Vax C86-TOe Series Installation instructions

vax.co.uk
C86-TOe Series
Impact 102
Let’s get started

Thank you for buying this Impact 102.
Taking care of your carpets
The Impact 102 is designed to make vacuuming carpets and hard oors regularly, as eective and
ecient as possible and this user guide will help you get the most out of your machine.
Maintaining your carpets and hard oors will ensure they keep their appearance for longer.
You’ve chosen carpets and hard oors for your home for a reason and Vax will help you take
good care of them.
Taking care of your Impact 102
Also inside this guide are instructions on maintaining your new machine, so that it’s always ready
when you are to tackle your carpets and hard oors.
Basic safety precautions
3Turn o all controls on the vacuum cleaner before
disconnecting or connecting the power cord.
3Always make sure both the pre-motor/post-motor
lters are in place before use.
3Always switch o the vacuum cleaner before
disconnecting or connecting the hose and accessories.
3Keep all openings clear and free from debris as this
may aect the airow/suction.
3Always replace the fuse in the plug with a British
13amp fuse. Always protect the power cable from
heated surfaces and open ames.
3Take extra care when positioning and using the vacuum
cleaner on the stairs.
3Use only CE approved 13amp extension cords, non-
approved extension cords may overheat. Care should
be taken to arrange the extension cord as it can be a
trip hazard.
3Store your vacuum cleaner in a cool, dry area. If lters
have been cleaned as per user guide instructions
ensure they are thoroughly dry before storing away.
Please keep instructions for further use.
Don’ts
Do’s
8Don’t use this vacuum cleaner if it has been dropped,
damaged or left outdoors or the lters not in their
original place.
8Don’t run over the power cord or use vacuum cleaner
if the power cord or plug is damaged. Please contact
our Customer Care Line on: 0844 4128 455 (Mon-Fri
8.30am-6-30pm Sat 9.00am-5.00pm).
8Don’t handle the plug or use the vacuum cleaner with
wet hands.
8Don’t pull or carry this vacuum cleaner by the power
cord. Don’t use the power cord as a handle, pull the
power cord around corners, sharp edges or close
a door over the power cord. Don’t unplug vacuum
cleaner by pulling on the power cord.
8Don’t lift or carry the vacuum cleaner by the dirt
container handle.
8Don’t vacuum up any ammable or combustible
materials (lighter uid, petrol, kerosene etc.) or use the
vacuum cleaner in an area with explosive vapours
or liquid.
8Don’t vacuum up hot coals, cigarette butts, matches
or smoking hot burning items or use in an area where
there may be harmful uids (chlorine, bleach, and
ammonia drain cleaner).
8Don’t attempt to remove blockages with sharp objects
as this may cause damage to your vacuum cleaner.
8Don’t vacuum up hard or sharp objects such as glass,
nails, screws or coins etc.
8Don’t use the vacuum cleaner with incorrect voltage
as this may result in damage or injury to the user.
The correct voltage is listed on the ratings label.
Let’s talk safety
Taking care of you
We’re here if you need us. Instead of taking me back
to the shop, simply visit:
vax.co.uk/support or call:
(UK) 0844 412 8455 (ROI) 1-800 928 308
Monday-Friday 8.30am to 6.30pm, Saturday 9.00am to 5.00pm
Calls are charged at the UK local rate. Please make a note of the serial number and model number
of the product before calling.
Alternatively, you can write to us at:
Vax Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire, WR9 0QH, UK
Let us know what you think @VaxUK
This vacuum cleaner is intended for household use
only and NOT for commercial or industrial use.
• Only use the vacuum cleaner indoors on dry surfaces
and keep the area you’re cleaning well lit.
• Keep ngers, hair and loose clothing away from moving
parts and openings whilst using the vacuum cleaner.
• This vacuum cleaner can be used by children aged
from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
vacuum cleaner in a safe way and understand the
hazards involved. Children shall not play with the
vacuum cleaner. Cleaning and user maintenance shall
not be made by children without supervision.
• Only Vax recommend tools and accessories should
be used with this vacuum cleaner.

