Vaporesso XROS MINI User manual

User Manual
VAPORESSO XROS MINI

Thank you for choosing Vaporesso product.
Please read this instruction carefully before
use to ensure a perfect experience. If there is
any additional requirement about this product,
please consult the local agent or contact us
through our website: www.vaporesso.com
EXPLODED VIEW
Dimensions: 98.9 x 23.4 x 13.5mm
POD Capacity: 2ml
POD Resistance:
1.2Ω
0.8Ω Mesh(Not included, Compatible)
Battery Capacity: 1000mAh
Output Power 11W/16W
Charging Current: DC 5V/1A, Type-C
Display: Single 3-Color LED Indicator
SPECIFICATIONS
Drip Tip
Filling Hole
Replaceable POD
LED Indicator
Type-C USB Port

PACKING LIST
1 x VAPORESSO XROS MINI Battery
1 x VAPORESSO XROS Series 1.2Ω POD (2ml)
1 x Type-C USB Cable
1 x User Manual
1 x Warranty Card
Figure 1: Replace the POD

Figure 2: Fill the E-liquid

1English
ENGLISH
USE INSTRUCTIONS
1. Replace the POD
1) Pull out the used POD from the device;
2) Put the new POD into the device firmly.
2. Fill the E-liquid
- Snap off the drip tip from the POD;
- Gently insert the e-liquid filling bottle tip into the filling slot;
- Press down and squeeze the e-liquid through the slot;
- Install the drip tip back and confirm it’s shut firmly;
- Please wait 5 minutes for the e-liquid to soak into the coil completely.
3. Start Vaping
Inhale directly to enjoy extraordinary vaping experience.
4. Baery Level
LED Color Baery Status
High (70%-100%)
Medium (30%-70%)
Low (0%-30%)

2
English
PROTECTIONS
5. Charge the Baery
After connecting the Type-C cable to the device, the LED indicator will breathe in red light.
Once the battery is fully charged, the indicator will turn into green light.
Protections Situation Indicator
Low Resistance Protection The device detects an ultra-low resistance. x 5 Stop Output
Short-circuit Protection The device detects a short circuit. x 5 Stop Output
No Load Protection The device does not detect an atomizer. x 5 Stop Output
High Resistance Protection The device detect an ultra-high resistance. x 5 Stop Output
Low Voltage Protection The battery voltage drops too low. x 3 Stop Output
Over Charge Protection The device is fully charged. Stop Charging
Over Discharge Protection The battery voltage drops too low during
vaping.
x 3 Stop Output
Auto-Shut off Protection Constantly vape for 8 seconds or more. x 3 Stop Output

3English
CAUTIONS
1. Please turn off the device when it is not in use.
2. Do not leave the charging device unattended.
3. Do not drop, throw or abuse your device, which may cause damage.
4. Please use a standard USB output charger with proper charging current and voltage range.
5. Keep away from the water or any flammable gas, liquid .
6. Do not expose the device to direct sunlight, dust, moisture or mechanical shock.
7. Do not expose the device to extreme temperature. (Recommended temperature range: -10~60℃
/14~140℉while using and -10~45℃/14~113℉while storing).
8. EEE Recycling: the product should not be treated as household waste, instead, it should
be handed over to the applicable collection point for the recycling of electrical and electronic
equipment.
9. Battery Recycling: the product battery should not be treated as household waste, instead, it
should be handed over to the applicable used battery collection point for recycling.
10. Only have your device repaired by Vaporesso. Do not attempt to repair it by yourself as damage
or personal injury may occur.

4
English
WARNINGS
This refillable electronic cigaree is intended for use with compatible e-liquid, which may contain
nicotine. Nicotine is an addictive substance and it is not suitable or recommended to use in
following cases:
1. This device is not suitable for:
- Persons under the legal smoking age.
- Persons experiencing heart disease, stomach or duodenal ulcers, liver or kidney problems, long-
term throat disease or difficult breathing due to bronchitis, emphysema or asthma.
- Persons with an overactive thyroid gland or experiencing phaeochromocytoma (a tumour of the
adrenal gland that can affect blood pressure).
- Persons taking certain medications like Theophylline, Ropinirole or Clozapine and etc..
2. This device is not recommended for:
- Non-smokers
- Pregnant or breastfeeding women
3. You may experience the following results if you use nicotine containing e-liquid with this
product. If it happens, please consult a healthcare professional and show them this leaflet if
possible:
- Feeling faint - Nausea - Dizziness - Headache - Coughing - Irritation of the mouth or throat
- Stomach discomfort - Hiccups - Nasal congestion - Vomition
- Chest palpitations/pain or an irregular heart rate
This device should not be used by persons under the legal smoking age.

1Français
FRANÇAIS
CONSIGNES D’UTILISATION
1. Remplacement de la cartouche
1) Retirez la cartouche usagée de l’appareil ;
2) Placez fermement la cartouche neuve dans l’appareil.
2. Recharge de l’E.-liquide
- Retirez le drip tip de la cartouche ;
- Insérez délicatement le bout de la bouteille de recharge d’E.-liquide dans l’orifice de remplissage;
- Appuyez sur la bouteille pour faire passer l’E.-liquide à travers l’orifice ;
- Remettez le drip tip en place et assurez-vous qu’il est fermement fixé ;
Veuillez patienter 5 minutes, le temps que l’E.-liquide imbibe complètement la résistance.
3. Commencer à vapoter
Inspirez directement d’alimentation pour vivre une expérience de vapotage extraordinaire.
4. Niveau de charge de la baerie
Couleur du voyant DEL État de charge de la baerie
Élevé (70-100 %)
Moyen (30-70 %)
Bas (0-30 %)
5. Charge de la baerie
Lorsqu’on raccorde le câble de type C à l’appareil, le voyant DEL émet une lumière rouge. Une
fois la batterie complètement chargée, le voyant émet une lumière verte stable.
