High Definition PTZ Camera Featuring the Quick-Connect™ DVI/HDMI SR Interface
Quick-Connect DVI/HDMI SR Interface
PN: 998-1105-018
INSTALLATION AND USER GUIDE
Arctic White Version
Part Number 999-6946-000AW (North America)
Part Number 999-6946-001AW (International)
Black Version
Part Number 999-6946-000 (North America)
Part Number 999-6946-001 (International)

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 2 of 20
Inside Front Cover - Blank

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 3 of 20
Overview:
The WallVIEW HD-19 HD PTZ camera and Quick-Connect
DVI/HDMI EZCamera™ Cat-5e cabling system using HSDS™, is a
system that allows for easy installation and integration of a camera
system capable of simultaneous HD analog YPbPr and composite
(CVBS). The HD-19 camera is built around a 1/3-type high-speed
Exmor CMOS image sensor with a total of 1.3 Megapixels and a
19X optical zoom lens, making it the ideal choice for a wide range of
high definition video applications including, 720p, 1080i or 1080p.
Because the camera module is built around a new, high speed
CMOS image sensor with an increased pixel aperture size, high
frame rate, high signal to noise while using the column-parallel A/D
conversion method, the resolution, saturation and the sensitivity of
the sensor is increased. The HD-19 achieves improved picture
quality even in low light environments requiring a minimum
illumination rated at an astonishing 0.7 LUX (F1.6 - 50IRE).
The WallVIEW HD-19 is available in Black and in Arctic White and is equipped with a slip-clutch mechanism for
smooth pan/tilt operation and control. The HD-19 outputs HD video (YPbPr at 1080p/60/59.94/50/30/25,
1080i/59.94/50, 720p/59.94/50, 480i/30fps and 576i/25fps) and SD video (CVBS at 480i/NTSC or 576i/PAL)
simultaneously.
The HD-19 is paired with the Quick-Connect DVI/HDMI SR Interface, which provides power to the camera and
returns HSDS video from the camera up to 100’ (30.5m) over a single Cat-5e cable. The Quick-Connect
DVI/HDMI features extended control functions including Daisy Chain Control Emulation (DCCE™), which allows
single control port codecs to control multiple HD-19 cameras, and IR forwarding in modulated and non-modulated
formats for extending the reach of the IR remotes included with today’s most popular videoconferencing systems.
The WallVIEW HD-19 is an exceptional camera for a wide range of HD video applications such as houses of
worship, corporate boardrooms, live events and distance-learning.
Intended Use:
Before operating the device, please read the entire manual thoroughly. The system was designed, built and
tested for use indoors, and with the provided power supply and cabling. The use of a power supply other than the
one provided or outdoor operation has not been tested and could damage the device and/or create a potentially
unsafe operating condition.
Important Safeguards:
Read and understand all instructions before using. Do not operate any device if it has been dropped or damaged.
In this case, a Vaddio technician must examine the product before operating. To reduce the risk of electric shock,
do not immerse in water or other liquids and avoid extremely humid conditions.
Save These Instructions:
The information contained in this manual will help you install and operate your product. If these instructions are
misplaced, Vaddio keeps copies of Specifications, Installation and User Guides and most pertinent product
drawings for the Vaddio product line on the Vaddio website. These documents can be downloaded from
www.vaddio.com free of charge.
Use only the power supply provided with the system. Use of any unauthorized
power supply will void any and all warranties.
Please do not use “pass-thru” type RJ-45 connectors. These pass-thru type connectors do not
work well for professional installations and can be the cause of intermittent connections which
can result in the RS-232 control line failing and locking up, and/or compromising the HSDS™
signals. For best results please use standard RJ-45 connectors and test all cables for proper
p
in-outs
p
rior to use and connection to Vaddio
p
roduct.

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 4 of 20
UNPACKING:
Carefully remove the device and all of the parts from the packaging.
Unpack and identify the following parts for 999-6946-000:
One (1) ClearVIEW HD-19 HD PTZ Camera
One (1) Vaddio IR Remote Commander
One (1) Quick-Connect DVI/HDMI SR Interface One (1) Laird Technologies 28A2432-0A2 Clamp-on Ferrite Cylinder (Wrap IR forwarding
LED wires twice before screwing stripped wire ends to 3 conductor Molex Euro Jack)
Two (2) Laird Technologies 28A0640-0A2 Clamp-on Ferrite (Clamp around 0.8" diameter DVI Cable at the Quick-Connect DVI end)
One (1) Laird Technologies HFA163090-0A2 Clamp-on Ferrite (Clamp around 0.8" diameter shielded DVI Cable at the Monitor end)
One (1) Vaddio PowerRite™ 24 VDC, 2.0 Amp Power Supply
One (1) 998-1001-232 EZCamera Control Adapter (for control systems)
One (1) 998-1002-232 EZCamera Control Adapter (for TANDBERG VC systems) One (1) 3-pos Phoenix type connector
One (1) Thin Profile Wall Mount with Mounting Hardware
One (1) AC Cord Set for North America
Documentation
(Note: The 999-6946-001 Int’l Version includes the Euro and UK power cables)
ClearVIEW HD-19 PTZ Camera, Front View with Feature Call-outs:
1) Camera and Zoom Lens:
The 19X optical zoom lens is built around a 1/3-type high-speed CMOS image sensor with a total of 1.3
Megapixels for precise HD video image acquisition.
2) Red Tally Light:
A red tally light is illuminated when the camera receives a VISCA command from an external control system.
3) IR Sensors:
IR sensors are built into the front of the ClearVIEW HD-19 to receive IR signals from the IR remote control
supplied with the camera as well as other 3rd party remotes for the IR forwarding feature.
4) Blue Power Light:
A Vaddio blue power light is illuminated when the camera is turned on.
Compatible Vaddio Switchers and Joystick Controllers:
ProductionVIEW™ HD MV
(999-5625-000)
Precision Camera Controller
(999-5700-000)
AutoPresenter
(999-5675-000)
②
①
③
④

