Vanco PULSEAUDIO PA-SW31T User manual

The PulseAudio PA-SW31T digital optical audio switcher allows for up to three SPDIF/
TOSLINK digital audio sources to be selected to play to a device with a SPDIF/TOSLINK
digital audio optical input. Inputs can be selected with the provided IR remote, or with a 3rd
party universal remote for easy and flexible control.
Digital Optical Audio
3x1 Switch with IR
• Three digital optical audio input signals switch to one digital optical audio output
• Supports all Toslink/SPDIF digital optical audio formats up to DTS & DD 5.1CH and 192KHz
• Output distance is up to 40m using quality optical fiber cable with loss of less than 0.2Db/m
• Input can be selected through remote control or button on the switch
• Can be placed out of sight with the included IR receiver
• Discreet IR source selection
• Dimensions: 2.1” W x 2.1” D x 0.9” H (54mm x 54mm x 23.5mm)
PACKAGE CONTENTS
• (1) PulseAudio PA-SW31T 3x1 Switch
• (1) Remote Control
• (1) 5V USB Cable
• (1) IR Receiver
• (1) Product Manual
FEATURES
Digital Optical Audio 3x1 Switch with IR
Part # PA-SW31T

1. Connect digital audio sources such
as a Blu-Ray Player, game console,
media player, Cable or Satellite
Receiver, etc. to the Toslink inputs
using digital optical cables
2. Connect digital audio output such
as an A/V Receiver to the Toslink
output on the unit using digital
optical cables
3. For power, plug in the switcher with
the included USB power cable to a
USB power source
4. Power on the sources, followed by
the output device(s)
CONNECT AND OPERATE
Support Audio Format........................... LPCM2.0/DTS/Dolby-AC3
Peak Wavelength ..................................... 650nm
Max Baud Rate.......................................... 16 Gbps
Output Cable Distance .......................... < 40m (use the optical fiber cable loss less the 0.2Db/m)
Max Working Current ............................. 100mA
Power Adapter Format.......................... Input: AC (50Hz, 60Hz) 100V-240V; Output: DC5V
Operating Temperature Range........... 0 to 40 degrees Celsius
Operating Humidity Range .................. 5 to 90% RH (no condensation)
Dimensions ................................................. 2.1” W x 2.1” D x 0.9” H (54mm x 54mm x 23.5mm)
Weight.......................................................... 0.07 lbs (35g)
SPECIFICATIONS
Bluetooth Receiver
Left Side Right Side
Blu-Ray Player
Cable Box
Amplifier/Pre-Amp/AVR
