Televic Plixus Series User manual

conference
PLIXUS
INSTALLATION GUIDE

Copyright Statement
No part of this publication or documentation accompanying this product may be reproduced in any form or
by any means or used to make any derivative such as translation, transformation, or adaptation without the
prior written permission of the publisher, except in case of brief quotations embodied in critical articles or
reviews. Contents are subject to change without prior notice.
Copyright © 2020 by Televic Conference NV. All rights reserved.
The authors of this manual have made every effort in the preparation of this book to ensure the accuracy of
the information. However, the information in this manual is supplied without warranty, either express or
implied. Neither the authors, Televic Conference NV, nor its dealers or distributors will be held liable for any
damages caused or alleged to be caused either directly or indirectly by this book.
Trademarks
All terms mentioned in this manual that are known to be trademarks or service marks have been
appropriately capitalized. Televic NV cannot attest to the accuracy of this information. Use of a term in this
book should not be regarded as affecting the validity of any trademark or service mark.

DOCUMENT HISTORY
Version Date Description
0.1 2015-08-31 Initial draft
0.2 2015-10-09 Expansion & clarification
0.3 2015-10-13 Expansion & clarification
0.4 2015-12-15 Expansion & clarification
0.5 2016-01-26 Expansion & clarification
1.0 2016-03-01 Initial release
1.1 2016-10-05 Add G3 compatibility
1.2 2016-10-18 Correction on SW version G3
1.3 2017-01-13 Add remark on redundancy and NE power supply
1.4 2017-01-17 Update chpt 3.3 (power use) & 7.3 (system update)
1.5 2017-03-27 Add NEXT and Video products , Add ERS
1.6 2017-05-11 Minor changes
1.7 2017-06-06 Added cabling guidelines
2.0 2018-02-13 Rearranged content, update layout and adjust guide to new Plixus
AER.
3.0 2019-06-17 Added new features
4.0 2019-12-05 Added Confidea FLEX
DO CUMENT HISTO RY 3

CONTENTS
Document history 3
Introduction
Getting started 10
About this manual 10
Compatibility 11
About Plixus 12
Concept and design 12
Safety instructions
Safety instructions 14
Safety 14
FCC & ICES Information 14
Conformity and Certification Info for Japan 15
Important safety instructions 16
Power connections 18
Plixus components
Components 21
General overview 21
Component range 23
Plixus MME 24
Overview 24
Control dial functionality 24
Rear connectivity 26
Dante™ interface 27
Supported Video Formats 28
Factory defaults restore button 28
Plixus AE-R 29
Overview 29
Recording feature 29
Rear end connectivity 30
Power supply 30
Factory defaults restore button 30
Plixus Power Supply 32
DO CUMENT HISTO RY 4

Plixus AE-R power supply 32
Plixus power supply 32
Plixus NEXT 33
DIP switch table 34
General Network Extender Guidelines 34
Redundancy 35
Video-IN 37
Video-In box 37
Video request 38
Video-OUT 39
Video-Out box 39
Video selection 40
Video stream routing 41
uniBOX 42
Delegate equipment 44
Audio only equipment 44
Multimedia equipment 44
Advanced delegate equipment 44
Interpreter equipment 46
Plixus Nameplate Properties 47
Overview 47
Installation design
Plixus component properties 50
100 Mbit powered over Plixus Cable 50
1Gbit powered over Plixus cable 50
1Gbit externally powered 51
General installation guidelines 53
Units per branch / loop 53
When to use a network extender 54
Installation diagram 55
Configuration with Plixus engine only 55
Configuration with network extender 55
Examples 59
Configuration with Plixus AE-R and Lingua IDs 60
Power supply design 61
Power availability and consumption table 61
Plixus AE-R power supply 62
Calculator tool 63
Cable requirements 63
DO CUMENT HISTO RY 5