Contents Getting to know your machine
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
Let’s talk technical
What to do if it goes wrong
Getting in touch
Accessories
Notes
Impact 102
Included with
your machine
Impact 102 Pet
+
Name Impact 102
Voltage 220-240~50Hz
Wattage 700watts
Cord Length 5m
Weight 4.9kg
Technical Specication
Subject to technical change without notice.
Filter Kit (Type 109)
1-1-134393-00
TurboTool (Type 6)
1-1-134419-00
Tool Connector (Type 1)
1-1-133838-00
Crevice Tool (Type 10)
1-9-128020-00
Combination Floor Tool (Type 6)
1-1-134330-00
Upholstery tool (Type 4)
1-9-128019-00
Accessories & Consumables
*To purchase consumables and accessories, please visit vax.co.uk
Initial Setup for normal operation
1. Use the base accessories.
a. Shortest hose
b. Extension tube set to shortest practicable length.
2. Clean lters installed.
3. Dust receptacle empty.
4. All Bleeds must be closed.
5. Floor heads/tools set to Carpet Mode for carpet cleaning.
6. Mechanical Agitation turned ON for carpet cleaning.
7. Floor heads/tools set to Hard Floor Mode for hard oor cleaning.
8. Mechanical Agitation turned OFF for hard oor cleaning.
On/o button
Post-motor
lter cover
Floor head
parking slot
Cord rewind
button
Dirt container
release button
Dirt container handle
Shroud
Carry handle
Post-motor lter
release button
Hose entry point
Accessory hose and handle
2 pc extension tube
Combination oor head
Crevice tool
Upholstery tool
Post-motor lter
Pre-motor lter
Frame Foam
TurboTool
Tool connector

TIP
Brushes on the oor head
should be visible when using
on hard oors.
Assembling your upright
Press both buttons at end
of hose and insert into
hose entry point.
Unwind the power cord.
Do not pull further than the
yellow marker.
Insert hose grip into
extension tube.
Plug into mains and push
the on/o button to turn
your machine on.
Insert the other end of the
telescopic tube into the
oor head.
Before you begin cleaning
IMPORTANT: The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does
overheat the thermostat will automatically turn the vacuum cleaner o. If this happens, switch the vacuum cleaner
o and unplug. Remove and empty the dirt container also check the vacuum cleaner for blockages. Allow the vacuum
cleaner to cool for approximately 1 hour (if you have cleaned the lters please wait 24 hours for the lters to fully dry
before putting back into the machine).
For best cleaning results clean the pre-motor lter every time the dirt container is emptied and replace
the post-motor lter every 12 months.
If the vacuum cleaner is blocked, switch o and unplug before removing the blockage.
Important: The base of the vacuum cleaner should always be positioned at on the oor when starting and in use.
WARNING: When unwinding the power cord do not pull further than the yellow marker.
Getting started Using your machine
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE
WARNING
Always switch o the vacuum
cleaner before connecting
or disconnecting the hose
/attachments, or removing and
emptying the dirt container.
For use on carpets, click
rocker switch forward. For
use on hard oors click rocker
switch back.
Slide vent cover on hose grip open
to reduce suction if required.
Lower brushes for hard oors.Raise brushes for carpets.

Don’t over ll the dirt container
to avoid blocking the air ow
through the vacuum cleaner.
WARNING
Emptying and cleaning the dirt container
Cleaning the shroud
Using your tools
Using your machine
Taking care of your machine
Taking care of your machine
Always use the carry handle to lift and
carry the machine. Do not use the dirt
container handle.
Choose an accessory and
push onto the telescopic
extension tube or hose.
Press dirt container
release button and lift
to remove.
Press the button at the
top of the dirt container
to release lter.
Hold dirt container over
a bin allowing dirt/debris
to fall out.
Replace lid, making sure
central protruding (part A) is
over outer protruding piece
(part B) to complete the hinge.
Attach accessory to hose end. If required use tool connector.
Rinse both dirt container and shroud under water
(Max 40°C). Leave to dry for 24 hours or until fully
dry before placing back in the machine.
Carrying your machine
IMPORTANT: Unplug and switch o vacuum cleaner before performing maintenance or troubleshooting checks.
IMPORTANT: The shroud cannot be removed from the dirt container.
A
B
Cleaning the pre-motor lter
Press dirt container release
button and lift to remove.
Leave to dry for 24
hours or until fully dry
before placing back in
the machine.
Line up the pre-motor lter frame with dirt container,
push into place.
If the pre-motor lter is not correctly tted the pre-
motor latch will prevent the dirt container from locking
into place.
Tap the lter frame and
foam over a bin to remove
any dirt/debris.
Remove the pre-motor
lter together with frame
and foam.
Rinse both the frame
and foam under water
(Max 40°C).
Warning: Do not wash the pre-motor lter in the washing machine or dishwasher.
For best cleaning results clean the pre-motor lter every time the dirt container is emptied.

