VALBERG BI 1D 199 F W742C User manual

Adjust Mode
Super
Smart
1 42 3 5

EN
WARRANTY CONDITION
This product is guaranteed for a period of 2 years from the date of purchase* against any failure
resulting from a manufacturing or material defect. This warranty does not cover defects or
damage resulting from incorrect installation, improper use or abnormal wear of the product.
*as shown on the sales receipt.
FR
CONDITION DE GARANTIE
Ce produit est garanti pour une période de 2 ans à partir de la date d’achat*, contre toute
défaillance résultant d’un vice de fabrication ou de matériau. Cette garantie ne couvre pas les
vices ou les dommages résultant d’une mauvaise installation, d’une utilisation incorrecte ou
de l’usure anormale du produit.
*sur présentation du ticket de caisse.
NL
GARANTIEVOORWAARDEN
Dit product wordt gegarandeerd voor een periode van 2 jaar vanaf de aankoopdatum*, voor
elke storing die het gevolg is van een fabricagefout of het materiaal. Gebreken of schade door
slechte installatie, onjuist gebruik of abnormale slijtage van het product worden niet gedekt
door deze garantie.
*op vertoon van kassabon.
ES
CONDICIONES DE GARANTÍA
El certificado de garantía de este producto tiene una duración de 2 años a partir de la fecha de
compra* que se limita a los defectos de fabricación y averías del material. Se excluyen de la
garantía deficiencias o daños originados por una mala instalación, errores en la manipulación
o por un uso inadecuado.
*previa presentación del comprobante de compra.
MADE IN PRC
ELECTRO DEPOT
1 route de Vendeville
59155 FACHES-THUMESNIL
FRANCE

967752 - BI 1D 199 F W742C
Fridge
Réfrigérateur
Koelkast
Frigorίco
INSTRUCTIONS FOR USE ....................02
CONSIGNES D'UTILISATION ....................14
GEBRUIKSAANWIJZINGEN ....................26
INSTRUCCIONES DE USO ....................38
2/2 09/2022 - V4

38 mm
550 mm 560 mm
0321-0221 mm
0121 mm
1182 mm
15 mm
540 mm
min.
200 cm2
min.
200 cm2
18 mm
0221 mm

2FR
A
2 EN
Thank you!
Thank you for choosing this VALBERG product.
The VALBERG products which have been chosen,
tested and recommended by ELECTRO DEPOT,
are easy to use, reliable and of an impeccable
standard.
Satisfaction guaranteed every time you use this
appliance.
Welcome to ELECTRO DEPOT.
Visit our website: www.electrodepot.fr

3FR
Aperçu de l’appareil
A
3 EN
Table of contents
AOverview of the
appliance
CUseful information
BUsing the appliance Upside down door
Installation
Initial use
Control panel
Operation
Cleaning and care
Troubleshooting
Disposing of your old appliance
Recommended ambient temperature
Temperature control adjustment
Components

4
A
EN
Recommended ambient temperatures
Respect the climatic classes indicated in the product information on the appliance's nameplate.
You can use this to check the recommended temperature range of the room where the appliance
is located:
- SN: Between 10 and 32°C
- N: Between 16 and 32°C
- SN: Between 16 and 38°C
- Tel.: Between 16 and 43°C
A multi-class appliance can handle the lowest and highest temperature of all classes covered.
Using the appliance outside the recommended temperature range will lead to inferior performance
and premature ageing.
Temperature control adjustment
For optimal use and to save energy, adjust the temperature control(s) of the appliance according
to the ambient temperature of the room in which it is being used and respect the climatic class.
Refer to the product sheet to find out the climatic class associated with the minimum and
maximum recommended ambient temperatures for the appliance as well as the temperature
setting recommended for storing food under optimal conditions.
The ambient temperatures in °C are given as a rough guide.
The set positions can be affected by the location of the appliance in the room, how often the
door is opened or the load of food inside.
The temperature control may need to be changed to compensate for these factors.
Examples of locations:
- Room which is unheated in winter, such as a garage in a cold region.
- Living area which is normally heated, such as a kitchen.
- Room with no air conditioning in summer in a hot region.
Overview of the appliance

