0020241666_01 Safety instructions 1
Safety instructions
Contents
1 Safety.................................................................... 2
1.1 Action-related warnings ......................................... 2
1.2 Intended use.......................................................... 2
1.3 General safety information .................................... 2
1.4 Regulations (directives, laws, standards) .............. 3
2 Notes on the documentation .............................. 4
2.1 Observing other applicable documents ................. 4
2.2 Storing documents................................................. 4
2.3 Validity of the instructions...................................... 4
3 Product description............................................. 4
3.1 Design of the product............................................. 4
3.2 Identification plate.................................................. 5
3.3 CE label ................................................................. 5
4 Setting the target cylinder temperature ............ 5
5 Handing over to the operator ............................. 5
6 Troubleshooting .................................................. 6
6.1 Detecting and rectifying faults ............................... 6
6.2 Procuring spare parts ............................................ 6
7 Decommissioning................................................ 6
8 Recycling and disposal....................................... 6
9 Customer service................................................. 6
Appendix .............................................................................. 7
A Detecting and rectifying faults ........................... 7
B Inspection and maintenance work –
Overview............................................................... 7
C Technical data...................................................... 8

1 Safety
2Safety instructions 0020241666_01
1 Safety
1.1 Action-related warnings
Classification of action-related warnings
The action-related warnings are classified in
accordance with the severity of the possible
danger using the following warning signs and
signal words:
Warning symbols and signal words
Danger!
Imminent danger to life or risk of
severe personal injury
Danger!
Risk of death from electric shock
Warning.
Risk of minor personal injury
Caution.
Risk of material or environmental
damage
1.2 Intended use
There is a risk of injury or death to the user or
others, or of damage to the product and other
property in the event of improper use or use
for which it is not intended.
The domestic hot water cylinder is designed
to keep drinking water that is heated to a
maximum 85 °C ready for use in households
and businesses. The product is designed to
be integrated into a central heating installa-
tion. It is designed to be combined with heat
generators whose power lies within the limits
specified in the technical data. To control the
domestic hot water generation, weather com-
pensators and control systems from suitable
heat generators can be used. These are heat
generators that provide cylinder charging and
can be connected to a temperature sensor.
Intended use includes the following:
–observance of accompanying operating,
installation and servicing instructions for
the product and any other system compon-
ents
–installing and fitting the product in accord-
ance with the product and system approval
–compliance with all inspection and main-
tenance conditions listed in the instruc-
tions.
Intended use also covers installation in ac-
cordance with the IP class.
Any other use that is not specified in these
instructions, or use beyond that specified in
this document shall be considered improper
use. Any direct commercial or industrial use
is also deemed to be improper.
Caution.
Improper use of any kind is prohibited.
1.3 General safety information
1.3.1 Risk caused by inadequate
qualifications
Applicability: Not for Russia
The following work must only be carried out
by competent persons who are sufficiently
qualifiedtodoso:
Applicability: Russia
The following work must only be carried out
by Vaillant-certified competent persons who
are sufficiently qualified to do so:
–Set-up
–Disassembly
–Installation
–Start-up
–Maintenance
–Repair
–Decommissioning
▶Observe all instructions that are included
with the product.
▶Proceed in accordance with the current
state of technology.
▶Observe all applicable directives, stand-
ards, laws and other regulations.
1.3.2 Risk of death from electric shock
There is a risk of death from electric shock if
you touch live components.
Before commencing work on the product:
▶Unplug the mains plug.
▶Or disconnect the product from the power
supply by switching off all power supplies
(electrical partition with a contact opening
of at least 3 mm, e.g. fuse or line protec-
tion switch).

Safety 1
0020241666_01 Safety instructions 3
▶Secure against being switched back on
again.
▶Wait for at least 3 minutes until the con-
densers have discharged.
1.3.3 Risk of death due to lack of safety
devices
The schematic drawings included in this doc-
ument do not show all safety devices re-
quired for correct installation.
▶Install the necessary safety devices in the
system.
▶Observe the applicable national and inter-
national laws, standards and guidelines.
1.3.4 Risk of being burned or scalded by
hot components
▶Only carry out work on these components
once they have cooled down.
1.3.5 Risk of injury due to the heavy
weight of the product
▶Make sure that the product is transported
by at least two people.
1.3.6 Risk of material damage caused by
using an unsuitable tool
▶Use the correct tool to tighten or loosen
screw connections.
1.4 Regulations (directives, laws,
standards)
▶Observe the national regulations, stand-
ards, guidelines and laws.

2 Notes on the documentation
4Safety instructions 0020241666_01
2 Notes on the documentation
2.1 Observing other applicable documents
▶You must observe all the operating and installation in-
structions included with the system components.
2.2 Storing documents
▶Pass these instructions and all other applicable docu-
ments on to the system operator.
2.3 Validity of the instructions
These instructions apply only to:
Product article number
VIH R 300/3 BR 0010020639
VIH R 400/3 BR 0010020640
VIH R 500/3 BR 0010020641
VIH R 300/3 MR 0010020661
VIH R 400/3 MR 0010020662
VIH R 500/3 MR 0010020663
VIH RW 300/3 BR 0010020645
VIH RW 400/3 BR 0010020646
VIH RW 500/3 BR 0010020647
VIH RW 300/3 MR 0010020667
VIH RW 400/3 MR 0010020668
VIH RW 500/3 MR 0010020669
VIH S 300/3 BR 0010020642
VIH S 400/3 BR 0010020643
VIH S 500/3 BR 0010020644
VIH S 300/3 MR 0010020664
VIH S 400/3 MR 0010020665
VIH S 500/3 MR 0010020666
VIH SW 400/3 BR 0010020648
VIH SW 500/3 BR 0010020649
VIH SW 400/3 MR 0010020670
VIH SW 500/3 MR 0010020671
3 Product description
3.1 Design of the product
2
1
3
1 Casing top
2 Display element
3 Cleaning eye
The product is a domestic hot water cylinder. The domestic
hot water cylinder is equipped with external heat insulation.
The vessel for the domestic hot water cylinder is made of
enamelled steel. The pipe spirals that transfer the heat are
located inside the vessel. As additional corrosion protection,
the vessel has a protection anode.
A circulation pump can be used as an option to increase
the hot water comfort, particularly at more distant draw-off
points.

