About this guide
This user guide describes the information needed to install and
use the Cisco TelePresence Precision 60 and Cisco TelePresence
SpeakerTrack 60 cameras.
User documentation
The user documentation for the Cisco TelePresence systems,
running the TC software, have several guides aimed at various
user groups.
• Video conference room primer
• Video conference room acoustics guidelines
• Getting started guide for the TelePresence systems
• User guide for the TelePresence systems
• Administrator guides for the TelePresence systems
• API reference guides for the C Series and Codec SX80
• TC Console user guide for the C Series and Codec SX80
• Physical interfaces guides for the C Series and Codec SX80
• Regulatory compliance and safety information guides
• Legal and licensing information for products using TC software
Download the user documentation
Go to:http://www.cisco.com/go/telepresence/docs and select
your product to see the user documentation for your product.
Software
The camera software is automatically upgraded through the codec.
Minimum software version requirement is TC 7.1.
Contents
Introduction
Physical interface
Connecting the camera
Appendix
Factory reset
Introduction

Cisco TelePresence Precision 60 and SpeakerTrack 60
D15296.03 Cisco TelePresence Precision 60 and SpeakerTrack 60, APRIL 2016. Copyright © 2016 Cisco Systems, Inc. All rights reserved.
5
Camera guide
CHAPTER 2
Physical interface
Contents
Introduction
Physical interface
Connecting the camera
Appendix
Factory reset
Physical interface

Cisco TelePresence Precision 60 and SpeakerTrack 60
D15296.03 Cisco TelePresence Precision 60 and SpeakerTrack 60, APRIL 2016. Copyright © 2016 Cisco Systems, Inc. All rights reserved.
6
Camera guide
Precision 60
Video
• HDMI is the main video source. The maximum resolution
is 1080p60.
• 3G-SDI is the secondary video source. The maximum reso-
lution is 1080p60.
• In multiple camera scenarios, the HDMI output should be used.
• For long cable lengths, HDMI extenders supporting EDID
should be used. The extender must not alter the SPA address
or any EDID information incorrectly.
Power
• Connect power (12 VDC, 2.5 A).
• Always use the provided cables and adapter.
Ethernet
For camera control and software upgrades.
Do NOT connect a camera control cable to the Ethernet
codec port of the device. This will destroy the system.
Kensington lock
The Kensington lock may be used to prevent the camera from
being moved from its place or to prevent theft. The LED is lit during a call.
The LED is continuously lit when power is
On, and flickers when receiving signals
from the remote control.
Power
supply
Ethernet
RJ45
HDMI Video
out
3G-SDI out
Display port*
Kensington lock
* For future use
Pin-hole for
factory reset
Contents
Introduction
Physical interface
Connecting the camera
Appendix
Factory reset
Physical interface

Cisco TelePresence Precision 60 and SpeakerTrack 60
D15296.03 Cisco TelePresence Precision 60 and SpeakerTrack 60, APRIL 2016. Copyright © 2016 Cisco Systems, Inc. All rights reserved.
7
Camera guide
SpeakerTrack 60
Video
• Two HDMI cables from the cameras.
Power
• Power out to cameras (internal connection).
• Power in: 12 VDC, 6.5 A
Always use the provided cables and adapter.
Ethernet
Two Ethernet ports are used for the internal camera control con-
nection. The third connector is used for connecting the codec.
Do NOT connect a camera control cable to the Ethernet
codec port of the device. This will destroy the system.
Microphone connectors
The right set is used for internal connection to the microphone
panel. The left set of connectors is intended for future use.
Kensington lock
The Kensington lock may be used to prevent the camera from
being moved from its place or to prevent theft.
For more information about the internal connection
setup, please see the SpeakerTrack 60 installation guide:
http://www.cisco.com/go/telepresence/docs
The camera LED is lit during a call on the
camera that is currently sending the live
picture.
The status LED is continuously lit when
power is On, and flickers when receiving
signals from the remote control.
Power out to
cameras
Ethernet
RJ45
codec
Ethernet
RJ45
camera control
Additional
connectors*
Power in USB*
Microphones
on panel
Chinch
connectors*
* For future use
Contents
Introduction
Physical interface
Connecting the camera
Appendix
Factory reset
Physical interface