5
A
EN
Components
1Control panel and light 4Crisper
2Glass shelves 5Bottle racks
3Crisper lid
Overview of the appliance

6EN
Using the appliance
B
Upside down door
Tools required: Phillips screwdriver/flathead screwdriver/Allen key.
• Make sure that the appliance is unplugged and empty.
• To remove the door, the appliance must be tilted backwards. Lay the appliance on a solid
object so that it cannot slip while the opening direction of the doors is being reversed.
• All the parts that have been removed must be kept in a safe place so that the door can be
replaced.
• Do not lay the appliance down flat as this could damage the cooling system.
• We recommend that the appliance should be handled by 2 people during assembly.
Unscrew the upper hinge. Lift off the door and place it on a padded surface to prevent
scratching.
Remove the pin from the lower hinge from right to left.
Unscrew the pin from the upper hinge. Then reverse the hinge and screw in the pin on the hinge.
Replace the door and the upper left hinge. Make sure that the door is aligned horizontally
and vertically and that the seals are closed on all sides before tightening the
lower hinge. Use a spanner to tighten the hinge if necessary.
Installation
Installation kits
Guide x 2
Guide cover x 2
Runner x 2
Runner cover x 2
ShortShort screw x 15
Long screw x 2
Rubber seal x 1



1


7EN
Using the appliance
B
Installing the appliance
Make sure that the dimensions of the unit and ventilation conditions are suitable.
Take care to push the appliance carefully into the unit. Make sure that the opening side is as
close as possible to the wall of the unit.
Screw a guide into the holes located at the side of the appliance door using short screws. Insert
the runner in the guide and then fully open and close the appliance door and the wooden door
to make sure that the wooden door can easily close completely.
Runner
Screws
Guide
 Open the appliance door and the wooden door at the same time and mark the position in which
the runner can function effectively at all angles when closing and opening the door. Remove the
runner from the guide and attach the runner to the wooden door using 2 short screws. Then
attach the runner cover to the runner.
Unscrew the guide from the appliance door.
Repeat steps 2 to 5 to attach another runner and another runner cover.
Runner
Screws
Assemble 2 guides on runners and attach them using short screws. Then attach the runner
covers to the runners.
Check again that the door can open and close easily and that the appliance if properly sealed.
If this is not the case, make some slight adjustments to the appliance. Then attach the lower
support to the wooden unit using 2 long screws.
Attach the upper support to the wooden unit using short screws.
Attach the rubber seal in the space between the appliance and the wooden unit on the opening
side of the door.
Positioning
Install this appliance in a place in which the ambient temperature corresponds to the climate
class indicated on the nameplate.
10
11
12
13




8EN
Using the appliance
B
Location
of heat sources such as radiators, boilers, sunlight, etc. Make sure that air can circulate freely
around the back of the unit. To guarantee optimum performance, appliances which are positioned
below an overhanging element should be at a minimum distance of at least 100 mm between
the top of the appliance and the wall element. Ideally the appliance should not be positioned
underneath wall elements. The equipment can be correctly levelled by adjusting the feet at the
bottom of the appliance.
CAUTION
It must be possible to disconnect the appliance from the
electricity supply; The plug must be easily accessible after
installation
Electrical connection
Before connecting the appliance, make sure that the voltage and frequency indicated on the
nameplate correspond to your domestic power supply. This appliance must be earthed. There
is a pin in the power supply plug for this purpose. If the household socket is not earthed, you
should contact a qualified electrician to connect the appliance to a separate earthing point in
line with the statutory requirements for power supplies. The manufacturer accepts no liability
if the above-mentioned safety measures are not respected. The appliance is compliant with
European directives.
Initial use
Cleaning the inside
Before using the appliance for the first time, wash the interior and all internal accessories with
lukewarm water and a neutral soap to remove the characteristic odour of new products. Dry
thoroughly.
WARNING
Do not use abrasive powders or detergents as they will
damage the finish.