Press button on post-
motor lter cover pull
to remove.
For best cleaning results, replace the post-motor lter every 12 months.
Tap the post-motor lter
over a bin to release dirt
/debris. Always replace
before using your vacuum.
Pull tabs on post-motor
lter to remove.
Press cord rewind button
to retract cord into
vacuum cleaner.
Place oor head into
parking slot located at rear
of vacuum cleaner
for storage and carrying.
Cleaning the post-motor lter
Storing your vacuum cleaner
Let’s talk technical Let’s talk technical
Do not wash the post-motor lter.
WARNING
IMPORTANT: Remove accessory from hose or telescopic extension tube before performing maintenance or trouble
shooting checks.
Removing blockages from the TurboTool*
Tabs
Slide the locking ring
to remove.
Lift and separate
the housing.
Using a pair of scissors,
remove any threads
or hair caught around
the brushbar.
Line up the tabs on front of
housing and push together
to ret. Slide locking ring
into groove to secure.
34
1
2
34
1
23
4
12
3
4
12
TIP
To test for a blockage in hose,
drop a small ball of paper into the
hose. The paper will drop through
if the hose is clear.
Remove the hose from the vacuum
cleaner and telescopic extension tube.
Remove any blockage by inserting wire
coat hanger in to hose.
Removing a blockage from the hose

• Check the ‘This pack contains’ panel on the box to make sure
the part is included with your vacuum cleaner.
• The dirt container may not be correctly tted, remove the dirt container
from the vacuum cleaner and check pre-motor lter and dirt container
are assembled correctly, ret ensuring it’s locked into place. Go to
‘Taking care of your machine’.
• The lter may be clogged, clean the lter. Go to ‘Taking care of your
machine’.
• The dirt container may be blocked, empty the dirt container. Go to
‘Taking care of your machine’.
• There may be a blockage in the hose/tube. Disconnect from the vacuum
cleaner and carefully remove any blockages. Go to ‘Let’s talk technical’.
• The lters may be clogged, clean the lter.
Go to ‘Taking care of your machine’.
• The plug may not be fully pushed into the electrical socket.
• Check the fuse in the plug if this needs replacing, always replace with
a 13amp fuse.
• The motor thermostat may have tripped. If this has happened, unplug
the vacuum cleaner. Remove and empty the dirt container and check
the hose for blockages. Clean the lters and allow the vacuum cleaner
to cool for approximately 1 hour (if you have washed the lters you will
need to wait 24 hours for the lters to fully dry before putting them back
into the vacuum cleaner).
SolutionProblem
Warning: To reduce the risk of personal injury, unplug the vacuum cleaner before performing maintenance
/troubleshooting checks.
What to do if it goes wrong Getting in touch
Is there an accessory
missing?
Why won’t the vacuum
cleaner pick up?
Why does my vacuum
cleaner have no power?
Why is dust escaping
from the vacuum?
* Calls are charged at the UK local rate. Please make a note of the serial number and model number of the vacuum cleaner
before calling.

Accessories
Don’t forget your accessories!
Order at: www.vax.co.uk/spares-and-solutions
Notes
Pro cleaning kit (Type 2)
1-1-133326-00
All our best tools all in one kit that makes cleaning
your home quicker, easier and with even better results.
We’ve taken care of cleaning all of the hard to reach
areas such as on top of cupboards and in between
blinds to the dust that collates behind and
within the radiator.
TurboTool (Type 6)
1-1-134419-00
Use the TurboTool for vacuuming your stairs, upholstery
and car interiors. It’s great for picking up stubborn pet hair.
Fur ‘n’ Flu Tool
1-1-131392-00
Specically designed to remove extra stubborn
pet hair from upholstery, furniture and carpets.

Vax Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire, WR9 0QH, UK
email: inf[email protected] website: vax.co.uk
Version 1.0
EEC Statement of Compliance: Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility,
declare that the C86-TOe series is manufactured in compliance with the following Directives:
Safety: 2006/95/EC Low Voltage Directive. EMC: 2004/108/EC Electromagnetic Compatibility Directive.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
@VaxUK
© 2014 All rights reserved. VAX®, VAX Lozenge are trade marks or registered trade marks of Techtronic Floor Care Technology Ltd.
This manual suits for next models
1
Table of contents
Other Vax Vacuum Cleaner manuals

Vax
Vax U86-IAe Series Installation instructions

Vax
Vax VX2 User manual

Vax
Vax VX49 Installation instructions

Vax
Vax V-2000 U User manual

Vax
Vax Swift duo V-134E User manual

Vax
Vax EVOLVE CLSV-LXKS User manual

Vax
Vax AirTM Lift DRIVE User manual

Vax
Vax V-043 User manual

Vax
Vax agility COMPACT User manual

Vax
Vax Dual V Advance User manual
