Vector VEC184POB Instruction Manual

1
VEC184POB
POWER SERIES
SPOTLIGHT
2,000,000
CORDED • CORDLESS • RECHARGEABLE
KEY INFORMATION YOU SHOULD KNOW:
• REPLACEABLE 12V BATTERY
•PORTABLE, CORDLESS, RECHARGEABLE
• ULTRA BRIGHT AREA LIGHT
• HIGH INTENSITY QUARTZ BEAM
• BUILT-IN UTILITY WORK STAND
OWNER’S MANUAL AND
WARRANTY INFORMATION
THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY,
OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. READ
CAREFULLY BEFORE USE, AND RETAIN FOR FUTURE REFERENCE.
4140 S.W. 28th Way, Ft. Lauderdale, FL 33312
Toll Free: [phone]
IF YOU SHOULD EXPERIENCE A PROBLEM WITH YOUR
PURCHASE CALL TOLL FREE [phone]. IN MOST
CASES A SERVICE REPRESENTATIVE CAN RESOLVE
YOUR PROBLEM OVER THE PHONE.
BEFORE RETURNING THIS PRODUCT FOR ANY REASON,
PLEASE CALL TOLL FREE [phone]
TM

2
SAVE THESE INSTRUCTIONS
NOTE: This unit is shipped in a partially charged state. Initial charge time is approximately
18-20 hours, 15 hours thereafter.
IMPORTANT SAFETY INSTRUCTIONS
WARNINGS: Contains non-spillable, sealed, lead-acid battery. Battery must be recycled or dis-
posed of properly. For battery disposal information call toll-free [phone].
DO NOT dispose of batteries in fire, as this may result in an explosion.
DO NOT open battery or short circuit, as this may cause the bat-
tery to leak or get hot, causing personal injury.
Please read Instruction Manual completely for all safety and warning instructions.
WARNINGS: USE ONLY WITH CHARGER PROVIDED WITH UNIT.
DURING AC RECHARGE OR DC RECHARGE:
a) Never turn on while charging.
b) After recharge – disconnect cord and wait 5 minutes before use.
DO NOT OVERCHARGE:
a) AC recharge 15 hours.
b) DC recharge 5 hours maximum.
1. Do not substitute power cords or adapters. Only recharge with supplied AC
and DC recharge adapters. Recharge adapters for this unit supply 12 volts
DC. Do not recharge with adapters other than the ones supplied with this unit.
2. Do not submerge in water. This unit is not waterproof - it is weather resistant.
3. Do not overcharge battery.
4. Do not operate spotlight while recharging. This will prevent battery recharge
and overheat the charging adapters.
5. Lens gets very hot when spotlight is operating. Do not touch lens - keep chil-
dren away from spotlight. This is not a toy!
6. Keep combustibles away from spotlight lens - extreme heat can cause fires.
7. Keep sharp objects away from glass lens - it is breakable.
8. Do not drop or throw spotlight, it contains glass and a sealed lead acid bat-
tery.
9. Dispose of unusable batteries in a responsible manner (see battery disposal
section).
10. Make sure that during recharge, cords are protected from damage.
11. Do not crush, cut, pull or expose recharge adapter cords to extreme heat.
12. Keep recharge cords away from sharp edges. Position recharge cords so that
they do not become entangled or become a safety hazard.
1. INTRODUCTION
Congratulations on purchasing the Vector 2,000,000 Power Series Spotlight, an
advanced design combination spotlight and area light. It instantly converts use from a
powerful spotlight to a soft, long-lasting area light. It uses a powerful, proven-technol-
ogy, rechargeable, non-spillable, sealed, lead-acid battery that allows for years of
dependable use, recharge after recharge. The spotlight was designed from the ground
up to be the most versatile and practical light for travel, camping, picnicking, tailgate
parties and boating. This spotlight gives you the kind of light you need, when and
where you need it.