Cisco TelePresence Precision 60 and SpeakerTrack 60
D15296.03 Cisco TelePresence Precision 60 and SpeakerTrack 60, APRIL 2016. Copyright © 2016 Cisco Systems, Inc. All rights reserved.
8
Camera guide
CHAPTER 3
Connecting to a codec
Contents
Introduction
Physical interface
Connecting the camera
Appendix
Factory reset
Connecting the camera

Cisco TelePresence Precision 60 and SpeakerTrack 60
D15296.03 Cisco TelePresence Precision 60 and SpeakerTrack 60, APRIL 2016. Copyright © 2016 Cisco Systems, Inc. All rights reserved.
9
Camera guide
Codec compatibility
Precision 60
The Precision 60 camera is compatible with the Cisco
TelePrescence SX80 codec.
SpeakerTrack 60
The SpeakerTrack 60 system is compatible with the following
codecs:
• Cisco TelePrescence SX80 codec
• Cisco TelePrescence C90 codec
• Cisco TelePrescence C60 codec
• Cisco TelePrescence C40 codec
The codec has to run TC 7.1 software or a later version.
Cisco TelePrescence SX80
Codec C40/C60
Codec C90
Contents
Introduction
Physical interface
Connecting the camera
Appendix
Factory reset
Connecting the camera

Cisco TelePresence Precision 60 and SpeakerTrack 60
D15296.03 Cisco TelePresence Precision 60 and SpeakerTrack 60, APRIL 2016. Copyright © 2016 Cisco Systems, Inc. All rights reserved.
10
Camera guide
Connect Precision 60 to SX80 Codec
• Connect the video cable to one of the codec’s camera inputs
(HDMI). We recommend using the 1st camera input for the
main camera.
• Connect Ethernet to the codec’s 2nd or 3rd Ethernet port.
• Connect to power.
Power
(100-240 VAC, 50/60 Hz)
Power
adapter
Always use the provided power cable
and adapter (12 V
DC
, minimum 3 A).
RJ45 HDMI
Contents
Introduction
Physical interface
Connecting the camera
Appendix
Factory reset
Connecting the camera

Cisco TelePresence Precision 60 and SpeakerTrack 60
D15296.03 Cisco TelePresence Precision 60 and SpeakerTrack 60, APRIL 2016. Copyright © 2016 Cisco Systems, Inc. All rights reserved.
11
Camera guide
Connect SpeakerTrack 60 to SX80 Codec
Power
(100-240 VAC, 50/60 Hz)
Always use the provided power cable
and adapter (12 VDC, minimum 3 A).
Power
adapter
RJ45
HDMI 1 HDMI 2
• Connect the video cables to the codec’s camera inputs
(HDMI 1 and 2).
• Connect Ethernet to the codec’s 2nd or 3rd Ethernet port.
• Connect to power.
For further information about camera assembly and cabling,
refer to the SpeakerTrack 60 installation guide:
http://www.cisco.com/go/telepresence/docs
When using a SpeakerTrack 60 with a C Series codec, the
codec cannot be controlled with a Cisco Remote Control
TRC5. Instead, a Cisco TelePresence Touch 8 user interface
or an external control device must be used.
Contents
Introduction
Physical interface
Connecting the camera
Appendix
Factory reset
Connecting the camera

Cisco TelePresence Precision 60 and SpeakerTrack 60
D15296.03 Cisco TelePresence Precision 60 and SpeakerTrack 60, APRIL 2016. Copyright © 2016 Cisco Systems, Inc. All rights reserved.
12
Camera guide
Connect SpeakerTrack 60 to Codec C40
Power
(100-240 VAC, 50/60 Hz)
Always use the provided power cable
and adapter (12 V
DC
, minimum 3 A).
Power
adapter
RJ45 HDMI 1 HDMI 2
• Connect the video cables to the codec’s camera inputs
(HDMI 1 and 2).
• Connect Ethernet to the codec’s 2nd or 3rd Ethernet port.
• Connect to power.
For further information about camera assembly and cabling,
refer to the SpeakerTrack 60 installation guide:
http://www.cisco.com/go/telepresence/docs
When using a SpeakerTrack 60 with a C Series codec, the
codec cannot be controlled with a Cisco Remote Control
TRC5. Instead, a Cisco TelePresence Touch 8 user interface
or an external control device must be used.
Contents
Introduction
Physical interface
Connecting the camera
Appendix
Factory reset
Connecting the camera

