Vax EVOLVE CLSV-LXKS User manual

CLSV-LXKS
CLSV-LXBS
USER GUIDE
Cordless Vacuum

DON’TS
• Don’t leave the charger plugged in when unattended.
• Don’t use the machine if it is faulty or has been dropped, damaged or left outdoors.
• Don’t use the machine to pick up any flammable or combustible materials
(lighter fluid, petrol, kerosene etc.) or use the machine in an area with explosive
vapours or liquid.
• Don’t use the machine to pick up hot coals, cigarette butts, matches or smoking
hot burning items or use in an area where there may be harmful fluids (chlorine,
bleach and ammonia drain cleaner).
• Don’t handle the charger, battery or use the machine with wet hands.
• Don’t unplug the charger by pulling on the power cord.
• The power cord cannot be replaced. If the cord is damaged the charger should be
scrapped.
• Don’t attempt to remove blockages with sharp objects as this may cause damage
to the machine.
• Don’t use the machine with the incorrect battery or charger as this may result in
damage or injury to the user. The correct battery charger information is listed on
the battery pack ratings label.
• Don’t charge the battery outdoors, or leave the charger connected to the mains
when not in use.
• Don’t use the machine with a damaged battery. If the battery is damaged contact
us on: 08000 927737
• Don’t use on a surface that is damaged, uneven or incorrectly fitted.
• The brushbar constantly rotates in carpet and hard floor mode. Never use on one
spot for any prolonged period of time as this may damage the floor surface.
• Don’t use the machine on stairs.
SAFETY GUIDE
This machine is intended for household use only and NOT for commercial
or industrial use.
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE AND USE ONLY AS
INSTRUCTED IN THIS GUIDE.
The full user guide can be found at: support.vax.co.uk
CLSV-LXKS
CLSV-LXBS
VAX Ltd, Artillery House, Heritage Way, Droitwich, WR9 8YB, UK

BATTERY SAFETY PRECAUTIONS
• Replace the battery with a VAX ONEPWR battery only. Use of another battery may
present a risk of fire or explosion.
• Don’t attempt to disassemble the battery, remove any component projecting from the
battery terminals and do not dispose of in a fire. The battery and charger have no
user serviceable parts. Fire or injury may result.
• Prior to disposal, protect exposed terminals with heavy insulating tape to prevent
shorting. The battery is to be disposed of safely at your local battery recycling centre.
• When the battery pack is not in use, keep it away from other metal objects that can
make a connection from one terminal to another. Shorting the battery terminals
together may cause burns or a fire.
• In case of battery leakages, avoid any contact with skin and contact us on:
08000 927737
DO’S
• Only VAX ONEPWR batteries (BVXXXXX) and chargers (BV05XXX) should be used
with this machine.
• Always stand the charger on a stable, level surface, uncovered and away from any
heat source.
• Always remove the battery from the machine before carrying out any maintenance
or if storing unused for a long period of time.
• Keep all openings clear, free from debris and don’t overfill the dirt container as this
may affect the airflow/suction.
• Turn off all controls on the machine before disconnecting or connecting the battery.
• This machine is not intended to be used or cleaned by persons with reduced
physical, sensory or mental capabilities, or lack of experience or knowledge, unless
they have been given instructions concerning the safe use of the machine by a
person legally responsible for their safety. They should be supervised whilst using
the machine. Children shall not use, clean or play with this machine, which when
not in use should be secured out of their reach.
• Only use the machine indoors on dry surfaces and keep the area you’re cleaning
well lit.
• Always use the correct mode for your flooring and check the suitability with the
flooring manufacture before use. To prevent any damage being sustained, test on a
inconspicuous area of the flooring/surface first.
• Always make sure the separator and filter are fitted correctly before using your
machine and only use the machine with the filter and separator in place.
• Always check that the floorhead and brushbar are free from damage, dirt and debris
before using.
• Keep fingers, hair and loose clothing away from moving parts and openings whilst
using the machine.
• Store the machine in a cool, dry area. Keep the machine away from rain and moisture.
• Use only CE approved 13amp extension cords, non-approved extension cords may
overheat. Care should be taken to arrange the extension cord as it can be a trip hazard.

