Vax Essentials VEC-104 User manual

Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
User Guide
Bagless Cylinder
Get Cleaning...
What’s your Vax model number? (Located on the top flap of the packaging)
What’s your serial number? (Located on the base of the machine)
Note these down in case you need them in future. Please keep instructions for further use.
––––––––––
Essentials series
e.g. VEC-104
VEC-104 & 105 Essentials UG V1.0.qxd:Use guide 2/9/11 16:03 Page 1

---
4
2
1
63
1 Dirt container
2 Central HEPA filter
3 Carry handle
4 Hose inlet
5 Cord rewind
6 Dirt container release button
7 Blockage indicator
8 Floor tool parking
9 On/off switch
10 Dirt container empty catch
Unit
Accessories
10
Filters
2
1
PLEASE NOTE: some parts may vary
according to model. Please check
inside flap of box for more details.
11 Combination floor head
12 Telescopic extension tube
13 Hose
14 Dusting brush
15 Crevice tool
16 Tool storage handle clip
17 TurboTool (some models only)
18 Fibre post-motor filter
13
14
5
7
8
9
15
16
17
11
12
2 18
Mac ine Overview
2 Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
VEC-104 & 105 Essentials UG V1.0.qxd:Use guide 2/9/11 16:03 Page 2

---
General Safety Information
vax.co.uk 3
FOR HOUSEHOLD USE ONLY.
When using the vacuum cleaner, basic safety precautions should
always be observed, including the following:
1. Only use the vacuum cleaner indoors on dry surfaces. Do not
handle the plug or vacuum cleaner with wet hands. Do not use
outdoors or on wet surfaces.
2. Turn off the vacuum cleaner controls before disconnecting or
connecting from the mains supply.
3. Always unplug the vacuum cleaner before connecting or
disconnecting the vacuum hose and accessories.
4. Children should be supervised to ensure that they do not play
with the appliance.
5. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
6. Use only as described in this manual. Use only Vax
recommended attachments.
7. Do not use the vacuum cleaner if it has been dropped,
damaged, left outdoors or dropped into water. Do not use the
vacuum cleaner with a damaged cord or plug. If the supply cord
is damaged, it must be replaced by the manufacturer or a
recommended Service Agent to avoid hazard and
invalidating the guarantee.
8. Do not pull or carry by cord. Do not use the cord as a handle,
close a door on the cord or pull cord around sharp edges or
corners. Do not run the vacuum cleaner over the cord. Keep the
cord away from heated surfaces.
9. Do not put any ob ects into openings. Do not use with any
openings blocked and do not restrict air-flow. Keep all openings
free of dust, lint, hair or anything that might reduce airflow.
10. Keep hair, loose clothing, fingers and all parts of the body away
from openings and moving parts.
11. Do not pick up hot coals, cigarette butts, matches or any hot,
smoking or burning ob ects.
12. Do not pick up flammable or combustible materials (lighter fluid,
petrol, kerosene etc.) or use in the presence of explosive liquids
or vapours.
13. Do not vacuum up harmful or toxic materials (chlorine, bleach,
ammonia, drain cleaner etc.).
14. Do not vacuum up hard or sharp ob ects such as glass, nails,
screws, coins, etc.
15. Do not use without ALL of the filters in place.
16. Take extra care when vacuuming on stairs.
17. Keep vacuuming area well lit.
18. Store the vacuum cleaner in a cool, dry area.
19. Turn off the on/off switch before unplugging the vacuum
cleaner
20. Use only CE-approved 13 amp extension cords.
Non-approved cords may overheat. Care should be taken to
arrange the cord so that the cord cannot be tripped over.
WARNING: Always switch off and unplug the vacuum
cleaner from the electrical outlet before assembling, opening
or emptying the dirt container, or before connecting/disconnecting the
attachments.
CAUTION: The vacuum cleaner is a very powerful unit.
Before plugging the cord into the electrical outlet, make sure
the switch is in the ‘off’ position.
IMPORTANT: If the inlet, hose or telescopic tube is blocked,
switch off the vacuum cleaner and remove the blockage(s)
before re-starting the vacuum cleaner. See Maintenance: Clearing
blockages.
IMPORTANT: Washing filters maintains vacuum
performance. Vax recommends that they should
be checked and cleaned periodically (depending on the level of use).
Make sure all filters are completely dry before inserting back into the
vacuum cleaner.
IMPORTANT: The motor is equipped with a thermal cut-out.
If for any reason the unit should overheat, the thermostat
will automatically turn the unit off. Should this occur, unplug the
vacuum cleaner from the electrical outlet and turn off the switch.
Remove dirt container and empty. Clean filters. Allow the unit to cool
for approximately one (1) hour. To re-start, plug into an electrical
outlet and switch back on.
T is vacuum cleaner is intended for ouse old use only and NOT for
commercial or industrial use.
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
VEC-104 & 105 Essentials UG V1.0.qxd:Use guide 2/9/11 16:03 Page 3

