VECTECH 190
SOLDERING TESTER
Soldering iron temperature
tester
Instruction manual
1. Notes:
1. The grounding column on the test plate is convenient for users
to connect with crocodile clips, and its interior is connected to
the simulated ground, please do not loosen it, so as not to have
poor grounding.
2. The temperature sensor is very thin, only ф0.2 in diameter, and
must be very careful, if too much force is used, it will cause a
break.
3. The test point of the temperature sensor is specially treated, but
frequent testing will cause it to wear, so once there is wear, it
should be replaced immediately to ensure the accuracy of the
test.
4. When there is flux at the terminal, it should be wiped clean
with an alcohol-stained cloth, and it cannot be cleaned with
paint thinners or benzene.
5. Before testing, new solder is applied to the soldering iron head,
which is necessary to ensure good contact between the
soldering iron tip, the temperature sensor and the test plate.
6. During the test, please do not touch the soldering iron tip to the
non-stiff steel platform under the test point, so as not to cause
measurement errors.
7. The overflow flag is -1 or 1, and during the test voltage and
resistance, the soldering iron tip and the test plate do not
contact, at which point a numerical value shows that this is
normal.
8. In the process of testing voltage and resistance, the AC power
source required to be used must have a ground wire.
9. When testing voltage and resistance, if the data exceeds the
specified value, check whether the tightening screw of the
soldering iron tip is loose, tighten it, and then retest.
二、
The part name
:
1. With R2-R1, the resistance R=R2-R1 between the soldering
tip and ground can be obtained.
(5) Overflow display
2. The overflow code is 1, which indicates that the sensor is not
connected when measuring the temperature of the soldering
iron, and when measuring voltage and resistance, the soldering
iron tip is not in contact with the test plate or that the ground
wire inside the soldering iron is broken.
3. The overflow code is -1, possibly because the red or blue
termination of the temperature sensor is reversed or the
measured temperature is below 0ºC
五、
Ground wire
:
The grounding wire is the connection between the soldering iron
grounding wire and the temperature tester, which is used to measure
the voltage and resistance of the soldering iron tip to ground.
六、
Maintenance & Calibration
:
1. If there is solder at the terminals, it can be wiped off with a
soft cloth dipped in alcohol, not with diluents or benzene.
2. Repeated tests can wear out the sensor, if you need
accurate measurements, replace the sensor with a new one.
1. The life of a sensor varies depending on the flux and solder
you use, and in general, a single sensor can measure up to
50 times.
2. If you want to calibrate the temperature tester, contact your
nearest dealer.
七、
Replaceable parts
:
serial number numbering name
1 47112.1 Sensor [K thermocouple/10pcs.].
2 11012 Ground wire
3 12107.1 Power Supply Export Seat UL
4 12107 Power Supply Export Seat CCC
1.As shown in the image above, connect the temperature tester to
the soldering iron.
2.If your soldering iron is a temperature-controlled soldering iron,
set it to the use temperature and wait until it reaches thermal
stability.
3. Dial the selection switch to "mV".
4.Connect the ground terminal to the grounding post on the test
plate with the grounding pin.
5.Read display data V1。
6. Disconnect the ground wire.
7.Clean the tip and apply new solder。
8.A small solder bead is placed in the center of the test plate and the
solder beads are heated with a soldering iron until they are
completely melted.
9.When the display is stable, read the data V2, if the power plug of
the soldering iron is a crocodile clip, it is better than the three-core
plug, just use the ground wire clip to connect the ground terminal,
you can complete the measurement.
七、 With V2-V1, the voltage difference between the soldering
tip and ground can be obtained V=V2-V1。
(4) Measure the resistance between the soldering iron tip and
ground
1.Dial the selector switch to the "OHM" file and measure R1 and
R2 using the same method used to measure V1 and V2。
三、
Technical indicators:
name
Temperature tester
Scope of the test
temperature
0-600
℃/32-1200℉
voltage 0-90mV(AC)
resistance
0-90
Ω
resolution
temperature 1℃/1℉
voltage 0.1mV
resistance
0.1
Ω
accuracy
temperature ±3℃
±6℉
voltage ±
(3%+2Word)
resistance ±
(1%+2Word)
Temperature
sensors KType thermocouple
display
LCD display
(
LCD)
3.5bit
Out-of-range
display -1,1
Voltage
measurement Complies with MIL-STD-2000
Rated power 1W
size
200
(
W
)×
50
(
H
)×
120
(
D
)
mm
weight approximately1.1kg
Usage
environment 0-40℃/32-104℉0-80RH%
四、
Usage
:
①
Get ready
1. Press the sliding key in the direction indicated by the arrow
and install the sensor (red-ended connection marker
There are red dot terminals, blue ends connecting blue dot
terminals)。
2. Plug in the power supply and turn on the power switch。
②
Test the temperature of the tip
1. Turn the °F/°C transfer switch to the appropriate position.
(°F: shows Fahrenheit temperature, °C: shows Celsius
temperature).
2. Toggle the selector switch toward the "TEMP" file.
3. Soldering iron tip, coated
with new solder。
4. Quickly place the tip on the
test point of the temperature
sensor
*If you need to test the
temperature with an external
K-type sensor, you need to
insert the K-type sensor plug
into the external K-sensor
socket on the left side of the
soldering iron tester (the sensor on the terminal of the temperature
measurement zone must be removed.
5. The displayed value is constantly increasing, wait a few seconds,
and then read it after the value stabilizes.
③
Measure the voltage difference between the tip and ground
4
烙铁
测试点
