VALBERG SBS 442 E W742C User manual

979046 - SBS 442 E W742C
979048 - SBS 442 E X742C
INSTRUCTIONS FOR USE ....................02
CONSIGNES D'UTILISATION ....................22
GEBRUIKSAANWIJZINGEN ....................42
INSTRUCCIONES DE USO ....................62
2/2 01/2023
Fridge - freezer
Réfrigérateur - congélateur
Koelvrieskast
Frigorífico - congelador
EN
WARRANTY CONDITION
This product is guaranteed for a period of 2 years from the date of purchase* against any failure
resulting from a manufacturing or material defect. This warranty does not cover defects or
damage resulting from incorrect installation, improper use or abnormal wear of the product.
*as shown on the sales receipt.
FR
CONDITION DE GARANTIE
Ce produit est garanti pour une période de 2 ans à partir de la date d’achat*, contre toute
défaillance résultant d’un vice de fabrication ou de matériau. Cette garantie ne couvre pas les
vices ou les dommages résultant d’une mauvaise installation, d’une utilisation incorrecte ou
de l’usure anormale du produit.
*sur présentation du ticket de caisse.
NL
GARANTIEVOORWAARDEN
Dit product wordt gegarandeerd voor een periode van 2 jaar vanaf de aankoopdatum*, voor
elke storing die het gevolg is van een fabricagefout of het materiaal. Gebreken of schade door
slechte installatie, onjuist gebruik of abnormale slijtage van het product worden niet gedekt
door deze garantie.
*op vertoon van kassabon.
ES
CONDICIONES DE GARANTÍA
El certificado de garantía de este producto tiene una duración de 2 años a partir de la fecha de
compra* que se limita a los defectos de fabricación y averías del material. Se excluyen de la
garantía deficiencias o daños originados por una mala instalación, errores en la manipulación
o por un uso inadecuado.
*previa presentación del comprobante de compra.
MADE IN PRC
ELECTRO DEPOT
1 route de Vendeville
59155 FACHES-THUMESNIL
FRANCE

2FR
A
2EN
Thanks!
Thank you for choosing this VALBERG product.
Chosen, tested and recommended by ELECTRO DEPOT,
VALBERG branded products are easy to use, reliable,
and of an impeccable standard.
With every use of this appliance, you can be sure of
complete satisfaction.
Welcome to ELECTRO DEPOT.
Visit our website: www.electrodepot.fr

3FR
Aperçu de l’appareil
A
3EN
Table of contents
AOverview of the
appliance
CUseful information
BUsing the appliance Installation
Use
Useful hints and tips
Cleaning and maintenance
Troubleshooting
Disposing of your old appliance
Recommended ambient temperature
Temperature control adjustment
Description of the appliance
Control panel

4FR
Aperçu de l’appareil
A
EN
Overview of the appliance
A
Recommended ambient temperature
A multi-class appliance can handle the lowest and highest temperature of all classes covered.
Using the appliance outside the recommended temperature range will lead to inferior performance
and premature ageing.
Adjusting the thermostat
For optimal use and energy savings, adjust the temperature control(s) of the appliance according
to the ambient temperature of the room, in which it is being used, and respect the climate class.
Refer to the product sheet to find out the climate class associated with the minimum and
maximum recommended ambient temperatures for the appliance as well as the temperature
setting recommended for storing food under optimal conditions.
The ambient temperatures in °C are given as a rough guide.
The set positions can be affected by the location of the appliance in the room, how often the
door is opened or the load of food inside.
The temperature control position(s) may need to be changed to compensate for these factors.
Examples of locations:
- Unheated room in winter like a garage in a cold region.
- Kitchen/lounge area with normal heating.
- Room that is not air-conditioned in summer in a hot region.
lnstall this appliance at a location where the ambient temperature corresponds to the
climate class indicated on the rating plate of the appliance:
for refrigerating appliances with climate class:
- extended temperate: this refrigerating appliance is intended to be used at ambient
temperatures ranging from 10 °C to 32 °C; (SN)
- temperate: this refrigerating appliance is intended to be used at ambient temperatures
ranging from 16 °C to 32 °C;(N)
- subtropical: this refrigerating appliance is intended to be used at ambient temperatures
ranging from 16 °C to 38 °C;(ST)
- tropical: this refrigerating appliance is intended to be used at ambient temperatures
ranging from 16 °C to 43 °C;(T)
4

5FR
Aperçu de l’appareil
A
5EN
Overview of the appliance
A
1LED lighting 6Refrigerator shelves
2Door rack 7Refrigerator door racks
3Freezer shelves 8Refrigerator drawers
4Freezer door racks 9Adjustment foot
5Freezer drawer(s)
Description of the appliance
NOTE
The image opposite is provided for information purposes
only. Your model may differ from the illustration.