Setting the target cylinder temperature 4
0020241666_01 Safety instructions 5
3.2 Identification plate
Information on the identific-
ation plate
Meaning
Serial no., Cер.№Serial number
VIH Vaillant type designation,
indirectly heated high-pressure
cylinder
R Round
S Solar heating coil
W Heat pump heating coil
300, 400, 500 Volumetric capacity (litres)
/3 Unit generation
B, M, H Insulation:
–B=Basic
–M = Medium
–H=High
R Cleaning eye
ACI Display for magnesium protec-
tion anode
EN 12897:2016,
EH 12897:2016
Standard applied
Cylinder
Top heating coil
Bottom heating coil
ww/jjjj Production period: Week/year
V[l], V[л] Nominal volume
PS[bar], PS[бар] Maximum operating pressure
Tmax[°C], Tмакс[°C] Maximum operating temperat-
ure
A[m
2], A [м2]Heat transfer surface
Pt [bar], Pt [бар]Testpressure
P₁,P₂Continuous output
V₁,V₂Nominal circulation volume
flow
Heat loss, Потери тепла,
Втрати тепла
Downtime loss
Heater connection,
Подключение отопителя,
Підключення отопітеля
Recommended dimensions of
the pipelines to connect the
boiler
Read the instructions.
Serial-No.
Bar code with serial number,
The 7th to 16th digits of the
serial number form the article
number
3.3 CE label
The CE label shows that the products comply with the basic
requirements of the applicable directives as stated on the
identification plate.
The declaration of conformity can be viewed at the manufac-
turer's site.
4 Setting the target cylinder
temperature
Danger!
Risk of death from Legionella.
Legionella multiply at temperatures below
60 °C.
▶Ensure that the operator is familiar with all
of the Anti-legionella measures in order
to comply with the applicable regulations
regarding legionella prevention.
1. Set the target cylinder temperature.
–Water temperature: ≥60 ℃
2. Check the water hardness.
Water temperature: > 3.57 mol/m³
▶Soften the water.
3. Check the conductivity.
Conductivity: > 1,250 µS/cm
▶Take measures to protect against corrosion.
4. Take protective measures against legionella.
5 Handing over to the operator
1. Teach the end user how to handle the installation. An-
swer any questions the operator may have. In particu-
lar, draw attention to the safety information which the
operator must follow.
2. Explain to the operator how the safety devices work and
where they are located.
3. Inform the end user that they must have the product
maintained in accordance with the specified intervals.
4. Provide the operator with all relevant instructions and
unit documentation for safe-keeping.
5. Inform the end user about the ways to limit the domestic
hot water outlet temperature so that scalding can be
prevented.
6. Inform the end user about the legionella protection
measures that have been taken.

6 Troubleshooting
6Safety instructions 0020241666_01
6 Troubleshooting
6.1 Detecting and rectifying faults
▶If problems occur whilst operating the product, check
certain points with the aid of the table in the appendix.
Detecting and rectifying faults (→Page 7)
6.2 Procuring spare parts
The original components of the product were also certified
by the manufacturer as part of the declaration of conformity.
If you use other, non-certified or unauthorised parts during
maintenance or repair work, this may void the conformity of
the product and it will therefore no longer comply with the
applicable standards.
We strongly recommend that you use original spare parts
from the manufacturer as this guarantees fault-free and safe
operation of the product. To receive information about the
available original spare parts, contact the contact address
provided on the reverse of these instructions.
▶If you require spare parts for maintenance or repair
work, use only the spare parts that are permitted for the
product.
7 Decommissioning
1. Disconnect the power supply, if required.
2. Close all of the isolators fitted on-site.
3. Drain the cylinder (→installation instructions).
4. Disconnect the connection cables.
5. Remove the cylinder and correctly dispose of the indi-
vidual components (→installation instructions).
8 Recycling and disposal
Disposing of the packaging
▶Dispose of the packaging correctly.
▶Observe all relevant regulations.
9 Customer service
The contact details for our customer service are provided in
the appendix or on our website.

Appendix
0020241666_01 Safety instructions 7
Appendix
A Detecting and rectifying faults
Fault Possible cause Remedy
No flow rate at the water
tap
1. The water supply valve is closed.
2. The main filter is blocked.
3. The pressure reducer is not installed correctly.
1. Check and open the water supply valve.
2. Close the water supply valve, clean the filter
and the water pressure reducer.
3. Check whether the pressure reducer has been
installed correctly.
Low flow rate and pres-
sure at a water tap
1. The filter in the cold water supply is clogged. 1. Close the cold water supply, clean the filter for
the water pressure reducer.
Waterfromthewatertap
is cold
1. The cylinder was not started up.
2. The water supply valve is not fully open.
3. The heat generator is not operating.
4. The thermal cut-out was triggered.
5. The 2-port motorised valve is defective.
6. The immersion heater is defective.
1. Open all of the relevant valves.
2. Check the thermostat or the room thermostat
and, if required, set this.
3. Check the heat generator to see if a fault code
is present.
4. Check and initialise the cylinder.
5. Check the connections for the 2-port motorised
valve.
Hot water temperature at
the water tap too high
1. The thermostat is set too high.
2. The thermostatic valve is not present or is
defective.
1. Check the temperature. It must be between 60
and 65 °C.
2. Install a mixer valve.
3. Check the cabling. Repair the cable.
4. Reduce the temperature of the thermostat to
60 °C.
5. Replace the thermostatic valve.
Irregular domestic hot
water output at the water
tap
1. The expansion vessel is defective.
2. The thermal cut-out has been triggered
(thermal control).
1. Compare the temperature between the con-
trols. The maximum temperature has priority.
2. Set the expansion vessel.
3. Interrupt the power supply to the product and
the heat generator. Check the thermal cut-outs
and replace these in the event of a defect.
VIH .. .../3 MR only
The control panel does
not display any func-
tions.
1. The power supply is interrupted. 1. Reconnect the power supply.
2. Check the plug connection.
VIH .. .../3 MR only
F.01/F.02
1. Interruption in the cable for the top (F.01)or
bottom (F.02) cylinder temperature sensor
2. Top (F.01) or bottom (F.02) cylinder temperat-
ure sensor is defective.
1. Check the cable for the cylinder temperature
sensor.
2. Replace the cable harness.
VIH .. .../3 MR only
F.03
1. The external current anode is defective.
2. The cylinder is corroded.
1. Check the electrical connections.
2. Replace the external current anode.
3. Replace the cylinder.
B Inspection and maintenance work –Overview
The table below lists the manufacturer requirements with respect to minimum inspection and maintenance intervals. If na-
tional regulations and directives require shorter inspection and maintenance intervals, you should observe these instead of
the intervals listed.
# Maintenance work Interval
1 Check the connections for tightness (visual inspection). Annually
2 Check the temperature and pressure expansion relief valve (by actuating
it).
Annually
3 Check the pressure in the expansion vessel (annual manometer). Annually
4 Check the tightness of the flange in the cleaning eye (visual inspection) Annually
5 Check the state of wear of the magnesium protection anode Annually
6 Clean the cylinder Annually
7 Check the contacts of the external current anode for corrosion Annually

