Vecow SPC-7000 User manual

USER
Manual
USER
Manual
1.0.0 Edition 20210329
Intel®Core™ i7/i5/i3 (Tiger Lake) Ultra-Compact Fanless Embedded System
1 GigE LAN, 1 2.5G GigE LAN, 10G USB, 2 COM, 9V to 55V, -40°C to 75°C
SPC-7000/7100/7200

ii
©Vecow SPC-7000/7100/7200 User Manual
Version Date Page Description Remark
1.00 2021/03/29 All O󰀩cial Release
Record of Revision

iii
©Vecow SPC-7000/7100/7200 User Manual
This manual is released by Vecow Co., Ltd. for reference purpose only. All
product o󰀨erings and specications are subject to change without prior notice.
It does not represent commitment of Vecow Co., Ltd. Vecow shall not be liable
for direct, indirect, special, incidental, or consequential damages arising out of
the use of the product or documentation or any infringements upon the rights of
third parties, which may result from such use.
Disclaimer
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy, and if it is not installed and used
in accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC
The products described in this manual complies with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to
remain CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.
CE
Declaration of Conformity
This document contains proprietary information protected by copyright. No part
of this publication may be reproduced in any form or by any means, electric,
photocopying, recording or otherwise, without prior written authorization
by Vecow Co., Ltd. The rights of all the brand names, product names, and
trademarks belong to their respective owners.
Copyright and Trademarks

iv
©Vecow SPC-7000/7100/7200 User Manual
Part Number Description GigE
LAN
2.5G
LAN
10G
USB COM SIM Socket
SSD
Bracket
CPU
TDP
Thermal
Solution
SPC-7000-
1185G7E i7-1185G7E
1 1 2 2 1 1
12W,
15W
Heat
Spreader
SPC-7000-
1145G7E i5-1145G7E
SPC-7100-
1185G7E i7-1185G7E
12W,
15W Heat Sink
SPC-7100-
1145G7E i5-1145G7E
SPC-7200-
1185G7E i7-1185G7E
28W Fan Sink
SPC-7200-
1145G7E i5-1145G7E
Order Information

v
©Vecow SPC-7000/7100/7200 User Manual
Part Number Description
DDR4 32G Certied DDR4 32GB 3200MHz RAM
DDR4 16G Certied DDR4 16GB 3200MHz RAM
DDR4 8G Certied DDR4 8GB 3200MHz RAM
DDR4 4G Certied DDR4 4GB 3200/2666/2400 MHz RAM
VESA Mount VESA Mounting Kit
DIN-RAIL DIN Rail Kit
PWA-120W 120W, 24V, 90V AC to 264V AC Power Adapter with 3-pin Terminal Block
4G Module 4G/GPS Module with Antenna
5G Module 5G Module with Antenna
WiFi & Bluetooth
Module WiFi & Bluetooth Module with Antenna
Optional Accessories

vi
©Vecow SPC-7000/7100/7200 User Manual
Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
1.2 Features 2
1.3 Product Specication 3
1.3.1 Specications of SPC-7000 3
1.3.2 Specications of SPC-7100 5
1.3.3 Specications of SPC-7200 7
1.4 Supported CPU List 9
1.5 Mechanical Dimension 10
1.5.1 SPC-7000 Mechanical Drawing 10
1.5.2 SPC-7100 Mechanical Drawing 10
1.5.3 SPC-7200 Mechanical Drawing 11
CHAPTER 2 GETTING TO KNOW YOUR SPC-7000 12
2.1 SPC-7000/7100/7200 Packing List 12
2.2 Front Panel I/O & Functions 13
2.3 Rear Panel I/O & Functions 17
2.4 Connector/Jumper Locations 19
2.5 Main Board Jumper Settings 39
2.6 Ignition Control 42
CHAPTER 3 SYSTEM SETUP 45
3.1 How to Open Your SPC-7000 45
3.2 Installing DDR4 SO-DIMM Module 46
3.3 Installing M.2 47
3.4 Installing SSD/HDD 49
3.5 Installing SIM Card 50
3.6 Installing Antenna Cable 51
3.7 Mounting Your SPC-7000 52

vii
©Vecow SPC-7000/7100/7200 User Manual
CHAPTER 4 BIOS SETUP 53
4.1 BIOS Setting 53
4.2 Main Manu 54
4.3 Advanced Functions 54
4.4 Chipset Functions 67
4.5 Security 74
4.6 Boot Functions 76
4.7 Save & Exit 77
APPENDIX A : GPIO GUIDE 78
APPENDIX B : Software Functions 81
APPENDIX C : RAID Functions 84
APPENDIX D : Power Consumption 94
APPENDIX E : Supported Memory & Storage List 97

