VALBERG MWO 23 EK 343C2 User manual

01/2023 - V5
974949 - MWO 23 EK 343C2
Microwave Oven
Four à micro-ondes
Microgolfoven
Horno microondas
EN
WARRANTY CONDITION
This product is guaranteed for a period of 2 years from the date of purchase* against any failure
resulting from a manufacturing or material defect. This warranty does not cover defects or
damage resulting from incorrect installation, improper use or abnormal wear of the product.
*as shown on the sales receipt.
FR
CONDITION DE GARANTIE
Ce produit est garanti pour une période de 2 ans à partir de la date d’achat*, contre toute
défaillance résultant d’un vice de fabrication ou de matériau. Cette garantie ne couvre pas les
vices ou les dommages résultant d’une mauvaise installation, d’une utilisation incorrecte ou
de l’usure anormale du produit.
*sur présentation du ticket de caisse.
NL
GARANTIEVOORWAARDEN
Dit product wordt gegarandeerd voor een periode van 2 jaar vanaf de aankoopdatum*, voor
elke storing die het gevolg is van een fabricagefout of het materiaal. Gebreken of schade door
slechte installatie, onjuist gebruik of abnormale slijtage van het product worden niet gedekt
door deze garantie.
*op vertoon van kassabon.
ES
CONDICIONES DE GARANTÍA
El certificado de garantía de este producto tiene una duración de 2 años a partir de la fecha de
compra* que se limita a los defectos de fabricación y averías del material. Se excluyen de la
garantía deficiencias o daños originados por una mala instalación, errores en la manipulación
o por un uso inadecuado.
*previa presentación del comprobante de compra.
INSTRUCTIONS FOR USE ....................02
CONSIGNES D'UTILISATION ....................16
GEBRUIKSAANWIJZINGEN ....................30
INSTRUCCIONES DE USO ....................44
MADE IN PRC
ELECTRO DEPOT
1route de Vendeville
59155FACHES-THUMESNIL
FRANCE
2/2

A
C
F
B
D
E

2 3
EN EN
A
Thanks!
Thank you for choosing this VALBERG product.
Chosen, tested and recommended by ELECTRO DEPOT,
the products of the VALBERG brand are easy to use,
reliable and of an impeccable standard.
Thanks to this appliance, you can be sure that each
use will bring you satisfaction.
Welcome to ELECTRO DEPOT.
Visit our website: www.electrodepot.fr
Table of contents
APreview of
theappliance
Utensils
Names of oven parts and accessories
Countertop installation
BUsing the appliance Operation
CUseful
information Troubleshooting

4 5
EN EN
Preview of theappliance Preview of theappliance
A A
Utensils
CAUTION
Personal Injury Hazard
It is hazardous for anyone other than a competent person to carry out any service or repair
operation that involves the removal of a cover which gives protection against exposure to
microwave energy.
See the instructions on "Materials you can use in microwave oven or to be avoided in
microwave oven." There may be certain non-metallic utensils that are not safe to use for
microwaving. If in doubt, you can test the utensil in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil
in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
Materials you can use in microwave oven
Utensils Remarks
Browning dish
Follow manufacturer’s instructions.The bottom of browning dish
must be at least 3/16 inch (5mm) above the turntable. Incorrect
usage may cause the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer’s instructions. Do not
use cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm. Most glass
jars are not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no metallic
trim. Do not use cracked or chipped dishes.
Oven cooking bags Follow manufacturer’s instructions. Do not close with metal tie.
Make slits to allow steam to escape.
Paper plates and
cups
Use for short-term cooking/warming only. Do not leave oven
unattended while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic
Microwave-safe only. Follow the manufacturer’s instructions.
Should be labeled "Microwave Safe". Some plastic containers
soften, as the food inside gets hot. "Boiling bags" and tightly
closed plastic bags should be slit, pierced or vented as directed by
package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only ( meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray May cause arcing. Transfer food into microwave-safe dish.
Food carton with
metal handle May cause arcing. Transfer food into microwave-safe dish.
Metal or metal-
trimmed utensils
Metal shields the food from microwave energy. Metal trim may
cause arcing.
Metal twist ties May cause arcing and could cause a re in the oven.
Paper bags May cause a re in the oven.
Plastic foam Plastic foam may melt or contaminate the liquid inside when
exposed to high temperature.
Wood Wood will dry out when used in the microwave oven and may split or
crack.

