VAIL PRODUCTS PXBC2-8515/20 User manual

MADE IN THE U.S.A.
OWNER’S MANUAL
XBC2-8515/20
XBC2-7715/20
Rev. 11-9-2022

SPECIFICATIONS AND DESIGN ARE SUBJECT TO CHANGE WITHOUT NOTICE AND WITHOUT LIABILITY.

TABLE OF CONTENTS
Introduction.......................................................................................................................................5
Safety ................................................................................................................................................7
Decals..............................................................................................................................................12
Pre-Operation..................................................................................................................................14
Installation Instructions...................................................................................................................15
Operating Instructions.....................................................................................................................16
Troubleshooting ..............................................................................................................................19
Lubrication......................................................................................................................................21
Maintenance....................................................................................................................................22
Bolt Torque Specifications..............................................................................................................29
Specifications..................................................................................................................................30
Parts Section....................................................................................................................................31
Limited Warranty ............................................................................................................................41

READ ENTIRE MANUAL BEFORE
OPERATING EQUIPMENT!
If you do not understand any section of this manual and/or function of this
product please contact your local authorized dealer immediately.
SPECIFICATIONS AND DESIGN ARE SUBJECT TO CHANGE WITHOUT NOTICE AND WITHOUT LIABILITY.

5
Introduction
Never let anyone operate a Vail Products®unit without reading
the “Safety Precautions” and “Operating Instructions” sections
of this manual. Always choose hard, level ground to park the
vehicle on and set the brake so the unit cannot move.
This is the “Safety Alert Symbol” used by this industry. This Symbol is used to warn of possible
injury. Be sure to read all warnings carefully. They are included for your safety and for the safety of
others working with you.
THIS SYMBOL BY ITSELF OR WITH A WARNING WORD IS USED THROUGHOUT THIS MANUAL TO
CALL YOUR ATTENTION TO INSTRUCTIONS INVOLVING YOUR PERSONAL SAFETY OR THE
SAFETY OF OTHERS.
FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN INJURY OR DEATH.
BEFORE OPERATION
The primary responsibility for safety with the equipment falls to the operator. Make sure
the equipment is operated only by trained individuals that have read and understand this
manual. If there is any portion of this manual for function you do not understand, contact
your local authorized dealer or the manufacturer to obtain further assistance. Keep this
manual available for reference. Provide the manual to any new owners and/or operators.
Thank you for purchasing Vail Products®. Our products have been specically designed to
meet and exceed the standards and requirements our customers demand. They have been
eld tested under the most severe conditions to provide consistent and reliable service with
minimum downtime.
Introduction to Vail Products®
GENERAL INFO
Only minor maintenance (such as cleaning and lubricating) is required to keep your Vail
Products®unit in top operating condition. Be sure to observe all maintenance procedures
and safety precautions in this manual and on any safety decals located on the product and
SERVICE INFO
Use only Vail Products®replacement parts. Substitute parts may not meet the required
specications. Record the model & serial numbers of your unit in this manual. The parts
department needs this information to ensure that you receive the correct parts.

SPECIFICATIONS AND DESIGN ARE SUBJECT TO CHANGE WITHOUT NOTICE AND WITHOUT LIABILITY.

7
Safety
SAFETY PRECAUTIONS
READ MANUAL PRIOR TO INSTALLATION
Improper installation, operation, or maintenance of this equipment could
result in serious injury or death. Operator and maintenance personnel
should read this manual, as well as all manuals related to this equipment
and the prime mover thoroughly before beginning installation, operation,
or maintenance. Always wear proper safety glasses, goggles or a face
shield when driving pins in or out, or when any operation causes dust,
ying debris or any other hazardous material.
NOTE! FOLLOW ALL SAFETY INSTRUCTIONS IN THIS MANUAL AND THE
PRIME MOVER’S MANUAL(S).
READ AND UNDERSTAND ALL SAFETY STATEMENTS
Read all safety decals and safety statements in all manuals prior to
operating or working on this equipment. Know and obey all OSHA
regulations, local laws, and other professional guidelines for your
operation. Know and follow good work practices when assembling,
maintaining, repairing, mounting, removing, or operating this equipment.
KNOW YOUR EQUIPMENT
Know your equipment’s capabilities, dimensions and operations before
operating. Visually inspect your equipment before you start, and never
operate equipment that is not in proper working order with all safety
devices intact. Check all hardware to ensure it is tight. Make certain that
all locking pins, latches and connection devices are properly installed and
secured. Remove and replace any damaged, fatigued or excessively worn
parts. Make certain all safety decals are in place and are legible.
Keep decals clean and replace them if they become worn or illegible.

