Vantage Hearth Q-ETS3 User manual

INSTALLATION
VANTAGECONTROLS.COM
1061 South 800 East • Orem, Utah 84097 • Telephone [phone] • Fax [phone] Vantage Thermostat Communication Station— MODEL: Q-ETS3 & STHERR101
Overview
The Q-ETS3, WireLink™ and the STHERR101, RadioLink®
thermostat interface stations provide bi-directional
communication between a Vantage control system and the
HVAC system. Any button or time control using InFusion
Design Center or QLink software can be programmed to
change Setpoints, Operational Mode, Fan mode and
Occupied/Unoccupied settings on a Vantage thermostat.
Current set points, Indoor/Outdoor temperatures, Operational
Mode, Fan mode and Occupied/Unoccupied (status) may be
displayed on Vantage LCD TouchScreens. A Vantage Q-ETS3
or STHERR101 station and a Vantage thermostat are used
together, in a one-to-one ratio, to control HVAC systems.
Please completely read, the Vantage Communicating
Thermostat |Operating and Installation Manual in conjunction
with this instruction sheet. Click on the manual below:
Or visit: http://dealer.vantagecontrols.com/
Note: Vantage Controls’ Thermostat is warranted for one year.
This is in contrast with the 5 year warranty carried on most
Vantage products.
System Requirements
Each Vantage thermostat requires one Q-ETS3 or STHERR101
to interface with the Vantage Communicating Thermostat
Part # STAT.
Specifications Q-ETS3
WireLink
STHERR101
RadioLink
Dimensions HWD
3” x 1” x 0.375”
76mm x 25mm x
10mm
4.5” x 1.5” x 0.75”
114mm x 38mm x 19mm
Weight 0.8oz
23g
1.4oz
40g
Station Power
connections*
24V / 36V Station
Bus
and
24Vac from
thermostat base
24Vac from thermostat
base
Station Count
Design Center
0.36W on IC-24
0.54W on IC-36 1 RadioLink Station
Station Count
QLink
1 WireLink Station 1 RadioLink Station
Status LED
Indicator Yes Yes
Station Bus
Wiring
2C 16AWG, non-shield, <30pF per foot
Station Bus should be separated a minimum
of 18" from other parallel communication
and/or high voltage runs.
Ambient
Operating
Temperature
32-95°F -or- 0-35°C
Ambient
Operating
Humidity
5-95% non-condensing
*CAUTION: 36V stations have a symbol on the Serial
Number sticker. Any Q-ETS3, not displaying this symbol,
should not be connected to a 36Volt Station Bus.
Software/Firmware
Vantage’s Q-ETS3 & STHERR101thermostat interface stations
are compatible with InFusion Design Center software and
QLink software. NOTE: The Q-ETS3 requires QLink version 2.50
and Controller firmware version 5.70 or higher. The STHERR101
requires QLink version 4.0 - build 310 and Controller firmware
version 7.4 or higher. For new projects it is recommended that
firmware and software be kept to the most current release.
Station Connection
Installation of Vantage products should be performed or
supervised by a Certified Vantage Installer. The Q-ETS3
connects to the Vantage System Station Bus with the two
black wires labeled Station Bus. The Station Bus wire should
comply with the Vantage Station Bus wiring specification. The
STHERR101 connects to the Vantage System via a RadioLink™
enabled system.
Mounting the Q-ETS3 or STHERR101
The Q-ETS3 or STHERR101 may be mounted behind the
thermostat in a single gang box or may hang through a 1¾”
(4.44cm) hole in the wall. The Black wire X1 and Green wire
X2 attach to terminals labeled X1 & X2 of the thermostat sub
base. The Red wire 24V attaches to the R terminal (screw
terminals on right) of the thermostat sub base along with the
24V power source. The Q ETS3 or STHERR101 do not supply
power to the thermostat.
Please see the Vantage Communicating Thermostat |Operating
and Installation Manual for each of the following topics:
•Configuration, Q-ETS3, WireLink™
•Configuration, STHERR101, RadioLink®
•Status LED Diagnostic Information for Q-ETS3 or
STHERR101
•Thermostat Setup with InFusion
•Thermostat Setup with QLink
•External Sensors
•Temperature Averaging
Globally Display Outdoor Sensor
In Design Center, click on Settings | Project Preferences |
Thermostat and the Global Sensor drop down list. Select the
thermostat that has the external sensor. In QLink Select Use as
the Globally Displayed External Sensor from the Thermostat
Station properties window. This will broadcast the value of the
external sensor to all other thermostats connected to the
Vantage System. If Use as the Globally Displayed External
Sensor is not checked, other thermostats on the system will
not display the outdoor temperature.
Occupied (formerly Auto(Day)) and Unoccuped (formerly
(Night)) Modes
Most Thermostat Functions only work when the thermostat is
in Occupied (formerly Auto(Day)) Mode. If the thermostat is in
Unoccupied (formerly Manual(Night)) mode, the thermostat
automatically changes to Occupied when a command is
received. However, it is possible to end any task with a
command to leave the thermostat in Occupied or Unoccupied
modes as desired.

This device contains transmitter module:
FCC ID: PII-VSUB075-1
IC: 3505A-VSUB0751
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this product not expressly approved by Vantage
Controls could void the user’s authority to operate this product.
Status LED Diagnostic Information
During setup and configuration the Q-ETS3 or STHERR101 LED
will blink at different intervals. The STATUS LED blinks evenly
or flashes 2, 3, 4, 5 or 6 times followed by a pause to indicate
status information.
One Even blink: The Q-ETS3 or STHERR101 is correctly
configured.
Two blinks: Q-ETS3 or STHERR101 is operating correctly but is
not configured.
Three blinks: Q-ETS3 or STHERR101 is not communicating with
the Controller. Verify that station bus wiring conforms to
Vantage guidelines or for STHERR101, verify that the serial
number is correct in the software and is in communication
range with the RadioLink Enabler.
Four blinks: Q-ETS3 or STHERR101 Factory problem. Please
contact the factory.
Five blinks: Q-ETS3 (only) Configuration mode. InFusion or
QLink is ready for configuration button presses (Configuration
the Q-ETS3, WireLink™ above) to associate serial number with
programming.
Six blinks: Q-ETS3 or STHERR101 is not communicating with
the thermostat. The thermostat is not properly wired to the
station or, in the case of the Q-ETS3 only, the thermostat is not
powered.
Off: The Q-ETS3 station is not connected to the station bus,
the Controller is not in place or is not powered. The STHERR101
is not powered.
Fahrenheit / Celsius
In Design Center, click on Settings | Project Preferences |
Thermostat and click in the desired box. In QLink select
System | Global Parameters from the menu and select Display
Temperatures in Fahrenheit. This choice will determine how the
set points are handled throughout QLink, including displaying
temperatures on LCD stations. To toggle Fahrenheit and
Celsius display on the thermostat, go to Menu | Temperature |
Units and select Imperial or Metric and Save Changes (see the
thermostat manual).
Thermostat Status on Touch Screens
In the Touch Screen Designer window select the Status
design tool. Draw a Status object on the screen. Right click the
status object and click on Select Thermostat to finish
programming. Above steps may vary slightly for different
touch screens and or versions of Vantage software.
Thermostat Reset and Calibrations
Please see the Thermostat owners manual:
Standard Q-ETS3 Thermostat Wiring
39818 / InFusion and QLink Systems Warranty at: http://www.vantagecontrols.com/warranty ©Vantage Controls
