Varytec x-cross User manual

User manual
X-Cross

2 / 7
Table of contents
1. Safety instructions............................................................................................................................ 3
1.1. FOR SAFE AND EFFICIENT OPERATION............................................................................ 3
2. Technical Data ................................................................................................................................. 4
3. Operation.......................................................................................................................................... 4
3.1. System menü........................................................................................................................... 4
3.2. DMX Control............................................................................................................................ 5
3.3. Automatic mode....................................................................................................................... 6
3.4. Sound to Light mode ............................................................................................................... 6
3.5. Master Slave mode.................................................................................................................. 6
3.6. Version number ....................................................................................................................... 6

3 / 7
1. Safety instructions
•This device is suitable for indoor use only.
•All modifications to the device will void the warranty.
•Repairs are to carry out by skilled personnel only.
•Use only fuses of the same type and original parts as spare parts.
•Protect the unit from rain and humidity to avoid fire and electric shocks.
•Make sure to unplug the power supply before opening the housing.
1.1.FOR SAFE AND EFFICIENT OPERATION
Be careful with heat and extreme temperature
Avoid exposing it to direct rays of the sun or near a heating appliance.
Not put it in a temperature bellow 32°F / 0°C, or e xceeding 104°F / 40°C.
Keep away from humidity, water and dust
Do not place the set in a location with high humidity or lots of dust.
Containers with water should not be placed on the set.
Keep away from sources of hum and noise
Such as transformer motor, tuner, TV set and amplifier.
To avoid placing on un-stable location
Select a level and stable location to avoid vibration.
Do not use chemicals or volatile liquids for cleaning
Use a clean dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.
If out of work, contact sales agency immediately
Any troubles arose, remove the power plug soon, and contact with an engineer for repairing,
do not open the cabinet by yourself, it might result a danger of electric shock.
Take care with the power cable
Never pull the power cable to remove the plug from the receptacle, be sure
to hold the plug. When not using the device for an extended period of time, be sure to
disconnect the plug from the receptacle
.

4 / 7
Important: Damages caused by the disregard of this user manual are not subject to
warranty. The dealer will not accept liability for any resulting defects or
problems. Make sure the electrical connection is carried out by qualified
personnel. All electrical and mechanical connections have to be carried out
according to the European safety standards.
2. Technical Data
Power supply
230V
50Hz
Power consumption
20
W
Current
0.
11
A
Sound
to Li ht
Via
built in mic
DMX512
connection
3 Pin XLR
Wei ht
5
K
Measurements
41
0
x 385 x 59
0
m
m
Maximum ambient temperature
-
20
°
-
+40°
C
Maximum housin temperature
+20
°
-
+60°
C
Fuse
F1A, 250V
Channel
2
Number of LEDs
160 x 5
mm LEDs (40
x
R, 30
x
G, 30
x
B, 30
x
W, 30
x
A)
3. Operation
3.1.System menü
the system menu is built like described below this information. Generally you can leave menus
with ESC, until you reach the highest control line (see diagram). With ENTER you can recall a
function to set up the according values, then you can change these values by using the
UP/DOWN buttons. Always confirm your set up by using ENTER. With ESC you can go back and
leave this menu.

5 / 7
3.2.DMX Control
To set up your desired DMX address, first of all push ESC, then use the UP/DOWN buttons until
you see “Addr” in the display. Now press ENTER, to enter the menu. Now the display shows
“Axxx”. In this case x stands for the set dmx address. Now set up your own desired dmx address
by using the UP/DOWN buttons. Leave the menu with the ESC button.
The fixture can be controlled by dmx.
DMX
Channel
Value
Func
tion
1
0
–
7
8 – 15
16 – 23
24 – 31
32 – 39
40 – 47
48 – 55
56 – 63
64 – 71
72 – 79
80 – 87
88 – 95
96 – 103
104 – 111
112 – 119
120 – 127
128 – 135
136 – 143
144 – 151
No function
Pro ram 1
Pro ram 2
Pro ram 3
Pro ram 4
Pro ram 5
Pro ram 6
Pro ram 7
Pro ram 8
Pro ram 9
Pro ram 10
Pro ram 11
Pro ram 12
Pro ram 13
Pro ram 14
Pro ram 15
Pro ram 16
Pro ram 17
Pro ram 18

6 / 7
152
–
159
160 – 167
168 – 175
176 – 183
184 – 191
192 – 199
200 – 207
208 – 215
216 – 223
224 – 231
232 – 239
240 – 247
248 – 255
Pro ram 19
Pro ram 20
Pro ram 21
Pro ram 22
Pro ram 23
Pro ram 24
Pro ram 25
Pro ram 26
Pro ram 27
Pro ram 28
Pro ram 29
Sound 1
Sound 2
2
0
–
255
Speed from slow to fast
3.3.Automatic mode.
To enter the automatic mode push the ESC button. After that use the UP/DOWN buttons until
“auto” is shown in the display. Push ENTER to enter the menu Now the display shows „Aut”. Push
Enter to see the speed adjust menu. The display shows “SP x” and x stands for a letter from 1 to
9, which is for adjusting the speed.
3.4.Sound to Light mode
to choose the sound to light mode, go on as you read here:
Push the ESC button first. Then use UP/DOWN buttons until you see “Soun” in the display. Push
ENTER You can read “Soux” in the display and with the UP/DOWN buttons you can choose
between the 2 sound programs. Push Enter to see the speed adjust menu. The display shows “SP
x” and x stands for a letter from 1 to 9, which is for adjusting the speed.
3.5.Master Slave mode
Push the ESC button first. Then use UP/DOWN buttons until you see “SLav” in the display. Push
ENTER. Now the fixtures works in slave mode and copies exact the values from the master
fixture.
For the connection of master fixture and slave fixture, please use a standard dmx 3 pole XLR 110
Ohms cable. Connect the male connector to the master and the female connector to the slave
fixture. Go on like this until all the fixtures you want to be connected, are connected. Set up your
desired settin s at the master and all the slaves will copy the functions of this fixture.
3.6.Version number
Push the ESC button first. Then use UP/DOWN buttons until you see “VER” in the display. Push
ENTER: Now you can see the actual software version. Leave the menu with ESC.

7 / 7
Importer:
B & K Braun GmbH
Industriestraße 1
D-76307 Karlsbad
www.bkbraun.com
[e-mail]