6FR 6EN
1In mode, the refrigerator automatically adjusts the temperature of the two
compartments depending on the internal and ambient temperatures.
2In mode, the refrigerator selects the setting which will consume the
minimum amount of energy.
3
In mode, the cooling compartment operates at its lowest temperature for
approximately 2,5 hours. At the end of this time, the temperature set
before activating this mode is automatically re-established.
In mode, the freezing compartment operates at its lowest temperature for
4 approximately 50 hours. At the end of this time, the temperature set before
activating this mode is automatically re-established.
5 LOCK, this symbol lights up if the buttons are locked.
6 Displays the temperature set for the freezer compartment
7 Displays the temperature set for the refrigeration compartment
When any door is left open or not closed completely for about 60 seconds, the appliance
will sound an alarm. Close the fridge door then the alarm will stop.
If the door is not well closed, then the alarm will sound every 35 seconds until the doors
are well closed.
If doors are open for 10 continuous minutes without closing, the internal LED light would
be turned off automatically.
Control panel
Buttons
APress this button to set the freezer (left-hand side) compartment temperature
from -14°C to -22°C.
BPress this button to adjust the temperature of the refrigeration compartment
(right-hand side) between 2 °C and 8 °C or to switch it off (OFF). If you choose
“OFF”, the refrigeration compartment will be turned off.
CPress this button to select the operating mode: SMART, ECO, SUPER
COOLING , SUPER FREEZING or USER ADJUSTMENTS (no symbol displayed).
DPress and hold this button for 3 seconds to lock the other 3 buttons. Press
this button for 1 second to unlock the other 3 buttons.
BB Using the appliance

7FR
Utilisation de l’appareil
B
7EN
Using the appliance
B
by a qualified electrician or other competent person.
• An approved maintenance centre should carry out maintenance on this appliance; Only
original spare parts may be used.• Do not put hot food in the appliance.
• Do not pile food up; this prevents the air from circulating properly;
• Make sure that food does not touch the back of the compartment(s).
• In the event of a power cut, do not open the door(s).
•Do not open the door(s) too often.
• Unpack the appliance and check that it is not damaged. Do not connect the appliance if it is
damaged. Notify the sales outlet from which you purchased the appliance immediately in case
of damage. Keep the packaging in this case.
• We recommend waiting for at least four hours before connecting the appliance to allow the
oil to return to the compressor.
• Make sure that air can circulate freely around the appliance to prevent overheating. Follow
the installation instructions to guarantee sufficient ventilation.
• Wherever possible, the product spacers should be installed against a wall so that users are
not at risk of touching or catching hot parts (compressor, condenser) and therefore not at risk
of burns.
• The appliance must not be installed in the vicinity of radiators or cookers.
• Make sure that the mains socket remains accessible once the appliance has been installed.
• Any electrical operations required when maintaining the appliance should be carried out
Installation
NOTE
Follow the instructions provided in the corresponding
paragraphs for all electrical connections.

8 FR
Utilisation de l’appareil
B
8 EN
Using the appliance
B
• Do not leave the door(s) open for too long.
• Do not adjust the thermostat to excessively cold temperatures.
• Certain accessories, such as the trays, can be removed to obtain a larger storage volume
and consume less energy.
Removing the doors
Tool required: cross-head screwdriver, flat screwdriver.
• Make sure that the appliance is unplugged and empty.
• To remove the door, you need to tilt the appliance backwards. It must rest on a solid surface,
to prevent it sliding while the door is removed.
• All the parts that have been removed must be kept in a safe place so that the door can be
replaced.
• Do not lie the appliance flat; this could damage the cooling system.
• It is preferable for 2 people to handle the appliance during assembly
1. Unscrew the hinge cover using the cross-head screwdriver.

9 FR
Utilisation de l’appareil
B
9 EN
Using the appliance
B
2. Disconnection the cable bundle.
3. Unscrew the upper hinge.
4. Lift the door and place on a soft, padded surface. Then remove the other door following the
same procedure.

10 FR
Utilisation de l’appareil
B
10 EN
Using the appliance
B
5. Unscrew the lower hinges.
6. Once the appliance is in position, replace the doors following the procedure in reverse.
Space required
• Choose a location which is not directly exposed to sunlight.
• Make sure that sufficient space is available so that the doors can be opened easily.
• Choose a place in which the ground is level (or almost level).
• Make sure that there is sufficient space for the refrigerator to be installed on a level surface.
• Allow space to the right, left, rear and above the appliance when you install it. This will help
to reduce its electricity consumption and thus your energy bills.