2
Welcome to the VAX family!
You are now the proud owner of a VAX Evolve.
Here, you’ll find everything you need to know about your machine and, most importantly, instructions on
how to get started so that you can get cleaning!
14 15
2
1Handle
2Power ON/OFF
3Mode selector button
4Mode indicator
5Main unit
6Brushbar
7Battery dock
8Dirt container release button
9Filter (hidden)
10 Dirt container lid release button
11 Separator
12 Dirt container
13 Dirt release button
14 ONEPWR battery*
15 ONEPWR charger*
5
1
7
8
9
11
10
13
12
6
Weight 3.2kg (without battery pack). Dirt bin capacity 1.2L.
Runtime and charge time dependent on battery pack and mode used. *Included with model CLSV-LXKS only.
Subject to technical change without notice. Images are illustrative only.
3
2
4

33
Registration & Support
All ONEPWR products come with
a standard one year warranty
Register your product to receive
2 YEARS FREE additional
warranty†
For details visit: vax.co.uk/registration
Scan here
For help and support with
your new product
or visit us online: support.vax.co.uk
Still need to get in touch?
Our UK based Customer Care Team are here to
support you. For help with assembly, operational or
performance problems, or buying and fitting new
accessories, you can find all our contact details at
vax.co.uk/contact
This user guide can be found online at:
support.vax.co.uk
† Registration required. Terms and conditions apply,
see vax.co.uk for details.
2
Press the battery symbol
to check the battery status
Charging the battery
Charge the battery for
3 hours before use*
1Assembly
Attach the handle to the
main body of the machine
until it clicks into place
3Operation
Switch on the machine
and select a mode
HARD FLOOR
CARPET
BRUSH OFF
For delicate floors and
flooring not suitable for
use with a rotating brushbar
3
Quick Start

4
WARRANTY & TECHNICAL
TECHNICAL
Statement of Compliance: Manufacturer/EU importer: VAX Limited, hereby on our
own responsibility, declare that the VAX Evolve is manufactured in compliance
with the following Legislation:
Safety: 2014/35/EU Low Voltage Directives/Electrical Equipment (Safety)
Regulations 2016. EMC: 2014/30/EU Electromagnetic Compatibility Directive/
Electromagnetic Compatibility Regulations 2016.
Waste electrical products should not be disposed of with household
waste. Please recycle where facilities exist. Check with your Local
Authority or retailer for recycling advice.
VAX is a trade mark of Techtronic Cordless GP.
© 2021 Techtronic Cordless GP. All rights reserved.
WARRANTY
If a VAX ONEPWR machine is used
in the way it is intended and it breaks
down within the guarantee period, it’s
our responsibility to repair or replace it.
Here’s what isn’t covered:
• Normal wear and tear of consumable
items, for example: belts, filters,
brushrolls, fuses etc.
• Batteries which have become faulty
as a result of improper handling.
• Batteries which have a reduced
service life as a result of normal wear.
• Accidental damage
- Damage as a result of use not in
accordance with the product
user guide.
- Damage caused by not carrying out
regular maintenance.
- Damage to the charger cable.
- Blockages caused by misuse.
• Faults caused by:
- Negligent use, misuse, neglect or
careless operation of the machine.
- Use of the machine cleaner which
is not in accordance with the
user guide.
- Use of a VAX ONEPWR machine
for anything other than normal
domestic household purposes
in the country in which it was
purchased.
- Use of parts, accessories and
consumables, which are not
genuine VAX components.
- Faulty installation or repairs –
unless carried out by a qualified
electrician or engineer.
VAX Ltd, Artillery House, Heritage Way, Droitwich, WR9 8YB, UK.

5
GETTING STARTED
VAX Ltd, Artillery House, Heritage Way, Droitwich, WR9 8YB, UK.
CHARGING THE BATTERY
Slide the battery down on to the charger
until it clicks into place.
The charger light will flash white to
show when the battery is charging.
The light on the charger will stop
flashing and go off when the battery
is fully charged.
Once fully charged, slide the battery off
the charger to remove.
To check the battery charge
level press the battery symbol.
THIS MACHINE IS ONLY TO BE USED WITH VAX ONEPWR BATTERIES AND CHARGER.
PLEASE READ THE SAFETY GUIDE BEFORE USE.
NOTE: Before first use, ensure the battery is fully charged. Failure to fully charge the battery
before first use may result in poor battery performance. The life expectancy of the battery will vary
depending on the usage of the machine.
ASSEMBLY
Push the handle into the main body
until it clicks into place.

6
GETTING STARTED
OPERATION
Slide the battery onto the machine until
it clicks into place.
Place your foot on the floorhead. Pull the handle backwards to recline.
WARNING: The brushbar constantly rotates in carpet and hard floor mode.
Never use on one spot for any prolonged period of time as this may damage the floor surface.
To prevent any damage being sustained test on an inconspicuous area of the flooring first.
To remove the battery press both the
buttons to release.
Press the on/off button to switch the
machine on.
Press the mode selector button to switch
between modes.
HARD FLOOR
CARPET
BRUSH OFF
For delicate floors and flooring not
suitable for use with a rotating brushbar.

