appliance is visibly damaged, do not use it. Contact our Customer
Services.
䡲If the appliance is not operating properly, disconnect it from the electricity
supply immediately.
䡲If the mains cable of the appliance is damaged, it must be replaced by
Customer Services in order to avoid hazard.
䡲Caution: Accessible parts may become hot when used with cooking
appliances.
䡲Do not flambé food underneath the hood as the grease filters if laden with
grease could catch fire.
䡲If frying on the cooking surface, do not leave the frying appliance unattend-
ed. The cooking oil in the frying appliance could overheat and catch fire.
Constantly monitor the temperature of the cooking oil, keeping it below the
temperature at which it can catch fire. Change the cooking oil regularly –
dirty oil catches fire more easily than clean oil.
䡲Clean the filters regularly. Failure to do so can increase the fire hazard due
to the build-up of grease in the grease filter.
䡲Do not operate the individual cooking zones of the cooking surface without
a pan on them or with an empty pan on them so as to avoid damaging the
appliance or the kitchen fittings through a build-up of heat. Avoid open fires
with oil, gas, wood and coal fired cookers.
䡲Ensure there is adequate ventilation when the extraction fan is on so as to
avoid creating a disturbing underpressure in the kitchen and to achieve
optimal air extraction.
䡲Avoid a cross-current of air, which could blow the cooking vapours over
the cooking area.

… Safety precautions
7
䡲If other appliances – fuelled by gas or other fuels – are being used at the
same time, ensure that there is a sufficient supply of fresh air. This does
not apply to air recirculation appliances.
䡲If other firing systems are being used at the same time (e.g. wood, gas, oil
or coal-fired heating appliances), safe operation is only possible providing
a room negative pressure of 4 Pa (0.04 mbar) is not exceeded at the
location of the appliance. Risk of toxic fumes! An adequate flow of fresh air
must be guaranteed e.g. via non-closable openings in doors or windows
and in combination with an air-intake/exhaust-air wall box or by other
technical means.
䡲When carrying out maintenance work on the appliance, including replacing
the light bulb, cut off the electricity supply to the appliance (remove the
screw fuse from the holder or switch the circuit breaker off, or disconnect
from the mains supply).
䡲When cleaning the appliance make sure no water gets inside the
appliance. Use a moderately damp cloth. Do not spray the inside or
outside of the appliance with water. Do not use a steam cleaner. If water
gets inside the appliance, it can cause damage.

8
Appliance description
The appliance is used to extract cooking fumes and smells from a cooking
area and is normally installed in an overhead unit. This particular model can
be used in the extraction mode or the recirculation mode.
Extraction model
The integrated fan extracts cooking fumes and smells from above the cook-
ing surface. The air is cleaned through the grease filter and then fed through
the exhaust air conduit to the outside.
Recirculation model
Using an activated charcoal filter in the appliance
After passing through the grease filter, the fumes over the stove top are
removed by an activated charcoal filter. The cleaned air then flows through
the grating – above on the appliance – back into the room.
Using an air recycling cartridge (LRC1)
The appliance suctions the fumes over the stove top through the grease filter,
which retains the grease particles. The air is then blown through a pipeline to
the air recycling cartridge. An activated charcoal filter is installed in this car-
tridge, which rids the air of odours. The cleaned air is then aerodynamically
blown back into the room through the exhaust grating.
When the appliance is in use, ensure there is a sufficient supply of
fresh air to replace the air that is being extracted.
The activated charcoal filter is more efficient if operated at the lower
power levels.

… Appliance description
9
Equipment
䡲Glass shield, extractable
䡲2 extractor fans with 4 power levels
䡲1 metal grease filter
䡲Illumination
䡲1 activated charcoal filter (not included in delivery)
The extractor fan has 4 power levels: 1, 2, 3, P
䡲1 = low, 2 = medium, 3 = high power, P = intensive level.
䡲The levels 1 to 3 are suitable for continuous operation.
䡲The level P (power) is used for brief, intensive extraction of fumes, e.g.
when searing. Level P is available for 5 minutes. After this time, operation
automatically continues at level 2.

… Appliance description
10
Construction
1Glass shield (extractable)
2Operating elements
3Metal grease filter
4Grip flap
5Halogen spotlight
6Halogen spotlight holder
1
4 5/6
2
3

… Appliance description
11
Operating and display elements
1Readiness indicator
Digital display/saturation indicator of metal grease filter and
activated charcoal filter
Illumination ON–OFF
Ventilation OFF/resetting of saturation indicator
Automatic running-on
Decrease power level
Increase power level
Depending on the model and features, the specification of the appli-
ance may differ from the standard specification described herein.
1

12
Use
Switching on the appliance
APull out the glass shield 1.
The extraction fans can only be switched
on if the glass shield is slightly pulled out.
Switching the extractor fan on/off
APressing the button switches the appliance on at power level 1.
Pressing the button again selects the levels 2, 3 and P, respectively.
APressing the button selects the next lower power level. The fan
cannot be switched off with the button!
ATo switch off the fan, press the button.
Once the appliance is connected to the mains electricity, the readi-
ness indicator lights up.
The appliance operates most effectively when the glass shield is
completely pulled out.
Level P is available for 5 minutes. After this time, operation automati-
cally continues at level 2. To select power level P again, repeatedly
press the button.
We recommend immediately switching on the appliance to level 1.
After cooking, allow to run at level 2 for about another 15 minutes
(running-on time) so that the odours can be completely extracted.
1

… Use
13
Switching the automatic running-on function on/off
ATo switch on the automatic running-on function during operation, press the
button.
– The running-on time is activated. This is indicated and confirmed by the
lighting up of the last selected power level and the readiness indicator.
The runnning-on times are individually specified for the respective power
level.
䡲Power level 1 = 20 minutes
䡲Power level 2 = 15 minutes
䡲Power level 3 = 10 minutes
䡲Power level P = 5 minutes
– After the specified time, the fans automatically switch off.
ATo switch off the automatic running-on function, press the button
again.
– The readiness indicator stops flashing. Operation continues at the set
power level.
Switching the illumination on/off
ATo switch on, press the button.
ATo switch off, press the button again.
The illumination can always be switched on or off. It is independent of the
operating mode or the position of the glass shield.