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 5 of 20
ClearVIEW HD-19 PTZ Camera, Rear View with Feature Call-outs:
5) RS-232 IN & IR Out:
The RS-232 accepts modified VISCA protocol for camera control, as well as transmits IR signaling received by
the IR receivers, which can be transmitted to third party devices.
6) Dip Switch Settings:
Settings for IR remote, baud rate, SD output format, and image flip can be configured on these switches. See
page 5 for additional information on switch settings.
7) HD Video Select:
A rotary switch allows the user to choose the component HD output video resolution and format. See page 6 for
additional information on switch settings.
8) 12 VDC Input:
Power input for the standard, ClearVIEW HD-19 camera power supply.
9) YPbPr Output:
Component HD video is fed through the DB-15 connector. YPbPr and Composite signals are simultaneous. This
is an HD camera and the SD signals are down converted and are really not the sweet spot of this camera.
9) Composite Video (CVBS) Output:
The CVBS output feeds out SD video signals and is configurable with the dip switches to choose between
480i/NTSC or 576i/PAL in 4:3 formats. Squeeze and letterbox modes are also available (see dipswitches 6&7).
11) EZ Power/Video Port:
This RJ-45 connector is only used with the Quick-Connect SR Interface and the Quick- Connect DVI-D/HDMI SR
Interface to supply power and return HSDS video from the camera.
12) Slot for Optional Cards:
Optional slot cards can be plugged into the ClearVIEW HD-19 camera (the HD-SDI Slot Card and the EZIM CCU
Slot Card are available separately).
⑥
⑤
⑧
⑦
⑩
⑨
⑫
⑪

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 6 of 20
Quick-Connect DVI/HDMI - SR Interface I/O Description
1) Blue LED Power Indicator.
2) 24 VDC Power Port: Coax Power Connector, 5.5mm OD x 2.5mm ID, Positive Center.
3) Recessed Color Space Conversion Switch: Toggles between HDMI YCbCr and sRGB (RGBHV) color
space. Change the color space to accommodate either YCbCr or RGBHV monitors.
4) RS-232 Control Input (from joystick controller, codec or control system).
5) To Camera: RS-232 Control to & from Camera and IR signals returned from the camera.
6) Daisy Chain Control Port: Daisy Chain Control Emulation (DCCE) output to next Quick-Connect DVI/HDMI
SR Interface (does not function with the AutoTrak System).
7) IR Output Port: Non-modulated (for hard connections) and Modulated for use with IR emitters.
8) DVI-D Output: High Definition Multimedia Interface (HDMI) Transmitter, HDMI (v 1.3 with deep color) and
DVI v 1.0 Compliant - use Recessed Color Space Conversion Switch to toggle between HDMI YCbCr and
sRGB (RGBHV) color spaces to suit your monitors
9) YPbPr Output: Analog Component Video Output on DE-15F (HD-15F) Connector, Resolutions up to
1080p/60 with monitor support.
10) EZCamera Power & HD Video Port: Supplies power to camera and returns HD video from the camera via
Cat-5e. Maximum distance on the CAT-5e cable is 100’ (30.5 m).
Installation Basics:
The WallVIEW HD-19 product was designed for installation on a vertical wall surface with Cat-5e cable
connectivity for Power, Video and Control signaling (two Cat-5e cables are required). Installation is simplified in
that no custom 8-Pin mini-din cables or expensive coax plenum cables are needed and no power outlets are
required near the camera bracket. All cabling is routed to the head-end using Cat-5e cables.
Before Installing:
Locate the camera mounting location paying close attention to camera viewing angles, lighting conditions,
possible line of site obstructions, and checking for in-wall obstructions where the camera is to be mounted.
Pick a mounting location that will optimize the performance of the camera.
The Thin Profile Wall Mount for the WallVIEW HD-19 can be mounted directly to a 2-gang wall box or can be
mounted to the drywall using four dry wall anchors.
RS-232 Cabling:
For RS-232, use a standard Cat-5e cable and RJ-45 connectors (568B termination) from the RS-232 port on the
back of a Vaddio camera controller or switcher. If the camera is connected to a third-party control system (such
as AMX or Crestron), a DB-9 to RJ-45 control adapter cable is supplied. Use of pass-thru type RJ-45
connectors is highly discouraged. The Vaddio Cat-5e wiring standard uses pins 7 and 8 on both the
video and the control Cat-5e cables. The pass-through connectors have proven to provide insufficient
connectivity for these important signals. They are “ok” for voice and data, but not for video and control.
Videoconferencing Codecs and RS-232:
Depending on the codec and RS-232 port used, special DB-9 to RJ-45 adapters may sometimes be required.
Refer to Vaddio’s price list or website for Tech Notes on the WallVIEW HD-19 page on specific diagrams for
wiring the camera to videoconferencing codecs. Any special adapters and configuration information will be noted.
Remember to always power up the cameras before booting up the codec.
①②③④⑤ ⑥ ⑦⑨⑧ ⑩