Appendix
8Safety instructions 0020241666_01
C Technical data
Technical data –VIH R/RW general
VIH R 300/3
BR
VIH R 400/3
BR
VIH R 500/3
BR
VIH R 300/3
MR
VIH R 400/3
MR
VIH R 500/3
MR
Nominal capacity 294 l 398 l 490 l 294 l 398 l 490 l
Domestic hot water capacity
of the heating coil for the
heating circuit
9.9 l 10.9 l 15.2 l 9.9 l 10.9 l 15.2 l
Maximum pressure of the
heating coil during operation
1MPa 1MPa 1MPa 1MPa 1MPa 1MPa
Operating pressure 1MPa 1MPa 1MPa 1MPa 1MPa 1MPa
Maximum temperature of the
heating circuit
110 ℃110 ℃110 ℃110 ℃110 ℃110 ℃
Maximum hot water temper-
ature
85 ℃85 ℃85 ℃85 ℃85 ℃85 ℃
Energy efficiency class B B B A A A
Standby energy consumption
per 24 hrs
1.40 kWh 1.52 kWh 1.78 kWh 1.16 kWh 1.22 kWh 1.31 kWh
Heating coil pressure loss
(heating circuit)
0.0058 MPa 0.0066 MPa 0.00162 MPa 0.0058 MPa 0.0066 MPa 0.00162 MPa
Heating coil surface (heating
circuit)
1.5 m²1.7 m²2.3 m²1.5 m²1.7 m²2.3 m²
Volume of domestic hot wa-
ter at 40 C (V₄₀) (heating cir-
cuit)
473 l 578 l 742 l 473 l 578 l 742 l
Net weight 103 kg 136 kg 170 kg 115 kg 149 kg 186 kg
Weight filled ready for opera-
tion
397 kg 535 kg 661 kg 409 kg 548 kg 677 kg
VIH RW 300/3
BR
VIH RW 400/3
BR
VIH RW 500/3
BR
VIH RW 300/3
MR
VIH RW 400/3
MR
VIH RW 500/3
MR
Nominal capacity 281 l 375 l 460 l 281 l 375 l 460 l
Domestic hot water capacity
of the heating coil for the
heating circuit
20.4 l 28.9 l 38.6 l 20.4 l 28.9 l 38.6 l
Maximum pressure of the
heating coil during operation
1MPa 1MPa 1MPa 1MPa 1MPa 1MPa
Operating pressure 1MPa 1MPa 1MPa 1MPa 1MPa 1MPa
Maximum temperature of the
heating circuit
110 ℃110 ℃110 ℃110 ℃110 ℃110 ℃
Maximum hot water temper-
ature
85 ℃85 ℃85 ℃85 ℃85 ℃85 ℃
Energy efficiency class B B B A A A
Standby energy consumption
per 24 hrs
1.40 kWh 1.54 kWh 1.84 kWh 1.05 kWh 1.16 kWh 1.04 kWh
Heating coil pressure loss
(heating circuit)
0.00106 MPa 0.0056 MPa 0.00117 MPa 0.00106 MPa 0.0056 MPa 0.00117 MPa
Heating coil surface (heating
circuit)
3.1 m²4.4 m²5.9 m²3.1 m²4.4 m²5.9 m²
Volume of domestic hot wa-
ter at 40 C (V₄₀) (heating cir-
cuit)
423 l 577 l 710 l 423 l 577 l 710 l
Net weight 141 kg 181 kg 235 kg 153 kg 195 kg 251 kg
Weight filled ready for opera-
tion
422 kg 556 kg 694 kg 434 kg 570 kg 710 kg