11 FR
Utilisation de l’appareil
B
11 EN
Using the appliance
B
Levelling and stabilizing the refrigerator
Doors
At least
50mm At least
50mm
135
1800
1490

12 FR
Utilisation de l’appareil
B
12 EN
Using the appliance
B
• Level and stabilize the refrigerator by adjusting the feet.
• Turn the feet clockwise to raise them manually.
• Turn the feet anticlockwise to lower them manually.
Environment
Install this appliance in a place in which the ambient temperature corresponds to the climate
class indicated on the nameplate.
Location
• The appliance must be installed at a distance from heat sources, such as radiators, boilers,
direct sunlight, etc. Ensure that air can circulate freely at the rear of the appliance. If the appliance
is positioned underneath a wall unit, the distance between the top of the appliance and the wall
unit should be at least 100 mm for optimum efficiency. In as far as possible, it is always preferable
not to position the appliance under wall cabinets The appliance can be levelled precisely thanks
to one or more adjustable feet at the bottom.
CAUTION
It must be possible to disconnect the appliance from the
electricity supply; The plug must be easily accessible after
installation.
Electrical connections
Before connecting the appliance, check that the voltage and frequency indicated on the nameplate
correspond to your domestic power supply. The appliance must be earthed. There is a contact
in the plug on the supply cable for this purpose. If your domestic power supply is not earthed,
connect the appliance to the earth by another means according to the regulations in force and
following the recommendations of a qualified electrician.
The manufacturer accepts no liability if the above-mentioned safety measures are not respected.
The appliance is compliant with European directives.

13 FR
Utilisation de l’appareil
B
13 EN
Using the appliance
B
Use
Before using the appliance for the first time
Cleaning the interior
Before using the appliance for the first time, wash the interior and all internal accessories with
lukewarm water and a neutral soap to remove the characteristic odour of new products. Then
dry thoroughly.
NOTE
Do not use abrasive powders or detergents as they will damage
the finish of the appliance.
Daily use
Freezing fresh food
• The freezing compartment is used to freeze fresh food and to keep food frozen and deep-
frozen for a long period of time.
• Place the fresh food that you wish to freeze in the lower compartment.
• The maximum quantity of food that can be frozen in 24 hours is indicated on the nameplate.
• The freezing process takes 24 hours; do not add any other food to be frozen during this
period.
Storing deep-frozen food
When using for the first time or after an extended period of downtime, allow the appliance to run
at the lowest temperature setting for at least 2 hours before placing products in the compartment.
NOTE
In the event of accidental defrosting (for example, if the
power is cut for a period longer than shown in the technical
specifications table under the heading “Rise in temperature
period”), the defrosted food must be eaten quickly or cooked
immediately and then refrozen (after cooking).

14 FR
Utilisation de l’appareil
B
14 EN
Using the appliance
B
CAUTION
The 2 star door rack, whose temperature is between -12°
and -18°, is not suitable for storing ice-cream.
Defrosting
Frozen or deep-frozen food can be defrosted in the refrigeration compartment or at room
temperature, depending on the time available, before they are used. Small amounts or pieces
of food can be cooked from frozen as soon as they are taken out of the freezer. In this case, they
will take longer to cook.
Accessories
Removable shelves
The refrigerant walls are fitted with different runners so that you can position the shelves as
you wish.
Positioning the door racks
The door racks can be positioned at different heights to allow you to store food packaging of
different sizes. Follow the method outlined below to make these adjustments: pull the tray
gradually in the direction of the arrows until this comes away completely. Then reposition these
to suit your needs.
Door rack
2 stars