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 7 of 20
First Time Set-up with the HD-19:
The ClearVIEW HD-19 was designed to be exceptionally easy to use and operate. There is documentation at the
back of the manual for pin-outs for all of the connectors on the ClearVIEW HD-19 camera.
Step 1: Using the HD Video Select Rotary Switch and Camera Settings Dip Switch on the back of the camera,
set up the camera’s output resolution and functional preferences. There is a label on the bottom of the camera
that identifies the choices.
Label on the Bottom of HD-19
Set the HD output resolution for the camera with the Rotary Switch.
Set the IR frequency of the camera if it is to respond to the IR remote control.
If using RS-232 for control, leave the IR OUT OFF (SW3) and choose 9600bps
If using the IR forwarding feature, turn the IR OUT ON (SW3).
If inverting the camera, turn the IMAGE FLIP ON (SW8).
Dip Switch Settings:
IR 1 & 2: The IR remote has the capability of operating up to three different PTZ cameras from one
remote. Use the selector buttons at the top of the IR remote to select the frequency.
IR Out 3: The IR output is sent out on the RS-232 RJ-45 jack on the back of the camera. Turning on the
IR output will allow IR signals to be transmitted over the CAT-5 cable to the head end. When using RS-
232 control or Vaddio CCU controllers (also via RS-232), turn the IR OUT to OFF.
Baud Rate 4: The options for baud rate are either 9600 bps or 38,400 bps. Default is 9600 bps.
SD Format 5: Choose between NTSC or PAL formats
SD Configurations 6 & 7: SD video can be set to standard 4:3, squeeze mode or letterbox mode.
Image Flip 8: To invert the HD-19, turn the IMAGE FLIP ON (switch down).
Test Bars 9: Turning on the non-standard test bars will override the camera video output. These non-
standard test bars are 75% IRE.
Switch 10: Leave up - or in the OFF position
HD Video Select Switch Camera Settings 10-Pos Dip Switch
HD-19
Rear
Panel
IR 1
1 & 2 UP
ON
SD
NTSC
SD
PAL
SD 4:3
6 & 7 UP
SD
LB
FLIP
OFF
ON ON
DIP SWITCH SETTINGS
8
1234567910
HD VIDEO SELECT
720p/59.94
1080i/59.94
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
1080p/59.94
1080p/60
720p/50
1080i/50
1080p/50
21 5 4
37 68109
ON
IR 2
ON IR 3 ON
IR
OUT
OFF
9600
bps
38400
bps SD
SQ
TEST
BARS
OFF
10
OFF
480i/29.97 1080p/25
1080p/30
576i/25

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 8 of 20
System Connectivity Example 1:
Basic system connectivity of a Vaddio WallVIEW™ DVI/HDMI HD-19 and Quick-Connect DVI/HDMI SR Interface
with Vaddio ProductionVIEW™ Precision Camera Controller and PreVIEW HD Monitors.
WallVIEW DVI/HDMI
HD-19 System
Quick-Connect
DVI/HDMI SR
Interface
Two (2) - Cat-5e Cables
Total - Up to 100’ (30.48m)
RS-232 Control - Cat-5e
Power to Camera
HSDS Video from
Camera - Cat-5e
Vaddio Precision Camera Controller
(Up to 7 PTZ Cameras can be controlled)
R
S
-2
3
2
o
n
Ca
t-
5e
Large Format HDMI Monitor
(Simulated Video Feed)
Vaddio PreVIEW™ HD 7.0 Rack Monitors
(Simulated Video Feeds)
*HDMI with
Adapter Cable
YP
b
P
r
YPbPr & Power on
one (1) Cat-5e up to
100’ (30.5m)
Dancing Bear Camera
(Simulated Feed)
*The Recessed Color Space
Conversion Switch enables the
use of either HDMI YCbCr or
DVI-D sRGB (RGBHV) color
space for added flexibility.

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 9 of 20
System Connectivity Example 2: System connectivity of two (2) Vaddio HD-19 cameras and two (2) Quick-
Connect DVI/HDMI SR Interfaces configured with single control port codec and Daisy Chain Control Emulation
(DCCE).
BASIC INSTALLATION INSTRUCTIONS
Step 1: After determining the optimum location of the camera system, route the
two (2) Cat-5e cables from the camera to the Quick-Connect DVI-HDMI SR
Interface located at the head-end. The two Cat-5e cables should feed-through the
oval slot located on the rear flange of the wall mount. The bracket can be mounted
on a 2-gang wall box or to the drywall with wall anchors. The mounting holes are
slotted and are 90° opposing to provide easy leveling. Mark the cables
Power/Video and RS-232.
Step 2: Follow the sample wiring diagrams for connecting the Cat-5e cables to the camera and Quick-Connect
DVI/HDMI SR Interface. Additional diagrams are available on our website for installation with a variety of
videoconferencing codecs, using the RS-232 I/O connectors for IR signaling.
NOTE: Check all Cat-5e cables for in advance of the final connection. Plugging the system in
wrong may cause damage to the camera system and void the warranty.
Step 3: Place the camera onto the camera mount and plug in the Cat-5e cable marked Power/Video into the EZ
POWER HD VIDEO RJ-45 on the camera. Plug the Cat-5e marked RS-232 into the RS-232 / IR OUT jack. Use
the ¼”-20 screws provided to secure the camera to the mount. NOTE: Set up the camera first (see page 7).
Step 4: At the head end, plug the Cat-5e cable labeled Power/Video into the EZCamera POWER & HD VIDEO
RJ-45 jack on the Quick-Connect DVI/HDMI Interface. Plug the Cat-5e marked RS-232 into the RS-232
CONTROL - TO CAMERA RJ-45.
Thin Profile
Camera
Wall Mount
WallVIEW DVI/HDIM HD-19
HD Camera Systems
DVI to HDMI
Cable
IR
Daisy Chain Link between
Quick-Connect Interfaces
DVI Cable
Computer
with DVI
Output
C60 Codec
Microphones
ETHERNET
DVI Cable
Single RS-232 Port Codec with
Daisy Chain Camera Control
Codec IR Remote:
Forwarded through
Main Camera for
Codec Control
RS-232 RS-232
Two (2) - Cat-5e
Cables - up to
100’
(
30.48m
)
Power to Camera
HD Video from
Camera - Cat-5e
Power to Camera
HD Video from
Camera - Cat-5e
RS-232 & IR Return Cat-5e
Two (2) - Cat-5e
Cables - up to 100’
(
30.48m
)
RS-232 & IR Return Cat-5e
HD Video Monitors
(Simulated Video Feeds)
Monitor 1 Monitor 2
DVI-D
HDMI
Quick-Connect
DVI/HDMI SR
Interfaces

