0020323584_00 Operating instructions 3
Operating instructions
Contents
1 Safety ............................................ 4
1.1 Action-related warnings ................. 4
1.2 Intended use .................................. 4
1.3 General safety information............. 5
2 Notes on the documentation ...... 6
2.1 Observing other applicable
documents ..................................... 6
2.2 Storing documents......................... 6
2.3 Validity of the instructions.............. 6
3 Product description..................... 6
3.1 Product designation....................... 6
3.2 Product design............................... 6
3.3 Information on the data plate......... 6
3.4 CE marking .................................... 7
4 Operation...................................... 7
4.1 Switching on the product ............... 7
4.2 Increasing the water
temperature ................................... 7
4.3 Lowering the water temperature .... 7
5 Eliminating faults......................... 7
6 Maintenance ................................. 8
6.1 Caring for the product.................... 8
6.2 Cleaning/checking the flow
regulator......................................... 8
6.3 Cleaning/checking the draw-off
point ............................................... 8
6.4 Procuring spare parts .................... 8
6.5 Checking the product..................... 9
7 Decommissioning........................ 9
8 Recycling and disposal............... 9
Appendix ............................................... 10
A Eliminating faults....................... 10

4Operating instructions 0020323584_00
1 Safety
1.1 Action-related warnings
Classification of action-re-
lated warnings
The action-related warnings
are classified in accordance
with the severity of the pos-
sible danger using the follow-
ing warning symbols and signal
words:
Warning symbols and signal
words
Danger!
Imminent danger to life
or risk of severe personal
injury
Danger!
Risk of death from electric
shock
Warning.
Risk of minor personal
injury
Caution.
Risk of material or envir-
onmental damage
1.2 Intended use
There is a risk of injury or death
to the user or others, or of dam-
age to the product and other
property in the event of im-
proper use or use for which it
is not intended.
The products are designed
to heat up water at an indi-
vidual draw-off point, partic-
ularly at hand wash basins.
These products are not de-
signed for supplying a shower.
The products can be used in
open or closed systems.
Intended use includes the fol-
lowing:
–observance of the operating
instructions included for the
product and any other install-
ation components
–compliance with all inspection
and maintenance conditions
listed in the instructions.
This product can be used by
children aged from 3 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge if
they have been given supervi-
sion or instruction concerning
use of the product in a safe way
and understand the hazards in-
volved. Children must not play
with the product. Cleaning and
user maintenance work must
not be carried out by children
unless they are supervised.
Any other use that is not spe-
cified in these instructions, or
use beyond that specified in this
document, shall be considered
improper use. Any direct com-
mercial or industrial use is also
deemed to be improper.
Caution.

0020323584_00 Operating instructions 5
Improper use of any kind is
prohibited.
1.3 General safety
information
1.3.1 Danger caused by
improper operation
Improper operation may present
a danger to you and others, and
cause material damage.
▶Carefully read the enclosed
instructions and all other ap-
plicable documents, particu-
larly the "Safety" section and
the warnings.
▶Only carry out the activities
for which instructions are
provided in these operating
instructions.
1.3.2 Risk of death due to
changes
to the product or the
product environment
▶Never remove, bridge or
block the safety devices.
▶Do not tamper with any of the
safety devices.
▶Do not damage or remove
any tamper-proof seals on
components.
▶Do not make any changes:
–The product itself
–The water and electricity
supply lines
–to the drain pipework
–to constructional condi-
tions that may affect the
operational reliability of the
product
1.3.3 Risk of death caused by
improper repair work
▶If the power supply cable is
damaged, never replace this
yourself.
▶Contact the manufacturer,
customer service or a simil-
arly qualified person.
1.3.4 Risk of injury and
material damage due to
maintenance and repairs
carried out incorrectly or
not carried out at all
▶Never attempt to carry out
maintenance work or repairs
on your product yourself.
▶Faults and damage should be
immediately eliminated by a
competent person.
▶Adhere to the maintenance
intervals specified.
1.3.5 Risk of material damage
caused by frost
▶Do not install the product in
rooms prone to frost.

