Vaporesso GTX GO 80 User manual

User Manual
VAPORESSO GTX GO 80

Thank you for choosing Vaporesso
product. Please read this instruction
carefully before use to ensure a perfect
experience. If there is any additional
requirement about this product, please
consult the local agent or contact us
through our website: www.vaporesso.com
EXPLODED VIEW
1
2
3
4
5
6
7
8
SPECIFICATIONS
Dimensions: Ø26 x 133.2mm
Coil: GTX 0.2Ω MESH Coil (45-60W)
Pod Capacity: 5ml /2ml
Output Power: 5-80W
Output Voltage: 0-4V
Resistance Range: 0.1-2Ω
Baery Capacity: Built-in 3000mAh
Charging: DC 5V/2A, Type-C
GTX

①Drip Tip
②PCTG Tube
③Air-inlet Port
④Power Button
⑤Battery
⑥Top Cap
⑦ Coil
⑧Type-C USB Port
① Abtropfspitze
②PCTG-Rohr
③Lufteinlass-Anschluss
④Einschalttaste
⑤Akku
⑥Obere Kappe
⑦ Coil
⑧Typ C-USB-Anschluss
①Punta de goteo
②Tubo PTCG
③Puerto de entrada de aire
④Botón de encendido
⑤Batería
⑥Tapa superior
⑦ Coil
⑧Puerto USB tipo C
①Ponta de gotejamento
②Tubo PCTG
③Porta de entrada de ar
④Botão de alimentação
⑤Bateria
⑥Tampa superior
⑦Bobina
⑧Porta USB Tipo C
①Drip Tip
②Tube PCTG
③Port d’entrée d’air
④Bouton d’alimentation
⑤Batterie
⑥Capuchon supérieur
⑦ Coil
⑧Port USB type C
①Beccuccio
②Tubo PCTG
③Porta ingresso aria
④Pulsante di accensione
⑤Batteria
⑥Cappuccio superiore
⑦ Coil
⑧Porta USB Tipo C
English Italiano
Español
Français
Deutsch Português

Nederlands
日本語
ΕλληνικάPolski
Bahasa 中文
①Druppelpunt
②PCTG-buis
③Luchtinlaatpoort
④Aan/uit-knop
⑤Accu
⑥Dop
⑦ Coil
⑧USB-poort type C
①Drip Tip
②Tabung PCTG
③Port Masukan Udara
④Tombol Daya
⑤Baterai
⑥Tutup Atas
⑦ Coil
⑧Port USB Tipe-C
①ドリップチップ
②PCTG 管
③ エアインレットポート
④ 電源ボタン
⑤ バッテリー
⑥ トップキャップ
⑦Coil
⑧ USB ポート（タイプ C）
①烟嘴
② PCTG 管
③ 进气口
④ 电源键
⑤ 电池
⑥ 顶盖
⑦雾化芯
⑧ Type-C USB 接口
① Ustnik
②Rurka PCTG
③Port wlotu powietrza
④Przycisk zasilania
⑤Akumulator
⑥Nasadka górna
⑦ Coil
⑧PortUSB typu C
①Επιστόμιο
②PCTG Σωλήνας
③Θύρα εισόδου αέρα
④Κουμπί ενεργοποίησης
⑤Μπαταρία
⑥Άνω κεφαλή
⑦Coil
⑧Θύρα USB Τύπου-C

FIGURES
Figure 1: Replace the coil Figure 2: Fill e-liquid
PACKING LIST
1 x GTX GO 80 Battery
1 x GTX POD 26 (5ml/2ml TPD)
1 x GTX 0.2Ω MESH Coil
1 x Type-C USB Cable
1 × User Manual
1 × Warranty Card
OPEN CLOSE

1English
ENGLISH
USE INSTRUCTIONS
1. Install the POD
Connect the battery and the pod by magnetic absorption, please ensure the assembly is stable.
2. Replace the Coil
- Place the drip tip of the pod face down, and pull out the used coil;
- Install a new coil to the pod;
- Press the coil to align the coil base with the pod.
* Refer to the gure 1.
3. Fill E-liquid
- Unscrew the top cap from the pod refer to the arrow;
- Fill e-liquid through the lling slot;
- Screw the top cap to reinstall it back into place as shown;
- Please wait 5 minutes for the e-liquid to soak into the coil completely.
* Refer to the gure 2.
4. Adjust the Airow
Please rotate the pod to match the air-inlet port with the battery to adjust the airow volume.