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 10 of 20
Step 5: Plug your RS-232 controller (Vaddio’s ProductionVIEW HD, Precision Camera Controller, ControlVIEW
XHD, AutoPresenter, etc…) into the RS-232 CONTROL INPUT. If you are using a 3rd party controller (Crestron®,
or AMX®) use the provided 9-pin to RJ-45 control adapter and then a Cat-5e cable to plug this RS-232 controller
into this port.
Step 6: Connect the HD Video Outputs (DVI or HDMI with adapter cable - or - analog HD YPbPr video) into a
display device or video console. Please make sure that the video console or the display device is set up to
receive the HD camera resolution that was chosen with the rotary switch on page 6. Most monitors are
automatic, however all consoles will need set-up prior to termination.
Step 7: Connect the Vaddio 24 VDC, 2.0A power supply to the POWER Connector on the Quick-Connect and
plug the power adapter into an AC outlet. Power will travel down the Power/Video Cat-5e cable to the camera.
The camera will “Home” to a centered position, return HSDS video back to the Quick-Connect and is ready for
control from the IR remote or RS-232 camera controller. Boot Order: Always turn the cameras on first, then
the controller or codec.
Daisy Chain Configurations/Installation Instructions: In some cases, daisy chain control situations just can’t
be avoided. Because of this, Vaddio added “Daisy Chain Control Emulation” or DCCE™ to the Quick-Connect
DVI/HDMI - SR Interface in order to use the HD-19 camera in these situations. See Connectivity Example 2
(previous page) where the codec requires daisy chain control wiring.
1) For daisy chain control, first complete steps above, since all the cabling between the camera and the Quick-
Connect DVI/HDMI Interface is the same.
2) Instead of running a cable from the 1st camera to the 2nd camera, run a Cat-5e patch cable from the 1st Quick-
Connect DVI/HDMI Interface’s RS-232 CONTROL DAISY CHAIN RJ-45 jack, to the 2nd Quick-Connect DVI-
HDMI SR Interface’s RS-232 CONTROL INPUT RJ-45 jack.
3) Within the modified VISCA® protocol that the codec and the HD-19 use, the 1st in the chain will set up as
Camera #1, the second will set up as Camera #2 in the chain, allowing the codec IR remote to select which
camera it will switch to and which to control.
4) In the case of TANDBERG codecs, use the IR Modulated output of the Quick-Connect and a Xantech IR
emitter (282D or 283D) and attach the emitter to the front panel of the codec (in front of the IR receiver).
5) Polycom codecs with IR receivers can connect the IR feed-through the same way as the TANDBERG, but do
not use daisy chain control. Several Polycom codecs can also be connected directly with the non-modulated
signal to the codec’s IR signal input port.
Basic Daisy Chain Connectivity:
RS-232 from Codec
Single Control Port
Dais
y
Chain Port Out
RS-232
To Camera
#2
RS-232
To Camera
#1
RS-232 Control IN
RS-232

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 11 of 20
General Specifications:
WallVIEW DVI/HDMI HD-19
Part Numbers WallVIEW HD-19 (North America) P/N: 999-6946-000 (Black), 999-6946-000AW (Arctic White)
WallVIEW HD-19 (International) P/N: 999-6946-001(Black), 999-6946-001AW (Arctic White)
V
addio HD-19
Image Sensor 1/3-Type Exmor High-speed, Progressive Scan CMOS Sensor with 1.3 Megapixels
Video Output
Resolutions
HD: 1080p/60/59.94/50/30/25, 1080i/59.94/50, 720p/59.94/50
SD: 480i/NTSC & 576i/PAL (Crop, Squeeze or Letterbox mode)
Color: The Recessed Color Space Conversion Switch enables the use of either HDMI YCbCr or
DVI-D sRGB (RGBHV) color space for added flexibility.
Lens/ Focal Length 19X Optical Zoom, F=4.5mm wide to 85mm tele end (F1.6-F2.9), Min. Focus Distance 1.0m
Horizontal Viewing Angle 58.1° Wide End to 3.2° Tele End - 16:9 Format
Video S/N Ratio >52 dB
Minimum Illumination 0.7 LUX (F1.6, 50IRE)
Serial Control Protocol RS-232 (Modified VISCA)
Pan Range Pan: +170 degrees to -170 degrees, Tilt: +90 degrees to -30 degrees, Invertible for Ceiling
Mount
Preset Positions 16 (internal), 6 recalled via IR Remote
Tally Light Available through RS-232 Control
Connectors 12 VDC Power Input: EIAJ-04 Coaxial Power Connector
HD Video Outputs: YPbPr on DE-15 (D-Sub 15-pin HD)
SD Video Output: BNC Connector
RS-232/IR Out: RJ-45 Jack (RS-232 Communication and IR Out (with Quick-Connect -SR
Interfaces)
EZ Power HD Video: RJ-45 Jack, for use with Quick-Connect SR Interface or Quick-
Connect DVI/HDMI SR Interface. Supplies power to the camera and returns HD video from
the camera to the Quick-Connect - SR Systems.
HD Video Select 16-Position Rotary Switch: Used to set HD Video Resolution Output
Camera Settings 10-Position Dip Switch: Settings for IR Select, Baud Rate 9600, Image Flip, SD LB and SQ,
Test Bars
OSD (On Screen Display) for fine tuning
Accessories EZIM HD-SDI Slot Card PN# 998-6900-007
EZIM CCU Slot Card PN# 999-6900-006 - For Use with Quick-Connect CCU Only
Operating Temperature 32° to 104° F (0° to 40° C) / 20% to 80% Relative Humidity
Dimensions (H x W x D) 8.5” (215.9mm) H x 6.75” (171.45mm) W x 7.7” (195.58mm) D
Weight 5.79 lbs. (2.625635463kg.)
Quick-Connect DVI/HDMI SR (Short Range) Interface
Connectors Power Connector: 5.5mm OD, 2.5mm ID coaxial connector
RJ-45: Four (4) Control IN, Control OUT, Daisy Chain OUT, EZCamera Power Video Port
Video Output: DE-15 connector for HD Analog Component (Y,PB,PR) video only (No SD Support)
IR Output: Transmits modulated or non-modulated IR signals received from the HD-19 IR receiver
Video Outputs: DVI-D (Female - Single Link) or HDMI with adapter cable (using the Recessed Color
Space Conversion Switch) , DE-15F (High Density D-Sub 15-Pin F) for HD YPbPr
Cat-5e Cable Distance Up to 100’ (30.5m)
Power Supply 24 VDC, 2 Amp
Dimensions / Weight 1.6” (40.64mm ) H x 8” (203.2mm) W x 6.751” (171.45mm) D, ½-Rack Size / 1.21 lbs.
(0.548846804 kg)
Accessory Options 1-RU Rack Mount Panel for two (2) units (side by side): P/N: 998-6000-003
1m (3.3’) DVI-D Male to HDMI Male P/N: 440-5643-001
3m (10’) DVI-D Male to HDMI Male P/N: 440-5643-003
Thin Profile Wall Mount HD-19
Materials 12-Gauge CRS with Black Powder Coat Paint
Dimensions 5.125” (130.175)mm H x 6.75” (171.45mm) W x 10” (254mm) D
Weight Approx. 2.4 lbs. (1.08862176kg)