6Operating instructions 0020323584_00
2 Notes on the
documentation
2.1 Observing other applicable
documents
▶Always observe all operating instruc-
tions enclosed with the installation com-
ponents.
2.2 Storing documents
▶Store these instructions and all other
applicable documents for further use.
2.3 Validity of the instructions
These instructions apply only to:
Product –Article numbers
VED H 3/3 0010044420
VED H 4/3 0010044421
VED H 6/3 0010044422
3 Product description
3.1 Product designation
This product is an electric instantaneous
water heater.
The hydraulically controlled small instant-
aneous water heater heats the domestic
hot water directly at the draw-off point.
The domestic hot water heating element
starts automatically when the water tap
is opened. An installation with short lines
guarantees minimal heat losses. The avail-
ability of domestic hot water at the draw-off
point depends on the following factors:
–Water temperature at the cold water
connection for the small instantaneous
water heater
–Heating element output
–Flow rate quantity
The bare-wire heating element is suit-
able for various water hardness levels
(hard and soft). This heating element is
not sensitive to scale deposition.
The heating element guarantees fast and
efficient domestic hot water generation
at the sink. Installing the enclosed flow
regulator guarantees an optimum jet of
water.
3.2 Product design
1 2 3
4
1 Front panel
2 Cold water con-
nection
3 Domestic hot
water connection
4 Power supply
cable
3.3 Information on the data plate
The data plate is located on the left-hand
side section of the front casing.
Information on the
data plate
Meaning
Serial-No. Serial number
miniVED Type designation
x = 3, (4, 6) Product variant
/3 Product generation
3,53 kW (4,4 kW, 5,7
kW)
Rated power
1/N/PE
230V ~ 50/60 Hz
Electrical connection
data
IP25 IP rating
1 MPa (10bar) Rated excess pres-
sure
ρ15>1100 Ω•cm Min. specific resist-
ance of the water
max. 35 °C Max. permissible inlet
temperature

0020323584_00 Operating instructions 7
Information on the
data plate
Meaning
VDE/GS mark
VDE/EMC mark
Do not dispose of
the product in the
household waste.
Read all of the in-
structions.
Barcode with serial
number,
The 7th to 16th digits
of the serial number
form the article num-
ber
3.4 CE marking
The CE marking shows that the products
comply with the basic requirements of the
applicable directives as stated on the de-
claration of conformity.
The declaration of conformity can be
viewed at the manufacturer's site.
4 Operation
4.1 Switching on the product
Danger!
Risk of scalding caused by
hot water
During operation, the domestic
hot water temperature can
reach 50 °C and above. As of
a domestic hot water temper-
ature of 43 °C, there is a risk of
scalding.
▶We recommend operating
the product with a filter at the
cold water connection and
a flow regulator at the water
tap for the draw-off point.
▶Only start up the product once the cas-
ing has been completely closed.
▶Open the valve and/or activate the
sensor for the valve with infrared detec-
tion. The domestic hot water heating
element starts automatically. The tem-
perature can be adjusted at the valve.
▶You can find the required minimum flow
rate for starting the heating element
in the technical data in the installation
instructions.
4.2 Increasing the water
temperature
Condition: Even though the tap is set to the max-
imum temperature, the water temperature is too low
for you.
▶Decrease the flow rate at the tap.
4.3 Lowering the water
temperature
Condition: Even though the tap fitting has been set
to the minimum temperature, the water is too hot.
▶Increase the flow rate quantity at the
tap fitting or increase the cold water
volume.
5 Eliminating faults
Danger!
Risk of death caused by im-
proper repair work
▶If the power supply cable is
damaged, never replace this
yourself.
▶Contact the manufacturer,
customer service or a simil-
arly qualified person.

