Vanco Evolution EVMX44PRO User manual

4K 4x4 HDBaseT™
Audio and Video Matrix
Switcher with ARC, IR,
IP and RS-232
Part Number:
EVMX44PRO
www.vanco1.com • 800.626.6445
4K HDBaseT™4x4
MAT R I X
with ARC, IR, IP and RS-232

www.vanco1.com 800.626.6445 2
1. Do not expose this unit to water, moisture, or
excessive humidity.
2. Do not install or place this unit in a built-in
cabinet, or other conned space without
adequate ventilation.
3. To prevent risk of electrical shock or re
hazard, due to overheating do not obstruct
unit’s ventilation openings.
4. Do not install near any source of heat,
including other units that may produce heat.
5. Do not place unit near ames.
6. Only clean unit with a dry cloth.
7. Unplug unit during lightening storms or when
not used for an extended period of time. A
surge protector is strongly recommended.
8. Protect the power cord from being walked on
or pinched, particularly at the plugs.
9. Use unit only with accessories specied by
the manufacturer.
10. Refer all servicing to qualied personnel.
CAUTION
HDMI is a very complex technology requiring continuous authentication of the signal and the same
video resolution and audio settings on all electronic equipment in the system. When there are multiple
sources and displays, the video resolution and audio setting on all connected units must be adjusted
to correspond with that of the display having the lowest video and audio capability.
WARNING
DEAR CUSTOMER
Thank you for purchasing this product.
For optimum performance and safety, please
read these instructions carefully before connecting, operating or
adjusting this product. Please keep this manual for future reference.
This product is 100% inspected and tested in the United States to verify
HDMI performance parameters.

www.vanco1.com 800.626.6445 3
INTRODUCTION
The Evolution by Vanco EVMX44PRO 4K 4x4 HDBaseT™ Audio and Video Matrix Switcher with ARC, IR, IP and RS-232 allows
4 HDMI sources to be distributed to up to 4 displays simultaneously, with mirrored HDMI outputs for a total of 8 outputs! The
EVMX44PRO is capable of transmitting 4K@60Hz, 4:4:4 Chroma Subsampling, and HDR up to 131ft/40m over a single Cat6
cable, and 4K@60Hz, 4:4:4 Chroma Subsampling with HDR10 and Dolby Vision on the HDMI inputs and HDMI outputs. For
control, the EVMX44PRO features multiple methods including simple control using the front panel control, IR control, RS-232,
and an easy to use UI accessible via IP. Control switching sources to displays from a computer or a wireless device such as
a tablet or mobile phone. Need an audio matrix as well? The EVMX44PRO also features the ability to send any HDMI audio
input to up to 4 zones. Compatible with both the EVRXHD2 and EVRXDSC HDBaseT receivers to create a modular matrix
unit, add downscaling, ARC, audio extraction, and RS-232 to any HDBaseT output. For switching multiple sources to multiple
displays using HDBaseT technology, with many features for control, audio switching, ARC, 4K HDR resolution, and scaling, the
EVMX44PRO is a great choice for any application.
FEATURES
4K 4x4 HDBaseT™ Audio and Video Matrix Switcher with ARC, IR, IP and
RS-232
Part # EVMX44PRO
• 4K 4x4 HDBaseT Matrix with mirrored HDMI outputs
• Extends 4K@60Hz 4:4:4, and HDR10 up to 131ft/40m over a single Cat6 cable
• Outputs 4K@60Hz 4:4:4, HDR10 and Dolby Vision on the HDMI inputs and HDMI outputs
• Extends 1080p resolution up to 230ft/70m over a single Cat6 cable
• HDCP 2.2 compliant
• Two receiver options that are sold separately (EVRXHD2 and EVRXDSC) based on features required
• Features POC (Power over Cable) technology - providing power for either receiver option
• Downscales 4K to 1080p on all HDMI outputs as well as HDBaseT outputs using EVRXDSC receiver
• ARC (Audio Return Channel) capable with EVRXDSC receiver
• Includes built-in audio matrix with digital and analog audio outputs for up to 4 zones
• Built-in EDID management and advanced HDCP handling
• Controllable via front panel, IR, RS-232 and third party control systems, as well as a built in GUI via IP
connection
• Features IR, IP and RS-232 for control
• Includes EV-IRMST IR integration cable for seamless integration with 3rd Party IR Systems
• Dimensions: 17.2” W x 1.7” H x 14” D
• EVMX44PRO HDBaseT Matrix Switcher
• (2) Mounting Ears with 6 Screws
• (4) Plastic feet
• (6) IR Receivers
• (5) IR Emitters
• (1) IR Remote
• (8) 3-pin Terminal Blocks
• (1) RS-232 Cable (3-pin to DB9)
• (1) IR Control Cable (EV-IRMST)
• (1) Power Cord
• (1) Product Manual
PACKAGE CONTENTS