Install nameplate in Plixus network 65
Use Nameplate and delegate unit on the same seat 66
Use Nameplate in standalone mode 66
Combine Plixus with Confidea G3 67
Combine wired and wireless units 67
Combine interpretation with wireless units 68
Range extension with multiple access points 69
Split and combine rooms 70
Create redundancy 70
Installation process
Introduction 73
Power supply 74
Power network extenders 74
Power uniCOS units and uniBOX 74
Power supply of the central unit 75
Install cables 77
Install microphones 78
General microphone characteristics 78
Technical microphone characteristics 78
Microphone connector characteristics 79
Microphone Operation Modes 79
Install delegate units 81
Connect Plixus units 81
Connect to Plixus engine 81
Install Confidea FLEX 82
Attach uniCOS T/MM10 to a fixed surface 84
Install the uniCOS units in the respective mounting bracket 86
Mount uniCOS F/MM 7 in the bracket 86
Remove uniCOS F/MM 7 from the bracket 88
Mount uniCOS F/MM 10 in the bracket 89
Remove uniCOS F/MM 10 from the bracket 91
Install Confidea G3 92
Connect Wireless Conference Access Point (WCAP) to Plixus network 92
Cabling of Nameplate 93
Connect to Plixus conference ports 93
Connect to USB 95
Mount the Nameplate 96
Portable usage 96
Fixed usage 97
DO CUMENT HISTO RY 6

Mount the side panels 97
Detach bottom 98
Configuration
Introduction 101
Plixus Core 101
Plixus Core versus CoCon 101
Configure IP settings 104
Change IP settings in Windows 104
Change IP settings in macOS 106
Getting started with Plixus Core 109
Access Plixus Core 109
Explore Plixus Core 109
The Home page 111
Initialization 112
Introduction 112
How to initialize units 113
Hot swap procedure 115
Activate Dante on seat 117
Discussion options 120
Number of open microphones 120
Microphone mode 120
Microphone LED 122
Recording 123
Record using the record button 123
Record using Plixus Core 123
Manage recorded files 125
Audio settings 126
General volume 126
Dynamics processing 126
Auto gain reduction 127
Audio routing 128
Audio routing configuration 128
Auxiliary levels 130
Additional options 130
Interpretation 131
Add new language 131
Add Interpretation configuration from CoCon 132
Video 133
Operator 134
DO CUMENT HISTO RY 7

Regional settings 135
Network settings 136
Network information 136
Camera protocol 136
REST API 139
Users 141
Update versions 142
Update Plixus system 142
Update versions 144
System info 145
Diagnostics 147
Overview 147
Filter 148
Visualize loops and branches 149
View device details 150
Highlight devices 151
Test device 152
Use Intercom on delegate units 154
uniCOS units 154
Lingua ID units 156
Confidea units 157
Couple with Confidea G3 158
Couple WCAP with engine 158
Associate units with WCAP 159
Takeover WCAP 160
DO CUMENT HISTO RY 8

INTRODUCTION
This chapter will give you a short introduction to this manual together with a
general description of the Plixus network and its functionalities.

GETTING STARTED
About This Manual
Throughout this guide we use icons to designate different types of information:
This is a note. A note gives additional information, such as the meaning of the color of the
microphone LEDs. A note also provides information that may only be applicable to some situations.
This is a tip. A tip gives you an alternative way to do a particular step or procedure, or lets you know
of an option that you may find helpful.
This indicates that something is very important. Important information is something that you need to
do in order to accomplish a certain task.
This provides safety precaution information, that is, information that you need to be careful about to
prevent potential problems when using our systems.
GETTING STAR TED 10

Compatibility
This user manual applies to the following products:
Product Version
Plixus MME ≥ CRP 5.2
Plixus AE-R ≥ CRP 5.2
Confidea WCAP G3 ≥ 3.1
Confidea G3 delegate units ≥ 3.1
GETTING STAR TED 11

ABOUT PLIXUS
Concept And Design
Figure 1-1 : Plixus CAT 5e cable characteristics
Plixus is a state-of-the-art conference architecture that excels in performance, security & reliability.
It is a packet-based IP network that radically simplifies the conference architecture by sending all
information over a single CAT 5e cable. HQ audio, HD video, and data travel over a single cable. Dedicated
bandwidth is reserved for audio and video. The result is permanent and uninterrupted crystal-clear audio
and video. Plixus also eliminates the large amount of equipment and cabling that was traditionally required
to bring video to each delegate. Video splitters, distribution amplifiers and several cables to each delegate
position are no longer needed. As a result, Plixus drastically reduces the installation cost and simplifies the
maintainability of the total system architecture.
The Plixus architecture is also engineered with redundancy & maintenance in mind. All delegate stations
are interconnected in daisy-chain and the last unit in the chain can close the loop for increased reliability
and redundancy. Moreover, Plixus is conceived with a self-healing topology: data will always travel the
shortest route and in the case of an error, Plixus will self-correct and reroute data via the fastest available
pathway. Ultimately, it offers all parties peace of mind with Plixus’ rock-solid reliability.
Finally, Plixus offers the best of both worlds. The mission-critical part of the central unit is entirely closed off
while the DANTE™ interface enables third-party devices to communicate with the closed core network. As
a result, Plixus acts as a gatekeeper who guarantees safe & secure communication and allows device
extensibility via the DANTE™ interface.
ABO UT PL IX US 12

SAFETY INSTRUCTIONS
This chapter describes all safety instructions needed to use the Plixus devices. Read
this before using the equipement.