1
©Vecow SPC-7000/7100/7200 User Manual GENERAL INTRODUCTION
GENERAL INTRODUCTION
1.1 Overview
SPC-7000/7100/7200 is an Ultra-compact Embedded Box PC. Powered by
11th Gen Intel® Core™ i7/i5/i3 Processor and runs on Intel® SoC with 28W
TDP supported delivering up to 22% faster CPU performance than the previous
generation, Vecow SPC-7000/7100/7200 delivers high-performance computing
and real-time capabilities for critical Industrial IoT deployment.
This ultra-compact embedded Box PC includes 32GB of DDR4 3200MHz
memory and features advanced Intel® Iris® Xe graphics, enabling dual DisplayPort
displays with 8K Resolution. Available across high-speed connectivity such as
USB (10G), and GigE LAN (2.5G), SPC-7000/7100/7200 is capable of supporting
demanding AI-enabled workloads in a wide range of industrial use cases.
Vecow SPC-7000/7100/7200 provides a wide range of I/O interfaces including
1 GigE LAN, 2.5GigE LAN, 4 USB, 2 COM, as well as 1 SIM card socket. It
has 1 SATA III and 1 M.2 Key B for storage. In addition, it provides M.2 socket
to support 5G/WiFi 6/4G/LTE/GPRS/UMTS wireless networks and SUMIT A, B
(optional) socket for 10G LAN, 10G SFP+, 5G, SIM socket, PoE+, Series port
and video capture expansion. The system features -40°C to 85°C extended
operating temperature, 9V to 55V DC-in, as well as ignition power control to
allow the deployment of industrial applications in harsh industrial environments
and is ideal for Factory Automation, Service Robot, Cellular V2X, Smart Retail
and any AIoT/Industry 4.0 applications.
1

2
©Vecow SPC-7000/7100/7200 User Manual GENERAL INTRODUCTION
1.2 Features
• 11th Gen Intel® Core™ i7/i5/i3 processor (Tiger Lake UP3) delivers new
generation system productivity than ever, up to 28W TDP
• Compact design, up to -40°C to 75°C operating temperature
• DDR4 3200MHz memory, up to 32GB
• Dual DisplayPort display, up to 4K resolution
• Multiple USB supports up to 10Gbps data transfer
• 1 Independent 2.5GigE LAN supports Intel® Time Sensitive Networking (TSN) for
real-time data synchronization
• 1 GigE LAN supports iAMT, TPM 2.0 supported
• 9V to 55V wide range DC Power Input, Ignition Control
• SIM Socket for 5G/WiFi/4G/3G/LTE/GPRS/UMTS
• Optional supports full function SUMIT A, B expansions for multiple 10GigE LAN,
10G SFP+, 5G Network, SIM Socket, PoE LAN, Serial Port, GigE LAN, Fiber
LAN, or Video Capture
• Optional VHub One-Stop AIoT Solution Service supports OpenVINO based AI
accelerator and advanced Edge AI applications

3
©Vecow SPC-7000/7100/7200 User Manual GENERAL INTRODUCTION
1.3 Product Specication
1.3.1 Specications of SPC-7000
System
Processor Quad Core Intel® Core™ i7/i5/i3 U-series Processor
(Tiger Lake UP3)
Chipset Intel® SoC (Tiger Lake)
BIOS AMI
SIO IT8786E
Memory 1 DDR4 3200MHz SO-DIMM, up to 32GB
Graphics
Graphics Processor Intel® Iris® Xe Graphics
Interface • DisplayPort 1 : Up to 4096 x 2304 @60Hz
• DisplayPort 2 : Up to 4096 x 2304 @60Hz
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT
LAN 2 Intel® I225-IT supports 2.5 GigE LAN
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Storage
SATA 1 SATA III (6Gbps)
M.2 1 M.2 Key B 2260 Socket
I/O Interface
Serial 2 COM RS-232/422/485 (ESD 8kV)
USB
• 2 USB 3.1 (External)
• 2 USB 2.0 (External)
• 2 USB 2.0 (Internal)
LED Power, HDD, WWAN, WLAN
SIM Card 1 Nano SIM Card Socket (External)
Expansion
M.2
2 M.2 sockets :
• 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230)
SUMIT • 1 SUMIT A Connector
• 1 SUMIT B Connector
Power
Power Input 9V to 55V DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Remote Switch 2-pin Terminal Block