---
Assemblind your vacuum cleaner
Operating t e appliance
NOTE: Fully extend the
power cord before each use.
A yellow mark on the cord
indicates the recommended
cord length. Do not exceed
the cord length beyond the
yellow mark.
Packing away and storage
NOTE: For convenience there is a
parking slot located at the back of
the vacuum cleaner where the
floor tool can be attached for
storage and carrying.
Keep your Vax like new
IMPORTANT: The condition of the filters affects the
performance of your machine. Please check and wash filters
periodically (depending on the level of use). For full cleaning
instructions, see page 5.
!
!
!
!
IMPORTANT: Do not use the vacuum cleaner without all of the
filters in place.
!
!
!
!
NOTE: The TurboTool, crevice tool and dusting brush can all be attached to the telescopic tube or caddy on the
hose handle.
Hard floors
Carpets
Operation
4Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
VEC-104 & 105 Essentials UG V1.0.qxd:Use guide 2/9/11 16:03 Page 4

---
Emptying and cleaning t e dirt container
Cleaning t e post-motor filter
Cleaning t e central HEPA filter
24hr
tap
24hr
tap
!
!
!
!
IMPORTANT: Water temperature should be at a maximum of 40° C when washing filters
!
!
!
!
IMPORTANT: Water temperature should be at a maximum of 40° C when washing filters
Operation
vax.co.uk 5
VEC-104 & 105 Essentials UG V1.0.qxd:Use guide 2/9/11 16:03 Page 5

---
6Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
Clearing blockages
WARNING: To reduce the risk of electric shock, the power cord must be disconnected from the mains
supply before performing maintenance/troubleshooting checks. Turn the vacuum cleaner off and unplug
from the electrical socket
!
!
!
!
Hose blockages
The flexible hose should be disconnected from the
vacuum cleaner. Carefully remove any blockages found
and reconnect the hose securely.
Accessory blockages
Remove accessory from the hose/handle tube.
Carefully remove the blockage and return to the cleaner.
Clearing debris from t e TurboTool (some models only)
NOTE: Switch the cleaner off and disconnect the power plug from the electrical outlet before performing this
check.
remove
locking ring
Maintenance (Keep your Vax as good as new)
replace
locking
ring
Turn the TurboTool over and
slide off the locking ring.
Detach lower housing and
remove blockage.
To re-assemble the TurboTool,
ensure that the tabs are engaged
and pivot the lower housing
closed. Slip the locking ring over
the neck of the TurboTool and into
the groove to finish.
VEC-104 & 105 Essentials UG V1.0.qxd:Use guide 2/9/11 16:03 Page 6

---
7
vax.co.uk
This page has been left intentionally blank
VEC-104 & 105 Essentials UG V1.0.qxd:Use guide 2/9/11 16:03 Page 7