Cisco TelePresence Precision 60 and SpeakerTrack 60
D15296.03 Cisco TelePresence Precision 60 and SpeakerTrack 60, APRIL 2016. Copyright © 2016 Cisco Systems, Inc. All rights reserved.
13
Camera guide
Connect SpeakerTrack 60 to Codec C60
Power
(100-240 VAC, 50/60 Hz)
Always use the provided power cable
and adapter (12 V
DC
, minimum 3 A).
Power
adapter
RJ45
HDMI 1 HDMI 2
• Connect the video cables to the codec’s camera inputs
(HDMI 1 and 2).
• Connect Ethernet to the codec’s 2nd or 3rd Ethernet port.
• Connect to power.
For further information about camera assembly and cabling,
refer to the SpeakerTrack 60 installation guide:
http://www.cisco.com/go/telepresence/docs
When using a SpeakerTrack 60 with a C Series codec, the
codec cannot be controlled with a Cisco Remote Control
TRC5. Instead, a Cisco TelePresence Touch 8 user interface
or an external control device must be used.
Contents
Introduction
Physical interface
Connecting the camera
Appendix
Factory reset
Connecting the camera

Cisco TelePresence Precision 60 and SpeakerTrack 60
D15296.03 Cisco TelePresence Precision 60 and SpeakerTrack 60, APRIL 2016. Copyright © 2016 Cisco Systems, Inc. All rights reserved.
14
Camera guide
Connect SpeakerTrack 60 to Codec C90
Power
(100-240 VAC, 50/60 Hz)
Always use the provided power cable
and adapter (12 V
DC
, minimum 3 A).
Power
adapter
RJ45
HDMI 1,2
• Connect the video cables to the codec’s camera inputs
(HDMI 1 and 2).
• Connect Ethernet to the codec’s 2nd Ethernet port.
• Connect to power.
For further information about camera assembly and cabling,
refer to the SpeakerTrack 60 installation guide:
http://www.cisco.com/go/telepresence/docs
When using a SpeakerTrack 60 with a C Series codec, the
codec cannot be controlled with a Cisco Remote Control
TRC5. Instead, a Cisco TelePresence Touch 8 user interface
or an external control device must be used.
Contents
Introduction
Physical interface
Connecting the camera
Appendix
Factory reset
Connecting the camera

Cisco TelePresence Precision 60 and SpeakerTrack 60
D15296.03 Cisco TelePresence Precision 60 and SpeakerTrack 60, APRIL 2016. Copyright © 2016 Cisco Systems, Inc. All rights reserved.
15
Camera guide
CHAPTER 4
Factory reset
Contents
Introduction
Physical interface
Connecting the camera
Appendix
Factory reset
Factory reset

Cisco TelePresence Precision 60 and SpeakerTrack 60
D15296.03 Cisco TelePresence Precision 60 and SpeakerTrack 60, APRIL 2016. Copyright © 2016 Cisco Systems, Inc. All rights reserved.
16
Camera guide
Precision 60
A factory reset should only be performed by a system admin-
istrator or in contact with Cisco technical support.
The camera will be reset to factory defaults, and all configuration
and logs will be erased.
It is not possible to undo a factory reset.
To perform a factory reset:
1. Locate the pin hole button at the back of the camera.
2. Use a pen or similar to press and hold the factory reset
button for 10 seconds.
3.The camera LED will be lit red during the factory reset.
Do not unplug power.
4. When the factory reset is complete, the camera restarts and
the camera LED lights up.
Pin-hole for
factory reset
Contents
Introduction
Physical interface
Connecting the camera
Appendix
Factory reset
Factory reset

