VALBERG CNF 268 F WD B625C2 User manual

EN
WARRANTY CONDITION
This product is guaranteed for a period of 2 years from the date of purchase* against any failure
resulting from a manufacturing or material defect. This warranty does not cover defects or
damage resulting from incorrect installation, improper use or abnormal wear of the product.
*on presentation of the receipt.
FR
CONDITION DE GARANTIE
Ce produit est garanti pour une période de 2 ans à partir de la date d’achat*, contre toute
défaillance résultant d’un vice de fabrication ou de matériau. Cette garantie ne couvre pas les
vices ou les dommages résultant d’une mauvaise installation, d’une utilisation incorrecte ou
de l’usure anormale du produit.
*sur présentation du ticket de caisse.
NL
GARANTIEVOORWAARDEN
Dit product wordt gegarandeerd voor een periode van 2 jaar vanaf de aankoopdatum*, voor
elke storing die het gevolg is van een fabricagefout of het materiaal. Gebreken of schade door
slechte installatie, onjuist gebruik of abnormale slijtage van het product worden niet gedekt
door deze garantie.
*op vertoon van kassabon.
ES
CONDICIONES DE GARANTÍA
*previa presentación del comprobante de compra.
MADE IN PRC
ELECTRO DEPOT
1 route de Vendeville
59155 FACHES-THUMESNIL
FRANCE
975261 - CNF 268 F WD B625C2
975263 - CNF 268 F WD S625C2
INSTRUCTIONS FOR USE ....................02
CONSIGNES D'UTILISATION ....................22
GEBRUIKSAANWIJZINGEN ....................42
INSTRUCCIONES DE USO ....................62
2/2 07/2022 - V3
Fridge - freezer
Réfrigérateur - congélateur
Koelvrieskast
Frigorífico - congelador
El certificado de garantía de este producto tiene una duración de 2 años a partir de la fecha de
compra* que se limita a los defectos de fabricación y averías del material. Se excluyen de la
garantía deficiencias o daños originados por una mala instalación, errores en la manipulación
o por un uso inadecuado.

1
2
3
4
5
6
7

2 FR
A
2 EN
Thank you!
Thank you for choosing this VALBERG product.
The VALBERG products which have been chosen,
tested and recommended by ELECTRO DEPOT,
are easy to use, reliable and of an impeccable
standard.
Satisfaction guaranteed every time you use this
appliance.
Welcome to ELECTRO DEPOT.
Visit our website: www.electrodepot.fr

3 FR
Aperçu de l’appareil
A
3 EN
Table of contents
AOverview of the
appliance
CUseful information
BUsing the appliance Installation
Temperature indicator
Use
Cleaning and maintaining the appliance
Troubleshooting guide
Recommended ambient temperatures
Temperature control adjustment
Description of the refrigerator

4 EN
Overview of the appliance
A
Recommended ambient temperatures
Respect the climatic classes indicated in the product information on the appliance's nameplate.
You can use this to check the recommended temperature range of the room where the appliance
is located:
- SN: Between 10 and 32°C
- N: Between 16 and 32°C
- SN: Between 16 and 38°C
- Tel.: Between 16 and 43°C
A multi-class appliance may generate the lowest and highest temperatures for all classes
covered. Use of the appliance outside the ambient temperature range may affect its performance
and lifespan.
Temperature control adjustment
For optimal use and to save energy, adjust the temperature control(s) of the appliance according
to the ambient temperature of the room in which it is being used and respect the climatic class.
Refer to the product sheet to find out the climatic class associated with the minimum and
maximum recommended ambient temperatures for the appliance as well as the temperature
setting recommended for storing food under optimal conditions.
The ambient temperatures in °C are given as a rough guide.
The set positions can be affected by the location of the appliance in the room, how often the
door is opened or the load of food inside.
The temperature control may need to be changed to compensate for these factors.
Examples of locations:
- Room which is unheated in winter, such as a garage in a cold region.
- Living area which is normally heated, such as a kitchen.
- Room with no air conditioning in summer in a hot region

5 EN
Overview of the appliance
A
1 Temperature control and light
adjustment 5Freezer drawers
2Ventilation sounds 6Trays and water tank
3Shelf 7Adjustable feet
4Crisper
Description of the refrigerator

6 EN
Using the appliance
B
Installation
If this appliance with a magnetic closure is intended to replace one with a spring closure, we
recommend that you deactivate the latter before disposing of the appliance. This will prevent
children from becoming trapped inside and putting their lives at risk.
Location
- Position your appliance away from sources of heat (heating, cooker, sunlight). The ambient
temperature in the room should be between + 10 °C and + 43 °C (class ST) to allow the appliance
to run at its optimum capacity. The appliance will not operate normally outside these limits.
- This appliance should be installed in such a way that the plug remains accessible.Make
sure that it is not resting on the supply cable after installation.
- Level the appliance by means of the 2 adjustable feet.
- Make sure that air can circulate freely behind the appliance and do not place it against a
wall to prevent noise due to vibration. Ensure that air can circulate freely around the appliance.
Insufficient ventilation would reduce efficiency and increase energy consumption.

