VANSEN 7200A User manual
SMART APP AIR PURIFIER
With UV-C LIGHT & AQI DISPLAY
Model: 7200A
USER MANUAL
PLEASE READ THOROUGHLY BEFORE USING THIS PRODUCT
2
WARNINGS & CAUTIONS
1. Ensure the power line fits properly into the port before plug in.
2. Improper usage may lead the product to damage.
3. DO NOT place the air purifier near sources of heat.
4. DO NOT sit on or place anything on top of the purifier
5. DO NOT immerse the air purifier in water or liquids.
6. DO NOT use the air purifier in wet or humid environments.
7. DO NOT let children use the air purifier alone, and keep it away
from pets.
8. DO NOT place the air purifier in an unstable area.
9. DO NOT attempt to repair or dissemble the air purifier.
10. When not being used, please turn the air purifier off to avoid
accidents caused by long working hours.
11. DO NOT insert fingers or objects into the air outlet when it is
working.
12.Use soft cloth when when clean the unit.
13. Remember to unpack the inside filter package when in first use.
14. Replace the filter every 6-month or less. This time may vary from
air quality and unit using frequency.
Introduction
Features:
4. Five Working Modes
This device has built-in fan and motor to provide cool air, with 3 fan
speeds, sleeping mode, and auto mode with indicator lights.
2. Air Quality Sensor & Air Quality Index LED Display
The inserted sensor detects PM 2.5 intelligently with 3 air quality indicators
and automatically adjust fan speed to optimize room air quality. You can
always see the air quailty at your home.
7.True HEPA filter for Efficient Purifying
This unit has H13 filter with nylon pre-filter and active carbon filter
for more efficient air purifying effect.
5. Three Brightness Night Light
Warm light creates peaceful night atmosphere with adjustable
brightness under L/M/H levels.
8. Filter Replacement Reminder
Convenient filter replacement indicator light saves the trouble to
monitor the filter lifespan.
Smart APP control air purifier, with PM2.5 air quality sensor and UV sterilizer,
it can clean the dust, pet dander, smoke, mold, and pollen in the air, and
protect your family and pets. Moreover, the convenient features of filter
replacement reminder, timer setting, and night light functions provide you
a daily quality service and decor your room.
3. The Efficient UV Sterilizer
The UV-C light helps to kill airborne viruse and bacteria.
6. Timer Function
1-12 hours timer selection allows you to set the time of turn off freely.
3
1. Smart APP Control
This air purifier can be linked with Tuya Smart APP, you can control all the
functions in your phone.
Accessories
H13 Filter Power Line
Product Diagram
Bottom Cap
H13 Filter
Main Body
Wind Outlet
Control Panel
4
Specifications
Input Voltage
Rated Power
CADR
Dimensions
Filter
Noise Level
H13 & Nylon pre-filter & Active carbon
ijPP
147CFM/250m³/h
AC: 100-240V, 50/60HZ
32W
6OHHSPRGHG%KLJKVSHHGG%
Effective Range 25-30㎡
Operating Conditions 41-104℉/5-40℃
Standy Power :
Operation Instructions in First Use
1. Reverse the unit to bottom,
screw the knob anticlockwise
to open the bottom cap.
2. Take out the filter.
5
3. Remove the filter PE bag. 4. Place the filter properly.
5. Screw the botton cap
clockwise to fix it well.
6. Connect the power line.
7. Operation
-On/Off
1st Touch: turn on the unit with AUTO mode.
2nd Touch: turn off the unit.
-Fan Speed Controls (can only be operated when the unit is powered on)
1st Touch: low fan speed.
2nd Touch: medium fan speed.
3rd Touch: high fan speed.
4th Touch: turn on the sleeping mode.
5th Touch: wake up the sleeping mode to set the timer, night light or UV-C light.
(The LED dispaly would be dimmed again if there’s no operations in 5s.)
6th Touch: Exit the sleeping mode, back to Auto mode.
6
-Night Light
1st Touch: low light brightness.
2nd Touch: medium brightness.
3rd Touch: high brightness.
4th Touch: turn off the night light.
-Timer Setting
Timer can be set from 1 to 12 hours.
Touch to add 1 hour.
Touch to cut 1 hour.
Long touch it for 3s to exit timer setting.
-UV-C Light
1st Touch: turn on the UV-C light.
2nd Touch: turn off the UV-C light.
-Filter Replace Reminder
When the filter replace indicator light turns red, it’s time to replace a new filter.
Please turn off the unit and unplug the cable line before changing a filter.
After replacement, long touch + buttons for 6s to reset the program
(filter replace indicator light flashes 3 times then turn off.)
Notes:
Under AUTO working mode, the indicator light and fan speed change
automatically as below:
*5((1LQGLFDWRUOLJKWIRU*22'DLUTXDOLW\ZLWK/2:IDQVSHHG
25$1*(LQGLFDWRUOLJKWIRU0(',80DLUTXDOLW\ZLWK0(',80IDQVSHHG
5('LQGLFDWRUOLJKWIRU3225DLUTXDOLW\ZLWK+,*+IDQVSHHG
Care & Maintenance
Clean the unit:
1. Unplug power firstly, and use a soft cloth to wipe the unit clean.
2. Don’t immerse the air purifier in water or liquids.
7
8
The air purifier can offer remote operation by using a home Wi-Fi
connection through the TuyaSmart app in your mobile phone.
-Connection
D(QVXUHWKHPRELOHGHYLFHLVFRQQHFWHGWRD*KRPH:L)LQHWZRUN
b. To set up the purifier, turn the purifier on at the power outlet. The purifier
must be turned on via the control panel.
c. Long touch the power button for 5s, until the flashed, then the purifier
is ready to be connected.
d. The would be flashed when connecting, when the connection is successful,
the purifier would appear in the main page of app. The would be illuminated.
*:L)L
*RRJOH3OD\6WRUH
Apple App Store
Operation
The circle would indicate current PM2.5 index, air quality and the filter lifespan.
-Device On
Touch the button to turn on or turn off the purifier.
-Speed Controls
Manual mode selected: Low, middle, high fan speed can be choosed.
Auto mode selected: the fan speed would changed upon the current air quality.
Sleep model selected: all LED display on the device is dimmed, only the night
light can be operated.
- Timer
1-12 hours can be chosen freely.
-Night light
3 level lightness can be chosen.
-UV-C light (UV Disinfection)
Touch the button to turn on or turn off the UV-C light.
-Reset Filter
Touch the button to reset the filter lifetime counting when you replace a new filter.
9
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
FCC Warning
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
NOTE 1: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by
the party responsible for compliance could void the user's authority to
operate the equipment.