6 7
EN EN
Preview of theappliance Preview of theappliance
A A
Cleaning the cooking compartment and putting the turntable in place. For new installations,
make sure all packaging and shipping tape has been removed. Before using the appliance
to prepare food for the rst time, you will need to put the turntable in place correctly. You
must clean the cooking compartment and accessories.
2
1
1. Glass Tray
2. Turntable Ring Assembly
NOTE:
1. Never use the appliance without the turntable. Make
sure that it is properly engaged. The turntable can turn
clockwise or anti-clockwise.
2. Never place the glass tray upside down. The glass tray
should never be restricted.
3. Both glass tray and turntable ring assembly must always
be used during cooking.
4. All food and containers of food are always placed on the
glass tray for cooking.
5. Never restrict the movement of the turntable.
6. If glass tray or turntable ring assembly cracks or breaks,
contact your nearest authorized service center.
Names of oven parts and accessories
Remove the oven and all materials from the carton and oven cavity. Your oven comes with
the following accessories:
Glass Tray Turntable Ring Assembly
Instruction Manual
A
C
F
B
D
E
A) Control panel
B) Turntable Ring Assembly
C) Observation window
D) Door assembly
E) Safety interlock system
F) Oven cavity

8 9
EN EN
Preview of theappliance Preview of theappliance
A A
– The minimum installation height is 85cm.
– The rear surface of appliance shall be placed against a wall. Leave a minimum clearance
of 30cm above the oven. A minimum clearance of 20cm is required between the oven
and any adjacent walls.
– Do not remove the legs from the bottom of the oven.
– Blocking the intake and/or outlet openings can damage the oven.
– Place the oven as far away from radios and TV as possible. Operation of microwave
oven may cause interference to your radio or TV reception.
2. Plug your oven into a standard household outlet. Be sure the voltage and the frequency
is the same as the voltage and the frequency on the rating label.
The appliance must not be placed in a cabinet.
WARNING :
Do not install oven over a range cooktop or other heat-
producing appliance. If installed near or over a heat source,
the oven could be damaged and the warranty would be void.
The accessible surface may be hot during operation.
Countertop installation
Remove all packing material and accessories. Examine the oven for any damage such as
dents or broken door. Do not install if oven is damaged. Cabinet: Remove any protective lm
found on the microwave oven cabinet surface. Do not remove the light brown Mica cover
that is attached to the oven cavity to protect the magnetron.
INSTALLATION
1. Select a level surface that provide enough open space for the intake and/or outlet vents.
0cm 30cm
20cm
20cm
min85cm
LIGHT SOURCE
Light source in this product can only be replaced by qualied professionals.
Please contact after-sales service if the light source fails. The light source shall be removed at the
end of the product's useful life, with sorting and recycling done separately.

10 11
EN EN
Using the appliance
BB Using the appliance
2. Turn the knob to set the weight of food. The range of weight is 100 to 2000g.
3. Press “ ”to start defrosting.
4. Once defrosting has nished, the buzzer will sound ve times.
NOTE:
During defrosting, the buzzer will sound to remind you to
turn the food over. If no operation, the oven will continue
working.
Defrost by Time
1. Press “ ” twice and then the screen will display “d-2”.
2. Turn the knob to set the desired defrost time. The range of time is 0:00-95:00.
3. Press “ ”to start defrosting.
4. Once defrosting has nished, the buzzer will sound ve times.
NOTES:
1. When half of the time has passed, the buzzer will sound
to remind you to turn the food over. If no operation, the
oven will continue working.
2. The defrost power is P30 and it cannot be changed.
Operation
Setting the Clock
1. Press “ ” twice and then“00:00” will display.
2. Turn the knob to set the hour gures. The time should be within 0-23.
3. Press “ ” to conrm.
4. Turn the knob to set the minute gures. The time should be within 0-59.
5. Press “ ” to conrm. The clock is set.
NOTES:
1. After the 4 step, if the “ ”button is not pressed or if there
is no operation within 1 minute, the setting is invalid.
2. To reset the clock, please repeat step 1 to step 5.
3. If the clock is not set, it would not function when powered.
Microwave Cooking
5 power levels are available.
Power Level 100% 80% 50% 30% 10%
Display P100 P80 P50 P30 P10
1. Press “ ” and then “P100” will display.
2. Press “ ” repeatedly or turn the knob to set the power level.
3. Press “ ” to conrm.
4. Turn the knob to adjust the cooking time. The range of time is 0:00-95:00.
5. Press “ ”to start cooking.
Setting the Kitchen Timer
1. Press “ ” once, and then “00:00” will display.
2. Turn the knob to set the desired time. The maximum time value is“95:00” .
3. Press “ ”to conrm. The timer starts counting down.
Defrost by Weight
1. Press “ ” once and then the screen will display “d-1”.