7 EN
Using the appliance
B
Connecting to the mains.
Your appliance is designed to operate at a single-phase voltage of 230 volts. It must be connected
to a plug with an earth contact and protected by a fuse. The electrical system must be compliant
with standard NF C 15-100.
DOOR
You can change the direction in which you appliance door opens by moving the hinges. Make
sure that the door is correctly aligned with the unit and that the seal is properly stuck down
when replacing the door.
We should remind you that the appliance must be unplugged when changing the direction
of the door.
You should prepare a foam support or similar material before positioning the refrigerator on
its back to access the base in order to prevent the cooling circuit at the back of the refrigerator
from being damaged.
Remove the hinge cover
Loosen the screws used to attach the upper right door hinge.
Self-tapping
screws with
special base
Upper left hinge

8 EN
Using the appliance
B
Remove the rod from the upper hinge, position on the other side and tighten firmly.
Lift off the lower door and position it on a surface which will not cause damage.
Loosen the screw attaching the door stop and install on the left side.
Note: When you remove the door, make sure that the washer located between the central hinge
and the bottom of the freezer door does not get lost.
Loosen the screws attaching the central hinge and remove the central hinge holding the lower
door in place.
-
Central hinge
Screw attaching the
central hinge
Lift off the lower door and position it on a surface which will not cause damage, then replace
the hinge cover on the other side.
Remove the screw covers from the left central hinge and place them over the uncovered holes
on the right side.
Screw cover
Screw cover
Screw cover
Screw cover
Lay the refrigerator on a foam support or similar material in order to prevent the cooling circuit
at the back of the refrigerator from being damaged.

9 EN
Using the appliance
B
Remove the two adjustable feet at the bottom and then remove the attachment plate and the
lower hinge.
Front
foot attachment
plate
Adjustable
lower foot
Screw attaching
the front
foot plate
Lower
hinge
Adjustable
lower foot
Screw attaching
the front
foot plate
Place the lower hinge on the left side and screw in place.
Place the attachment plate on the right side and screw in place. Replace the adjustable feet by
screwing them in place.
Lower
hinge
Front
foot attachment
plate
Install the lower door making sure that it does not fall.
Position the central hinge opposite its previous position and adjust. Screw the central hinge in
place.
Install the upper door making sure that it does not fall. Position the upper hinge and the upper
hinge axis in the hole of the upper door and adjust the position of the upper door.
Attach the upper hinge correctly with the screws.
Replace the upper hinge cover.
Upper
hinge

10 EN
Using the appliance
B
Temperature indicator
Your appliance is fitted with a temperature indicator located in the coldest area to help you to
adjust you appliance correctly.
In order to properly preserve the food in the refrigerator, particularly in the coldest part, make
sure that the temperature indicator shows the word "OK".
The symbol opposite indicates the coldest zone in your refrigerator. It defines the
top of this area.
If the word “OK” is not shown, the average temperature in this area is too high. Adjust
the temperature control to a colder position.
Each time the temperature adjustment button is changed, wait for the temperature inside the
appliance to stabilise before making a new adjustment, if this is necessary. Change the position
of the temperature control gradually and wait for at least 12 hours before checking again.
NB: after filling the appliance with fresh food or after opening the door repeatedly (or for a
prolonged period), it is normal for the "OK" message to disappear from the temperature indicator.
Wait at least 12 hours before resetting the temperature control.
Use
Starting
Once the appliance is correctly installed, we recommend that you clean the interior with slightly
soapy warm water (washing-up liquid).
Do not use an abrasive product or scouring powder as this could damage the finish.
Use
Household refrigerators are intended exclusively for the preservation of fresh food and drinks
and the short-term preservation of frozen products.
Food safety
The increasing consumption of ready meals and other sensitive foods means that the transport
and storage temperature of food needs to be better controlled:
• Store the most sensitive foods in the coldest zone of the appliance according to the indications
provided in this manual (temperature indicator section).
• Limit the number of times the door is opened.
• Position the temperature control adjustment to reduce the temperature. This adjustment
must be made gradually to prevent the food from freezing.