9EN
Using the appliance
B
Control panel
Buttons
• B1 – Press this button to adjust the refrigeration compartment cycle setting from1, 2, 3, 4
to 5.
• B2 – Press this button to select either Smart or Super mode and user settings.
Lights
• L1 – Indicates the refrigeration compartment setting.
• L2 – comes on after selecting the
Smart mode .
• L3 – comes on after selecting the
Super mode.
Operation
Temperature setting
•Press the Mode button (B2) to select the user settings.
• Press the Adjust button (B1) to adjust the refrigerator settings. A lower setting corresponds
to a lower temperature. The freezer temperature is controlled automatically at around - 18 °C.
Smart node
• Press the Mode button (B2) to select the
Smart mode.
• The appliance operates automatically according to the dominant ambient temperature
around the appliance.
Super mode
• Press the Mode button (B2) to select the
Super mode .
• The appliance operates to increase the cold setting in the freezer compartment to its highest
level. After 54 hours, the initial defined temperature is automatically reset.
Switching off the appliance
• Press the second Adjust button (B1) and keep it held down for 5 seconds to switch off the
appliance. Press the button again for5 seconds to switch on the appliance.
Refrigerator door opening alarm
• The alarm sounds if the door is left open for 90 seconds and only stops when the door is
closed.
14

10 EN
Using the appliance
B
Accessories
15 Removable shelves
The refrigerator walls are fitted with a series of guides so that the shelves can be positioned
as required.
Positioning the bottle racks in the door
16 Removable shelves
The bottle racks can be removed from the door in order to store packs of food of different
sizes. The following steps should be taken to make these adjustments: Gradually pull the
shelf in the direction of the arrows until it dislodges.

11 EN
Useful information
C
Cleaning and care
For hygiene reasons, the interior of the appliance including interior accessories should
be cleaned regularly.
WARNING
The appliance must not be plugged into the mains during
cleaning. Risk of electrocution! Switch off the appliance and
unplug it from the power supply, or switch off the circuit
breaker or remove the fuse before cleaning. Never clean the
appliance using a steam cleaner. Moisture could accumulate
around the electronic parts creating a risk of electrocution!
Warm vapours can cause damage to plastic parts. The
appliance must be dry before you switch it back on.
WARNING
Essential oils and organic solvents can damage plastic
elements, e.g. lemon juice or juice from orange zest, butyric
acid or any cleaning product containing acetic acid.
• Do not allow this type of substance to come into contact with the appliance parts.
• Do not use abrasive cleaning products.
• Take the food out of the freezer. Keep the food completely covered in a cool place.
• Switch off the appliance and unplug it from the power supply, or switch off the circuit breaker
or remove the fuse.
• Clean the appliance and the interior accessories with a cloth and warm water. After washing,
rinse with clean water and wipe down until completely dry.
• The accumulation of dust on the condenser increases energy consumption. The condenser
at the back of the appliance should therefore be cleaned carefully once a year using a soft
brush or vacuum cleaner. 1
• Switch the device back on once all the elements are dry.
1) If the condenser is at the back of the appliance.

12 EN
CUseful information
Cleaning the drainage hole
Clean the drainage hole located at the back of the refrigeration compartment periodically to
prevent defrosting water from entering the refrigerator. Use a cleaning product to clean the hole.
17
Changing the Light
This product contains a light source of energy efficiency class G.
Light source in this product can only be replaced by qualified professionals.
Please contact after-sales service if the light source fails.
The light source shall be removed at the end of the product’s useful life, with sorting and
recycling done separately.

13
CUseful information
EN
Troubleshooting
Fault Possible cause Oplossing
The appliance does not
work.
The appliance is switched off.
The appliance is not plugged in
or has been disconnected.
The fuse has blown or is faulty.
The plug is defective.
Press the Adjust button for5
seconds to switch on the
appliance.
Plug in the appliance
Check the fuse. Replace if
necessary.
Operating faults must be
repaired by an electrician.
The food is too warm. The temperature is not
correctly set.
The door has been left open
for an extended period.
A large amount of warm
food has been placed in the
appliance during the past 24
hours.
The appliance is near a heat
source.
Please consult the
Adjusting
the initial temperature section.
Only open the door for as long
as is necessary.
Turn the temperature control
temporarily to a colder setting.
Please consult the
Installation
position
Excessive cooling of
the appliance
The temperature setting is too
cold.
Turn the temperature
regulator temporarily to a
warmer setting.
Unusual noises. The appliance is not level.
The appliance is touching the
wall or other items.
A component (e.g. a pipe) at
the back of the appliance is
touching another part of the
appliance or the wall.
Adjust the wooden unit if it is
not level.
Move the appliance slightly.
If necessary, carefully fold the
component to move it slightly.
There is water on the
floor.
The water drainage hole is
blocked.
See the
Cleaning section.
Contact the repair centre if the malfunction persists.
