OWNER’S OPERATION AND INSTALLATION MANUAL
VENT-FREE NATURAL GAS
MINI-HEARTH®HEATER
®
VMH3000TNS
15,000 to 30,000 Btu/Hr
with Thermostat
This appliance may be installed in an aftermarket* manufactured (mobile) home, where not prohibited
by state or local codes.
*Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer. (i.e. Installation of this product is permitted
after the manufactured (mobile) home is sited)
WARNING:Iftheinformationinthismanualisnot
followed exactly, a fire or explosion may result
causing property damage, personal injury, or
loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas
supplier’s instructions.
• Ifyoucannotreachyourgassupplier,call
the fire department.
— Installation and service must be performed
byaqualifiedinstaller,serviceagency,orthe
gas supplier.
WARNING:Improperinstalla-
tion, adjustment, alteration,
service, or maintenance can
causeinjuryorpropertydam-
age. Refer to this manual for
correct installation and op-
erational procedures. For as-
sistance or additional infor-
mation consult a qualified in-
staller,serviceagency, orthe
gas supplier.
WARNING:Thisisanunvented
gas-fired heater. It uses air
(oxygen) from the room in
whichitisinstalled.Provisions
for adequate combustion and
ventilation air must be pro-
vided. Refer to Air For Com-
bustion and Ventilation sec-
tion on page 5 of this manual.
®
Shown With Optional
Mantel Which Features
a Built In Base

2
106055
GAS RESIDENTIAL HEATERS
®
SAFETY
INFORMATION
1. This appliance is only for use with the
typeofgas indicated on the ratingplate.
Thisappliance is not convertible foruse
with other gases.
2. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do not touch any electrical switch; do
not use any phone in your building.
• immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions
• ifyoucannot reach your gassupplier,
call the fire department
3. This heater shall not be installed in a
bedroom or bathroom.
4. Never install the heater
• in a recreational vehicle
• wherecurtains,furniture, clothing, or
otherflammableobjectsarelessthan
36inchesfromthe front, top, or sides
of the heater
• as a fireplace insert
• in high traffic areas
• in windy or drafty areas
5. This heater needsfresh,outside air ven-
tilation to run properly. This heater has
an oxygen depletion sensor (ODS) pi-
lot light safety system. The ODS shuts
down the heater if not enough fresh air
is available. See Air For Combustion
and Ventilation, pages 5 through 7.
6. Before using furniture polish,wax,car-
pet cleaner, or similar products, turn
heater off. If heated, the vapors from
theseproductsmaycreateawhite pow-
der residue within burner box or on
adjacent walls or furniture.
7. If heater shuts off, do not relight until
you provide fresh, outside air. If heater
keeps shutting off, have it serviced.
8. Do not run heater
• where flammable liquids or vapors
are used or stored.
• under dusty conditions.
9. Never place any objects on the heater.
10. Surface of heater becomes very hot
whenrunning heater. Keepchildrenand
adults away from hot surface to avoid
burns or clothing ignition. Heater will
remain hot for a time after shutdown.
Allow surface to cool before touching.
11. Carefully supervise young children
whenthey arein same roomwithheater.
12. Make sure screen is inplacebefore run-
ning heater.
13. Do not use heater if any part has been
under water. Immediately call a quali-
fied service technician to inspect the
room heater and to replace any part of
the control system and any gas control
which has been under water.
14. To prevent the creation of soot, follow
the instructions in Cleaning and Main-
tenance, page 19.
LOCAL CODES
Install and use heater with care. Follow all
localcodes.Intheabsenceoflocalcodes,use
the latest edition of The National Fuel Gas
CodeANSZ223.1,alsoknownasNFPA54*.
*Available from:
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
National Fire Protection Association, Inc.
Batterymarch Park
Quincy, MA 02269
PRODUCT
FEATURES
SAFETY DEVICE
This heater has a pilot with an Oxygen
Depletion Sensor Shutoff System (ODS).
TheODS/pilotisarequiredfeatureforvent-
free room heaters. The ODS/pilot shuts off
the heater if there is not enough fresh air.
PIEZO IGNITION SYSTEM
This heater has a piezo ignitor. This system
requires no matches, batteries, or other
sources to light heater.
THERMOSTATIC HEAT
CONTROL
This heater has a thermostat sensing bulb
andacontrolvalve.Thisresultsinthegreat-
est heater comfort. This can also result in
lower gas bills.
WARNINGS
IMPORTANT: Read this owner’s
manual carefully and completely
before trying to assemble, oper-
ate, or service this heater. Im-
properuseofthisheatercancause
seriousinjuryordeathfromburns,
fire, explosion, electrical shock,
and carbon monoxide poisoning.
DANGER: Carbon monoxide
poisoning may lead to death!
WARNING: Any change to
this heater or its controls can be
dangerous.
Carbon Monoxide Poisoning: Early
signs of carbon monoxide poisoning re-
semble the flu, with headaches, dizziness,
ornausea.Ifyouhavethesesigns,theheater
maynot beworking properly.Getfreshair
atonce!Haveheaterserviced. Somepeople
are more affected by carbon monoxide than
others. These include pregnant women,
peoplewithheartorlungdiseaseor anemia,
those under the influence of alcohol, and
those at high altitudes.
Natural Gas: Natural gas is odorless. An
odor-making agent is added to natural gas.
Theodorhelpsyoudetectanaturalgasleak.
However, the odor added to natural gas can
fade.Naturalgasmaybepresenteventhough
no odor exists.
Make certain you read and understand all
Warnings. Keep this manual for reference.
It is your guide to safe and proper operation
of this heater.
WARNING: Do not use a
blower insert, heat exchanger
insert, or other accessory not
approvedforusewiththisheater.
15. Turn off and unplug heater and let cool
beforeservicing.Only aqualifiedservice
person should service and repair heater.
16. Operating heater above elevations of
4,500 feet could cause pilot outage.

3
106055
OWNER’S MANUAL
PRODUCT
IDENTIFICATION
Figure 1 - Vent-Free Gas Log Propane/LP Gas Space Heater
1. Remove heater from carton.
2. Remove all protective packaging ap-
plied to heater for shipment.
3. Make sure your heater includes two
hardware packets.
4. Check heater for any shipping damage.
If heater is damaged, promptly inform
dealer where you bought heater.
ASSEMBLY
ASSEMBLING HEATER
Tools Required:
• Phillips screwdriver
• 5/16" hex wrench
• slotted screwdriver
Removing Front Panel Of Heater
1. Remove two screws near bottom cor-
ners of front panel with Phillips screw-
driver.
2. Pull bottomoffront panel forward, then
down (see Figure 2) .
Figure2-RemovingFrontPanelofHeater
Piezo Ignitor
Figure3-AttachingIgnitorCabletoPiezo
Ignitor
Ignitor
Cable
Continued