4
©Vecow SPC-7000/7100/7200 User Manual GENERAL INTRODUCTION
Others
TPM Optional Inneon SLB 9670VQ2.0FW7.85 supports TPM 2.0,
SPI Interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Ignition Control 16 Mode (Internal)
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x L x H) 150.4mm x 106.2mm x 44.0mm (5.92" x 4.18" x 1.73")
Weight 0.9 kg (1.98 lb)
Mounting
• Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• VESA Mount (Optional)
Environment
Operating Temperature -40°C to 65°C (-40°F to 149°F) at 15W TDP CPU
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

5
©Vecow SPC-7000/7100/7200 User Manual GENERAL INTRODUCTION
1.3.2 Specications of SPC-7100
System
Processor Quad Core Intel® Core™ i7/i5/i3 U-series Processor
(Tiger Lake UP3)
Chipset Intel® SoC (Tiger Lake)
BIOS AMI
SIO IT8786E
Memory 1 DDR4 3200MHz SO-DIMM, up to 32GB
Graphics
Graphics Processor Intel® Iris® Xe Graphics
Interface • DisplayPort 1 : Up to 4096 x 2304 @60Hz
• DisplayPort 2 : Up to 4096 x 2304 @60Hz
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT
LAN 2 Intel® I225-IT supports 2.5 GigE LAN
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Storage
SATA 1 SATA III (6Gbps)
M.2 1 M.2 Key B 2260 Socket
I/O Interface
Serial 2 COM RS-232/422/485 (ESD 8kV)
USB
• 2 USB 3.1 (External)
• 2 USB 2.0 (External)
• 2 USB 2.0 (Internal)
LED Power, HDD, WWAN, WLAN
SIM Card 1 Nano SIM Card Socket (External)
Expansion
M.2
2 M.2 sockets :
• 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230)
SUMIT • 1 SUMIT A Connector
• 1 SUMIT B Connector
Power
Power Input 9V to 55V DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Remote Switch 2-pin Terminal Block

6
©Vecow SPC-7000/7100/7200 User Manual GENERAL INTRODUCTION
Others
TPM Optional Inneon SLB 9670VQ2.0FW7.85 supports TPM 2.0,
SPI Interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Ignition Control 16 Mode (Internal)
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x L x H) 150.4mm x 106.2mm x 57.0mm (5.92" x 4.18" x 2.24")
Weight 1.3 kg (2.87 lb)
Mounting
• Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• VESA Mount (Optional)
Environment
Operating Temperature -40°C to 75°C (-40°F to 167°F) at 15W TDP CPU
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

7
©Vecow SPC-7000/7100/7200 User Manual GENERAL INTRODUCTION
1.3.3 Specications of SPC-7200
System
Processor Quad Core Intel® Core™ i7/i5/i3 U-series Processor
(Tiger Lake UP3)
Chipset Intel® SoC (Tiger Lake)
BIOS AMI
SIO IT8786E
Memory 1 DDR4 3200MHz SO-DIMM, up to 32GB
Graphics
Graphics Processor Intel® Iris® Xe Graphics
Interface • DisplayPort 1 : Up to 4096 x 2304 @60Hz
• DisplayPort 2 : Up to 4096 x 2304 @60Hz
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT
LAN 2 Intel® I225-IT supports 2.5 GigE LAN
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Storage
SATA 1 SATA III (6Gbps)
M.2 1 M.2 Key B 2260 Socket
I/O Interface
Serial 2 COM RS-232/422/485 (ESD 8kV)
USB
• 2 USB 3.1 (External)
• 2 USB 2.0 (External)
• 2 USB 2.0 (Internal)
LED Power, HDD, WWAN, WLAN
SIM Card 1 Nano SIM Card Socket (External)
Expansion
M.2
2 M.2 sockets :
• 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230)
SUMIT • 1 SUMIT A Connector
• 1 SUMIT B Connector
Power
Power Input 9V to 55V DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Remote Switch 2-pin Terminal Block