8Operating instructions 0020323584_00
Danger!
Risk of electric shock
If there are faults or leaks, there
is a risk of electric shock.
▶Earth the product.
▶If a fault occurs, use the par-
tition that is installed on-
site (e.g. fuses or power
switches) to disconnect the
product from the power sup-
ply.
▶In the event of a leak at the
unit, close the cold water
supply immediately.
▶Have the fault eliminated
by customer service or a
competent person.
▶Use the table in the appendix to elimin-
ate the faults. (→Page 10)
▶If you are unable to eliminate the fault,
contact your competent person.
6 Maintenance
Availability, safety, reliability, and the ser-
vice life of the product can only be guar-
anteed by carrying out regular inspections.
The inspection may require maintenance
to be carried out earlier, depending on the
results.
6.1 Caring for the product
▶Clean the casing with a damp cloth and
a little solvent-free soap.
▶Do not use sprays, scouring agents,
detergents, solvents or cleaning agents
that contain chlorine.
6.2 Cleaning/checking the flow
regulator
1
2
3
1. Unscrew the terminal (1) for the water
tap.
2. Regularly check the flow regulator for
the water tap at the draw-off point in
order to clean or, if required, replace
it.
3. Each time you replace the flow regu-
lator (2), also replace the seal (3).
6.3 Cleaning/checking the draw-off
point
▶Regularly descale the draw-off point
using commercially available agents in
order to remove any scale depositions.
6.4 Procuring spare parts
The original components of the product
were also certified by the manufacturer as
part of the declaration of conformity. If you
use other, non-certified or unauthorised
parts during maintenance or repair work,
this may result in the product no longer
meeting the applicable standards, thereby
voiding the conformity of the product.
We strongly recommend that you use ori-
ginal spare parts from the manufacturer as
this guarantees fault-free and safe opera-
tion of the product. To receive information
about the available original spare parts,
contact the contact address provided on
the back page of these instructions.

0020323584_00 Operating instructions 9
▶If you require spare parts for mainten-
ance or repair work, use only the spare
parts that are permitted for the product.
6.5 Checking the product
▶Check during maintenance:
–Abnormalities on the product.
–The cleanliness of the water filter in the
cold water connector.
–The leak-tightness of the supply lines.
The electrical installation of the product
must only be checked by a qualified elec-
trician.
If the cold-water filter is dirty or damaged,
it must be cleaned and serviced by a com-
petent person.
7 Decommissioning
▶Disconnect the instantaneous water
heater from the power supply.
▶To have the product permanently de-
commissioned, contact your competent
person.
8 Recycling and disposal
▶The competent person who installed
your product is responsible for the dis-
posal of the packaging.
If the product is labelled with this
mark:
▶In this case, do not dispose of the
product with the household waste.
▶Instead, hand in the product to a collec-
tion centre for waste electrical or elec-
tronic equipment.
If the product contains batteries that
are labelled with this mark, these batteries
may contain substances that are hazard-
ous to human health and the environment.
▶In this case, dispose of the batteries at
a collection point for batteries.
Validity: Croatia
You can find information about the law re-
garding sustainable waste management
and the Waste Electrical and Electronic
Equipment (WEEE) Regulations on Vail-
lant's website at www.vaillant.hr.

10 Operating instructions 0020323584_00
Appendix
A Eliminating faults
Fault Possible cause Troubleshooting
Despite the water
tap at the draw-
off point being
fully opened, the
product does not
start.
The power supply to the
product has been inter-
rupted.
Check the circuit breaker (fuse) and, if required,
switch it on.
The flow regulator in the
water tap at the draw-off
point is calcified or dirty.
Clean and/or descale the flow regulator or, if
required, replace it.
The water inlet is interrup-
ted.
Purge the product and the cold water supply
pipe.

0020323584_00 Installation and maintenance instructions 11
Installation and
maintenance instructions
Contents
1 Safety .......................................... 12
1.1 Action-related warnings ............... 12
1.2 Intended use ................................ 12
1.3 General safety information........... 13
1.4 Electrical specifications................ 15
1.5 Regulations (directives, laws,
standards).................................... 15
2 Notes on the documentation .... 16
2.1 Observing other applicable
documents ................................... 16
2.2 Storing documents....................... 16
2.3 Validity of the instructions ............ 16
3 Product description................... 16
3.1 Product design............................. 16
3.2 Information on the data plate ....... 16
3.3 CE marking .................................. 17
4 Set-up.......................................... 17
4.1 Checking the scope of delivery .... 17
4.2 Minimum clearances.................... 17
4.3 Product dimensions ..................... 17
4.4 Requirements for the
installation site ............................. 18
4.5 Wall-mounting the product........... 18
4.6 Removing the frame from the
product......................................... 18
4.7 Installing the frame ...................... 18
4.8 Installing the product.................... 19
5 Installation.................................. 19
5.1 Carrying out basic preparation
for the installation......................... 20
5.2 Installing the domestic hot and
cold water connection.................. 20
5.3 Connecting the product to the
electricity supply .......................... 21
6 Start-up ....................................... 21
6.1 Removing air pockets .................. 21
6.2 Checking function and leak-
tightness ...................................... 22
7 Handing the product over to
the end user ............................... 22
8 Troubleshooting ........................ 22
9 Inspection and maintenance .... 23
9.1 Procuring spare parts .................. 23
9.2 Preparing for maintenance .......... 23
9.3 Checking the product................... 23
9.4 Carrying out maintenance
work ............................................. 24
9.5 Completing inspection and
maintenance work........................ 24
10 Draining the product ................. 24
11 Decommissioning...................... 24
12 Recycling and disposal............. 25
Appendix ............................................... 26
A Troubleshooting ........................ 26
B Wiring diagram........................... 26
C Inspection and maintenance
work –Overview......................... 26
D Increasing the water
temperature ................................ 27
E Heating coil and specific
conductivity................................ 27
F Technical data............................ 28