8
SAFETY PRECAUTIONS
LOWER OR SUPPORT RAISED EQUIPMENT
Do not work under raised booms without supporting them. Do not use
support material made of concrete blocks, logs, buckets, barrels or any
other material that could suddenly collapse or shift positions. Make sure
support material is solid , not decayed, warped, twisted or tapered. Lower
booms to ground level or on blocks. Lower booms and attachments to the
ground before leaving the cab or operator’s station.
USE CARE WITH HYDRAULIC FLUID PRESSURE
Hydraulic uid under pressure can penetrate the skin and cause serious
injury or death. Hydraulic leaks under pressure may not be visible. Before
connecting or disconnecting hydraulic hoses, read your prime mover’s
operator’s manual for detailed instructions on connecting and disconnect-
ing hydraulic hoses or ttings.
• Keep unprotected body parts, such face, eyes and arms as far away as
possible from a suspected leak.
•If injured by Hydraulic Fluid, seek Medical Attention at once.
• Wear safety glasses, protective clothing and use a piece of cardboard or
wood when searching for hydraulic leaks.
NOTE! DO NOT USE YOUR HANDS! SEE ILLUSTRATION BE LOW
Safety

9
Safety
SAFETY PRECAUTIONS
DO NOT MODIFY MACHINE OR ATTACHMENTS
Modications may weaken the integrity of the attachment and may impair
the function, safety, life and performance of the attachment. When making
repairs, use only the manufacturer’s genuine parts, following authorized
instructions. Other parts may be substandard in t and quality. Never
modify any ROPS (Roll Over Protection Structure) or FOPS (Falling
Object Protective Structure) equipment or device.
NOTE! ANY MODIFICATIONS MUST BE AUTHORIZED IN WRITING
BY THE MANUFACTURER.
SAFELY MAINTAIN AND REPAIR EQUIPMENT
• Do not wear loose clothing or any accessories that can catch in
moving parts. If you have long hair, cover or secure it so that it does
not become entangled in the equipment.
• Work on a level surface in a well lit area.
• Use properly grounded electrical outlets and tools.
• Use the correct tools for the job at hand. Make sure they are in good
condition for the task required.
• Wear the protective equipment specied by the tool manufacturer.
SAFELY OPERATE EQUIPMENT
Do not operate equipment until you are completely trained by a qualied
operator in how to use the controls, know its capabilities, dimensions and
all safety requirements. See your machine’s manual for instructions.
• Keep all step plates, grab bars, pedals and controls free of dirt, grease, debris
and oil.
• Never allow anyone to be around the equipment when it is operating.
• Do not allow riders on the attachment or the prime mover.
• Do not operate the equipment from anywhere other than the correct operator’s
position.
• Never leave equipment unattended with the engine running, or with this
attachment in a raised position.
• Do not alter or remove any safety feature from the prime mover or this attachment.
• Know your work site safety rules as well as trafc rules and ow. When
in doubt on any safety issue, contact your supervisor or safety coordinator for
an explanation.

10 Safety
EQUIPMENT SAFETY PRECAUTIONS
KNOW WHERE UTILITIES ARE
Observe overhead electrical and other utility lines. Be sure equipment will clear them. When
digging, call your local utilities for location of buried utility lines, gas, water and sewer, as
well as any other hazard you may encounter.
EXPOSURE TO RESPIRABLE CRYSTALLINE SILICA DUST
ALONG WITH OTHER HAZARDOUS DUSTS MAY CAUSE
SERIOUS OR FATAL RESPIRATOR DISEASE.
It is recommended to use dust suppression, dust collection and if necessary personal
protective equipment during the operation of any attachment that may cause high levels
of dust.
REMOVE PAINT BEFORE WELDING OR HEATING
Hazardous
fumes/dust can be generated when paint is heated by welding, soldering or using a torch. Do
all work outside or in a well ventilated area and dispose of paint and solvent properly.
Remove paint before welding or heating. When sanding or grinding paint, avoid breathing the
dust. Wear an approved respirator. Allow fumes to disperse thoroughly before welding or
heating.
END OF LIFE DISPOSAL
At the completion of the useful life of the unit, drain all fluids and dis-mantle by
separating the different materials (rubber, steel, plastic, etc.). Follow all federal, state
and local regulations for recycling and disposal of the fluid and components.
OPERATING THE ATTACHMENT
• Block off work area from bystanders, livestock, etc. Falling trees or branches
can cause severe injury or death.
•Let others know when and where you will be working. Make sure no one is
behind the equipment or for several hundred feet in any direction around the
equipment when in operation. Never allow anyone to approach the rotary cutter
when in operation.
•Due to the potential danger of flying debris, it is the owner’s responsibility and
is “ABSOLUTELY MANDATORY that an IMPACT-RESISTANT,
SHATTERPROOF 1/2" THICK POLYCARBONATE FRONT CAB
DOOR” be installed on the machine to protect the operator.
•Operate only from the operator’s station.
•Do not exceed rated operating capacity of the prime mover.
•Be sure all covers are properly installed before operating unit.
•Do not lift loads in excess of the capacity of the prime mover. Lifting capacity
decreases as the load is moved further away from the unit.
• Never try to board or exit equipment while it is running.
•Test all controls before you begin operation.
