Vanguard VMH3000TNSA Quick start guide

Save this manual for future reference.
OWNER’S OPERATION AND INSTALLATION MANUAL
VENT-FREE NATURAL GAS
MINI-HEARTH®HEATER
VMH3000TNSA
15,000 to 30,000 Btu/Hr
with Thermostat
This appliance may be installed in an aftermarket*, permanently located, manufac-
tured (mobile) home, where not prohibited by state or local codes.
This appliance is only for use with the types of gas indicated on the rating plate.
This appliance is not converrtible for use with other gases.
WARNING:Iftheinformationinthismanualisnot
followed exactly, a fire or explosion may result
causing property damage, personal injury, or
loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas
supplier’s instructions.
• Ifyoucannotreachyourgassupplier,call
the fire department.
— Installation and service must be performed
byaqualifiedinstaller,serviceagency,orthe
gas supplier.
WARNING:Improperinstalla-
tion, adjustment, alteration,
service, or maintenance can
causeinjuryorpropertydam-
age. Refer to this manual for
correct installation and op-
erational procedures. For as-
sistance or additional infor-
mation consult a qualified in-
staller,serviceagency, orthe
gas supplier.
WARNING:Thisisanunvented
gas-fired heater. It uses air
(oxygen) from the room in
whichitisinstalled.Provisions
for adequate combustion and
ventilation air must be pro-
vided. Refer to Air For Com-
bustion and Ventilation sec-
tion on page 5 of this manual.
®
Shown with Optional
Mantel Which Features
a Built-In Base
*Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer.

2
107101
NATURAL GAS RESIDENTIAL HEATERS
®
For more information, visit www.desatech.com
SAFETY
INFORMATION
LOCAL CODES
Install and use heater with care. Follow all
local codes. In the absence of local codes, use
the latest edition of The National Fuel Gas
Code,ANSZ223.1,alsoknownasNFPA54*.
*Available from:
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
National Fire Protection Association, Inc.
Batterymarch Park
Quincy, MA 02269
WARNINGS
IMPORTANT: Read this owner’s
manual carefully and completely
before trying to assemble, oper-
ate, or service this heater. Im-
properuseofthisheatercancause
seriousinjuryordeathfromburns,
fire, explosion, electrical shock,
and carbon monoxide poisoning.
DANGER: Carbon monoxide
poisoning may lead to death!
WARNING: Any change to
this heater or its controls can be
dangerous.
CarbonMonoxidePoisoning:Earlysignsof
carbon monoxide poisoning resemble the flu,
with headaches, dizziness, or nausea. If you
have these signs, the heater may not be work-
ing properly. Get fresh air at once! Have
heater serviced. Some people are more af-
fectedbycarbonmonoxidethanothers.These
includepregnantwomen,peoplewithheartor
lung disease or anemia, those under the influ-
ence of alcohol, and those at high altitudes.
Natural Gas: Natural gas is odorless. An
odor-making agent is added to natural gas.
Theodorhelpsyoudetectanaturalgasleak.
However, the odor added to natural gas can
fade.Naturalgasmaybepresenteventhough
no odor exists.
Make certain you read and understand all
warnings.Keepthismanualforreference.It
isyourguidetosafeandproperoperationof
this heater.
WARNING: Do not allow fans
toblowdirectlyintothefireplace.
Avoidanydraftsthatalterburner
flame patterns. Ceiling fans can
create drafts that alter burner
flame patterns. Altered burner
patterns can cause sooting.
WARNING: Do not use a
blower insert, heat exchanger
insert,orotheraccessorynotap-
proved for use with this heater.
Due to high temperatures, the
appliance should be located out
oftraffic andawayfromfurniture
and draperies.
Do not place clothing or other
flammable material on or near
the appliance. Never place any
objects on the heater.
Surface of heater becomes very
hot when running heater. Keep
children and adults away from
hot surface to avoid burns or
clothing ignition. Heater will re-
main hot for a time after shut-
down. Allow surface to cool be-
fore touching.
Carefully supervise young chil-
drenwhentheyareinsameroom
with heater.
Make sure screen is in place be-
fore running heater.
1. This appliance is only for use with the
typeof gas indicatedontherating plate.
Thisappliance is notconvertibleforuse
with other gases.
2. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do not touch any electrical switch; do
not use any phone in your building.
• immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions
• ifyou cannot reachyourgas supplier,
call the fire department
3. This heater shall not be installed in a
bedroom or bathroom.
4. This heater needsfresh,outside air ven-
tilation to run properly.This heater has
an Oxygen Depletion Sensing (ODS)
safety shutoff system. The ODS shuts
down the heater if not enough fresh air
is available. See Air For Combustion
and Ventilation, pages 5 through 7.
Keeptheapplianceareaclearand
free from combustible materials,
gasoline, and other flammable
vapors and liquids.
5. Before using furniturepolish,wax, car-
pet cleaner, or similar products, turn
heater off. If heated, the vapors from
theseproducts maycreatea white pow-
der residue within burner box or on
adjacent walls or furniture.
6. If heater shuts off, do not relight until
you provide fresh, outside air. If heater
keeps shutting off, have it serviced.
7. Do not run heater
• where flammable liquids or vapors
are used or stored.
• under dusty conditions.
8. Never place any objects on the heater.
9. Do not use heater if any part has been
under water. Immediately call a quali-
fied service technician to inspect the
room heater and to replace any part of
the control system and any gas control
which has been under water.
10. To prevent the creation of soot, follow
the instructions in Cleaning and Main-
tenance, page 19.
11. Turn off and unplug heater and let cool
beforeservicing.Onlya qualified service
person should service and repair heater.
12. Operating heater above elevations of
4,500 feet could cause pilot outage.

3
107101
OWNER’S MANUAL
For more information, visit www.desatech.com
PRODUCT
FEATURES
SAFETY DEVICE
This heater has a pilot with an Oxygen
Depletion Sensing (ODS) safety shutoff
system. The ODS/pilot is a required feature
for vent-free room heaters. The ODS/pilot
shuts off the heater if there is not enough
fresh air.
PIEZO IGNITION SYSTEM
This heater has a piezo ignitor. This system
requires no matches, batteries, or other
sources to light heater.
THERMOSTATIC HEAT
CONTROL
This heater has a thermostat sensing bulb
andacontrolvalve.Thisresultsinthegreat-
est heater comfort. This can also result in
lower gas bills.
PRODUCT
IDENTIFICATION
Figure 1 - Vent-Free Gas Log Propane/LP Gas Space Heater
1. Remove heater from carton.
2. Remove all protective packaging ap-
plied to heater for shipment.
3. Make sure your heater includes two
hardware packets.
4. Check heater for any shipping damage.
If heater is damaged, promptly inform
dealer where you bought heater.
ASSEMBLY
ASSEMBLING HEATER
Tools Required:
• Phillips screwdriver
• 5/16" hex wrench
• slotted screwdriver
Removing Front Panel Of Heater
1. Remove two screws near bottom cor-
ners of front panel with Phillips screw-
driver.
2. Pull bottom offrontpanelforward, then
down (see Figure 2) .
Figure2-RemovingFrontPanelofHeater
Continued
