VALBERG SBS 529 WD F X742C User manual

EN
WARRANTY CONDITION
This product is guaranteed for a period of 2 years from the date of purchase* against any failure
resulting from a manufacturing or material defect. This warranty does not cover defects or
damage resulting from incorrect installation, improper use or abnormal wear of the product.
*as shown on the sales receipt.
FR
CONDITION DE GARANTIE
Ce produit est garanti pour une période de 2 ans à partir de la date d’achat*, contre toute
défaillance résultant d’un vice de fabrication ou de matériau. Cette garantie ne couvre pas les
vices ou les dommages résultant d’une mauvaise installation, d’une utilisation incorrecte ou
de l’usure anormale du produit.
*sur présentation du ticket de caisse.
NL
GARANTIEVOORWAARDEN
Dit product wordt gegarandeerd voor een periode van 2 jaar vanaf de aankoopdatum*, voor
elke storing die het gevolg is van een fabricagefout of het materiaal. Gebreken of schade door
slechte installatie, onjuist gebruik of abnormale slijtage van het product worden niet gedekt
door deze garantie.
*op vertoon van kassabon.
ES
CONDICIONES DE GARANTÍA
El certificado de garantía de este producto tiene una duración de 2 años a partir de la fecha de
compra* que se limita a los defectos de fabricación y averías del material. Se excluyen de la
garantía deficiencias o daños originados por una mala instalación, errores en la manipulación
o por un uso inadecuado.
*previa presentación del comprobante de compra.
MADE IN PRC
ELECTRO DEPOT
1 route de Vendeville
59155 FACHES-THUMESNIL
FRANCE

967657 - SBS 529 WD F X742C
INSTRUCTIONS FOR USE ....................02
CONSIGNES D'UTILISATION ....................20
GEBRUIKSAANWIJZINGEN ....................40
INSTRUCCIONES DE USO ....................60
2/2 09/2022 - V4
Fridge - freezer
Réfrigérateur - congélateur
Koelvrieskast
Frigorífico - congelador

1 2
3
4
5
6
7
8
9
10

A B
C D
a b c d e
f g

2 FR
A
2 EN
Thanks!
Thank you for choosing this VALBERG product.
Chosen, tested and recommended by ELECTRO DEPOT,
VALBERG branded products are easy to use, reliable,
and of an impeccable standard.
With every use of this appliance, you can be sure of
complete satisfaction.
Welcome to ELECTRO DEPOT.
Visit our website: www.electrodepot.fr

3 FR
Aperçu de l’appareil
A
3 EN
Table of contents
AOverview of the
appliance
CUseful information
BUsing the appliance Installation
Before using the appliance for the first time
Daily use
Using the water dispenser
Useful hints and tips
Cleaning and maintenance
Troubleshooting
Disposing of your old appliance
Recommended ambient temperature
Temperature control adjustment
Description of the appliance
Control panel

4 FR
Aperçu de l’appareil
A
4 EN
Overview of the appliance
A
Ambient temperatures of use
Respect the climate classes indicated in the product information on the appliance's nameplate.
You can use this to check the recommended temperature range of the room where the appliance
is located:
- SN: Between 10 and 32°C
- N: Between 16 and 32°C
- ST: Between 16 and 38°C
- T: Between 16 and 43°C
A multi-class appliance can handle the lowest and highest temperature of all classes covered.
Using the appliance outside the recommended temperature range will lead to inferior performance
and premature ageing.
Adjusting the thermostat
For optimal use and energy savings, adjust the temperature control(s) of the appliance according
to the ambient temperature of the room, in which it is being used, and respect the climate class.
Refer to the product sheet to find out the climate class associated with the minimum and
maximum recommended ambient temperatures for the appliance as well as the temperature
setting recommended for storing food under optimal conditions.
The ambient temperatures in °C are given as a rough guide.
The set positions can be affected by the location of the appliance in the room, how often the
door is opened or the load of food inside.
The temperature control position(s) may need to be changed to compensate for these factors.
Examples of locations:
- Unheated room in winter like a garage in a cold region.
- Kitchen/lounge area with normal heating.
- Room that is not air-conditioned in summer in a hot region.

5 FR
Aperçu de l’appareil
A
5 EN
Overview of the appliance
A
Description of the appliance
Control panel
BUTTONS
APress this button to set the freezer (left-hand side) compartment temperature
from -14°C to -22°C.
B
Press this button to set the refrigeration (right-hand side) compartment
temperature from 2°C to 8°C, or to turn if off (“OFF”). If you choose “OFF”, the
refrigeration compartment will be turned off.
CPress this button to select the operating mode: “SMART”, “ECO”, “SUPER
COOLING”, “SUPER FREEZING” or USER SETTING (no symbol shown).
DPress and hold this button for 3 seconds to lock the other 3 buttons.
Press this button for 1 second to unlock the other 3 buttons.
1Freezer shelf 6Refrigerator vegetable drawer
2Refrigerator shelf 7Adjustable feet
3Refrigerator door tray 8Freezer drawer
4Water tank 9Freezer drawer cover
5Refrigerator vegetable drawer
cover 10 Freezer door tray

6 FR
Aperçu de l’appareil
A
6 EN
Overview of the appliance
A
DISPLAY
Door open alarm
If one of the doors remains open for 90 seconds, an alert will sound regularly until the door
is closed.
AIn “SMART” mode, the refrigerator automatically adjusts the temperature of both
compartments, depending on the internal and ambient temperatures.
BIn “ECO” mode, the refrigerator selects the setting allowing for minimal energy
consumption
C
In “SUPER COOLING” mode, the refrigeration compartment operates at its
lowest temperature for approximately 2 hours. At the end of this time, the
temperature set before activating this mode is automatically re-established.
D
In “SUPER FREEZING” mode, the freezer compartment operates at its lowest
temperature for approximately 6 hours. At the end of this time, the temperature
set before activating this mode is automatically re-established.
E“LOCK”: this symbol lights up if the buttons are locked.
FDisplays the temperature set for the freezer compartment
GDisplays the temperature set for the refrigeration compartment