12 Installation and maintenance instructions 0020323584_00
1 Safety
1.1 Action-related warnings
Classification of action-re-
lated warnings
The action-related warnings
are classified in accordance
with the severity of the pos-
sible danger using the follow-
ing warning symbols and signal
words:
Warning symbols and signal
words
Danger!
Imminent danger to life
or risk of severe personal
injury
Danger!
Risk of death from electric
shock
Warning.
Risk of minor personal
injury
Caution.
Risk of material or envir-
onmental damage
1.2 Intended use
There is a risk of injury or death
to the user or others, or of dam-
age to the product and other
property in the event of im-
proper use or use for which it
is not intended.
The products are designed
to heat up water at an indi-
vidual draw-off point, partic-
ularly at hand wash basins.
These products are not de-
signed for supplying a shower.
The products can be used in
open or closed systems.
–observance of accompanying
operating, installation and
maintenance instructions for
the product and any other
system components
–installing and setting up the
product in accordance with
the product and system ap-
proval
–compliance with all inspection
and maintenance conditions
listed in the instructions.
Intended use also covers in-
stallation in accordance with the
IP code.
Any other use that is not spe-
cified in these instructions, or
use beyond that specified in this
document, shall be considered
improper use. Any direct com-
mercial or industrial use is also
deemed to be improper.
Caution.
Improper use of any kind is
prohibited.

0020323584_00 Installation and maintenance instructions 13
1.3 General safety
information
1.3.1 Risk
caused by inadequate
qualifications
The following work must only
be carried out by competent
persons who are sufficiently
qualified to do so:
–Set-up
–Dismantling
–Installation
–Start-up
–Inspection and maintenance
–Repair
–Decommissioning
▶Proceed in accordance with
current technology.
Validity: Hong Kong OR Hong
Kong
In these instructions, the re-
gistered gas installer is referred
to throughout as "competent
person".
In these instructions, the re-
gistered electrical worker is re-
ferred to throughout as "quali-
fied electrician".
1.3.2 Risk of death due to lack
of safety devices
The basic diagrams included
in this document do not show
all safety devices required for
correct installation.
▶Install the necessary safety
devices in the installation.
▶Observe the applicable na-
tional and international laws,
standards and directives.
1.3.3 Risk of death from
electric shock
There is a risk of death from
electric shock if you touch live
components.
Before commencing work on
the product:
▶Unplug the mains plug.
▶Or disconnect the product
from the power supply by
switching off all power sup-
plies (electrical partition with a
contact gap of at least 3 mm,
e.g. fuse or circuit breaker).
▶Secure against being
switched back on again.
▶Check that there is no
voltage.
1.3.4 Risk of death from
electric shock from live
lines and connections
The water that is used must
demonstrate a specific resist-
ance ≥1100 Ω•cm at 15 °C.
Otherwise, the product must not
be used.
▶Before installing the unit, ask
your water company to inform
you about the water resist-
ance and conductivity.