www.vanco1.com 800.626.6445 4
SPECIFICATIONS
Video Input................................................................ (4) HDMI
Video Input Connector ................................................ (4) Type-A Female HDMI
Video HDMI Input Resolution....................................... Up to 4K@60Hz 4:4:4, HDR10, Dolby Vision
Video Output ............................................................. (4) HDBaseT, (4) HDMI
Video Output Connector.............................................. (4) RJ45, (1) Type-A female HDMI
Video HDMI Output Resolution .................................... Up to 4K@60Hz 4:4:4, HDR10, Dolby Vision, 1080p
3D supports 4K to 1080p downscaling
Video HDBaseT Output Resolution ............................... Up to 4K@60Hz 4:4:4, HDR10
Video HDMI Audio Signal ........................................... LPCM 7.1 audio, Dolby Atmos®, Dolby®TrueHD,
Dolby Digital® Plus, DTS:X™, and DTS-HD® Master Audio™ pass-through
Audio Output ............................................................. (4) Stereo analog L+R audio, (4) Digital SPDIF audio
Audio Output Connector ............................................. (4) 3-pin terminal blocks, (4) Toslink connectors
Digital SPDIF Audio Format......................................... Supports PCM, Dolby Digital, DTS, DTS-HD
Local Audio Sampling Rate.......................................... Supports 44.1KHz, 48KHz, 96KHz
ARC Audio Sampling Rate........................................... Supports 48KHz, 96KHz
Frequency Response .................................................. 20Hz – 20KHz, ±3dB
Audio Output Impedance............................................. 70 Ohms
Max Input Level .........................................................
L+R: 2.0Vrms ± 0.5dB. 2V = 16dB headroom above -10dBV (316mV) nominal consumer line level signal;
SPDIF:±0.05dBFS
THD+N ..................................................................... < 0.05% (-80dB), 20Hz – 20KHz bandwidth, 1KHz
sine at 0dBFS level (or max level)
SNR ......................................................................... RCA: > 80dB, 20Hz - 20KHz bandwidth;
SPDIF: > 90dB, 20Hz-20 kHz bandwidth

www.vanco1.com 800.626.6445 5
SPECIFICATIONS
Crosstalk Isolation ..................................................... SPDIF: < -70 dB, 10KHz sine at 0dBFS level (or max
level before clipping); L+R: < -80 dB, 10KHz sine at 0dBFS level (or max level before clipping)
L+R Level Deviation.................................................... L+R: < 0.3dB, 1KHz sine at 0dBFS level (or max level
before clipping)
Frequency Response Deviation .................................... < ± 0.5dB 20Hz - 20KHz
Output Load Capability ............................................... L+R: 1KΩ and higher (Supports 10x paralleled 10KΩ
loads)
Stereo Channel Separation.......................................... >70dB@1KHz
Noise Level ............................................................... L+R: -80dB; SPDIF: -90dB
Control Port .............................................................. (4) IR IN, (1) IR ALL IN, (4) IR OUT, (1) IR ALL OUT,
(1) IR EYE, (5) RS-232, (1) FW, (1) TCP/IP
Control Connector...................................................... (11) 3.5mm jacks, (1) RJ45, (5) 3-pin terminal block,
(1) Type-A USB
Transmission Mode .................................................... HDBaseT
Transmission Distance................................................ 1080p ≤ 230 feet (70 meters), 4K@60Hz ≤ 131
feet (40 meters)I
Bandwidth................................................................. 18 Gbps
Operation Temperature............................................... -5 to +55° (+23° to +131°F)
Storage Temperature ................................................. -25 to +70° (-13° to +158°F)
Relative Humidity....................................................... 10% to 90%, Non-condensing
External Power Supply ................................................ 100V~240V AC, 50/60Hz
Power Consumption ................................................... 65W (Max)
Dimensions ............................................................... 17.2” W x 1.7” H x 14” D
Weight ..................................................................... 9.7 lbs

www.vanco1.com 800.626.6445 6
Front Panel
1. LCD Screen: Shows current status as well as menu options
2. POWER LED: Illuminates red when the device is in standby mode, illuminates green when device is
powered on
3. IR Sensor and its LED: Illuminates RED when the IR sensor receives an IR signal from the IR remote to
control the matrix switcher (the IR sensor is on the right side of the LED)
4. INPUT: Inputs 1-4 for input source selection
5. OUTPUT: Outputs 1-4 for output display selection
6. Menu Buttons:
• LOCK: Lock or unlock the front panel buttons
• PRESET: Preset setting or to recall preset
• MENU: Menu or conrm/enter
• BACK: Back to the previous operation
• UP: Page up to scroll
• DOWN: Page down to scroll
PANEL DESCRIPTIONS
24
1
3
6
5