Appendix
0020241666_01 Safety instructions 9
Technical data –VIH S/SW general
VIH S 300/3
BR
VIH S 400/3
BR
VIH S 500/3
BR
VIH S 300/3
MR
VIH S 400/3
MR
VIH S 500/3
MR
Nominal capacity 287 l 392 l 481 l 287 l 392 l 481 l
Domestic hot water capacity
of the heating coil for the
heating circuit
5.4 l 8.5 l 8.5 l 5.4 l 8.5 l 8.5 l
Heat transfer fluid capacity
of the heating coil for the
solar circuit/environment
circuit
9.9 l 8.7 l 15.2 l 9.9 l 8.7 l 15.2 l
Maximum pressure of the
heating coil during operation
1MPa 1MPa 1MPa 1MPa 1MPa 1MPa
Operating pressure 1MPa 1MPa 1MPa 1MPa 1MPa 1MPa
Maximum temperature of the
heating circuit
110 ℃110 ℃110 ℃110 ℃110 ℃110 ℃
Maximum hot water temper-
ature
85 ℃85 ℃85 ℃85 ℃85 ℃85 ℃
Energy efficiency class BBBAAA
Standby energy consumption
per 24 hrs
1.40 kWh 1.53 kWh 1.79 kWh 1.11 kWh 1.22 kWh 1.38 kWh
Heating coil pressure loss
(heating circuit)
0.0017 MPa 0.0022 MPa 0.0024 MPa 0.0017 MPa 0.0022 MPa 0.0024 MPa
Heating coil surface (heating
circuit)
0.8 m²1.0 m²1.0 m²0.8 m²1.0 m²1.0 m²
Volume of domestic hot wa-
ter at 40 C (V₄₀) (heating cir-
cuit)
174 l 287 l 290 l 174 l 287 l 290 l
Heating coil pressure loss
(solar circuit/environment
circuit)
0.0058 MPa 0.0066 MPa 0.00183 MPa 0.0058 MPa 0.0066 MPa 0.00183 MPa
Heating coil surface (solar
circuit)
1.5 m²1.3 m²2.3 m²1.5 m²1.3 m²2.3 m²
Volume of domestic hot wa-
ter at 40 C (V₄₀) (solar circuit)
468 l 617 l 756 l 468 l 617 l 756 l
Net weight 121 kg 147 kg 184 kg 132 kg 160 kg 201 kg
Weight filled ready for opera-
tion
409 kg 540 kg 666 kg 420 kg 553 kg 683 kg
VIH SW 400/3
BR
VIH SW 500/3
BR
VIH SW 400/3
MR
VIH SW 500/3
MR
Nominal capacity 372 l 456 l 372 l 456 l
Domestic hot water capacity
of the heating coil for the
heating circuit
21.2 l 28.9 l 21.2 l 28.9 l
Heat transfer fluid capacity
of the heating coil for the
solar circuit/environment
circuit
9.6 l 13.5 l 9.6 l 13.5 l
Maximum pressure of the
heating coil during operation
1MPa 1MPa 1MPa 1MPa
Operating pressure 1MPa 1MPa 1MPa 1MPa
Maximum temperature of the
heating circuit
110 ℃110 ℃110 ℃110 ℃
Maximum hot water temper-
ature
85 ℃85 ℃85 ℃85 ℃
Energy efficiency class B B A A
Standby energy consumption
per 24 hrs
1.58 kWh 1.85 kWh 1.23 kWh 1.38 kWh
Heating coil pressure loss
(heating circuit)
0.0026 MPa 0.0057 MPa 0.0026 MPa 0.0057 MPa

Appendix
10 Safety instructions 0020241666_01
VIH SW 400/3
BR
VIH SW 500/3
BR
VIH SW 400/3
MR
VIH SW 500/3
MR
Heating coil surface (heating
circuit)
3.2 m²4.4 m²3.2 m²4.4 m²
Volume of domestic hot wa-
ter at 40 C (V₄₀) (heating cir-
cuit)
386 l 471 l 386 l 471 l
Heating coil pressure loss
(solar circuit/environment
circuit)
0.0021 MPa 0.0027 MPa 0.0021 MPa 0.0027 MPa
Heating coil surface (solar
circuit)
1.5 m²2.1 m²1.5 m²2.1 m²
Volume of domestic hot wa-
ter at 40 C (V₄₀) (solar circuit)
606 l 771 l 606 l 771 l
Net weight 189 kg 249 kg 203 kg 265 kg
Weight filled ready for opera-
tion
561 kg 703 kg 575 kg 719 kg
Technical data –Electrics
VIH R 300/3
MR
VIH R 400/3
MR
VIH R 500/3
MR
VIH RW 300/3
MR
VIH RW 400/3
MR
VIH RW 500/3
MR
Electrical connection for the
power supply unit
230 V, 50 Hz 230 V, 50 Hz 230 V, 50 Hz 230 V, 50 Hz 230 V, 50 Hz 230 V, 50 Hz
IP rating XX XX XX XX XX XX
VIH S 300/3
MR
VIH S 400/3
MR
VIH S 500/3
MR
VIH SW 400/3
MR
VIH SW 500/3
MR
Electrical connection for the
power supply unit
230 V, 50 Hz 230 V, 50 Hz 230 V, 50 Hz 230 V, 50 Hz 230 V, 50 Hz
IP rating XX XX XX XX XX
Technical data –Material
VIH R 300/3
BR
VIH R 400/3
BR
VIH R 500/3
BR
VIH R 300/3
MR
VIH R 400/3
MR
VIH R 500/3
MR
Cylinder material Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Corrosion protection Enamel with
magnesium
protection an-
ode
Enamel with
magnesium
protection an-
ode
Enamel with
magnesium
protection an-
ode
Enamel with
external cur-
rent protection
anode
Enamel with
external cur-
rent protection
anode
Enamel with
external cur-
rent protection
anode
Insulation material Polyurethane Polyurethane Polyurethane Polyureth-
ane + vacuum
panel
Polyureth-
ane + vacuum
panel
Polyurethane
+ vacuum
panel
Insulation thickness 75 mm 70 mm 70 mm 95 mm 100 mm 100 mm
Propellant for insulating ma-
terial
HFO-
1233zd(E)
HFO-
1233zd(E)
HFO-
1233zd(E)
1233zd(E) 1233zd(E) 1233zd(E)
Ozone depletion potential
ODP
WP 1 WP 1 WP 1 WP 1 WP 1 WP 1
VIH RW 300/3
BR
VIH RW 400/3
BR
VIH RW 500/3
BR
VIH RW 300/3
MR
VIH RW 400/3
MR
VIH RW 500/3
MR
Cylinder material Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Corrosion protection Enamel with
magnesium
protection an-
ode
Enamel with
magnesium
protection an-
ode
Enamel with
magnesium
protection an-
ode
Enamel with
external cur-
rent protection
anode
Enamel with
external cur-
rent protection
anode
Enamel with
external cur-
rent protection
anode
Insulation material Polyurethane Polyurethane Polyurethane Polyureth-
ane + vacuum
panel
Polyureth-
ane + vacuum
panel
Polyurethane
+ vacuum
panel
Insulation thickness 75 mm 70 mm 70 mm 95 mm 100 mm 100 mm

