VADDIO CeilingVIEW 70 PTZ HideAway User manual

Installation and User Guide
Camera and Electronic Products for Integrators
ⓒ2004 Vaddio - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and
pricing are subject to change without notice. CeilingVIEW, WallVIEW ControlVIEW, EZCamera and PowerRite are registered
trademarks of Vaddio, Inc. All other trademarks are property of their respective owners. Form Number 341- 075 Rev. D
CeilingVIEW 70 PTZ HideAway
Installed PTZ Ceiling Camera with Recessed, Motorized Camera Lift System
Vaddio’s CeilingVIEW 70 PTZ HideAway camera system is
designed to provide system integrators with an easy to install,
recessed, in ceiling, motorized camera lift system (see Figure 1).
The system features a Sony® EVI-D70 PTZ Camera mounted into a
recessed, metal ceiling camera enclosure with ceiling tile support
and is equipped with Vaddio’s EZCamera™ Cabling System which
allows the integrator to use Cat. 5 cabling to run power, video and
camera control. The camera lift has a motorized extension arm,
that when retracted, conceals the camera. When the camera is
activated the extension arm lowers and reveals the camera.
Contact closure or voltage sensing can be used to activate the lift
system remotely or the camera IR remote control can be used to
activate the lift with the ON/OFF button. The VISCA control
interface is included to allow the camera to work with any other
VISCA compatible control device. The PowerRite™ power supply
regulates the right amount of power needed for the camera over the
Cat. 5 cabling.
Before operating the Vaddio CeilingVIEW 70 PTZ HideAway,
please read the entire manual thoroughly. The camera system was
designed, built and tested for use indoors with the provided power
supply. The use of a power supply other than the one provided or
outdoor operation has not been tested and could damage the
camera and/or create a potentially unsafe operating condition.
The information contained in this manual will help you install and
operate your Vaddio CeilingVIEW 70 PTZ HideAway. If these
instructions are misplaced, Vaddio keeps copies of Specifications,
Installation and User Guides and most pertinent product drawings
for the Vaddio product line on the website. These documents can
be downloaded from www.vaddio.com free of charge.
SAVE THESE
INSTRUCTIONS
INTENDED USE
INTRODUCTION
Figure 1: Vaddio
CeilingVIEW 70
PTZ HideAway
shown retracted
(left) and lowered
into operating
position (right)

CeilingVIEW 70 PTZ HideAway – Document 341- 075 Rev. D
Page 2 of 14
Read and understand all instructions before using. Do not operate
the camera if the camera has been dropped or damaged. In this
case, a Vaddio technician must examine the product before
operating. To reduce the risk of electric shock, do not immerse in
water or other liquids and avoid extremely humid conditions.
Carefully remove the device and all of the parts from the packaging.
Unpack and identify the following parts:
•One (1) CeilingVIEW 70 PTZ Camera Module
•One (1) White trim ring with IR sensor attached
•One (1) Vaddio Quick-Connect Box
•One (1) Sony RM-EV100 IR Remote Controller
•One (1) Vaddio PowerRite 18VDC Power Supply
•One (1) AC power cable for Power Supply
•One (1) 12’ (4.57m) S-Video cable
•One (1) 12’ (4.57m) Composite Video cable
•Two (2) Adjustable ceiling tile support rails
•One (1) RJ-45 to DB9 EZCamera™ serial control converter
•Mounting Hardware
•Installation and User Guide (341-075 Rev. C)
UNPACKING
Use only the power supply provided with the CeilingVIEW 70 PTZ
HideAway camera system. Use of any unauthorized power supply will
void any and all warranties.
IMPORTANT
SAFEGAURDS
INSTALLATION
REMOVE the safety tape and then REMOVE the shipping hold-down
screw in the back of the camera module as indicated below (see Figure 2.
If power (over the Cat. 5 POWER/VIDEO cable) is connected to the
camera before the shipping hold-down screw is removed, serious
damage to the camera may result.
Remove
Sticker
Camera Top
Power/Video
RJ-45 Jack
Remove
Shipping
Screw
Camera Top
Figure 2: Top of camera shown with safety tape (left) and location of
shipping hold down screw and Power/Video Jack (right).