3
Two recharge adapters are supplied with the spotlight. It is rechargeable from
either a 12 volt DC accessory outlet, or from any 120 volt 60 Hz AC outlet. This
permits recharge flexibility for use around home, business or in the field. 12
volt DC power is available from most vehicles, boats, jump starters and portable
battery packs. Vector has a variety of portable power products that would make
ideal companions.
2. FEATURES
• High-intensity, ultra-white, 100-watt halogen bulb
• Corded/cordless, powerful Quartz Halogen Spotlight for use whenever and
wherever you need light
• provides up to 20 minutes of continuous light (when fully charged)
• Includes biuilt-in area light located in grip
• Corded - plug into any 12 volt DC accessory outlet for extended use and charging
• Built-in utility work stand for garage, work bench and roadside repairs
• Take anywhere - use cordless or plug into 12 volt DC outlet
• Replace 12 volt, 3 amp, sealed, non spillable battery
• Powerful, prefocused, replaceable quartz halogen bulb in spotlight
• Recharge from home or vehicle (AC and DC adapters included)
3. LOCATION DIAGRAM
4. OPERATION
A two-position switch (spotlight on/off) controls the operation of the main beam. The
area light is controlled by a two-position button (area light on/off) is located on the side
of the unit. The spotlight can be continuously lit for up to 20 minutes on a full battery
charge. The area light can be lit for up to 12 hours on a full battery charge.
Figure 1 shows locations of the handle, the handle lock button, spotlight ON/OFF
switch, area ON/OFF switch, and the recharging port with LED charging indicator.
5. RECHARGING
AC and DC recharge requires use of these sup-
plied recharge adapters. Do not charge spotlight
using any other adapters (see Figures 2 and 3).
TRIGGER LOCK
SWITCH
LED CHARGING
INDICATOR
FOUR POSITION
HANDLE
AREA LIGHT ON/OFF BUTTON
BEAM ON/OFF TRIGGER
FIGURE 1
AREA LIGHT
RECHARGE PORT
DC CHARGING PORT

4
5.1 AC RECHARGE
During Recharge:
a) Never turn on while charging.
b) Make sure that the AC power source is 120 volts, 60 Hz.
c) After recharge – disconnect cord and wait 5 minutes before use.
FIGURE 2 - AC CHARGER
WARNING: Use the supplied AC recharge adapter; do not substitute. AC recharg-
ing requires the use of the included AC charger/adapter that supplies
12 volts DC.
1. Connect the AC charger to an AC power source.
2. Plug the adapter’s barrel connecter into the recharge port located near the handle.
3. Recharge for 15 hours maximum.
4. After recharge, disconnect the barrel connector from the recharge port and store the
adapter.
5.2 DC RECHARGE
a) Never turn on spotlight while charging.
b) Maximum charge - 5 hours
c) After recharge – disconnect cord and wait 5 minutes before use.
FIGURE 3 - DC CHARGER
Make sure the DC source (jump starter, battery pack, vehicle accessory socket, etc) is
12 volt DC. The DC source should be able to supply at least 10 amps at 12 volt DC.
WARNING: Use the supplied DC recharge adapter, do not substitute.
DC recharge requires the use of the supplied DC recharge adapter.
1. Connect the DC recharge adapter’s DC plug to a 12 volt DC source.
2. Plug the adapter’s connecter into the recharge port located on the back of the unit.
3. Recharge for 5 hours maximum.
4. After recharge, disconnect the barrel connector from the recharge port and store the
adapter.