2
English
PROTECTIONS
5. System Operating
(1) Power on/off: press the power button 5 times in 2s.
(2) Start Vaping: press and hold the power button to start vaping. For your safety, please do not
vape for more than 10 seconds at a time.
(3) Baery Indicators:
LED Color Battery Status
High (70%-100%)
Medium (30%-70%)
Low (0%-30%)
Protections Situation Indicator
Low Resistance Protection The device detects an ultra-low resistance when
start to vape.
x 5 Stop Output
Short-circuit Protection The device detects a short circuit. x 5 Stop Output

3English
No Load Protection The device does not detect an atomizer when
start to vape.
Low Battery: x 5 Stop Output
Medium Battery: x 5 Stop Output
High Battery: x 5 Stop Output
High Resistance Protection The device detects an ultra-high resistance
when start to vape.
Low Battery: x 5 Stop Output
Medium Battery: x 5 Stop Output
High Battery: x 5 Stop Output
Low Voltage Protection The battery voltage drops too low when start to
vape.
x 3 Stop Output
Over Charge Protection The device is fully charged. Stop Charging
Over Discharge Protection The battery voltage drops too low during vaping. x 3 Stop Output
Auto-Shut o󰀨 Protection Constantly vape for 10 seconds or more. Low Battery: x 3 Stop Output
Medium Battery: x 3 Stop Output
High Battery: x 3 Stop Output
Over Heat Protection The device detects a high temperature PCBA. x 5 Stop Output

4
English
CAUTIONS
1. Please turn off the device when it is not in use.
2. Do not leave the charging device unattended.
3. Do not drop, throw or abuse your device, which may cause damage.
4. Please use a standard USB output charger with proper charging current and voltage range.
5. Keep away from the water or any ammable gas, liquid .
6. Do not expose the device to direct sunlight, dust, moisture or mechanical shock.
7. Do not expose the device to extreme temperature. (Recommended temperature range:
-10~60℃ /14~140℉ while using and -10~45℃ /14~113℉ while storing).
8. EEE Recycling: the product should not be treated as household waste, instead, it should
be handed over to the applicable collection point for the recycling of electrical and electronic
equipment.
9. Battery Recycling: the product battery should not be treated as household waste, instead, it
should be handed over to the applicable used battery collection point for recycling.
10. Only have your device repaired by Vaporesso. Do not attempt to repair it by yourself as
damage or personal injury may occur.

5English
WARNINGS
This rellable electronic cigaree is intended for use with compatible e-liquid, which may contain nicotine.
Nicotine is an addictive substance and it is not suitable or recommended to use in following cases:
1. This device is not suitable for:
- Persons under the legal smoking age.
- Persons experiencing heart disease, stomach or duodenal ulcers, liver or kidney problems, long-term
throat disease or difcult breathing due to bronchitis, emphysema or asthma.
- Persons with an overactive thyroid gland or experiencing phaeochromocytoma (a tumour of the adrenal
gland that can affect blood pressure).
- Persons taking certain medications like Theophylline, Ropinirole or Clozapine and etc..
2. This device is not recommended for:
- Non-smokers
- Pregnant or breastfeeding women
3. You may experience the following results if you use nicotine containing e-liquid with this product. If it
happens, please consult a healthcare professional and show them this leaet if possible:
- Feeling faint - Nausea - Dizziness - Headache - Coughing - Irritation of the mouth or throat
- Stomach discomfort - Hiccups - Nasal congestion - Vomition
- Chest palpitations/pain or an irregular heart rate
This device should not be used by persons under the legal smoking age.