CeilingVIEW 70 PTZ HideAway – Document 341- 075 Rev. D
Page 3 of 14
CAMERA
FRONT
CEILING TILE
The CeilingVIEW 70 PTZ HideAway is an integrated
document/object camera specifically designed for installation in a
suspended ceiling above a table or work surface. Recommended
ceiling heights are between 8 and 12 feet.
•Be sure to check above the ceiling tile where you plan to install
the camera to make sure the area is clear and that there is
enough room for the CeilingVIEW Camera Module and all of its
components.
•Keep in mind that other than viewing straight down, the
CeilingVIEW PTZ has the capability of panning +/-170 degrees
from center.
•The camera may be used with any 2’ tile. The camera module
enclosure and the tile support rails allow for flexibility and
positioning freedom when used with 2'x2' and 2'x4' ceiling tiles.
•For cutting ease, remove the marked ceiling tile and place on a
suitable and safe work surface.
Note: If camera is to be controlled as part of a multi camera system, please
refer to the section CHANGING CAMERA DEFAULT SETTINGS located on
Page 7 of this manual.
To mount the CeilingVIEW 70 PTZ HideAway:
1) Attach a string or plumb bob to the ceiling tile with a thumbtack.
2) Position the string directly over ample table space or work
surface to allow easy document and object positioning.
3) Using a sharp utility knife, score a 6-3/4" diameter circle into the
front of the tile centered on the string.
4) Carefully cut out the 6-3/4" hole.
5) Place the tile support rail on the backside of the tile and center
over the hole. Carefully place camera in cutout hole from the
back of tile (see Figures 3 and 4) and attach to support rails.
Getting
Started
Before
Installing
Step by Step
Mounting
Instructions
Figure 3:
Side View of CeilingVIEW
Camera Module
For installation reference,
the cutout area by the IR
detector cable hole is on
the side of the camera.

CeilingVIEW 70 PTZ HideAway – Document 341- 075 Rev. D
Page 4 of 14
6) Using the supplied thumbscrews and washers, attach the
support rails to the CeilingVIEW PTZ camera (see Figure 4).
Place rail edge between two washers and tighten thumbscrew
securely. Note: The thumbscrew sits on top of the rail, not through
the holes on the rail.
7) The Cat.5 cable (plenum rated as code dictates) is run from the
ceiling location where the camera is to be mounted, to where
the Quick-Connect Box is located (see Figure 5). Both the S-
Video and Composite Video outputs are active.
8) If needed, Cat.5 plenum rated cable(s) may be purchased from
Vaddio to connect your camera for video, power control and
control daisy-chaining between multiple cameras (see Figure 6).
CAMERA
THUMB SCREW
24" BRACKET
WASHERS
Figure 4:
Side View and Close-up
of Camera module and
support rail
Cabling the
Camera
S-Video
Output to
Display
Device
Composite
Video
Output to
Dis
p
la
y
Power from
PowerRite Power
Supply
Cat. 5 to/from
POWER/VIDEO
Jack on Camera
Module
Figure 5:
Quick-Connect
Box and
connections
Figure 6:
Daisy Chain Control
Connections between
cameras
(Vaddio Cameras shown, left to right:
CeilingVIEW 70 PTZ HideAway,
WallVIEW 70 PTZ and WallVIEW 50i
PTZ HideAway)
RS-232
Control
IN IN INOUT OUT

CeilingVIEW 70 PTZ HideAway – Document 341- 075 Rev. D
Page 5 of 14
CAMERA
CEILING TIL
E
IR board
connector
IR cable
and plug
Trim Ring
9) Connections (see Figure 7):
a. Attach the installed Cat.5 cable routed from the
POWER/VIDEO jack on the back of the camera to the
Quick Connect Box.
b. If a RS-232 control cable is to be used, it should be
attached to the RS-232 IN jack.
c. If a second or third camera is to be used, attach a cable to
the RS-232 OUT jack and route to the next camera.
10)The camera and ceiling tile should be carefully replaced in the
suspended ceiling at this time.
11)Locate the white trim ring assembly and plug the IR cable into
the IR board connector on the trim ring lip (see Figure 8). Take
care not to pull any more than about 2 inches of cable from the
camera enclosure. The connectors will fit together only one way
with a positive click. (Note: DO NOT hang the trim ring from the
camera by the IR cable) Carefully move trim ring into position on
bottom of ceiling tile while feeding IR cable back into camera
enclosure and secure with the two supplied white screws.
Finishing Up
Figure 7:
RJ-45 Connections on back
of Camera Module
•POWER/VIDEO
•RS-232 IN
•RS-232 OUT (for daisy-
chain control)
Figure 8:
Connecting the IR
sensor on Trim Ring
to the IR cable
Connections