www.vanco1.com 800.626.6445 7
Rear Panel
1. INPUTS: Connect HDMI sources to each corresponding HDMI input
2. IR IN:
• 1-4: Connect the included IR Receivers (RXs) to each port, the number on the IR input corresponds to the HDBaseT
outputs. Connect this if you would like to control the display(s) over HDBaseT (receiver(s) have IR outputs)
• ALL IN: Connect the included IR Receiver (RX) to this port, this will send an IR signal out to all HDBaseT receiver(s);
useful feature to turn on/off all displays at one time
3. IR OUT:
• 1-4: Connect the included IR Transmitters (TXs) to each port, the number on the IR output corresponds to the HDMI
inputs. Connect this if you would like to control the sources from each display location over HDBaseT (receiver(s) have
IR inputs)
• ALL OUT: Connect the included IR Transmitter (TX) to this port, this will send an IR signal from any HDBaseT receiver
regardless of the HDMI signal routing; useful feature to turn on/off an external amplier or audio distribution system at
any display location
4. OUTPUTS:
• 1-4 - HDBT: Connect HDBaseT receiver(s) to each output, option of the EVRXHD2 or EVRXDSC PoC receivers
• 1-4 - HDMI: Connect HDMI display(s) via HDMI cable; if needing to extend this signal over Cat6, an HDBaseT extender
is strongly recommended
5. AUDIO MATRIX OUT/ARC: Connect the included 3-pin terminal blocks for analog audio, and four digital
optical outputs for digital audio
• These audio outputs can either extract audio from the HDMI source(s) connected, or the display(s) over HDBaseT using
ARC. Sources can then be routed to any audio outputs for audio matrix capability
6. RS-232: 3-pin terminal blocks for RS-232 pass-through using EVRXDSC receivers
7. CONTROL:
• RS-232: Connect the included RS-232 cable to a computer or 3rd party control system for integration
• IR EYE: Connect the included IR Receiver (RX) to this port, this can be used to control the matrix unit with the included
IR remote; also a helpful feature to hide the matrix unit and lead out the IR Receiver to a different location for remote
control
• FIRMWARE: Connect a Type-A USB cable to upgrade rmware, any available rmware updates will be located on the
product page for this part # on www.vanco1.com, under the “downloads” tab
• TCP/IP: Connect to a local network such as a router or ethernet switch to give the matrix unit connectivity, this will give
the ability to control the matrix unit via IP with any device on the network such as a computer, tablet, or mobile phone
8. AC100V~240V: Connect the included power cord for power
9. GROUND: Optional: connect to ground
2
1
3
6
4 5
789

www.vanco1.com 800.626.6445 8
1. Connect HDMI sources to the HDMI inputs of the EVMX44PRO (NOTE: HDMI certied cables are
strongly recommended for 4K HDR resolution)
2. Connect Cat6 cables from the matrix unit outputs to each display location (NOTE: home run Cat6 cables
are strongly recommended as any coupling points such as punch down RJ45 jacks, female/female RJ45
jacks, etc. can cause signal degradation. Patch panels will cause even more signal degradation.)
3. Connect the HDBaseT Receivers to outputs 1-4, option of either the EVRXHD2 or EVRXDSC; connect
HDMI cables from the receivers to each HDMI display (NOTE: HDMI certied cables are strongly
recommended for 4K HDR resolution)
4. Connect HDMI displays to HDMI outputs 1-4 (NOTE: HDMI certied cables are strongly recommended
for 4K HDR resolution)
5. OPTIONAL: Connect an external amplier or AV Receiver to the digital and/or analog output(s) (NOTE:
audio source can be extracted from HDMI source inputs or EVRXDSC receiving using ARC function)
6. OPTIONAL: Connect a router or ethernet switch to the TCP/IP RJ45 jack on the EVMX44PRO, this will
connect the matrix unit to the network, and can be controlled via IP
7. Connect the included power cord
CONNECT AND OPERATE

www.vanco1.com 800.626.6445 9
FRONT PANEL CONTROL
The EVMX44PRO can be controlled by using the buttons on the front panel. Whenever a command is
accepted, the selected input/output buttons will blink three times to conrm.
5.1 Signal Switching (S= Source; D= Display)
• Switch an input to an output
Operation: INPUT# + OUTPUT# + MENU
Example: Switch Input 1 to Output 2:
• Switch an input to multiple outputs
Operation: INPUT# + OUTPUT# + OUTPUT# +… + MENU
Example: Switch Input 1 to Output 2, 3, and 4
Press
Press INPUT 1
Press OUTPUT 2
Press to conrm
Note: In default status, 4 IR OUT ports correspond with 4 HDMI INPUTS. When you switch an HDMI input, the
corresponding IR OUT will be switched synchronously
Press OUTPUT 2,3,4
Press to conrm
5.2 Panel Button Locking/Unlocking
Press and hold for three seconds Press and hold
for three seconds to unlock

www.vanco1.com 800.626.6445 10
5.3 Status Information Inquiry
Press
or navigation buttons to check the previous or next setting
Press enter status
information tab
Press
LCD Screen Description
Shows current input/
output routing
Shows status of HDMI
inputs
(Y= input source
connected; N=
no input source
connected)
1-4= HDBaseT output 1-4
Shows status of
HDBaseT outputs
(Y= HDBaseT receiver
connected; N= no
HDBaseT receiver
connected)
5-8 HDMI loop output 1-4
Shows status of HDMI
outputs
(Y= HDMI display
connected; N=
no HDMI display
connected)