11 EN
Using the appliance
B
• Clean the interior of the refrigerator regularly.
When starting it up the first time, the display screen (including the indicator light of the button)
will switch on completely for 3 seconds and then the appliance will run on the intermediate
program (programme 3, at a temperature of 4°C) with the corresponding LED on.
Temperature setting
Rapid refrigeration
The interior temperature is adjusted using the electronic temperate control which is activated
using the button inside the appliance (see “Description of the appliance”, point n°1).
Press the SET button to change the mode or temperature of your appliance. The refrigerator
will set itself to the mode indicated if you do not press any button for 15 seconds.
Rapid
ref
Fast refrigeration function
This model allows a temperature of 2°C to be maintained inside the unit for a fixed length of
time (2.5 hours); in order to cool food more quickly. For example, after completely filling the
refrigerator.
Stopping the mode:
1.After the refrigerator has been running for 2.5 hours in the fast refrigeration mode, it will
automatically return to the previous mode.
2.When you select another mode, the rapid refrigeration mode will automatically stop.
Storing food
Food preservation can be improved by placing it in the suitable location for the food type concerned.

12 EN
Using the appliance
B
The coldest zone of the refrigerator compartment is located at the bottom of the appliance
above the crisper.
Food placement:
• On the shelves: cooked foods, desserts and all items that need to be consumed quickly,
fromage frais, cold cuts.
• On the glass above the crisper: fresh meat, poultry, fish. Storage time 1 to 2 days.
• In the crisper : fruit and vegetables.
• In the door frame: in the bottom tray: Bottles, with the following items higher up: small
items (cream, yoghurt, etc.). Butter and eggs should be placed in the upper tray.
For optimum food hygiene:
Remove packaging before placing food inside the refrigerator. (e.g. packaging of packs of
yoghurt, etc.).
Wrap food items in containers of an appropriate quality to prevent bacteria from being transferred
between food.
Leave prepared food to cool before placing in the appliance.
Setting the temperature of the freezer compartment
(summer) (winter)
Ambient temperature T°C Freezer temperature
control
Thermostat setting for ambient T°C : NORMAL ≈ +24°C (± 4°C) 4°C / NORMAL
Thermostat setting for ambient T°C : COLD ≈ +16°C (± 4°C) 4°C / COOLER
Thermostat setting for ambient T°C : HOT ≈ +32°C (± 4°C) 3°C / COOL

13 EN
Using the appliance
B
Water distributor
Dispenser Stopper Lid
Handle
Tank
Piston
NOTE
Before using the water dispenser for the first time, lift it
out carefully holding with both hands. Unscrew the spout
and clean it and the tank with soap and water.

14 EN
Using the appliance
B
ASSEMBLYOnce the components have been cleaned and dried, assemble in the following
order: screw in the spout, lid and stopper.
WARNING
Make sure that the spout is inserted correctly in the hole
provided (1) when assembling the tank. Installing the
tank in the door (2).
Check the vertical and horizontal alignment of the tank
in the door (3) and (4).
FILLING
Before filling the tank, make sure that it is correctly positioned and stable. Do not exceed the 3
litre limit when filling the tank.
The tank can be filled by taking out the stopper and removing the lid.
WARNING
Take care not to touch any other parts when filling the
tank as this could damage the water dispensing system
and cause leaks.

15 EN
Using the appliance
B
Locking
Water Dispenser
DISTRIBUTION
Make sure that the lid and stopper are correctly positioned before starting to distribute water.
Water can only be distributed if the refrigerator door is closed.
Make sure that the lock is in “Unblocked” position before distribution. Water distribution is
deactivated when the safety system is in “Blocked” position. This prevents children from spilling
water for example.
Dispenser lever
Suggested position
WARNING
Do not press the lever when the dispenser is blocked as
this could damage the dispenser mechanism.
NOTE
The only containers that may be used are the glasses
and goblets provided.

16 EN
Using the appliance
B
Water collection tank Wire grill
CLEANING
Lift the tank carefully by holding it in both hands.
Unscrew the spout and clean it and the tank with soap and water, leaving them to dry in the
open air or dry with a soft cloth.
The water collection tank may start to overflow after it has been used several times. Wipe down
regularly with a dry cloth to prevent overflowing. Remove the wire grill at the top of the water
collection tank to do so.
FREEZER COMPARTMENT
The freezer compartment can be used to freeze fresh products and to store frozen products.
The quantity of food to be frozen must not exceed the quantity written on the nameplate. If the
quantity to be frozen exceeds this value, it is still possible to freeze the food in separate parcels.
Freezing fresh food
• Only freeze high-quality food after it had been cleaned and prepared if necessary.
• Allow prepared foods to cool down to ambient temperature before placing them in the freezer.
• All products to be frozen must be wrapped in polyethylene bags, aluminium freezer trays or
plastic boxes. These parcels must be tightly sealed.
• The size of each parcel should corresponds to the quantity consumed by the family so that they
can be used at a single sitting. Products can be frozen quickly and evenly if the parcels are small.
• Do not freeze quantities exceeding the freezing capacity of the appliance indicated on the
nameplate all at once.
• A defrosted product must never be refrozen.
• Do not place liquids in their glass packaging, bottles or cans of zzy drinks in the freezer
as they could explode.
• Do not consume ice lollies straight from the freezer as this can cause burns linked to the cold.