CeilingVIEW 70 PTZ HideAway – Document 341- 075 Rev. D
Page 6 of 14
12) With the Cat.5 cable routed from the POWER/VIDEO jack on
the back of the camera to the Quick Connect Box, connect the
supplied Vaddio PowerRite power supply. The camera will lower
into position and the S-Video and Composite Video signals will
be live and viewable after the camera is fully lowered and in the
“Home” position (Reminder: Use of a power supply other than the
provided Vaddio power supply will void warranty and may cause camera
and equipment damage).
The Camera can be controlled with the Sony RM-EV100 IR Remote
Controller or through RS-232 using VISCA control protocols.
The Sony RM-EV100 IR Remote Controller controls the following
functions when used with a CeilingVIEW 70 PTZ HideAway (see
Figure 9). A fresh set of AA batteries (not included) should be
installed in the provided Sony remote control. To operate, aim
remote at camera and depress desired button.
If you are using a control system (i.e. Crestron or AMX), plug the
Cat.5 cable from the RS-232 IN jack on the camera to your control
system using the Cat.5 to DB9 serial adapter supplied by Vaddio. If
you are controlling more than one camera, plug the Cat.5 cable from
the RS-232 OUT jack on the first camera to the RS-232 IN jack on
the second camera. Repeat procedure if third camera is to be used.
If control of motor only is desired, there is an external connector
provided on the top of the camera. This contact is normally open
and the motor will be in the retracted state. By providing a contact
closure across this connection when power is available and
connected via the Cat. 5 POWER/VIDEO cable, the motor will lower,
Initial
Camera
Power Up
CONTROLLING
THE CAMERA
Figure 9:
RM-EV100 IR Remote Controller
•Power on/off
oOn = Lowers camera
oOff = Retracts the camera
•Camera Select: 1, 2, 3
•Focus: Auto
Manual (Near & Far)
•Zoom: Slow – Tele, Wide
Fast – Tele, Wide
•Back Light: Back Light Compensation
•Pan-Tilt: Left, Right, Up, Down, Reset
•Home: Home/Centered Position
•Position: Preset, Reset
•Presets: 6 (1 through 6)
•Cancel: Not Used
•L/R Direction Set: Std, Rev
IR Remote
Control
Systems
Motor Control
Only (limited
use)

CeilingVIEW 70 PTZ HideAway – Document 341- 075 Rev. D
Page 7 of 14
FRONT
IMAGE FLIP IR SELECT
COVER
PLATE
RETAINER
SCREWS
COVER
PLATE
COVER
PLATE OFF
but will not power up the camera. Release of the closure will retract
the camera. The IR Remote Controller or RS-232 commands can
power up and lower/retract the camera only. The mating connector
can be found at Radio Shack (in the US) under part number 274-226
(see Figure 10).
Please refer to Figure 11 for this procedure.
•Camera must first be lowered into place and power unplugged.
•Place camera on suitable work surface.
•Remove the 4 cover plate retainer screws.
•Carefully lift off cover plate while threading the IR cable back through hole.
•Looking between the rear of the EVI-D70 camera body and the interconnect
circuit board, locate the 2 switches (it may be necessary to slightly tilt the
camera assembly to get the best view of the switches).
•The default setting for the image flip function is ON. Move this switch to the
left to disable.
•The default setting for IR select is 1. If this to be camera number 2 in a 2
camera system, set this switch to position 2. If this camera is number 3 in a 3
camera system, set switch to positions3.
•Carefully thread the IR cable back through the cover plate and secure plate to
camera enclosure using the 4 retaining screws.
Motor Control Connection
Figure 10:
Motor Control connection
shown
Mating Connector –
Radio Shack # 274-226
CHANGING CAMERA
DEFAULT SETTINGS
Figure 11: Cover Plate Removal and default settings access