7 FR
Utilisation de l’appareil
B
7 EN
Using the appliance
B
Installation
If your kitchen door opening is not wide enough for the refrigerator to pass through, the doors
and handles of the appliance can be removed by following the procedure below.
Removing the handles
Tool required: spanner from the accessories bag.
• Ensure that the appliance is unplugged and empty
• All the parts removed must be kept so that the handles can be replaced afterwards.
• Unscrew the handles using the spanner.
• Pull on the handles to remove them.
• One the appliance is in place, replace the handles by reversing the above procedure.

8 FR
Utilisation de l’appareil
B
8 EN
Using the appliance
B
Removing the handles
Tool required: Phillips screwdriver, flat screwdriver.
• Ensure that the appliance is unplugged and empty.
• The appliance must be tilted backwards slightly to remove the door. It must rest on a solid
surface, to prevent it sliding while the door is removed.
• All the parts removed must be kept so that the door can be replaced afterwards.
• Do not lay the appliance flat, as this would risk damaging the cooling system.
• It is preferable for the appliance to be handled by 2 people during assembly.
• Unscrew the hinge cover using the Phillips screwdriver.
• Unplug the electrical loom.

9 FR
Utilisation de l’appareil
B
9 EN
Using the appliance
B
• One the appliance is in place, replace the doors by reversing the above procedure.
• Unscrew the upper hinge.
• Lift off the door and place this on a soft, padded surface. Then remove the other door
following the same procedure.
• Unscrew the lower hinges.

10 FR
Utilisation de l’appareil
B
10 EN
Using the appliance
B
Space required
• Choose a location which is not directly exposed to sunlight.
• Ensure there is sufficient space to be able to open the refrigerator doors easily.
• Select an area where the floor is level (or almost level).
• Make sure that there is sufficient space for the refrigerator to be installed on a level surface.
• Allow space to the right, left, rear and above the appliance when you install it. This will help
to reduce its electricity consumption and thus your energy bills.
100mm
50 mm
50 mm
1200 mm
1400 mm
130°
At least At least

11 FR
Utilisation de l’appareil
B
11 EN
Using the appliance
B
Levelling and stabilizing the refrigerator
• Level and stabilize the refrigerator by adjusting the feet.
• Turn the feet clockwise to raise these up manually.
• Turn the feet anticlockwise to lower these manually.
Placement
Install this appliance in a place in which the ambient temperature corresponds to the climate
class indicated on the nameplate.
Location
• The appliance must be installed at a distance from heat sources, such as radiators, boilers,
direct sunlight, etc. Ensure that air can circulate freely at the rear of the appliance. For optimum
operation, if the appliance is placed under a wall cabinet, the distance between the top of the
appliance and the wall cabinet must be at least 100 mm. In as far as possible, it is always
preferable not to position the appliance under wall cabinets The appliance can be levelled
precisely thanks to one or more adjustable feet at the bottom.
CAUTION
You must be able to unplug the appliance from the mains;
the socket must therefore be easily accessible after
installation.
Electrical connections
• Before plugging in the appliance, check that the voltage and frequency shown on the rating
plate match your domestic electricity supply.
This appliance must be earthed. The plug on the power cord is equipped with a pin for this
purpose. If your domestic electricity supply socket is not earthed, earth the appliance in another
way, in accordance with the regulations in force and after consulting a qualified electrician. The
manufacturer declines any liability if the aforementioned safety measures are not taken. This
appliance complies with European regulations.
Doors

12 FR
Utilisation de l’appareil
B
12 EN
Using the appliance
B
Before using the appliance for the first time
Cleaning the inside
• Before using the appliance for the first time, wash the interior and all the interior accessories
with warm water and a neutral soap, in order to remove the characteristic new appliance smell.
Then dry thoroughly.
NOTE
Do not use abrasive detergents or scouring powders, as
these damage the appearance of the appliance.
Daily use
Freezing fresh food
• The freezer compartment allows for freezing fresh food and keeping frozen food for a long
period of time.
• Place the fresh food you wish to freeze into the lower compartment.
• The maximum quantity of food that can be frozen in 24 hours is indicated on the nameplate.
• The freezing process takes 24 hours: do not add other food to be frozen during this time.
Storing deep-frozen food
• When using for the first time or after an extended period of downtime, allow the appliance
to run at the lowest temperature setting for at least 2 hours before placing products in the
compartment.
NOTE
In the event of accidental defrosting (for example, if the
power is cut for a period longer than shown in the technical
specifications table under the heading “Rise in temperature
period”), the defrosted food must be eaten quickly or cooked
immediately and then refrozen (after cooking).
Defrosting
• Before use, deep-frozen or frozen food items can be thawed in the refrigerator compartment
or at room temperature, depending on how much time you have to do this.

13 FR
Utilisation de l’appareil
B
13 EN
Using the appliance
B
• Small or chopped food items can even be cooked from frozen without defrosting. In this
case, the cooking time is longer than usual.
Accessories
Removable shelves
• The refrigerator walls are fitted with a series of runners allowing the shelves to be positioned
as desired.
Positioning the door shelves
• The door trays can be positioned at different heights so that you can store food containers of
varying sizes. To adjust these settings, proceed as follows: pull the tray gradually in the direction
of the arrows until this comes away completely. Then reposition these to suit your needs.