17 EN
Using the appliance
B
Freezing fresh products:
Adjust the temperature control to obtain the lowest temperature possible without allowing it to
fall below 0° in the refrigerator.
Do not open the freezer door during freezing.
Leave the appliance in freezing mode for 24 hours and then reposition the temperature control
button in the central position after this period of time.
Storing frozen food
• Frozen products can be grouped together to leave space free for freezing.
• When you purchase a frozen product, make sure that the packaging is intact, shows no traces
of humidity and is not inflated, which is an indication that defrosting has started.
• Respect the storage period indicated by the manufacturer on frozen products.
• Avoid opening the door too frequently and only leave it open for as long as is necessary. An
increase in temperature can reduce the storage period of food.
Defrosting
Meat, poultry and fish should be defrosted in the refrigerator to prevent bacteria from developing.
Other products may be defrosted in ambient air.
Small portions of food can be cooked straight from the freezer. Many ready meals can also
be cooked without having to be defrosted first. Always follow the instructions provided on the
packaging.
Bread and pastries can be defrosted in a warm oven.
Microwaves can be used to defrost most types of food. Follow the instructions provided in the
microwave manual.
NOTE
In the event of a power cut, frozen food will not be affected if
the appliance is switched off for less than 15 hours. However,
you should avoid opening the door (the time taken for the
appliance to return to the required temperature can be
significantly reduced if the appliance is fairly empty). As
soon as you notice signs of defrosting, the food should be
consumed as quickly as possible. Never refreeze food that
has already been defrosted.

18 EN
Useful information
C
Defrosting
‘No-Frost’ refrigerators and freezers which do not allow frost or ice to form do not require any
intervention for defrosting.
CLEANING
Unplug the appliance before cleaning. Never use abrasive products or scouring
sponges to clean the interior or exterior of your appliance.
• Remove all accessories (shelves, trays, crisper). Wash with warm water and a small amount
of gentle, odourless detergent (washing-up liquid for example), rinse with chlorinated water
and dry thoroughly.
• Wash the interior walls in the same way; pay particular attention to the cleanliness of the
shelf supports.
• Wash the door seal, not forgetting also to clean underneath the seal.
• Plug the appliance back in.
Clean the freezer every time you defrost it.
Dust the condenser at the back of the appliance from time to time; An accumulation of dust
could reduce the efficiency of the appliance.
Empty and clean the appliance if it has not been used for a long time; keep the door ajar
during the period of downtime.
REPLACING THE LIGHTBULB
This product contains a light source of energy
efficiency class F. Light source in this product can
only be replaced by qualified professionals.
Please contact after-sales service if the light source
fails.
The light source shall be removed at the end of
the product's useful life, with sorting and recycling
done separately.
Cleaning and maintaining the appliance

19 EN
Useful information
C
LED display in normal operation
• Should a malfunction occur, the corresponding LED fault indicator switches on and an error
code is displayed (display on a loop).
• During normal operation, the corresponding LED indicator is on, indicating the current ope-
rating mode of the refrigerator.
If you have problems with your appliance or think that it is not working properly, you can carry
out a few simple checks before contacting the customer services department by referring to the
table below: Warning! Do not try to repair the appliance yourself. Contact a qualified electrician,
an approved maintenance technician or the store from which you purchased the appliance if the
problem persists after you have checked the following points.
Problems Possible causes and solutions
The appliance does not work
properly.
Check whether the supply cable is properly connected.
Check the fuse or your power supply circuit and make any necessary
replacements.
The ambient temperature is too low. Try to increase the temperature
in the room.
Odours in the compartments
The interior of the appliance may need to be cleaned.
Certain foods, containers or packaging may give off odours.
Noises in the appliance
The following noises are fairly common:
• Noise of the compressor in operation.
• Rattling before the compressor starts.
Other unusual noises caused by the following may require your
intervention:
• The appliance is not level.
• The back of the appliance is touching the wall.
• Bottles or containers or rolling or falling.
It is normal to hear frequent noise coming from the motor, which
will run more under the following conditions:
• The temperature settings are colder than necessary.
Troubleshooting guide