CeilingVIEW 70 PTZ HideAway – Document 341- 075 Rev. D
Page 8 of 14
Vaddio supplies this control specification for the CeilingVIEW 70 PTZ HideAway
camera. This VISCA control set (as used in Sony EVI cameras) is used in
conjunction with additional Vaddio control commands (see comment section on
Table 1) for added functionality of the camera lift.
Communication Speed: 9600 bps (default)
Start bit: 1
Stop bit: 1
Data bits: 8
Parity: None
The control codes for the CeilingVIEW 70 PTZ HideAway are the same codes
used with the EVI-D70 pan/tilt/zoom camera. Vaddio is not translating these
codes and does not add any translation or memory capability to enable use of the
EVI-D70 camera as a main or auxiliary camera with videoconferencing system
codecs or the associated IR remote controllers.
For best control results, use the provided RM-EV100 IR Remote Controller or the
VISCA Commands (detailed in Table 1 below) with an external control system.
Table 1: VISCA Command List
RS-232
Command Set Command Command Packet* Comments
AddressSet Broadcast 88 30 01 FF Address setting
IF_Clear Broadcast 88 01 00 01 FF I/F Clear
CommandCancel 8x 2p FF p: Socket No.(=1or2)
On 8x 01 04 00 02 FF Power ON – Lowers Camera Lift
Mechanism and Turns camera ON
CAM_Power
Off(Standby) 8x 01 04 00 03 FF Power OFF – Retracts Camera Lift
Mechanism and Turns camera OFF
Stop 8x 01 04 07 00 FF
Tele(Standard) 8x 01 04 07 02 FF No
Wide(Standard) 8x 01 04 07 03 FF
Tele(Variable) 8x 01 04 07 2p FF p=0（Low）～7（Fast）
Wide(Variable) 8x 01 04 07 3p FF
CAM_Zoom
Direct 8x 01 04 47 0p 0q 0r 0s FF pqrs: Zoom Position
D-Zoom On 8x 01 04 06 02 FF Digital Zoom ON/OFF
CAM_Dzoom
D-Zoom Off 8x 01 04 06 03 FF
Stop 8x 01 04 08 00 FF
Far(Standard) 8x 01 04 08 02 FF
Near(Standard) 8x 01 04 08 03 FF
Far(Variable) 8x 01 04 08 2p FF p=0（Low）～7（High）
Near(Variable) 8x 01 04 08 3p FF
Direct 8x 01 04 48 0p 0q 0r 0s FF pqrs: Focus Position
Auto Focus 8x 01 04 38 02 FF AF ON/OFF
Manual Focus 8x 01 04 38 03 FF
CAM_Focus
Auto/Manual 8x 01 04 38 10 FF
RS-232
CO
MMAND LI
S
T
Communication
Specification *Communication Example:
For the VISCA Packet “8x 01 04 07 03 FF”
(CAM_Zoom_Wide), “x” corresponds with
the number and order of the camera in the
control chain (daisy chain) where x = 1 for
the first camera, x = 2 for the second
camera, etc…
Control
Disclaimer
Command List