12 13
EN EN
BUsing the applianceUsing the appliance B
Inquiring Function
If the clock has been set, the current time will display for three seconds by pressing
“” in the cooking state.
Auto menu
1. Turn the knob to right and then “A-1”will display.
2. Turn the knob to choose the menu you need. 8 auto menus are available.
3. Press “ ” to conrm.
4. Turn the knob to set the weight of food.
5. Press “ ”to start cooking.
Multi-Stage Cooking
NOTES:
1. Two cooking stages can be set in multi-stage cooking.
2. If you set defrost function, it will work automatically in
the rst stage.
3. Kitchen Timer and Auto menu cannot be set as one of
the multi-stage.
4. You can press “ ” to increase cooking time during
multi-stage cooking.
Example: Defrost food for 5 minutes and then cook with 80% microwave power for 7 minutes.
1. Press “ ” once,“d-1” displays, press “ ” to conrm.
2. Turn the knob to set the desired defrost time of 5 minutes.
3. Press “ ” until “P100” displays,press “ ” to conrm.
4. Turn the knob to set the power level of P80.
5. Turn the knob to set the cooking time of 7 minutes.
6. Press “ ”to start cooking.
Speedy Cooking
1. In waiting state, press “ ” to cook food with 100% power level for 30seconds.
Each press on the same key can increase 30 seconds and the maximum time value is
95 minutes.
2. In waiting state, turn the knob left to set a cooking time with 100% power. Then press
“” to start cooking.
Lock Function for Children
You can use this function to prevent children from accidentally turning the oven on.
To activate the lock:
In waiting state, press and hold “ ” for three seconds. A long beep sounds and the locked
icon or current time(if the clock is set)will display.
To deactivate the lock:
In locked state, press and hold“ ” for three seconds. A long beep sounds.

14 15
EN EN
Using the appliance
B
14 15
EN EN
CUseful information
Auto Menu Chart
Menu Weight Display
A-1
Auto Reheat
200g 200g
400g 400g
A-2
Meat
250g 250g
350g 350g
450g 450g
A-3
Vegetable
200g 200g
300g 300g
400g 400g
A-4
Pasta
50g (450g cold water) 50g
100g (800g cold water) 100g
A-5
Potato
1 (about 230g) 1
2 2
3 3
A-6 Fish
250g 250g
350g 350g
450g 450g
A-7
Beverage
1 (120ml) 1
2 (240ml) 2
3 (360ml) 3
A-8
Popcorn
50g 50g
100g 100g
Troubleshooting
Normal
Microwave oven interfering TV
reception
Radio and TV reception may be interfered when
microwave oven operating. It is similar to the
interference of small electrical appliances, like mixer,
vacuum cleaner, and electric fan.
It is normal.
Dim oven light In low power microwave cooking, oven light may
become dim. It is normal.
Steam accumulating on door,
hot air out of vents
In cooking, steam may come out of food. Most will get
out from vents. But some may accumulate on cool
place like oven door. It is normal.
Oven started accidentally with
no food in.
It is forbidden to run the unit without any food inside.
It is very dangerous.
Trouble Possible Cause Remedy
Oven cannot be
started.
1. Power cord is not
plugged in tightly.
Unplug. Then plug again after
10seconds.
2. Fuse blowing or circuit
breaker works.
Replace fuse or reset circuit
breaker (repaired by professional
personnel of our company)
3. Trouble with outlet. Test outlet with other electrical
appliances.
Oven does not heat. 4. Door is not closed well. Close door well.

16 17
FR FR
A
Merci !
Nous vous remercions d'avoir choisi ce produit VALBERG.
Choisis, testés et recommandés par ELECTRO DEPOT,
les produits de la marque VALBERG sont simples
d'utilisation, tout en offrant des performances fiables
et une qualité irréprochable.
Grâce à cet appareil, vous êtes assuré(e) que chaque
utilisation vous apportera satisfaction.
Bienvenue chez ELECTRO DEPOT.
Consultez notre site Internet : www.electrodepot.fr
www.electrodepot.be
Table des matières
AAperçu de l'appareil Ustensiles
Nom des pièces et des accessoires du four
Installation sur le plan de travail
BUtilisation de
l'appareil
Fonctionnement
CInformations
utiles Dépannage
Les notices sont aussi disponibles sur le site
http://www.electrodepot.fr/sav/notices/
http://www.electrodepot.be/fr/sav/notices
VVOOTRETRE AAVISVIS CCOMPTE !OMPTE !
PARTAGEZ
VOTRE EXPERIENCE
SUR LES PRODUITS
Parce que votre satisfaction est notre priorité, nous vous proposons de
donner votre avis sur ce produit. Il sera transmis et analysé par nos
équipes an d’améliorer continuellement le produit.
Donnez votre avis sur : http://www.electrodepot.fr/avis-client