Appendix
0020241666_01 Safety instructions 11
VIH RW 300/3
BR
VIH RW 400/3
BR
VIH RW 500/3
BR
VIH RW 300/3
MR
VIH RW 400/3
MR
VIH RW 500/3
MR
Propellant for insulating ma-
terial
HFO-
1233zd(E)
HFO-
1233zd(E)
HFO-
1233zd(E)
1233zd(E) 1233zd(E) 1233zd(E)
Ozone depletion potential
ODP
WP 1 WP 1 WP 1 WP 1 WP 1 WP 1
VIH S 300/3
BR
VIH S 400/3
BR
VIH S 500/3
BR
VIH S 300/3
MR
VIH S 400/3
MR
VIH S 500/3
MR
Cylinder material Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Corrosion protection Enamel with
magnesium
protection an-
ode
Enamel with
magnesium
protection an-
ode
Enamel with
magnesium
protection an-
ode
Enamel with
external cur-
rent protection
anode
Enamel with
external cur-
rent protection
anode
Enamel with
external cur-
rent protection
anode
Insulation material Polyurethane Polyurethane Polyurethane Polyureth-
ane + vacuum
panel
Polyureth-
ane + vacuum
panel
Polyurethane
+ vacuum
panel
Insulation thickness 75 mm 70 mm 70 mm 95 mm 100 mm 100 mm
Propellant for insulating ma-
terial
HFO-
1233zd(E)
HFO-
1233zd(E)
HFO-
1233zd(E)
1233zd(E) 1233zd(E) 1233zd(E)
Ozone depletion potential
ODP
WP 1 WP 1 WP 1 WP 1 WP 1 WP 1
VIH SW 400/3
BR
VIH SW 500/3
BR
VIH SW 400/3
MR
VIH SW 500/3
MR
Cylinder material Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Corrosion protection Enamel with
magnesium
protection an-
ode
Enamel with
magnesium
protection an-
ode
Enamel with
external cur-
rent protection
anode
Enamel with
external cur-
rent protection
anode
Insulation material Polyurethane Polyurethane Polyureth-
ane + vacuum
panel
Polyurethane
+ vacuum
panel
Insulation thickness 70 mm 70 mm 100 mm 100 mm
Propellant for insulating ma-
terial
HFO-
1233zd(E)
HFO-
1233zd(E)
1233zd(E) 1233zd(E)
Ozone depletion potential
ODP
WP 1 WP 1 WP 1 WP 1
Technical data –VIH R output
VIH R 300/3
BR
VIH R 400/3
BR
VIH R 500/3
BR
VIH R 300/3
MR
VIH R 400/3
MR
VIH R 500/3
MR
Output characteristic figure
NL (50 °C)
6.7 10.1 16.4 6.7 10.1 16.4
Output characteristic figure
NL (55 °C)
7.9 12.0 18.9 7.9 12.0 18.9
Output characteristic figure
NL (60 °C)
9.0 15.0 21.0 9.0 15.0 21.0
Output characteristic figure
NL (65 °C)
11.0 15.6 22.3 11.0 15.6 22.3
Output characteristic figure
NL (70 °C)
11.6 15.7 23.4 11.6 15.7 23.4
Continuous domestic hot
water output (heating circuit)
(60°C35K)
24.8 kW 27.1 kW 38.0 kW 24.8 kW 27.1 kW 38.0 kW
Continuous domestic hot
water output (heating circuit)
(70°C35K)
33.6 kW 36.8 kW 51.5 kW 33.6 kW 36.8 kW 51.5 kW
Continuous domestic hot
water output (heating circuit)
(80°C35K)
42.1 kW 46.0 kW 64.5 kW 42.1 kW 46.0 kW 64.5 kW