14 Installation and maintenance instructions 0020323584_00
1.3.5 Risk of death caused by
improper repair work
▶If the power supply cable is
damaged, never replace this
yourself.
▶Contact the manufacturer,
customer service or a simil-
arly qualified person.
1.3.6 Risk of a deadly electric
shock if you interfere
with an electric
component that is
connected to the low-
voltage network
▶Disconnect the product from
the power supply.
▶Secure the product against
being switched back on
again.
▶Check that the product is
voltage-free.
▶Completely disconnect the
unit from the voltage supply
before you open it.
1.3.7 Risk of deadly electric
shock if faults or leaks
occur
▶Earth the product.
▶If a fault occurs, use the par-
tition that is installed on-site
(e.g. fuses or power switches)
to disconnect the product
from the power supply.
▶In the event of a leak at the
unit, close the cold water sup-
ply immediately.
1.3.8 Risk of burns or
scalding caused by hot
components
▶Only carry out work on these
components once they have
cooled down.
1.3.9 Risk of material damage
caused by using an
unsuitable tool
▶Use the correct tool.
1.3.10 Risk of material damage
caused by the product
being under pressure
▶Take the max. permissible
(→Page 29) water connection
pressure into consideration.
1.3.11 Risk of material damage
caused by frost
▶Do not install the product in
rooms prone to frost.
1.3.12 Risk of material damage
if the electrical
specifications
are not observed for
the following products:
VED H 4/3 and VED H 6/3
If the electrical specifications
are not observed, there is a risk
of damage for the product and a
risk of fire.
▶Permanently connect the
product's hard-wired power
supply cable to the house
installation.

0020323584_00 Installation and maintenance instructions 15
▶Do not connect the product
via the plug.
1.3.13 Qualification
Only qualified electricians may
carry out the electrical installa-
tion.
1.4 Electrical specifications
▶Ensure that the nominal
mains voltage complies with
the specifications on the data
plate.
▶Ensure that the cable for the
house installation is connec-
ted to an electrical partition
with a contact gap of at least
3 mm (e.g. fuse or power
switch).
▶Use a line with suitable di-
mensions to connect the
product to the protective con-
ductor.
▶Install line protection.
1.5 Regulations (directives,
laws, standards)
▶Observe the national regula-
tions, standards, directives,
ordinances and laws.

16 Installation and maintenance instructions 0020323584_00
2 Notes on the
documentation
2.1 Observing other applicable
documents
▶Always observe all the operating and
installation instructions included with the
system components.
2.2 Storing documents
▶Pass these instructions and all other
applicable documents on to the end
user.
2.3 Validity of the instructions
These instructions apply only to:
Product –Article numbers
VED H 3/3 0010044420
VED H 4/3 0010044421
VED H 6/3 0010044422
3 Product description
3.1 Product design
4
5
2
3
7
89
4
10 6
1
1 Front cover
2 Cold water con-
nection
3 Domestic hot
water connection
4 Fixing screws for
the front panel
5 Single-pole
safety pres-
sure limiter:
VED H 4/3,
VED H 6/3
6 2-pole safety
pressure limiter:
VED H 3/3
7 Power supply
cable
8 Input Ifor
the power
supply cable:
VED H 3/3,
VED H 4/3
9 Input II for
the power
supply cable:
VED H 3/3,
VED H 4/3,
VED H 6/3
10 Differential pres-
sure switch
3.2 Information on the data plate
The data plate is located on the left-hand
side section of the front casing.
Information on the
data plate
Meaning
Serial-No. Serial number
miniVED Type designation
x = 3, (4, 6) Product variant
/3 Product generation
3,53 kW (4,4 kW, 5,7
kW)
Rated power
1/N/PE
230V ~ 50/60 Hz
Electrical connection
data
IP25 IP rating
1 MPa (10bar) Rated excess pres-
sure
ρ15>1100 Ω•cm Min. specific resist-
ance of the water
max. 35 °C Max. permissible inlet
temperature
VDE/GS mark
VDE/EMC mark
Do not dispose of
the product in the
household waste.
Read all of the in-
structions.
Barcode with serial
number,
The 7th to 16th digits
of the serial number
form the article num-
ber

