Vacmaster VQ1530SFDC User manual

VQ1530SFDC
1500W30L
IPX4
www.cleva-europe.com
MADE IN P.R.C

1
27
11
12
13
8
9
8
10
14
21 22 23 24 25 26
15 16 17 18 19 20
3
4
5
6

4
GB
TABLE OF CONTENTS
SECTION PAGE
Safety Information ......................................................................................................................... 5
Unpacking and Checking Carton Contents ................................................................................... 7
Assembly....................................................................................................................................... 7
Operation ...................................................................................................................................... 8
Maintenance.................................................................................................................................. 9
Troubleshooting........................................................................................................................... 10
Technical Data..............................................................................................................................11
Recycling and Disposal ................................................................................................................11
Plug/Fuse Replacement (UK & Ireland Only)...............................................................................11
Thank you for purchasing this Vacmaster® wet and dry vacuum cleaner. Feel condent that with
Vacmaster®you are obtaining a high quality product engineered for optimal performance. This
vacuum cleaner is suitable for use with both liquids and dry materials.
FOR YOUR SAFETY: CAREFULLY READ AND UNDERSTAND ALL INSTRUCTIONS.

5
GB
SAFETY INFORMATION
READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE
USING THIS VACUUM CLEANER.
When using the equipment, a few safety precautions must be
observed to avoid injuries and damage. Please read the complete
operating manual with due care. Keep this manual in a safe
place so that the information is always available. If you give
the equipment to any other person, give them these operating
instructions as well. We cannot accept any liability for damage or
accidents which arise due to a failure to follow these instructions
and the safety information.
• Never leave the appliance switched on unattended, if you leave
the work area, switch the appliance off or unplug it from the
power supply.
• Do not vacuum or use this Wet and Dry Vacuum cleaner near
ammable liquids, gases or explosive vapours like gasoline or
other fuels, lighter uids, cleaners, oil-based paints, natural gas,
hydrogen, or explosive dusts like coal dust, magnesium dust,
grain dust or gun power. Sparks inside the motor can ignite
ammable vapours or dust.
• This vacuum cleaner is not suitable for the vacuuming of
asbestos or asbestos dust.
• Do not vacuum anything that is burning or smoking, such as
cigarettes, matches, or hot ashes.
• Ensure the hose and connections are always pointed away from
the users face, hair, ears and eyes during operation and never
direct the nozzle towards persons or animals.
• Clear the working area of any items or precessions that you do
not wish to be vacuumed before operation.
• Keep cord away from heated surfaces.
• Do not expose to rain. Store indoors.
• Do not unplug by pulling on the cord. To unplug, grasp the plug,
not the cord.
• Do not use with damaged cord, plug or other parts.
• Do not pull or carry by cord, use cord as handle, close a door on
cord, or pull cord around sharp edges or corners.
• Do not handle the plug or vacuum cleaner with wet hands.
• To reduce the risk of health hazards from vapours or dusts, do

6
GB
not vacuum toxic materials.
• Frequently check that the oat valve positioned underneath the
motor is able to move freely.
• Do not use or store near hazardous materials.
• Do not use this vacuum cleaner with a torn lter or without the
lter installed.
• Do not allow to be used as a toy. Close attention is necessary
when used by or near children.
• To reduce the risk of injury from accidental starting, unplug
power cord before changing or cleaning lter.
• Do not leave vacuum cleaner unattended when plugged in.
Unplug from power supply when not in use and before carrying
out maintenance.
• Turn off Wet and Dry Vacuum cleaner before unplugging.
• Do not cover the ventilation openings. Do not vacuum with any
ventilation openings blocked; keep free of dust, lint, hair or
anything that may reduce air ow.
• Keep hair, loose clothing, ngers, all parts of body away from
openings and moving parts.
• If the supply cord is damaged, it must be replaced by the
manufacturer, a qualied service agent or similarly qualied
persons in order to avoid a hazard.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
• For additional protection: It is recommended that this vacuum
cleaner can be used in conjunction with residual current device
(RCD) with a rated residual current of 30mA or less.
• Always unplug the appliance after use and before cleaning or
changing the lters or accessories.
When using as blower:
• Direct air discharge only at work area.
• Do not use Wet/Dry Vacuum as a sprayer.
• Do not direct air at bystanders.
• Keep children away when blowing.
• Wear safety goggles.