Appendix
12 Safety instructions 0020241666_01
VIH R 300/3
BR
VIH R 400/3
BR
VIH R 500/3
BR
VIH R 300/3
MR
VIH R 400/3
MR
VIH R 500/3
MR
Continuous domestic hot
water output (heating circuit)
(60 °C 35 K)
611 l/h 668 l/h 936 l/h 611 l/h 668 l/h 936 l/h
Continuous domestic hot
water output (heating circuit)
(70 °C 35 K)
827 l/h 904 l/h 1,268 l/h 827 l/h 904 l/h 1,268 l/h
Continuous domestic hot
water output (heating circuit)
(80 °C 35 K)
1,035 l/h 1,130 l/h 1,586 l/h 1,035 l/h 1,130 l/h 1,586 l/h
Domestic hot water output
(50 °C)
342 l/10 min 520 l/10 min 536 l/10 min 342 l/10 min 520 l/10 min 536 l/10 min
Domestic hot water output
(55 °C)
371 l/10 min 459 l/10 min 587 l/10 min 371 l/10 min 459 l/10 min 587 l/10 min
Domestic hot water output
(60 °C)
396 l/10 min 517 l/10 min 623 l/10 min 396 l/10 min 517 l/10 min 623 l/10 min
Domestic hot water output
(65 °C)
439 l/10 min 528 l/10 min 644 l/10 min 439 l/10 min 528 l/10 min 644 l/10 min
Domestic hot water output
(70 °C)
451 l/10 min 530 l/10 min 662 l/10 min 451 l/10 min 530 l/10 min 662 l/10 min
Specific flow rate Delta
(50 °C 30 K)
39.9 l/min 49.0 l/min 62.5 l/min 39.9 l/min 49.0 l/min 62.5 l/min
Specific flow rate Delta
(55 °C 30 K)
43.3 l/min 53.6 l/min 68.5 l/min 43.3 l/min 53.6 l/min 68.5 l/min
Specific flow rate Delta
(60 °C 30 K)
46.2 l/min 60.3 l/min 72.7 l/min 46.2 l/min 60.3 l/min 72.7 l/min
Specific flow rate Delta
(65 °C 30 K)
51.2 l/min 61.6 l/min 75.1 l/min 51.2 l/min 61.6 l/min 75.1 l/min
Specific flow rate Delta
(70 °C 30 K)
52.6 l/min 61.8 l/min 77.2 l/min 52.6 l/min 61.8 l/min 77.2 l/min
Nominal heating medium
volume flow for the heating
circuit
1.81 m³/h 1.93 m³/h 2.79 m³/h 1.81 m³/h 1.93 m³/h 2.79 m³/h
Technical data –VIH RW output
VIH RW 300/3
BR
VIH RW 400/3
BR
VIH RW 500/3
BR
VIH RW 300/3
MR
VIH RW 400/3
MR
VIH RW 500/3
MR
Output characteristic figure
NL (50 °C)
3.3 5.5 8.1 3.3 5.5 8.1
Output characteristic figure
NL (55 °C)
3.6 5.9 8.7 3.6 5.9 8.7
Output characteristic figure
NL (60 °C)
3.8 6.1 8.9 3.8 6.1 8.9
Output characteristic figure
NL (65 °C)
3.8 6.1 8.9 3.8 6.1 8.9
Output characteristic figure
NL (70 °C)
3.8 6.1 8.9 3.8 6.1 8.9
Continuous domestic hot
water output (heating circuit)
(50 °C 35 K)
26.7 kW 38.3 kW 51.0 kW 26.7 kW 38.3 kW 51.0 kW
Continuous domestic hot
water output (heating circuit)
(55 °C 35 K)
35.5 kW 51.0 kW 68.0 kW 35.5 kW 51.0 kW 68.0 kW
Continuous domestic hot
water output (heating circuit)
(60 °C 35 K)
43.2 kW 62.2 kW 83.0 kW 43.2 kW 62.2 kW 83.0 kW
Continuous domestic hot
water output (heating circuit)
(50 °C 35 K)
656 l/h 941 l/h 1,255 l/h 656 l/h 941 l/h 1,255 l/h
Continuous domestic hot
water output (heating circuit)
(55 °C 35 K)
872 l/h 1,254 l/h 1,672 l/h 872 l/h 1,254 l/h 1,672 l/h

Appendix
0020241666_01 Safety instructions 13
VIH RW 300/3
BR
VIH RW 400/3
BR
VIH RW 500/3
BR
VIH RW 300/3
MR
VIH RW 400/3
MR
VIH RW 500/3
MR
Continuous domestic hot
water output (heating circuit)
(60°C35K)
1,063 l/h 1,531 l/h 2,041 l/h 1,063 l/h 1,531 l/h 2,041 l/h
Domestic hot water output
(50 °C)
302 l/10 min 403 l/10 min 494 l/10 min 302 l/10 min 403 l/10 min 494 l/10 min
Domestic hot water output
(55 °C)
340 l/10 min 453 l/10 min 494 l/10 min 340 l/10 min 453 l/10 min 494 l/10 min
Domestic hot water output
(60 °C)
377 l/10 min 504 l/10 min 618 l/10 min 377 l/10 min 504 l/10 min 618 l/10 min
Domestic hot water output
(65 °C)
415 l/10 min 554 l/10 min 679 l/10 min 415 l/10 min 554 l/10 min 679 l/10 min
Domestic hot water output
(70 °C)
453 l/10 min 604 l/10 min 741 l/10 min 453 l/10 min 604 l/10 min 741 l/10 min
Specific flow rate Delta
(50°C30K)
35.2 l/min 47.0 l/min 57.7 l/min 35.2 l/min 47.0 l/min 57.7 l/min
Specific flow rate Delta
(55°C30K)
39.6 l/min 52.9 l/min 64.9 l/min 39.6 l/min 52.9 l/min 64.9 l/min
Specific flow rate Delta
(60°C30K)
44.0 l/min 58.8 l/min 72.1 l/min 44.0 l/min 58.8 l/min 72.1 l/min
Specific flow rate Delta
(65°C30K)
48.4 l/min 64.6 l/min 79.3 l/min 48.4 l/min 64.6 l/min 79.3 l/min
Specific flow rate Delta
(70°C30K)
52.8 l/min 70.5 l/min 86.5 l/min 52.8 l/min 70.5 l/min 86.5 l/min
Nominal heating medium
volume flow for the heating
circuit
1.72 m³/h 2.58 m³/h 3.44 m³/h 1.72 m³/h 2.58 m³/h 3.44 m³/h
Technical data –VIH S output
VIH S 300/3
BR
VIH S 400/3
BR
VIH S 500/3
BR
VIH S 300/3
MR
VIH S 400/3
MR
VIH S 500/3
MR
Output characteristic figure
NL (50 °C)
1.0 1.9 1.9 1.0 1.9 1.9
Output characteristic figure
NL (55 °C)
1.1 2.2 2.2 1.1 2.2 2.2
Output characteristic figure
NL (60 °C)
1.3 2.6 2.6 1.3 2.6 2.6
Output characteristic figure
NL (65 °C)
1.4 3.0 3.1 1.4 3.0 3.1
Output characteristic figure
NL (70 °C)
1.6 3.7 3.7 1.6 3.7 3.7
Continuous domestic hot
water output (heating circuit)
(60°C35K)
13.5 kW 16.4 kW 16.4 kW 13.5 kW 16.4 kW 16.4 kW
Continuous domestic hot
water output (heating circuit)
(70°C35K)
18.3 kW 22.3 kW 22.3 kW 18.3 kW 22.3 kW 22.3 kW
Continuous domestic hot
water output (heating circuit)
(80°C35K)
22.8 kW 27.9 kW 27.9 kW 22.8 kW 27.9 kW 27.9 kW
Continuous domestic hot
water output (heating circuit)
(60°C35K)
331 l/h 404 l/h 404 l/h 331 l/h 404 l/h 404 l/h
Continuous domestic hot
water output (heating circuit)
(70°C35K)
448 l/h 549 l/h 549 l/h 448 l/h 549 l/h 549 l/h
Continuous domestic hot
water output (heating circuit)
(80°C35K)
562 l/h 686 l/h 686 l/h 562 l/h 686 l/h 686 l/h
Domestic hot water output
(50 °C)
144 l/10 min 191 l/10 min 191 l/10 min 144 l/10 min 191 l/10 min 191 l/10 min
Domestic hot water output
(55 °C)
150 l/10 min 203 l/10 min 207 l/10 min 150 l/10 min 203 l/10 min 207 l/10 min