8
©Vecow SPC-7000/7100/7200 User Manual GENERAL INTRODUCTION
Others
TPM Optional Inneon SLB 9670VQ2.0FW7.85 supports TPM 2.0,
SPI Interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Ignition Control 16 Mode (Internal)
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x L x H) 150.4mm x 106.2mm x 59.9mm (5.92" x 4.18" x 2.36")
Weight 1.4 kg (3.09 lb)
Mounting
• Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• VESA Mount (Optional)
Environment
Operating Temperature -40°C to 70°C (-40°F to 158°F) at 28W TDP CPU with Fan
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

9
©Vecow SPC-7000/7100/7200 User Manual GENERAL INTRODUCTION
1.4 Supported CPU List
Processor No. Cores TDP Cache Max. Frequency ECC Memory
Intel® Core™ i7-1185G7E 4 28W 12M Up to 4.4GHz N
Intel® Core™ i5-1145G7E 4 28W 8M Up to 4.1GHz N

10
©Vecow SPC-7000/7100/7200 User Manual GENERAL INTRODUCTION
1.5 Mechanical Dimension
1.5.1 SPC-7000 Mechanical Drawing
169.1 (6.66)
185.4 (7.30)
150.4 (5.92)
53.8 (2.12)
106.2 (4.18)
44.3 (1.74)
Unit : mm (inch)
1.5.2 SPC-7100 Mechanical Drawing
57.0 (2.24)
169.1 (6.66)
185.4 (7.30)
150.4 (5.92)
53.8 (2.12)
106.2 (4.18)
Unit : mm (inch)

11
©Vecow SPC-7000/7100/7200 User Manual GENERAL INTRODUCTION
1.5.3 SPC-7200 Mechanical Drawing
59.9 (2.36)
169.1 (6.66)
185.4 (7.30)
150.4 (5.92)
53.8 (2.12)
106.2 (4.18)
Unit : mm (inch)

12
©Vecow SPC-7000/7100/7200 User Manual GETTING TO KNOW YOUR SPC-7000
2
GETTING TO KNOW YOUR SPC-7000
2.1 SPC-7000/7100/7200 Packing List
Item Description Qty
1SPC-7000/7100/7200 Embedded System 1
2Driver/User Manual DVD 1
Item Description Outlook Usage P/N Qty
1
PHILLPIS
M4x16L with
washer, Ni
Mount 53-24D6416-30B 4
2PHILLPIS
M3*4L M.2 53-2426204-80B 3
3Wall-mounting
bracket Mount 62-01P0672-800 2
4
Terminal block
plug pitch
5.0mm 3-pin
DC IN/Switch 51-2211R03-S1A 2
5Foot Pad Foot Pad 53-4000042-303 4
6 Flat M3x4L, Ni Wall mount
bracket 53-2466204-30B 8
7 M.2 Tray M.2 62-01P0669-400 1

13
©Vecow SPC-7000/7100/7200 User Manual GETTING TO KNOW YOUR SPC-7000
2.2 Front Panel I/O & Functions
2.2.1 SPC-7000/7100/7200 Front I/O & Functions
In Vecow's SPC-7000/7100/7200 series family, all I/O connectors are located on the
front panel. Most of the general connections to the computer device, such as Audio,
USB3.2, USB 2.0, LAN Jack, and Display Port, are placed on the front panel.
2.2.2 Reset Tact Switch
It is a hardware reset switch. Use this switch to reset the system without power o󰀨
the system. Press the Reset Switch for a few seconds, then reset will be enabled.
2.2.3 Power Button
The power button is a non-latched switch. In case of system halts, you can press
and hold the power button for 4 seconds to compulsorily shut down the system.
Please note that a 4 seconds interval is kept by the system between two on/off
operations (i.e. once turning o󰀨 the system, you shall wait for 4 seconds to initiate
another power-on operation).