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 12 of 20
Compliance and CE Declaration of Conformity - ClearVIEW HD-19
Compliance testing was performed to the following regulations:
FCC Part 15, Subpart B Class A
ICES-003, Issue 4: 2004 Class A
EN 55022 A: 2006 + A1: 2007(CISPR 22:2005/A1:2005) Class A
AS/NZS CISPR 22: 2009 + A1: 2010 Class A
VCCI V-3/2010.04 ClassA
EMC Directive 2004/108/EC ClassA
FCC Part 15 Compliance
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part
15, Subpart B, of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his/her own
expense.
Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This
device must accept any interference including interference that may cause undesired operation of the device.
Changes or modifications not expressly approved by Vaddio can affect emission compliance and could void the
user’s authority to operate this equipment.
ICES-003 Compliance
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out
in the Radio Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’emet pas de bruits radioélectriques dépassant les limites applicables aux
appareils numeriques de la classe A préscrites dans le Règlement sur le brouillage radioélectrique édicte par le
ministère des Communications du Canada.
European Compliance
This product has been evaluated for Electromagnetic Compatibility under the EMC Directive for Emissions and
Immunity and meets the requirements for a Class A digital device. In a domestic environment this product may
cause radio interference in which case the user may be required to take adequate measures.
Standard(s) To Which Conformity Is Declared:
EMC Directive 2004/108/EC
EN 55024: 1998 + Amendments A1: 2001 + A2: 2003 Immunity
EN 61000-4-2: 1995 + Amendments A1: 1998 + A2: 2001 Electrostatic Discharge
EN 61000-4-3: 2006 + A1: 2008 Radiated Immunity
EN 61000-4-4: 2004 + Corrigendum 2006 Electrical Fast Transients
EN 61000-4-5: 2006 Surge Immunity
EN 61000-4-6: 2009 Conducted Immunity
EN 61000-4-8: 2010 Power Frequency Magnetic Field
EN 61000-4-11: Second Edition: 2004 Voltage Dips, Interrupts and Fluctuations
Compliance and CE Declaration of Conformity - Quick-Connect DVI/HDMI SR Interface

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 13 of 20
Compliance testing was performed to the following regulations:
FCC Part 15, Subpart B Class A
ICES-003, Issue 4: 2004 Class A
European Standard EN 55022 A: 2006 + A1: 2007(CISPR 22:2005/A1:2005) Class A
EMC Directive 2004/108/EC Class A
FCC Part 15 Compliance
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15, Subpart
B, of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his/her own expense.
Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must
accept any interference including interference that may cause undesired operation of the device.
Changes or modifications not expressly approved by Vaddio can affect emission compliance and could void the user’s
authority to operate this equipment.
ICES-003 Compliance
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio
Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’emet pas de bruits radioélectriques dépassant les limites applicables aux appareils
numeriques de la classe A préscrites dans le Règlement sur le brouillage radioélectrique édicte par le ministère des
Communications du Canada.
European Compliance
This product has been evaluated for Electromagnetic Compatibility under the EMC Directive for Emissions and Immunity and
meets the requirements for a Class A digital device. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
Ferrite cylinders are included in order to the Quick-Connect DVI/HDMI SR Interface to strictly comply with the European
Community EMC Directives compliance. Use these ferrites to ensure the elimination of possible EMI interference from cell
phones and AC motors.
Standard(s) To Which Conformity Is Declared:
EMC Directive 2004/108/EC
EN 55022 A: 2006 + A1 2007 (CISPR 22:2005/A1:2005) Conducted and Radiated Emissions
EN 55024: 1998 + Amendments A1: 2001 + A2: 2003 - Electromagnetic Compatibility - Immunity
EN 61000-4-2 Electrostatic Discharge
EN 61000-4-3 Radiated Immunity
EN 61000-4-4 Electrical Fast Transients
EN 61000-4-5 Surge Immunity
EN 61000-4-6 Conducted Immunity
EN 61000-4-8 Power Frequency Magnetic Field
EN 61000-4-11 Voltage Dips, Interrupts and Fluctuations