Appendix
14 Safety instructions 0020241666_01
VIH S 300/3
BR
VIH S 400/3
BR
VIH S 500/3
BR
VIH S 300/3
MR
VIH S 400/3
MR
VIH S 500/3
MR
Domestic hot water output
(60 °C)
161 l/10 min 219 l/10 min 223 l/10 min 161 l/10 min 219 l/10 min 223 l/10 min
Domestic hot water output
(65 °C)
166 l/10 min 234 l/10 min 237 l/10 min 166 l/10 min 234 l/10 min 237 l/10 min
Domestic hot water output
(70 °C)
177 l/10 min 258 l/10 min 261 l/10 min 177 l/10 min 258 l/10 min 261 l/10 min
Specific flow rate Delta
(50 °C 30 K)
16.8 l/min 22.3 l/min 22.3 l/min 16.8 l/min 22.3 l/min 22.3 l/min
Specific flow rate Delta
(55 °C 30 K)
17.5 l/min 23.7 l/min 24.2 l/min 17.5 l/min 23.7 l/min 24.2 l/min
Specific flow rate Delta
(60 °C 30 K)
18.8 l/min 25.6 l/min 26.0 l/min 18.8 l/min 25.6 l/min 26.0 l/min
Specific flow rate Delta
(65 °C 30 K)
19.4 l/min 27.3 l/min 27.7 l/min 19.4 l/min 27.3 l/min 27.7 l/min
Specific flow rate Delta
(70 °C 30 K)
20.7 l/min 30.1 l/min 30.5 l/min 20.7 l/min 30.1 l/min 30.5 l/min
Nominal heating medium
volume flow for the heating
circuit
0.989 m³/h 1.20 m³/h 1.20 m³/h 0.989 m³/h 1.20 m³/h 1.20 m³/h
Nominal heating medium
volume flow for the solar
circuit
1.81 m³/h 1.93 m³/h 2.79 m³/h 1.81 m³/h 1.93 m³/h 2.79 m³/h
Technical data –VIH SW output
VIH SW 400/3
BR
VIH SW 500/3
BR
VIH SW 400/3
MR
VIH SW 500/3
MR
Output characteristic figure
NL (50 °C)
1.2 2.2 1.2 2.2
Output characteristic figure
NL (55 °C)
1.4 2.5 1.4 2.5
Output characteristic figure
NL (60 °C)
1.5 2.8 1.5 2.8
Output characteristic figure
NL (65 °C)
2.0 3.0 2.0 3.0
Output characteristic figure
NL (70 °C)
2.0 3.0 2.0 3.0
Continuous domestic hot
water output (heating circuit)
(50 °C 35 K)
27.4 kW 38.2 kW 27.4 kW 38.2 kW
Continuous domestic hot
water output (heating circuit)
(55 °C 35 K)
36.4 kW 51.0 kW 36.4 kW 51.0 kW
Continuous domestic hot
water output (heating circuit)
(60 °C 35 K)
44.3 kW 62.2 kW 44.3 kW 62.2 kW
Continuous domestic hot
water output (heating circuit)
(50 °C 35 K)
674 l/h 941 l/h 674 l/h 941 l/h
Continuous domestic hot
water output (heating circuit)
(55 °C 35 K)
896 l/h 1,253 l/h 896 l/h 1,253 l/h
Continuous domestic hot
water output (heating circuit)
(60 °C 35 K)
1,091 l/h 1,530 l/h 1,091 l/h 1,530 l/h
Domestic hot water output
(50 °C)
213 l/10 min 264 l/10 min 213 l/10 min 264 l/10 min
Domestic hot water output
(55 °C)
239 l/10 min 297 l/10 min 239 l/10 min 297 l/10 min
Domestic hot water output
(60 °C)
266 l/10 min 330 l/10 min 266 l/10 min 330 l/10 min
Domestic hot water output
(65 °C)
292 l/10 min 363 l/10 min 292 l/10 min 363 l/10 min

Appendix
0020241666_01 Safety instructions 15
VIH SW 400/3
BR
VIH SW 500/3
BR
VIH SW 400/3
MR
VIH SW 500/3
MR
Domestic hot water output
(70 °C)
319 l/10 min 396 l/10 min 319 l/10 min 396 l/10 min
Specific flow rate Delta
(50°C30K)
24.8 l/min 30.8 l/min 24.8 l/min 30.8 l/min
Specific flow rate Delta
(55°C30K)
27.9 l/min 34.7 l/min 27.9 l/min 34.7 l/min
Specific flow rate Delta
(60°C30K)
31.0 l/min 38.5 l/min 31.0 l/min 38.5 l/min
Specific flow rate Delta
(65°C30K)
34.1 l/min 42.4 l/min 34.1 l/min 42.4 l/min
Specific flow rate Delta
(70°C30K)
37.2 l/min 46.2 l/min 37.2 l/min 46.2 l/min
Nominal heating medium
volume flow for the heating
circuit
1.7 m³/h 2.6 m³/h 1.7 m³/h 2.6 m³/h
Nominal heating medium
volume flow for the solar
circuit
2.0 m³/h 2.0 m³/h 2.0 m³/h 2.0 m³/h