CeilingVIEW 70 PTZ HideAway – Document 341- 075 Rev. D
Page 9 of 14
Command List
(Continued)
One Push Trigger 8x 01 04 18 01 FF One Push AF Trigger
Infinity 8x 01 04 18 02 FF Forced Infinity
Near Limit 8x 01 04 28 0p 0q 0r 0s FF pqrs: Focus Near Limit Position
Normal 8x 01 04 58 02 FF AF Sensitivity Norm/Low
AF Sensitivity
Low 8x 01 04 58 03 FF
CAM_ZoomFocus Direct 8x 01 04 47 0p 0q 0r 0s 0t 0u 0v
0w FF
pqrs: Zoom Position
tuvw: Focus Position
Auto 8x 01 04 35 00 FF Normal Auto
Indoor 8x 01 04 35 01 FF Indoor Mode
Outdoor 8x 01 04 35 02 FF Outdoor Mode
One Push WB 8x 01 04 35 03 FF One Push WB Mode
ATW 8x 01 04 35 04 FF Auto Tracing White Mode
Manual 8x 01 04 35 05 FF Manual Control Mode
CAM_WB
One Push Trigger 8x 01 04 10 05 FF One Push WB trigger
Reset 8x 01 04 03 00 FF R Gain Manual setting
Up 8x 01 04 03 02 FF
Down 8x 01 04 03 03 FF
CAM_RGain
Direct 8x 01 04 43 0p 0q 0r 0s FF pqrs: R Gain
Reset 8x 01 04 04 00 FF B Gain Manual setting
Up 8x 01 04 04 02 FF
Down 8x 01 04 04 03 FF
CAM_BGain
Direct 8x 01 04 44 0p 0q 0r 0s FF pqrs: B Gain
Full Auto 8x 01 04 39 00 FF Automatic exposure mode
Manual 8x 01 04 39 03 FF Manual control mode
Shutter Priority 8x 01 04 39 0A FF Shutter priority auto exposure mode
Iris Priority 8x 01 04 39 0B FF Iris priority auto exposure mode
CAM_AE
Bright 8x 01 04 39 0D FF Bright mode (Manual）
Auto 8x 01 04 5A 02 FF AutoSlowShutter ON/OFF
CAM_SlowShutter
Manual 8x 01 04 5A 03 FF
Reset 8x 01 04 0A 00 FF Shutter setting
（1/4sec～1/10000sec）
Up 8x 01 04 0A 02 FF
Down 8x 01 04 0A 03 FF
CAM_Shutter
Direct 8x 01 04 4A 00 00 0p 0q FF pq: Shutter Position
Reset 8x 01 04 0B 00 FF Iris setting
Up 8x 01 04 0B 02 FF
Down 8x 01 04 0B 03 FF
CAM_Iris
Direct 8x 01 04 4B 00 00 0p 0q FF pq: Iris Position
Reset 8x 01 04 0C 00 FF Gain setting
CAM_Gain
Up 8x 01 04 0C 02 FF

CeilingVIEW 70 PTZ HideAway – Document 341- 075 Rev. D
Page 10 of 14
Command List
(Continued)
Down 8x 01 04 0C 03 FF
Direct 8x 01 04 4C 00 00 0p 0q FF pqrs: Gain Position
Reset 8x 01 04 0D 00 FF Bright setting
Up 8x 01 04 0D 02 FF
Down 8x 01 04 0D 03 FF
CAM_Bright
Direct 8x 01 04 4D 00 00 0p 0q FF pqrs: Bright Position
On 8x 01 04 3E 02 FF Exposure Compensation ON/OFF
Off 8x 01 04 3E 03 FF
Reset 8x 01 04 0E 00 FF Exposure Compensation amount setting
Up 8x 01 04 0E 02 FF
Down 8x 01 04 0E 03 FF
CAM_ExpComp
Direct 8x 01 04 4E 00 00 0p 0q FF pqrs: ExpComp Position
On 8x 01 04 33 02 FF Back Light Compensation
CAM_BackLight
Off 8x 01 04 33 03 FF
On 8x 01 04 59 02 FF Setting for AE
Off 8x 01 04 59 03 FF
CAM_SpotAE
Position 8x 01 04 29 0p 0q 0r 0s FF pq: X(0 to F) , rs: Y(0 to F)
Reset 8x 01 04 02 00 FF Aperture Control
Up 8x 01 04 02 02 FF
Down 8x 01 04 02 03 FF
CAM_Aperture
CAM_Aperture
Direct 8x 01 04 42 0p 0q 0r 0s FF pqrs: Aperture Gain
On 8x 01 04 61 02 FF Mirror Image ON/OFF
CAM_LR_Reverse
Off 8x 01 04 61 03 FF
On 8x 01 04 62 02 FF Freeze Picture ON/OFF
CAM_Freeze
Off 8x 01 04 62 03 FF
Off 8x 01 04 63 00 FF Picture Effect setting
Neg.Art 8x 01 04 63 02 FF
CAM_PictureEffect
B&W 8x 01 04 63 04 FF
On 8x 01 04 01 02 FF ICR Mode ON/OFF
CAM_ICR
Off 8x 01 04 01 03 FF
On 8x 01 04 51 02 FF Auto ICR ON/OFF
CAM_AutoICR
Off 8x 01 04 51 03 FF
Reset 8x 01 04 3F 00 pp FF p: Memory number （=0 to 5）
Set 8x 01 04 3F 01 pp FF
CAM_Memory
Recall 8x 01 04 3F 02 pp FF
On 8x 01 04 75 02 FF Mute ON/OFF
Off 8x 01 04 75 03 FF
CAM_Mute
On/Off 8x 01 04 75 10 FF
CAM_Display On 8x 01 04 15 02 FF Display On/Off