---
FAQs
8Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
!
!
!
!
WARNING: to reduce t e risk of personal injury, unplug t e vacuum cleaner before performing
maintenance/troubles ooting c ecks.
Is t ere an accessory missing?
• Check the ‘Parts Overview’ page in this guide to
make sure the part is definitely included in your
unit.
• If it is missing, we’re here to help. Simply call us
on 0844 412 8455
W y won’t t e vacuum cleaner pick up?
• The dirt container may be incorrectly installed;
remove the dirt container from the unit by pressing
the dirt container release catch and then
re-attaching it to the unit, ensuring it is locked
firmly back into place.
• The filter may be clogged; refer to ‘Maintenance:
Cleaning the filters’ on page 5.
• The dirt container may be blocked; refer to
‘Maintenance: Emptying and cleaning the dirt
container’ on page 5.
• There may be a blockage in the tube/hose.
Disconnect from the vacuum cleaner, carefully
remove any blockages found and reconnect
securely.
W y is dust escaping from t e vacuum?
• The filter may be clogged; refer to ‘Maintenance:
Cleaning the filters’ on page 5.
• The dirt container may be blocked; refer to
‘Maintenance: Emptying and cleaning the dirt
container’ on page 5.
• The dirt container may be incorrectly installed;
remove the dirt container from the unit by pressing
the dirt container release catch and then
re-attaching it to the unit, ensuring it is locked
firmly back into place.
W at do I do if t e unit/an accessory becomes
damaged or broken?
• We’re here to help. Simply call 0844 412 8455 or
visit vax.co.uk
W y won’t t e accessories pick up properly?
• Hose blockages: remove the hose from the unit.
Carefully remove any blockages found and
reconnect hose securely.
• Accessory blockages: remove accessory from
handle/tube. Carefully remove blockage and
re-attach to the vacuum cleaner.
• The accessory may be faulty. Simply call us on
0844 412 8455 for assistance.
W y will t e vacuum cleaner not run?
• It may not be plugged into the electrical outlet
correctly; ensure that the plug is pushed in
securely.
• The electrical outlet may not be working properly;
check the fuse or breaker, or consult an electrician.
• The motor thermostat may have tripped; switch off
and unplug the vacuum cleaner, and leave for one
hour before switching the cleaner back on.
Instead of taking me back to the shop, simply call:
(UK) 0844 412 8455 (ROI) 1-800 928 308
vax.co.uk vaxireland.ie This does not aect your statutory rights
we’re here to help
(UK) 0844 412 8455
(ROI) 1-800 928 308
vax.co.uk
vaxireland.ie
This does not aect your statutory rights
Instead of taking me back
to the shop, simply call:
we’re here to help
VEC-104 & 105 Essentials UG V1.0.qxd:Use guide 2/9/11 16:03 Page 8

---
9
vax.co.uk
Ot er Information
UK Service & Help
Vax Customer Careline 0844 412 8455
Monday-Friday 8.30am to 6.30pm
Saturday-Sunday 9.00am to 5.00pm
If you have any queries about using your Vax, call the Vax Careline. Calls are charged at the UK national rate.
Please make a note of the serial number and model number of the carpet cleaner before calling. For the nearest
Service Agent, please call the Vax Customer Careline or visit vax.co.uk
Tec nical Specification
Voltage: 220-240V ~50Hz
Wattage: 2000 W
Capacity: 2.6L
Filters: Central HEPA filter (washable)
Fibre post-motor filter (washable)
Cord length: 5 m (approx)
Weight: 5.2kg
Sub ect to technical change without notice.
EEC Statement of Compliance
Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the VEC-104 and VEC-105
Essentials bagless cylinders are manufactured in compliance with the following Directives:
Safety: 2006/95/EC Low Voltage Directive
EMC: 2004/108/EC Electromagnetic Compatibility Directive
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
VEC-104 & 105 Essentials UG V1.0.qxd:Use guide 2/9/11 16:03 Page 9

---
10 Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
This page has been left intentionally blank
VEC-104 & 105 Essentials UG V1.0.qxd:Use guide 2/9/11 16:03 Page 10

---
11
vax.co.uk
This page has been left intentionally blank
VEC-104 & 105 Essentials UG V1.0.qxd:Use guide 2/9/11 16:03 Page 11

---
Vax Ltd., Kingswood Road, Hampton Lovett, Droitwic , Worcesters ire, WR9 OQH, UK
email: inf[email protected] - website: vax.co.uk
VEC-104 & 105 Essentials UG V1.0.qxd:Use guide 2/9/11 16:03 Page 12