7
GB
UNPACKING AND CHECKING CARTON
CONTENTS
1 Carry Handle 10 Caster 19 Power Tool Hose Adaptor
2 On/Off Switch 11 Blowing Port 20 Round Dust Brush
3Power Take-off Socket 12 Power Cord Storage Hooks 21 Cartridge Filter (pre-installed)
4 Suction Port 13 Anti-static Chain 22 Filter Retainer (pre-installed)
5 Container 14 Hose 23 Dust Bag
6 Drainage Port 15 Extension Wand (x2) 24 Foam Filter
7 Power Head 16 Crevice Tool 25 Screw (x6)
8 Accessory Storage 17 Handle with Air Flow Regulation 26 Instruction Manual
9 Latch 18 Floor Nozzle
ASSEMBLY
NOTE: A Phillips screwdriver is required.
1) Remove all the contents from inside of the vacuum cleaner container.
2) Attach the carry handle into the slots located on the top of the power head (Fig. 1).
3) Turn the container upside down and insert the feet with casters into the slots and apply
pressure until they click into place. Secure them with supplied screws (Fig. 2).
4) Your vacuum cleaner comes ready for dry vacuum cleaning with the cartridge lter pre-installed.
If the cartridge lter is not installed, refer to page 8.
5) Optionally, for improved dust ltration, fully t the dust bag ange onto the inlet stub (Fig. 3).
6) For wet vacuuming, replace the cartridge lter with the foam lter supplied. Do not use a dust
bag when wet vacuuming. If the foam lter is not installed, refer to page 9.
7) Secure the power head back on the container, using the 2 side latches. Insert the locking end
of the hose into the suction port of the container (Fig. 4).
8) Choose the desired accessories and/or extension wands and push t onto the hose nozzle.

8
GB
8) Choose the desired accessories and/or extension wands and push t onto the hose nozzle.
OPERATION
1. Switching On/Off
Connect the mains plug to a suitable a power outlet.
Position Status
I on
O off
II automatic synchronized start-up
2. Power Tool Take-Off Operation (Fig. 5)
WARNING: Always check the maximum wattage compatibility of the power tool take off
socket against the desired power tool before connecting to prevent overloading.
1) Connect the power cable of your power tool to the power take-off socket.
2) If applicable, connect the vacuum suction hose to the dust extractor connector on your tool with
the supplied adaptor.
3) Switch the vacuum cleaner to position II, as described in Switching ON/OFF. The moment you
switch on the power tool, the vacuum cleaner will also switch on. Once the electrical appliance
has been switched off, the vacuum cleaner switches off following a time lapse (around 5
second) to allow the suction tube to be emptied.
3. Dry & Wet Vacuum Operation
WARNING: ENSURE YOU READ, UNDERSTAND AND APPLY SECTION ENTITLED
‘SAFETY INFORMATION’.
1) Verify that the correct lter is installed for wet or dry vacuuming and the container latches are
secured.
2) Secure the locking end of the hose into the vacuum suction port.
3) Push the desired accessories onto the hose nozzle. The air ow regulation allows you to change
vacuum cleaner suction. For best cleaning results, fully close the air ow regulation (Fig. 6).
4) Plug the power cord into a power outlet.
5) Turn on the motor by assigning the switch to the “I” ON position.
6) Once you have completed vacuuming, switch to the “O” OFF position and unplug the power
cord from the power.
For Dry Vacuuming:
WARNING: BEFORE INSTALLING, REMOVING OR CLEANING THE VACUUM
CLEANER FILTER, ENSURE THAT THE POWER CORD IS UNPLUGGED AND
SWITCHED OFF.
1) To prepare your vacuum cleaner for dry vacuuming, install the cartridge lter over the lter cage
with the at end of the lter towards the vacuum power head. Carefully push lter until it sits
ush forming a tight seal.
2) Place the lter retainer cap on top of cartridge lter over the raised lip and tighten the retainer
lock clockwise to secure against the internal lter cage (Fig. 7).
3) Optionally, fully t the dust bag ange onto the inlet stub. The Vacuum cleaner can we be used
with or without dust bags.
IMPORTANT: Check the lter regular for optimal performance. An old or blocked lter will reduce
suction performance.