SAFETY INSTRUCTIONS
The safety instructions contain general safety guidelines that integrators, installers, operators, end users,
and anyone else who installs or uses Televic material is required to read and follow at all times.
Safety
All Televic systems are state of the art devices and have been designed to meet all quality standards.
Nevertheless, the individual components of the conference system can cause danger for persons and
material assets if
the conference system is not used as intended,
the conference system is set up by personnel not familiar with the safety regulations,
the conference system is converted or altered incorrectly,
the safety instructions are not observed.
FCC & ICES Information
(U.S.A and Canadian Models only).
This Class B digital apparatus complies with Canadian norm ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected
Consult the dealer or an experienced radio/TV technician for help
SAFETY INSTR UCTIONS 14

Consult the Federal Communications Commission’s manual “How to Identify and Resolve
Radio-TV Interference Problems”
Wireless discussion units and the Wireless Access Point comply with Part 15 of the FCC Rules and with RSS-
210 of Industry Canada.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference
2. This device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications made to this equipment not expressly approved by Televic Conference
NV may void the FCC authorization to operate this equipment.
Wireless discussion units and the Wireless Access Point comply with FCC radiation exposure limits
set forth for an uncontrolled environment. These Wireless discussion units and the Wireless Access
Point should be installed and operated with minimum distance of 20 cm between the radiator and
your body. The RF-parts of the Wireless discussion units and the Wireless Access Point must not be
co-located or operating in conjunction with any other antenna or transmitter.
Conformity And Certification Info For Japan
This device has been granted a designation number by Ministry of Internal Affairs and Communications
according to:
Ordinance concerning Technical Regulations Conformity Certification etc. of Specified Radio
Equipment (特定無線設備の技術基準適合証明等に関する規則)
Article 2 clause 1 item 19/3
Approval No.:
202WW10120791/2”
202XW10120791/2
This device should not be modified, otherwise the granted designation number will be invalid.
SAFETY INSTR UCTIONS 15

Important Safety Instructions
1. Read Instructions. All the safety and operating instructions should be read before the product,
device or system is operated.
2. Retain Instructions. The safety and operating instructions should be retained for future
reference. The instructions should be kept in the vicinity of the product or system.
3. Heed Warnings. All warnings on the product and the operating instructions should be closely
adhered to.
4. Follow Instructions. All instructions for installation or operating/use should be followed
closely.
5. Cleaning. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use only a damp cloth for cleaning. Do not use isopropanol based detergents to
clean uniCOSunits.
6. Ventilation. Any slots and openings in the device or equipment are provided for ventilation and
to ensure reliable operation of the product and to protect it from overheating. These openings must
not be blocked or covered. The openings should never be blocked by placing the product on a bed,
sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as
a bookcase or rack unless proper ventilation is provided or the manufacturer's instructions have
been adhered to.
7. Heat. The product should be situated away from heat sources such as radiators, heat registers,
stoves, or other products (including amplifiers) that produce heat. Do not use or operate any
equipment in environments that exceed the standard operating temperatures.
8. Modifications. Do not use any modifications, extension, or other attachments not
recommended by the product manufacturer as they may cause hazards.
9. Accessories. Only use attachments/accessories specified by the manufacturer. Do not place this
product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious
injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod,
bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the
product should follow the manufacturer's instructions, and should use a mounting accessory
recommended by the manufacturer.
10. Water and Moisture. Do not use this product near water or in a moistures environment - for
example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a
swimming pool, in an unprotected outdoor installation; and the like.
SAFETY INSTR UCTIONS 16