15 FR
Utilisation de l’appareil
B
15 EN
Using the appliance
B
Useful hints and tips
Tips for freezing
Here is some important advice in order to optimise the freezing process:
• The maximum quantity of food that can be frozen in 24 hours is indicated on the nameplate.
• The freezing process lasts 24 hours. Additional food products should not be added during
this period.
• You should only freeze fresh, perfectly clean, high-quality food products.
• Prepare small portions so that they can freeze through quickly and so that you have the
option of only defrosting the quantity that you need.
• Wrap food in aluminium foil or cling film and make sure that the parcels are airtight.
• Do not allow fresh, unfrozen food to come into contact with food which is already frozen as
this would increase the temperature of the latter.
• Food which is low in fat keeps better and for longer periods than fatty foods. Salt reduces
the storage time of food.
• Ice cubes can cause burns linked to the cold if consumed straight from the freezer
compartment.
• Frozen food can cause burns linked to the cold if consumed just after they have been removed
from the freezer compartment.
• It is advisable to make sure that the date is visible on each individual frozen portion so that
its storage time can be monitored.
Advice for the storage of frozen food.
To optimise the performance of this appliance, you must:
- Ensure that deep-frozen food products have been stored correctly by the retailer;
- Ensure that deep-frozen food is transferred from the food store to your freezer as quickly
as possible;
- Avoid opening the door too often or leaving it open for longer than is necessary;
• Avoid re-freezing defrosted food, as it will spoil quickly;
• Avoid exceeding the use-by date indicated by the manufacturer.

16 FR 16 EN
B
Advice for the refrigeration of fresh food
For optimum performance:
• Do not put hot food or liquids which evaporate in the refrigerator.
• Cover or wrap food, particularly if it has a strong flavour.
Refrigeration advice
Useful tips:
• Make sure that food is wrapped in polythene bags and placed on the glass shelves above
the vegetable compartment.
• As a precaution, only keep food in this way for a maximum of one or two days.
• Cooked food, cold dishes, etc. : these products should be covered and may be placed on any
of the shelves.
• Fruits and vegetables: these products must be washed thoroughly and placed in the specific
compartment(s) provided.
• Butter and cheese: these products must be placed in special, airtight containers or wrapped
in aluminium foil or polythene bags to expel as much air as possible.
• Bottles of milk: these products must be fitted with a lid and kept in the door racks.
• Bananas, potatoes, onions and garlic should not be kept in the refrigerator unless they are
wrapped.
Using the appliance

17 FR
Utilisation de l’appareil
B
17 EN
Using the appliance
B
CAUTION
When you adjust the temperature, this will be an average
temperature inside the entire refrigerator unit.
CAUTION
The temperatures inside each compartment may therefore
differ from the temperature values indicated on the panel,
depending on the quantity of food stored and the way it has
been positioned. The ambient temperature may also cause
the temperature inside the appliance to vary.
Temperature Setting Recommendation
Environment Temperature Temperature Setting
Thermostat setting for ambient T°C :
Fridge set on 3°C
NORMAL ≈ +24°C (± 4°C) Freezer set on -18°C
Thermostat setting for ambient T°C :
Fridge set on 3°C
COLD ≈ +16°C (± 4°C)
Freezer set on -18°C
Thermostat setting for ambient T°C :
Fridge set on 3
°C
WARM ≈ +32C (± 4°C)
Freezer set on -19°C
• Information above give users recommendation of temperature setting.
Impact on Food Storage
• Under Recommended setting, the best storage time of fridge is no more than 3 days.
• Under Recommended setting, the best storage time of freezer is no more than 1 month.
• The best storage time may reduce under other settings.

18 FR
Informations pratiques
C
18 EN
Useful information
C
Cleaning and maintenance
For hygiene reasons, the interior of the appliance and its
interior accessories should be cleaned regularly.
CAUTION
Risk of electric shock! The appliance must not be
connected to the mains during cleaning. Before
cleaning, switch off the appliance and disconnect
the plug from the power supply or turn off the circuit
breaker or remove the fuse.
CAUTION
Never clean the appliance using a steam cleaner. Moisture
could accumulate in the electrical components which
could create a risk of electric shock! Hot vapour could
damage plastic parts. The appliance must be completely
dry before it is switched on again.
CAUTION
Essential oils and organic solvents, such as lemon juice or
juice from orange rind, butyric acid and cleaning products
containing acetic acid can attack plastic parts.

19 FR
Informations pratiques
C
19 EN
Useful information
C
• Do not allow these substances to come into contact with appliance
parts.
• Do not use any abrasive product.
• Remove food from the freezer. Cover and place them in a cool place.
• Switch off the appliance and remove the mains plug or switch off the
appliance and turn off the circuit breaker or remove the fuse.
• Clean the appliance and interior accessories using a cloth soaked in
lukewarm water. After cleaning, rinse with clean water and dry with a
cloth.
• Once everything is dry, you can switch the appliance back on again.
Troubleshooting
CAUTION
Disconnect the power supply before carrying out any repair
work. Only an authorised electrician or other qualified
individual may carry out repair work which is not described
in this manual.
NOTE
Certain noises can be heard during normal use
(compressor, coolant circulation).
NOTE
LED bulbs cannot be replaced by the user. Contact the
after sales service in the event of a malfunction.