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 14 of 20
WARRANTY INFORMATION
(See Vaddio Warranty Policies posted on vaddio.com for complete details):
Hardware* Warranty: One year limited warranty on all parts. Vaddio warrants this product against defects in materials and
workmanship for a period of one year from the day of purchase from Vaddio. If Vaddio receives notice of such defects during
the warranty period, they will, at their option, repair or replace products that prove to be defective.
Exclusions: The above warranty shall not apply to defects resulting from: improper or inadequate maintenance by the
customer, customer applied software or interfacing, unauthorized modifications or misuse, operation outside the normal
environmental specifications for the product, use of the incorrect power supply, improper extension of the power supply cable
or improper site operation and maintenance.
Vaddio Customer Service: Vaddio will test, repair, or replace the product or products without charge if the unit is under
warranty and is found to be defective. If the product is out of warranty, Vaddio will test then repair the product or products. The
cost of parts and labor charge will be estimated by a technician and confirmed by the customer prior to repair. All components
must be returned for testing as a complete unit. Vaddio will not accept responsibility for shipment after it has left the premises.
Vaddio Technical Support: Vaddio technicians will determine and discuss with the customer the criteria for repair costs
and/or replacement. Vaddio Technical Support can be contacted through one of the following resources: e-mail support at
[email protected] or online at www.vaddio.com.
Return Material Authorization (RMA) Number: Before returning a product for repair or replacement, request an RMA from
Vaddio’s technical support. Provide a technician with a return phone number, e-mail address, shipping address, and product
serial numbers and describe the reason for repairs or returns as well as the date of purchase and proof of purchase. Include
your assigned RMA number in all correspondence with Vaddio. Write your assigned RMA number on the shipping label of the
box when returning the product. All returns are subject to a restocking fee without exception (see warranty policies at
vaddio.com).
Voided Warranty: The warranty does not apply if the original serial number has been removed or if the product has been
disassembled or damaged through misuse, accident, modifications, or unauthorized repair. Cutting the power supply cable on
the secondary side (low voltage side) to extend the power to the device (camera or controller) voids the warranty for that
device.
Shipping and Handling: Vaddio will not pay for inbound shipping transportation or insurance charges or accept any
responsibility for laws and ordinances from inbound transit. Vaddio will pay for outbound shipping, transportation, and
insurance charges for all items under warranty but will not assume responsibility for loss and/or damage by the outbound
freight carrier. If the return shipment appears damaged, retain the original boxes and packing material for inspection by the
carrier. Contact your carrier immediately.
Products Not Under Warranty: Payment arrangements are required before outbound shipment for all out of warranty
products.
*Vaddio manufactures its hardware products from parts and components that are new or equivalent to new in accordance with industry standard practices.
Other General Information:
Care and Cleaning
Do not attempt to take this product apart at any time. There are no user-serviceable components inside.
Do not spill liquids or liquid type substances onto the device.
Keep this device away from food or liquid.
For smears or smudges on the devices, wipe with a clean, soft cloth.
Do not use any abrasive pads or caustic chemicals at any time on any Vaddio equipment.
Operating and Storage Conditions:
Do not store or operate the device under the following conditions:
Temperatures above 40°C (104°F) or temperatures below 0°C (32°F)
High humidity, condensing or wet environments
In inclement weather
Dusty environments
In a swimming pool or the beach
Dry environments with an excess of static discharge
In a space/time vortex
Under severe vibration

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 15 of 20
Appendix 1: YPbPr Video Pin-Out for the HD-19 Camera and Quick-Connect SR Interface
EZCamera Power & HD Video RJ-45 Connector Pin-outs
The EZCamera Power and HD Video RJ-45 Connector is for use with either the Quick-Connect SR
Interface or the Quick-Connect DVI/HDMI SR Interface ONLY (568B Wiring Standard). The video
signals are differential (HSDS™) and can only be received by the interfaces above.
Appendix 2: ClearVIEW HD-19 Dimensions
Pin YPbPr
1 Pr
2 Y
3 Pb
4 -
5 -
6 Pr GND
7 Y GND
8 Pb GND
9 -
10 -
11 -
12 -
13 -
14 -
15 -
Pin YPbPr
1 Power+
2 Power-
3 Y+
4 PB+
5 PB GND
6 Y GND
7 PR+
8 PR-
12345678

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 16 of 20
Appendix 3: Communication Specification
Communication Speed: 9600 bps (default)
Start bit: 1
Stop bit: 1
Data bits: 8
Parity: None
No Flow control
NOTE: The Vaddio ClearVIEW HD-19 Control Protocol is similar, but not identical to the Sony® VISCA™
command set in order to be compatible with several popular control devices. Not all VISCA commands are
supported and there are many HD-19 specific commands in the following Command and Inquiry Lists.
HD-19 Command List (1/2)
Command Set Command Command Packet Comments
Address Set Broadcast 88 30 01 FF Address Set (Daisy chain)
IF_Clear Broadcast 88 01 00 01 FF IF Clear
Command Cancel 8x 2p FF p:socket number(1,2)
CAM_Power On
Off(Standby)
8x 01 04 00 02 FF
8x 01 04 00 03 FF
Power On/Off
CAM_Zoom Stop
Tele(Standard)
Wide(Standard)
Tele(Variable)
Wide(Variable)
Direct
Direct(Variable)
8x 01 04 07 00 FF
8x 01 04 07 02 FF
8x 01 04 07 03 FF
8x 01 04 07 2p FF
8x 01 04 07 3p FF
8x 01 04 47 0p 0q 0r 0s FF
8x 01 7E 01 4A 0v 0p 0q 0r 0s FF
pqrs: Zoom Position*
v:(Speed) 0-7
CAM_Focus Stop
Far(Standard)
Near(Standard)
Far(Variable)
Near(Variable)
AutoFocus
ManualFocus
Auto/Manual
Direct
8x 01 04 08 00 FF
8x 01 04 08 02 FF
8x 01 04 08 03 FF
8x 01 04 08 2p FF
8x 01 04 08 3p FF
8x 01 04 38 02 FF
8x 01 04 38 03 FF
8x 01 04 38 10 FF
8x 01 04 48 0p 0q 0r 0s FF
pqrs: Focus position*
CAM_WB Auto
Manual
One Push WB
8x 01 04 35 00 FF
8x 01 04 35 05 FF
8x 01 04 35 03 FF
CAM_RGain Reset
Up
Down
Direct
8x 01 04 03 00 FF
8x 01 04 03 02 FF
8x 01 04 03 03 FF
8x 01 04 43 00 00 0p 0q FF
pq:00-ff
CAM_BGain Reset
Up
Down
Direct
8x 01 04 04 00 FF
8x 01 04 04 02 FF
8x 01 04 04 03 FF
8x 01 04 44 00 00 0p 0q FF
pq:00-ff
CAM_AE Full Auto
Manual
Shutter Priority
Iris Priority
8x 01 04 39 00 FF
8x 01 04 39 03 FF
8x 01 04 39 0A FF
8x 01 04 39 0B FF
Auto Exposure Mode
Manual Control Mode
Shutter Priority Mode
Exposure Priority Mode (default)
CAM_Iris Reset
Up
Down
Direct
8x 01 04 0B 00 FF
8x 01 04 0B 02 FF
8x 01 04 0B 03 FF
8x 01 04 4B 00 00 0p 0q FF
pq(0x00-0x11)
CAM_Gain Reset
Up
Down
Direct
8x 01 04 0C 00 FF
8x 01 04 0C 02 FF
8x 01 04 0C 03 FF
8x 01 04 4C 00 00 0p 0q FF
pq(0x00-0x24)
CAM_Bright Reset
Up
Down
Direct
8x 01 04 0D 00 FF
8x 01 04 0D 02 FF
8x 01 04 0D 03 FF
8x 01 04 4D 00 00 0p 0q FF
pq(0x01-0x64)
Pin # RJ-45 RS-232 and IR Out Pins
1) Unused
2) Unused
3) Unused
4) IR Output (Diff Signal to Quick-Connect SR)
5) IR Ground (Diff Signal to Quick-Connect SR)
6) GND (GND of IR Short Range - Pin 3)
7) RXD (from TXD of control source)
8) TXD (to RXD of control source)
12345678

