58 Vario cooktops
VP 414 610
Stainless steel
Width 15" (38 cm)
Included accessory
2 spatulas
Installation accessories
In combination of several Vario
cooktops or VL 414 downdraft,
connecting strips must be used.
Choose respective VA 420 strip
from one of the below, depending
on type of installation.
VA 420 010
Connection strip for surface-mount
installation without appliance cover.
VA 420 011
Connection strip for surface-mount
installation with appliance cover.
VA 420 000
Connection strip for flush
installation without appliance cover.
VA 420 001
Connection strip for flush
installation with appliance cover.
VA 440 010
Stainless steel cover with mounting
strip.
VA 450 400
Stainless steel adjustment strip,
width 15". Necessary accessory in
a combination of 15" Varios with at
least one appliance cover to com-
pensate for the appliance depth.
Vario 400 series teppan yaki
VP 414
– Hard chrome-plated surface
for teppan cooking and use as
griddle, grill, searer and
warming plate. No pots or pans
necessary.
– Exact temperature control up to
480° F.
– Optimum heat distribution
– Solid stainless steel control
knobs
– Precision-crafted ⅛-inch
stainless steel frame
– For surface-mount installation
with a visible edge or for flush
installation
– Can be perfectly combined with
other Vario 400 series products
Cooking zones
Cooking area: W 12 ³⁄₁₆" x D
17 ⁵⁄₁₆".
Operation
Two control knobs with illuminated
ring, cooking position and output
marking.
Electronic temperature control from
240°F to 480°F plus warming plate
function.
Features
Two 1,500 W independent zones,
can be operated together as a
complete surface or independently
for front or rear operation.
Simple to clean surface.
Warming stage.
Safety
Safety lock.
Planning notes
Depending on the type of
installation — surface-/ or
flush-mounted, with or without
cover — the specific location of the
control knob positions may vary.
When using the appliance cover
VA 440 or adjustment strip VA 450
additional space for cut-out depth
needs to be considered.
In a combination of Vario cooktops
with at least one appliance cover,
the adjustment strip VA 450 is
required.
In a combination of several Vario
400 series cooktops a connection
strip must be used.
Depending on the type of
installation — surface-/ or
flush-mounted, with or without
cover — the respective VA 420
connecting strip must be used.
For flush installation the edge
height in the cut-out needs to be at
least ½" and for surface-mount ⅜".
Ensure a continuous cut surface
of 90°.
The weight capacity and stability,
especially in case of thin
countertops, must be supported
using suitable substructures. Take
the appliance weight and additional
loads into account.
Flush installation is possible in
countertops made of stone,
synthetics or solid wood. Heat
resistance and watertight sealing
of the edges must be observed. For
other materials, please consult with
your countertop manufacturer.
The groove must be continuous and
even, so that uniform placing of the
appliance on the gasket is ensured.
Do not use discontinuous lining.
The joint width may vary due to size
tolerances of the combinations and
of the countertop cut-out.
If installing several Vario products
in individual cut-outs allow for a
minimum distance of 2" between
the cooktops.
Built-in control panel can be inte-
grated in the bottom cabinet at
drawer level.
Front panel thickness ⅝" – 1".
The adjacent drawing “Installation
of the control knobs” must be
observed if the panel is more than
1" thick (there must be a recess at
the rear for proper control module
installation).
Above countertop minimum
clearance of 21" from adjacent
heat-sensitive cabinets or contact
surfaces must be observed
or thermal insulation must be
installed.
Appliance can be snapped into the
countertop from above.
Please read additional planning
notes on pages 72 – 79.
Rating
Total rating: 3.0 kW
Total Amps: 13
208 / 220-240V / 60Hz
Plan for a 55" connecting cable 55"
without plug (hardwire required).

Vario cooktops 59
Numbers indicated
inside parenthesis ( ) = mm
R
1
/
8
" (R 3)
90°
*
with appliance cover or adjustment strip.
See separate planning notes.
**
3
3
/