11. Moving. A product and cart combination should be moved with care. Quick stops, excessive
force, and uneven surfaces may cause the product and cart combination to overturn.
12. Power Sources. This product should be operated only from the type of power source indicated
on the marking label. If you are not sure of the type of power supply to your home, consult your
product dealer or local power company. For products intended to operate from battery power, or
other sources, refer to the operating instructions.
13. Power Lines. An outdoor system should not be located in the vicinity of overhead power lines
or other electric light or power circuits, or where it can fall into such power lines or circuits. When
installing an outdoor system, extreme care should be taken to keep from touching such power lines
or circuits, as contact with them might be fatal. U.S.A. models only - refer to the National Electrical
Code Article 820 regarding installation of CATV systems.
14. Grounding or Polarization. Do not defeat the safety purpose of the polarized or ground-type
plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wider blade or the third prong are provided for your safety.
If the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
15. Power-Cord Protection. Power-supply cords should be routed to that they are not likely to be
walked on or pinched by items placed upon or against them, paying particular attention to cords at
plug, convenience receptacles, and the point where they exit from the product.
16. Lightning. For added protection for this product during a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from the wall outlet. This will prevent
damage to the product due to lightning and power-line surges. (Not applicable when special
functions are to be maintained, such as evacuation systems.)
17. Overloading. Do not overload wall outlets, extension cords or integral convenience receptacles
as this can result in a risk of fire or electric shock.
18. Object and Liquid Entry. Never push objects of any kind into this product through openings as
they may touch dangerous voltage points or short-out parts that could result in a fire or electric
shock. Never spill liquid of any kind on the product.
19. Inflammable and Explosive Substance. Avoid using this product where there are gases, and
also where there are inflammable and explosive substances in the immediate vicinity.
20. Heavy Shock or Vibration. When carrying this product around, do not subject the product to
heavy shock or vibration.
21. Servicing. Do not attempt to service this product yourself as opening or removing covers may
expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
SAFETY INSTR UCTIONS 17

22. Damage Requiring Service. Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
a. When the power-supply cord or plug is damaged.
b. if liquid has been spilled, or objects have fallen into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the operating instructions. Adjust
only those controls that are covered by the operating instructions as an improper
adjustment of other controls may result in damage and will often require extensive work
by a qualified technician to restore the product to its normal operation.
e. If the product has been dropped or damaged in any way.
f. When the product exhibits a distinct change in performance-this indicates a need for
service.
23. Replacement Parts. When replacement parts are required, be sure the service technician has
used replacement parts specified by the manufacturer or have the same characteristics as the
original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.
24. Safety Check. Upon completion of any service or repairs to this product, ask the service
technician to perform safety checks to determine that the product is in proper operating condition.
25. Coax Grounding. If an outside cable system is connected to the apparatus, be sure the cable
system is grounded. U.S.A. models only: Section 810 of the National Electrical Code, ANSI/NFPA
No.70-1981, provides information with respect to proper grounding of the mount and supporting
structure, grounding of the coax to a discharge apparatus, size of grounding conductors, location of
discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
26. Usage: Non-uniform use of pixels, such as prolonged display of non-moving images (text or
graphics), can create a permanent ghost-like image of these objects or otherwise degrade image
quality. It can lead to uneven use results in uneven light output over time, and in severe cases can
create a ghost image of previous content. While this phenomenon is inherent to LCD technology,
Televic recommends a maximum use of 10 consecutive hours of displaying the same content for
any product with an LCD or OLED display. After 10 hours of use or at the end of the day it is
recommended, if possible, to turn off the displays by shutting down the system. Televic highly
discourages any user from leaving a system containing units with an LCD running 24/7.
Power Connections
For permanently connected equipment, a readily accessible disconnect device shall be incorporated in the
fixed wiring; For pluggable equipment, the socket-outlet shall be installed near the equipment and shall be
SAFETY INSTR UCTIONS 18

easily accessible.
This label may appear on the bottom of the apparatus due to space limitations.
The lightning flash with an arrowhead symbol, with an equilateral triangle, is intended
to alert the user to the presence of un-insulated ‘dangerous voltage’ within the
products enclosure that may be of sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation mark within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. Do not
open the cabinet; refer servicing to qualified personnel only.
To prevent electric shock, do not use this (polarized) plug with an extension cord receptacle or
other outlet unless the blades can be fully inserted to prevent blade exposure.
Installation should be performed by qualified service personnel only in accordance with the
National Electrical Code or applicable local codes.
Installation should be performed by qualified service personnel only in accordance with the
National Electrical Code or applicable local codes.
SAFETY INSTR UCTIONS 19

PLIXUS COMPONENTS
The Plixus architecture allows for a mix & match of components: from flushmount
devices to multimedia units and interpreter desk to PTZ cameras and third-party
Dante™-enabled applications.
This chapter will describe all available hardware components together with how
you can use these components to match your needs.