9
GB
For Wet Vacuuming:
1) To prepare your vacuum cleaner for wet vacuuming, remove the retainer cover and the dry use
cartridge lter.
2) Carefully install the supplied foam lter over the internal lter cage, making sure the whole cage
is covered (Fig. 8).
WARNING:
DO NOT USE THE CARTRIDGE FILTER FOR WET VACUUMING.
DO NOT USE A DUST COLLECTION BAG FOR WET VACUUMING.
IMPORTANT! When vacuuming large quantities of liquids, do not immerse the nozzle completely;
leave a gap at the tip of the nozzle to allow air inow. The machine is tted with a oat valve that
stops the suction action when the container reaches its maximum capacity. You will notice an
increase in motor noise. When this happens, turn off the machine, disconnect from power supply,
and drain the liquid. To continue vacuuming, replace the drainage cap. After wet vacuuming, empty
the container, clean and dry inside before storage.
4. Blower Operation
WARNING: KEEP BYSTANDERS CLEAR FROM BLOWING DEBRIS.
WARNING: WEAR A DUST MASK IF BLOWING CREATES DUST THAT MIGHT BE
INHALED.
1) Make sure the container and any collected waste is emptied before using as a blower. This also
includes removal of the dust bag.
2) Insert the locking end of the hose into the blowing port on the rear of the power head (Fig. 9).
3) Turn on the motor on by turning the switch to the ‘I’ ON position.
MAINTENANCE
WARNING: REMOVE THE POWERCORD FROM THE POWER SUPPLY BEFORE
CARRYING OUT ANY MAINTENANCE.
1) Keep all safety devices, air vents and the motor housing free of dirt and dust. Use a soft, dry
brush to clean the equipment regularly.
2) Clear all dirt or debris from the collection tank after each use. Allow to dry before replacing the
power head. Do not use cleaning agents or solvents; these may damage the appliance.
3) Check the hose, attachments, and power cord to verify that they have not been damaged or
any debris is trapped and blocking airow.
1. Cleaning Cartridge Filter
Remove the lter and clean by gently tapping or brushing off dirt. For optimal performance it is
recommended to replace the old lter with a new lter regularly.
2. Cleaning Foam Filter
Remove the foam lter and use a mild soap and water solution to wash and rinse with clean water
(Fig. 10). Allow lter to air dry before installing and using again.

10
GB
TROUBLESHOOTING
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK-UNPLUG BEFORE
TROUBLESHOOTING.
Cleaning Performance
Vacmaster vacuum cleaners are tested for endurance. If your motor is operating, then the most
likely cause for a loss in suction is a blockage or an opening in the vacuum.
To maintain a high cleaning performance from your machine, it is important to replace or clean
cartridge lters as necessary. Replace full dust bags to prevent performance drops. A performance
drop with clean lters can only be caused by a blockage in the tools or the hose.
PROBLEM POSSIBLE CAUSE SOLUTION
The appliance does
not work.
No power. Check the power supply and fuse.
Functional fault in the power
cord, switch, or motor.
Have the damaged part checked by
qualied personnel or contact the after
sales helpline.
Dust is escaping from
the motor cover.
The cartridge lter is missing
or damaged. Put in a cartridge lter or replace it.
Misuse the cartridge lter
when wet vacuuming, causing
the damage of cartridge lter
Replace the damaged cartridge lter
with a new one when dry vacuuming.
Misuse the foam lter when
dry vacuuming.
Replace the foam lter with the
cartridge lter.
Power tool take-off
socket does not work.
Power tool wattage is not
compatible with the power
take-off socket.
Check the wattage is compatible with
the power tool take-off socket.
Incorrect operating mode
selected.
Ensure the switch is moved into
position II.
Low suction power
and high operating
noise / vibrations.
Dust bag is full. Replace the dust bag.
Suction nozzle, hose, or tank
inlet is blocked.
Check the suction nozzle, hose, and
tank inlet for obstructions.
Cartridge lter is blocked. Remove the cartridge lter and clean.
Float valve has closed.
Empty the container of any liquid
waste and ensure the oat value
located underneath the lter is able to
move freely.

11
GB
TECHNICAL DATA
Model Number VQ1530SFDC
Motor 220-240V~50Hz
Power Input 1500W
Max. Power Consumption of the Power Tool Take-Off Socket Outlet 1490W for BS Socket
2180W for VDE Socket
Tank Volume 30L
Net Weight 8.3 kg
RECYCLING AND DISPOSAL
This marking indicates that this product should not be disposed with other household wastes
throughout the EU. The machine must be delivered in rigid packaging to avoid damage
during transportation. The packaging and the machine itself are manufactured from
recyclable materials and should be disposed of accordingly.
PLUG/FUSE REPLACEMENT
(UK & IRELAND ONLY)
This product is tted with a non-rewirable plug. If the plug has to be changed, refer to the picture
below.
6mm
6mm
FUSE
FITTED WITH BS 1362 13A FUSE ALWAYS RT FIT BS 1362 REPLACEMENT CARTRIDGE FUSE
6mm 32mm
E
L
N
13A
GREEN&
YELLOW
OR
GREEN
BROWN
OR
RED
CORD GRIP
BLUE
OR
BLACK

1
6
9 10
2
4 5
3
7
8

VQ1530SFDC
1500W30L
IPX4
www.cleva-europe.com
MADE IN P.R.C