7
CLEANING & MAINTENANCE
EMPTYING THE DIRT CONTAINER
CAUTION: Don’t over fill the dirt container to avoid blocking the air flow through the machine.
For best cleaning results, empty the dirt container after every use. Filters should be tapped over a
bin every 4-6 uses to remove dirt and debris and washed every 3 months. Filters should be replaced
every 6-9 months depending on the level of use.
Press down the dirt container
release button and pull the container
to remove.
Hold the dirt container over a bin and
press the dirt release button to allow dirt
and debris to fall out. To close, push the
dirt release door until it clicks into place.
To re-fit, tilt the dirt container and line the
front of the container up onto machine.
Push back until it clicks into place.
WARNING: Always remove the battery before carrying out any maintenance or troubleshooting.

8
CLEANING & MAINTENANCE
24hr
40°C
MAX
CLEANING THE FILTER AND SEPARATOR
Tap the filter and separator against a
bin to remove dirt and debris.
Wipe over the separator metal shroud
with a dry cloth.
Wash the filter under running water
(40°C max). Leave for at least 24hrs or
until fully dry before replacing.
Press the button on the lid of the dirt
container and lift the lid to access the
filter. Pull the tab on the filter to remove.
Lift the separator from the dirt container.Press down the dirt container release
button and pull the container to remove.
CAUTION: Ensure both the filter and separator are refitted before use.

9
CLEANING & MAINTENANCE
REMOVING AND CLEANING THE BRUSHBAR
Lie the machine on its back.
To remove any threads or hair, slide the
blade of a pair of scissors into the groove
on the brushbar and cut along the groove.
Clear any dirt/debris from the end caps
and inside the housing of the floorhead.
WARNING: Always remove the battery before carrying out any maintenance or troubleshooting.
CAUTION: If the brushbar has been obstructed, the brushbar motor protection sensor may activate
and the brushbar will stop. To reset clear any obstruction and wait 1 minute before switching the
machine on. For best performance and to reduce hair/dirt build up, remove and clean the brushbars
every 1-2 months (depending on the level of use).
Pull the brushbar out from the housing.
Align the arrow on the brushbar cover to the unlock symbol. Push firmly and twist the tab clockwise so the arrow is pointing to the lock symbol.
Turn the tab on the brushbar cover
anticlockwise to release the brushbar.
Refit the brushbar into the floorhead.

10
CLEANING & MAINTENANCE
CHECKING FOR BLOCKAGES
Press down the dirt container release
button and pull the container to remove.
Check for any blockages and use a blunt
object to remove the blockage.
Press the hose release button and pull
to release.
Place your foot on the floorhead. Pull the handle backwards to recline and lie flat.

11
TROUBLESHOOTING
THERE IS AN ACCESSORY MISSING
Check the contents on the box.
WHY DOES THE MACHINE HAVE NO POWER?
• The battery is not fitted correctly. See OPERATION page 7.
• The battery has no charge. See CHARGING THE BATTERY page 6.
• The motor thermostat may have tripped. Empty the dirt container and check for blockages.
Clean the filters and allow the machine to cool for approximately 1 hour. If you have washed
the filters, wait 24 hours to fully dry before placing back on the machine.
See CLEANING THE FILTER AND SEPARATOR page 9.
• The brushbar motor sensor has been activated. To reset clear any obstruction, wait 1 minute
before switching the machine on. See REMOVING AND CLEANING THE BRUSHBAR page 10
and OPERATION page 7.
WHY WON’T THE MACHINE PICK UP?
•The dirt container may not be correctly fitted. See EMPTYING THE DIRT CONTAINER page 8.
•The dirt container may be blocked. Check the dirt container for blockages.
See EMPTYING THE DIRT CONTAINER page 8.
•The filters may be clogged or need replacing. See CLEANING THE FILTER AND SEPARATOR
page 9.
•There maybe a blockage. See CHECKING FOR BLOCKAGES page 12.
•The brushbar has not been activated. See OPERATION page 7.
WHY WON’T THE BRUSHBAR ON THE FLOORHEAD TURN?
•The brushbar has not been activated. Go to OPERATION page 7.
•The brushbar may be obstructed. See REMOVING AND CLEANING THE BRUSHBAR page 10.

VAX Ltd, Artillery House, Heritage Way, Droitwich, WR9 8YB, UK.
[e-mail] vax.co.uk
For how-to videos and
warranty registration visit
www.vax.co.uk