0020323584_00 Installation and maintenance instructions 17
3.3 CE marking
The CE marking shows that the products
comply with the basic requirements of the
applicable directives as stated on the de-
claration of conformity.
The declaration of conformity can be
viewed at the manufacturer's site.
4 Set-up
Caution.
Risk of material damage
caused by inadequate fasten-
ing
If the product is inadequately
secured to the wall, the product
or connected products may be
damaged.
▶Secure the product's frame
using the screws and wall
plugs supplied.
▶Secure the product to the
frame.
▶Only operate the product if it
has been installed correctly
with the frame.
4.1 Checking the scope of delivery
1. Remove the product from its box.
2. If required, remove the protective film
from all of the product's components.
3. Check that the scope of delivery is
complete and intact.
4.1.1 Scope of delivery
Number Designation
1Electric instantaneous water
heater
1 Enclosed documentation
Number Designation
1
Enclosed accessories
–Filter (at the product's cold
water connection)
–Flow regulator
–3/8 flexible connection pipe
–3/8 T connecting element
–Seals
–Wall plug
–Screws
4.2 Minimum clearances
≥50
≥70
≥50
≥70
4.3 Product dimensions
30 20
120 79
191
143
165
95
5
28

18 Installation and maintenance instructions 0020323584_00
4.4 Requirements for the
installation site
▶Select the installation site so that the
pipes can be easily routed (water sup-
ply and drain).
▶Do not install the product close to stair-
ways or emergency exits.
▶Install the product in a frost-free room.
▶Install the product as close as possible
to the draw-off point.
Note
It is not necessary to install an
expansion relief valve.
▶Only install the product with the water
connections upwards below the sink.
▶Ensure that the fixing screws for the
front casing can also be accessed after
the installation.
4.5 Wall-mounting the product
1. Check the load-bearing capacity of
the wall.
2. Note the total weight of the product.
3. Only use fixing material that is permit-
ted for the wall.
4. If required, ensure that mounting ap-
paratus on-site has sufficient load-
bearing capacity.
5. Wall-mount the product as described.
4.6 Removing the frame from the
product
X2
1 2
3
1. Loosen the two fixing screws by two
rotations.
2. Use a flat-blade screwdriver to lever
the frame's seal.
3. Carefully tilt the product with the heat-
ing element towards yourself until
you can remove the product from the
frame.
4.7 Installing the frame
1. Guide the power supply cable through
the grommet.

0020323584_00 Installation and maintenance instructions 19
2. Use the frame as a template for de-
termining the drill holes.
3. Make sure that the supplied wall plugs
and screws are suitable for the wall.
4. Secure the frame to the wall using
wall plugs and screws.
4.8 Installing the product
X2
A
B
C
D
1. Check the corresponding input Ior
II, which is to be used depending on
the routing of the power supply cable
(→Page 16).
2. Guide the power supply cable through
the frame's grommet.
3. Position the heating element at the
base of the frame.
4. Carefully push the heating element
and the front panel towards the frame
until the lock clicks into place.
5. Secure the front casing using the two
screws.
5 Installation
Warning.
Risk of adverse health effects
caused by impurities in the
potable water.
Sealing residues, dirt or other
residues in the pipelines may
adversely affect the quality of
the potable water.
▶Flush all of the hot and cold
water pipes thoroughly be-
fore you install the product.
Danger!
Risk of scalding and/or dam-
age due to incorrect installa-
tion leading to escaping wa-
ter.
Mechanical stresses in the con-
nection cable can cause leaks.
▶Make sure that the connec-
tion cables are free from
mechanical stress when they
are installed.

20 Installation and maintenance instructions 0020323584_00
5.1 Carrying out basic preparation
for the installation
Condition: Pressure-tight installation with high-pres-
sure water tap
▶Install the 3/8 flexible connection pipe
and the 3/8 T connecting element as
shown in the figure.
▶See the high-pressure water tap's in-
structions for the installation.
Condition: If you want to install the product in an
installation that requires a non-return valve.
▶Install non-return valve:
–Between the product and fitting
–Between the main water tap and the
fitting
Condition: Non-pressurised installation with low-
pressure water tap
▶Install the corresponding water tap for a
non-pressurised installation.
▶See the low-pressure water tap's in-
structions for the installation.
5.2 Installing the domestic hot and
cold water connection
1
2
3
3
4
1. Connect the cold water pipe with
seal (3) and the water filter (2) to the
product's cold water connection (1).
2. Connect the domestic hot water pipe
for the draw-off point's hot water tap
with seal (3) to the product's domestic
hot water connection (4).