Cisco TelePresence Precision 60 and SpeakerTrack 60
D15296.03 Cisco TelePresence Precision 60 and SpeakerTrack 60, APRIL 2016. Copyright © 2016 Cisco Systems, Inc. All rights reserved.
17
Camera guide
SpeakerTrack 60
Factory resetting the device
A factory reset should only be performed by a system admin-
istrator or in contact with Cisco technical support.
The device will be reset to factory defaults, and all configura-
tion and logs will be erased.
If errors continue to occur, the cameras might have to be
reset, too. See the next page for instructions on how to reset
the cameras.
It is not possible to undo a factory reset.
To perform a factory reset:
1. Remove the top cover of the SpeakerTrack 60 device.
2. Locate the pin hole button at the top of the SpeakerTrack 60.
3. Use a pen or similar to press and hold the factory reset
button for 10 seconds.
4. The camera LED will be lit red during the factory reset.
Do not unplug power.
5. When the factory reset is complete, the device restarts
and the LED lights up.
REMOVE COVERREMOVE COVER
Pin-hole for
factory reset
1
REMOVE COVERREMOVE COVER
2
3
Contents
Introduction
Physical interface
Connecting the camera
Appendix
Factory reset
Factory reset

Cisco TelePresence Precision 60 and SpeakerTrack 60
D15296.03 Cisco TelePresence Precision 60 and SpeakerTrack 60, APRIL 2016. Copyright © 2016 Cisco Systems, Inc. All rights reserved.
18
Camera guide
SpeakerTrack 60
Factory resetting the cameras
In order to reset the cameras, they have to be lifted from the
carrier tray, to access to the pin-hole button on the back panel
of the camera.
A factory reset should only be performed by a system administra-
tor or in contact with Cisco technical support.
The cameras will be reset to factory defaults, and all configuration
and logs will be erased.
It is not possible to undo a factory reset.
To perform a factory reset:
1. Remove the top cover of the SpeakerTrack 60 device.
2. Unscrew the wing nut that fastens one of the cameras.
3. Locate the pin hole button at the back of the camera.
See also factory reset on Precision60.
4. Use a pen or similar to press and hold the factory reset button
for 10 seconds.
5.The camerra LED will be lit red during the factory reset.
Do not unplug power.
6. When the factory reset is complete, the camera restarts and
the camera LED lights up.
7. Set the camera back to the tray and tighten the wing nut (see
picture 2 on the right).
8. Repeat steps 2-7 with the other camera.
9. Set back the top cover.
1
2
When replacing the camera, make
sure the pins on the base plate
fit the holes in the camera inter-
face plate.
3
Locate the pin-hole on the back
plate of the camera.
Contents
Introduction
Physical interface
Connecting the camera
Appendix
Factory reset
Factory reset

Cisco TelePresence Precision 60 and SpeakerTrack 60
D15296.03 Cisco TelePresence Precision 60 and SpeakerTrack 60, APRIL 2016. Copyright © 2016 Cisco Systems, Inc. All rights reserved.
19
Camera guide
CHAPTER 5
Appendix
Contents
Introduction
Physical interface
Connecting the camera
Appendix
Factory reset
Appendix

Cisco TelePresence Precision 60 and SpeakerTrack 60
D15296.03 Cisco TelePresence Precision 60 and SpeakerTrack 60, APRIL 2016. Copyright © 2016 Cisco Systems, Inc. All rights reserved.
20
Camera guide
Technical specifications
Precision 60
• 1080p60 Full High Definition
• 10 x optical zoom
• 2x digital zoom
• 20x zoom combined
• Pan range: -100° to +100°
• Tilt range: -20° to +20°
• 80° horizontal field of view
• 48.8° vertical field of view
• Focus distance: 1.0m – ∞ (wide)
• F number: 1.5
• Camera control over Ethernet
• Automatic or manual focus, brightness and white balance
• IP network features:
• DNS lookup for service configuration
• Date and Time support via NTP
• TCP/IP
• DHCP
• LAN/Ethernet (RJ45) 10/100 Mbit network interface
• HDMI and 3G-SDI video interfaces
• Power adapter:
• Input: 100-120 or 200-240 VAC; 50 or 60 Hz
• Output: 12 V / 6.5 A
• Operating temperature and humidity:
• 0°C to 40°C (32°F to 104°F)
• 10 to 90 % relative humidity
• Storing and transport temperature and humidity:
• -20°C to 60°C (-4°F to 140°F)
• 10 to 90 % relative humidity, non condensing
• Height: 152 mm/6.0 in
• Width: 268mm/10.6 in
• Depth: 163mm/6.4in
• Weight: 2.5 kg/5.5lbs
• Part number: CTS-CAM-P60=
Contents
Introduction
Physical interface
Connecting the camera
Appendix
Factory reset
Appendix