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 17 of 20
HD-19 Command List (2/2)
Command Set Command Command Packet Comments
CAM_Backlight On
Off
8x 01 04 33 02 FF
8x 01 04 33 03 FF
CAM_Aperture Reset
Up
Down
Direct
8x 01 04 02 00 FF
8x 01 04 02 02 FF
8x 01 04 02 03 FF
8x 01 04 42 00 00 0p 0q FF
pq(0x00-0x1F)
CAM_Memory Reset
Set
Recall
8x 01 04 3F 00 0p FF
8x 01 04 3F 01 0p FF
8x01 04 3F 02 0p FF p:Memory No(=0-0xe)
CAM_IDWrite 8x 01 04 22 0p 0q 0r 0s FF pqrs:0x0000 – 0xFFFF
IR_Receive On
Off
On/Off
8x 01 06 08 02 FF
8x 01 06 08 03 FF
8x 01 06 08 10 FF IR forwarding/Local IR
Pan-tiltDrive Up
Down
Left
Right
UpLeft
UpRight
DownLeft
DownRight
Stop
Absolute Position
Home
Reset
8x 01 06 01 VV WW 03 01 FF
8x 01 06 01 VV WW 03 02 FF
8x 01 06 01 VV WW 01 03 FF
8x 01 06 01 VV WW 02 03 FF
8x 01 06 01 VV WW 01 01 FF
8x 01 06 01 VV WW 02 01 FF
8x 01 06 01 VV WW 01 02 FF
8x 01 06 01 VV WW 02 02 FF
8x 01 06 01 VV WW 03 03 FF
81 01 06 02 VV WW
0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z FF
0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z FF
8x 01 06 04 FF
81 01 06 05 FF
WW: Pan Speed (0x01-0x18)
VV:Tilt Speed(0x01-0x14)
YYYY: Pan Position**
ZZZZ: Tilt Position**
Tally On
Off
8x 01 7E 01 0A 00 02 FF
8x 01 7E 01 0A 00 03 FF
Preset Pan Speed Pan/Tilt/Zoom Speed 81 01 7E 01 0B WW SS ZZ FF WW: Pan Speed (0x01-0x18)
SS:Tilt Speed(0x01-0x14)
ZZ:Zoom Speed(0-7);
Motor Config Hard Motor Stops
Soft Motor Stops
8x 01 7E 01 70 00 00 FF
8x 01 7E 01 70 00 01 FF
BLK.Enhance Pedestal No Support No Support
GMA.Enhance Gamma 8x 01 7E 54 00 00 0p 0q FF pq: Gamma (0x00-0x10)
CRM.Enhance Chroma 8x 01 7E 55 00 00 0p 0q FF pq: Chroma (0x00-0x64)
KNE.Enhance Knee No Support No Support
DIS.Enhance Digital Image
Stabilizer
8x 01 7E 57 02 FF
8x 01 7E 57 03 FF
On
Off
SNR.Enhance Super Noise
Reduction
8x 01 7E 58 02 FF
8x 01 7E 58 03 FF
On
Off
AGC.Enhance AGC Mode 8x 01 7E 59 00 FF
8x 01 7E 59 01 FF
8x 01 7E 59 02 FF
8x 01 7E 59 03 FF
Off
Low
Medium
High
CAM_Shutter Reset
Up
Down
Direct
8x 01 04 0A 00 FF
8x 01 04 0A 02 FF
8x 01 04 0A 03 FF
8x 01 04 4A 00 00 0p 0q FF
pq(0x00-0x23)
CAM_ExpComp On
Off
Reset
Up
Down
Direct
8x 01 04 3E 02 FF
8x 01 04 3E 03 FF
8x 01 04 0E 00 FF
8x 01 04 0E02 FF
8x 01 04 0E 03 FF
8x 01 04 4E 00 00 0p 0q FF
AutoExposure Off
AutoExpouse On
Pq: 0x00-0x24
CAM_ICR
Cut Filter
ICR On
ICR Off
8x 01 04 01 02 FF
8x 01 04 01 03 FF
ICR On - Cut Filter Out
ICR Off - Cut Filter In
*Zoom and Focus Data:
CAM_Zoom: Range(0x000–0x6B3)
CAM_Focus: Range (0x000-0xC000) dependent on Zoom Position
**Additional Information:
Pan Range: 8044 – 7FBC (-32,700 to +32,700)
Tilt Range: E891 – 4C2B (-5,999 to +19,499)
Actual Pan/Tilt ranges defined in Inquiry list