Obsah
16 Bezpečnostní pokyny 0020241666_01
Bezpečnostní pokyny
Obsah
1 Bezpečnost ....................................................... 17
1.1 Výstražná upozornění související
s manipulací......................................................... 17
1.2 Použití v souladu s určením ................................ 17
1.3 Všeobecné bezpečnostní pokyny........................ 17
1.4 Předpisy (směrnice, zákony, vyhlášky
a normy)............................................................... 18
2 Pokyny k dokumentaci ...................................... 19
2.1 Dodržování platné dokumentace......................... 19
2.2 Uložení dokumentace.......................................... 19
2.3 Platnost návodu................................................... 19
3 Popis výrobku ...................................................19
3.1 Konstrukce výrobku ............................................. 19
3.2 Typový štítek........................................................ 19
3.3 Označení CE ....................................................... 20
4 Nastavení požadované teploty zásobníku ........ 20
5 Předání provozovateli ....................................... 20
6 Odstranění poruch ............................................ 20
6.1 Rozpoznání a odstranění poruch ........................ 20
6.2 Nákup náhradních dílů ........................................ 21
7 Odstavení z provozu ......................................... 21
8 Recyklace a likvidace........................................ 21
9 Servis ................................................................ 21
Příloha .............................................................................. 22
A Rozpoznání a odstranění závad ....................... 22
B Kontrolní a údržbové práce – přehled ............... 22
C Technické údaje................................................ 23

Bezpečnost 1
0020241666_01 Bezpečnostní pokyny 17
1 Bezpečnost
1.1 Výstražná upozornění související
s manipulací
Klasifikace výstražných upozornění souvise-
jících s manipulací
Výstražná upozornění související s manipu-
lací jsou pomocí výstražných značek a sig-
nálních slov odstupňována podle závažnosti
možného nebezpečí:
Výstražné značky a signální slova
Nebezpečí!
Bezprostřední ohrožení života nebo
nebezpečí závažného zranění osob
Nebezpečí!
Nebezpečí úrazu elektrickým prou-
dem
Varování!
Nebezpečí lehkých zranění osob
Pozor!
Riziko věcných nebo ekologických
škod
1.2 Použití v souladu s určením
Při neodborném používání nebo použití v roz-
poru s určením může dojít k ohrožení zdraví
a života uživatele nebo třetích osob, resp.
k poškození výrobku a k jiným věcným ško-
dám.
Zásobník teplé vody je určen pro dodávku
teplé vody s maximální teplotou 85 °C v do-
mácnostech a průmyslových podnicích. Výro-
bek je určen k instalaci do topného systému.
Je určen pro kombinaci se zdroji tepla, jejichž
výkon je v mezích, které jsou uvedeny v tech-
nických údajích. K regulaci ohřevu teplé vody
lze použít ekvitermní regulátory a regulace
vhodných zdrojů tepla. To jsou zdroje tepla,
které umožňují nabíjení zásobníku a připojení
snímače teploty.
Použití v souladu s určením zahrnuje:
– dodržování přiložených návodů k obsluze,
instalaci a údržbě výrobku a všech dalších
součástí systému
– instalaci a montáž v souladu se schvále-
ním výrobků a systému
– dodržování všech podmínek prohlídek
a údržby uvedených v návodech.
Použití v souladu s určením zahrnuje kromě
toho instalaci podle třídy IP.
Jiné použití, než je popsáno v tomto návodu,
nebo použití, které přesahuje zde popsaný
účel, je považováno za použití v rozporu s ur-
čením. Každé přímé komerční nebo průmys-
lové použití je také v rozporu s určením.
Pozor!
Jakékoliv zneužití či nedovolené použití je
zakázáno.
1.3 Všeobecné bezpečnostní pokyny
1.3.1 Nebezpečí při nedostatečné
kvalifikaci
Platnost: Nikoli pro Rusko
Následující práce smějí provádět pouze in-
stalatéři, kteří mají dostatečnou kvalifikaci:
Platnost: Rusko
Následující práce smějí provádět pouze in-
stalatéři s certifikací Vaillant, kteří mají dosta-
tečnou kvalifikaci:
– Montáž
– Demontáž
–Instalace
– Uvedení do provozu
– Údržba
– Oprava
– Odstavení z provozu
▶Dodržujte všechny návody dodané s vý-
robkem.
▶Postupujte podle aktuálního stavu tech-
niky.
▶Dodržujte všechny příslušné směrnice,
normy, zákony a jiné předpisy.
1.3.2 Nebezpečí úrazu elektrickým
proudem
Při dotyku součástí pod napětím hrozí nebez-
pečí úrazu elektrickým proudem.
Než začnete pracovat na výrobku:
▶Vytáhněte síťovou zástrčku.
▶Nebo vypněte výrobek odpojením všech
zdrojů proudu (elektrické odpojovací za-
řízení se vzdáleností kontaktů nejméně
3 mm, např. pojistka nebo výkonový spí-
nač).

1 Bezpečnost
18 Bezpečnostní pokyny 0020241666_01
▶Zajistěte výrobek před opětovným zapnu-
tím.
▶Vyčkejte nejméně 3 minuty, až se vybijí
kondenzátory.
1.3.3 Nebezpečí ohrožení života v důsledku
chybějících bezpečnostních zařízení
Schémata obsažená v tomto dokumentu ne-
zobrazují všechna bezpečnostní zařízení ne-
zbytná pro odbornou instalaci.
▶Instalujte nezbytná bezpečnostní zařízení.
▶Dodržujte příslušné předpisy, normy
asměrnice.
1.3.4 Nebezpečí popálení a opaření
horkými součástmi
▶Na součástech pracujte, až vychladnou.
1.3.5 Nebezpečí zranění v důsledku vysoké
hmotnosti výrobku
▶Výrobek přepravujte minimálně ve dvou
osobách.
1.3.6 Riziko věcných škod v důsledku
použití nevhodného nářadí
▶Při dotahování nebo povolování šroubo-
vých spojů používejte správné nářadí.
1.4 Předpisy (směrnice, zákony, vyhlášky
a normy)
▶Dodržujte vnitrostátní předpisy, normy,
směrnice a zákony.