… Use
14
Saturation indicator of metal grease filter
The saturation indicator of the metal grease filter lights up after 40 hours of
operation. The saturation level has been reached.
– The current extraction level flashes alternatingly with in the digital
display.
AThe grease filter must be cleaned.
Resetting the saturation indicator
ADepress the button for 3 seconds.
– The indicator light goes out.
Activating/deactivating the saturation indicator of the standard activated
charcoal filter
ATo activate, hold the buttons and pressed until lights up
in the digital display.
ATo deactivate, hold the buttons and pressed until goes out
in the digital display.
The saturation is not displayed in stand-by mode.
Only activate this function if the appliance is used as a recirculation
model.

… Use
15
Saturation indicator for standard activated charcoal filter
The saturation indicator only functions if it has been activated. This indicator
lights up after 160 hours of operation. The saturation level has been reached.
– The current extraction level flashes alternatingly with in the digital
display.
AThe standard activated charcoal filter must be replaced.
Resetting the saturation indicator
ADepress the button for 3 seconds.
– The indicator light goes out.
The saturation is not displayed in stand-by mode.

… Use
16
Switching off the appliance
AFully insert the glass shield 1.
– This switches off the extraction fan
and the illumination (stand-by mode).
– The settings remain saved
(exception: level P).
If the glass shield is pulled out slightly, the extractor fan switches to the set
power level or the illumination switches on, providing it was switched on when
the glass shield was fully inserted.
Inserting/pulling out the glass shield
AFully insert the glass shield 1.
– The extractor fan automatically switches off.
– The settings (power level and light) used during the last period of
operation remain saved. These are reactivated once the glass shield is
reopened. An exception is the power level «P».
APull out the glass shield 1partially or completely.
– In this position, the stove top lighting and the various power levels can
be switched on and off at will.
– The last used settings (power level and light) are reactivated. An
exception is the power level «P». This setting is deleted and the
ventilation must be reset.
– If the stove top lighting was previously switched on in the closed
position, the light remains uninterruptedly activated in the opened
position as well.
In this position, only the stove top lighting can be switched on and off.
1

17
Care and maintenance
Cleaning the housing
Cleaning the outside/inside
AClean the outside using a slightly damp cloth – and detergent if necessary
– and wipe dry.
Grease and condensate water can build up around the grease filter on the
inside.
AClean using a slightly damp cloth – and detergent if necessary – and wipe
dry.
Take care that no water gets into the housing! If water gets into the
housing, it can cause damage.
Do not use abrasive cleaners, scouring pads, steel wool etc. to
clean the appliance as they can damage the surface.

… Care and maintenance
18
Cleaning the grease filter
Under normal condtions of use, the grease filter must be cleaned at least
once monthly or whenever and the current power level flashes alternating-
ly in the digital display. With optimal care, the service life of the grease filter
is unlimited.
AClean the grease filter in the dishwasher.
ASelect the dishwasher program «Intensive» – or «Heavy» – with warm
pre-rinsing.
If a dishwasher is not available:
AClean the grease filter in a rinsing bath.
ASoak the filter approx. 2 hours in a hot rinsing bath and then clean with a
scouring brush.
Grease filters can become discoloured due to cleaning. This in no way
impairs their filtering effectiveness.

… Care and maintenance
19
Removing the grease filter
APull out the glass shield completely.
APull the grip flap 1in the centre recess on the grease filter downward.
– The grease filter 2is unlocked and can be taken out toward the bottom.
Installing the grease filter
APull out the glass shield completely.
AGrasp the grease filter and make sure that the grip flap is facing down.
Insert fixed centring pins at the back in the retaining slots in the housing.
AEnsure that all centring pins are seated in the correct retaining slots. Only
then will the grip flap latch completely in place. The grease filter is correctly
inserted if it lies flush with the housing.
21

… Care and maintenance
20
Replacing the standard activated charcoal filter
Standard activated charcoal filters are only used in the recirculation model.
The standard activated charcoal filter should be replaced after 3 to 6 months
of operation. Standard activated charcoal filters cannot be washed or
rejuvenated.
APull out the glass shield completely.
ARemove the metal grease filter.
APush the two red retaining slides 2on the standard activated charcoal
filter 1upward while lifting the filter from below as you pull it out of the
holder 3.
ASlide the new standard activated charcoal filter upward under the bracket
and fix it below on the holder 3. Allow the red retaining slides 2to latch in
place.
AReinsert the metal grease filter.
AScrew the fuse back in or switch the circuit breaker back on.
Remove the appliance’s fuse or switch the circuit breaker off.
The dirty standard activated charcoal filter can be disposed of with the
household waste.
1
2
3
1
2