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 18 of 20
HD-19 Inquiry List (1/1)
Inquiry Command Command Response Packet Comments
CAM_PowerInq 8x 09 04 00 FF y0 50 02 FF
y0 50 03 FF
On
Off(Standby)
CAM_ZoomPosInq 8x 09 04 47 FF y0 50 0p 0q 0r 0s FF pqr: 0-0x6B3
CAM_FocusPosInq 8x 09 04 48 FF y0 50 0p 0q 0r 0s FF pqrs: Focus Position
CAM_WBModeInq 81 09 04 35 FF y0 50 00 FF
y0 50 05 FF
y0 50 03 FF
Auto
Manual
One Push WB
CAM_RGain 8x 09 04 43 FF y0 50 00 00 0p 0q FF pq:000-0ff
CAM_BGain 8x 09 04 44 FF y0 50 00 00 0p 0q FF pq:000-0ff
CAM_Iris 8x 09 04 4B FF y0 50 00 00 0p 0q FF pq(0x00-0x11)
CAM_Gain 8x 09 04 4C FF y0 50 00 00 0p 0q FF pq(0x00-0x24)
CAM_Bright 8x 01 04 4D FF y0 50 00 00 0p 0q FF pq(0x01-0x64)
CAM_BacklightModeInq 8x 09 04 33 FF y0 50 02 FF
y0 50 03 FF
On
Off
CAM_ApertureInq 8x 09 04 42 FF y0 50 00 00 0p 0q FF Pq:x00-0x1F
CAM_MemoryInq 8x 09 04 3F FF y0 50 0p FF p:Preset 0-0xf
CAM_IDInq 8x 09 04 3F FF y0 50 0p 0q 0r 0s FF pqrs:0x0000 – 0xFFFF
CAM_ReceiveInq 8x 09 06 08 FF y0 50 02 FF
y0 50 03 FF
On
Off
Pan-TiltMaxSpeedInq 8x 09 06 11 FF y0 50 pp qq FF pp:Pan 0x01-0x18
qq:Tilt 0x01-0x14
Pan-tiltPositionInq 8x 09 06 12 FF FF y0 50 0p 0p 0p 0p 0q 0q 0q 0q FF pppp: Pan 0x8044-0x7FB2
qqqq: Tilt 0xE890-0x4C2C
TallyInq 8x 09 7E 01 0A FF y0 50 02 FF
y0 50 03 FF
On
Off
PresetSpeedInq 8x 09 7E 01 0B FF y0 50 pp qq rr FF pp:Pan 0x01-0x18
qq:Tilt 0x01-0x14
rr:Zoom 0x00-0x07
Motor Config 8x 09 7E 01 70 FF y0 50 00 FF
y0 50 01 FF
Hard Motor Stops
Soft Motor Stops
BLK.Enhance No support No Support Pedestal
GMA.Enhance 8x 09 7E 54 FF y0 50 00 00 0p 0q FF pq: Gamma (0x00-0x10)
CRM.Enhance 8x 09 7E 55 FF y0 50 00 00 0p 0q FF pq: Chroma (0x00-0x64)
KNE.Enhance No support No Support Knee
DIS.Enhance 8x 09 7E 57 FF y0 50 02 FF
y0 50 03 FF
On
Off
SNR.Enhance 8x 09 7E 58 FF y0 50 02 FF
y0 50 03 FF
On
Off
AGC.Enhance 8x 09 7e 59 FF y0 50 00 FF
y0 50 01 FF
y0 50 02 FF
y0 50 03 FF
y0 50 04 FF
Off
Low
Medium
High
Manual AGC
CAM_AEModeInq 8x 09 04 39 FF y0 50 00 FF
y0 50 03 FF
y0 50 0A FF
y0 50 0B FF
Auto Exposure Mode
Manual Control Mode
Shutter Priority Mode
Exposure Priority Mode
CAM_ShutterPosInq 8x 09 04 4A FF y0 50 00 00 0p 0q FF pq: 0x0-0x23
CAM_ExpCompModeInq 8x 09 04 3E FF y0 50 02 FF
y0 50 03 FF
On - AE Mode Off
Off – AE Mode On
CAM_ExpCompPosInq 8x 09 04 4E FF y0 50 00 00 0p 0q FF pq: ExpComp Pos
CAM_ICRModeInq 8x 09 04 01 FF y0 50 02 FF
y0 50 03 FF
On - ICR filter Out
Off – ICR filter In

ClearVIEW HD-19
ClearVIEW HD-19 Manual 342-0267 Rev. B Page 19 of 20
Appendix 3 (continued):
Iris Position:
Index F-Stop (Iris Position)
0x11 F1.6
0x10 F2.0
0x0F F2.4
0x0E F2.8
0x0D F3.4
0x0C F4.0
0x0B F4.8
0x0A F5.6
0x09 F6.8
0x08 F8.0
0x07 F9.6
0x06 F11.0
0x05 F14.0
0x04 F16.0
0x03 F19.0
0x02 F22.0
0x01 F28.0
0x00 Close
Gamma Position:
Index Gamma value
0x10 1.00
0xF 0.95
0xE 0.90
0xD 0.85
0xC 0.80
0xB 0.75
0xA 0.70
0x9 0.65
0x8 0.60
0x7 0.55
0x6 0.50
0x5 0.45
0x4 0.40
0x3 0.35 (Default)
0x2 0.30
0x1 0.25
0x0 0.20
Shutter Position( Speed):
Index Shutter (Speed)
0x23 1/30000
0x22 1/10000
0x21 1/5000
0x20 1/2500
0x1F 1/1500
0x1E 1/1000
0x1D 1/700
0x1C 1/600
0x1B 1/500
0x1A 1/480
0x19 1/360
0x18 1/300
0x17 1/250
0x16 1/240
0x15 1/200
0x14 1/180
0x13 1/150
0x12 1/120
0x11 1/100
0x10 1/60
0x0F 1/50
0x0E 1/30
0x0D x2
0x0C x4
0x0B x6
0x0A x8
0x09 x10
0x08 x12
0x07 x14
0x06 x16
0x05 x20
0x04 x24
0x03 x32
0x02 x40
0x01 x48
0x00 x60

©2011 Vaddio - All Rights Reserved ●WallVIEW DVI/HDMI HD-19 ●Document Number 342-0267 Rev. A
9433 Science Center Drive, Minneapolis, MN 55428
Toll Free: 800-572-2011 ▪Phone: [phone] ▪FAX: [phone]
www.vaddio.com
©2011 Vaddio - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and pricing are subject to
change without notice. Vaddio, ClearVIEW, ProductionVIEW, Quick-Connect, ControlVIEW™, AutoPresenter, DCCE, WallVIEW, EZCamera, HSDS and
PowerRite are registered trademarks of Vaddio. All other trademarks are property of their respective owners. Document Number 342-0267 Rev. B