5
6. PERIODIC MAINTENANCE
All batteries lose charge over time, especially when they are warm. AC recharge is rec-
ommended every two months, when not in frequent use. Use the AC recharger and
charge for the recommended time. If the unit gets dirty gently clean the outer surface of
the spotlight unit with a soft cloth moistened with a mild solution of water and detergent.
Periodically inspect the condition of recharge adapters, connectors, and wires. Replace
any components that may have become worn or broken.
7. PARTS REPLACEMENT
Three parts are replaceable by users. The quartz halogen bulb and sealed lead acid battery
are proprietary and are available through Vector Manufacturing. A substitute 12 volt H3
100 watt bulb may be used instead of a Vector bulb. These can also be purchased from pop-
ular automotive parts suppliers nationwide. The DC charging adapter fuse is replaceable.
Contact Vector Manufacturing’s Technical Support Department for replacement parts and
any additional information that you may need. They may be reached toll free
[phone].
7.1 DC PLUG FUSE REPLACEMENT
The fuse in the DC plug protects the charging circuit of the DC recharge adapter. If there
is no slight warming of the DC plug during recharge, you should suspect that 12 volts
DC is not powering the plug or the fuse is opened.
To replace the fuse:
1. Unscrew the end cap of the DC plug (counterclockwise).
2. Remove spring center contact and fuse.
3. Check fuse with a continuity checker.
4. If blown, locate replacement fuse with same type and rating.
5. Replace the fuse, spring, contact and end cap.
6. Screw end cap clockwise until it is finger tight-do not over-tighten.
7. Check for proper operation of DC charging adapter.
7.2 SPOTLIGHT BULB REPLACEMENT
To replace the H3 type 12 volt bulb, you will need a small Phillips-head type screwdriv-
er and a replacement bulb.
FIGURE 4 - LENS ASSEMBLY
™
MANUFACTURING,Ltd.
ULTRA
SPORT SPOT
2,000,000CandlePower
“O” RING
PHILIP'S
HEAD SCREWS
RUBBER BEZEL
LENS
REFLECTOR

6
Bulb life can be shortened by installing a bulb with dirt or fingerprints on it. During bulb
installation, avoid touching the glass part of the bulb (see Figure 4 and 5 for details).
1. Disconnect the unit from charging adapter.
2. Pull off the rubber bezel to reveal two small Phillips-head screws.
3. Using the screwdriver, remove (counterclockwise) the two screws. Set them aside.
4. Lift off the retaining ring, glass, and rubber ring and set them aside.
5. Carefully remove the reflector and bulb assembly.
6. Disconnect the bulb wire from the red power wire and set the burned out bulb
aside.
7. Unsnap the hairpin retaining wires from the reflector’s flange.
8. Using the screwdriver, loosen the retaining screw to remove the bulb from the
reflector (no need to completely remove this screw).
9. Lift out the bulb and the attached wire.
10. Insert the replacement bulb into the reflector’s flange.
11. Put back and secure the hairpin retaining wires.
12. Connect the bulb power wire to the red power wire.
13. Tighten the retaining screw on the flange.
14. Place the reflector in position in the body of the spotlight.
15. Replace the rubber “O” ring in the groove around the perimeter of the reflector.
16. Replace glass and retaining ring so that the screw holes are aligned.
17. Secure retaining ring with two screws.
18. Replace rubber bezel.
19. Operate switch to ensure proper operation of spotlight.
7.3 REPLACING THE BATTERY PACK
The sealed lead acid battery has a life of several years, if recharged promptly after each
use. When a fully charged battery only provides about ten minutes or less of spotlight
operation, it should be replaced with a new one. To replace the battery, you will need
a narrow shaft Phillips-head screwdriver and a replacement battery. The battery pack
can be replaced by doing the following:
1. Complete the bulb replacement steps through step 4, to remove the reflector
assembly.
2. Remove all the Phillips-head screws (counterclockwise) that fasten the two halves of
the housing body.
3. Separate the two body halves and carefully pop out the handle.
WARNING: DO NOT ALLOW BARE WIRES OR CONNECTORS TO CONTACT
EACH OTHER; DANGEROUS SPARKING CAN OCCUR.
METAL PRONGS PHILLIPS HEAD SCREW
BULB
REFLECTOR
METAL PRONGS
FIGURE 5 - BULB ASSEMBLY
PHILLIPS HEAD SCREW

7
4. Note polarity of battery. Note which color wire is on which terminal.
5. Disconnect the wires from the battery and set the battery aside.
6. Connect the replacement battery, making sure the correct color wires are on the new
battery terminals. Make sure the polarity of battery is correct.
WARNING: Incorrectly connected wires will damage the battery and recharge
adapter, double check battery polarity before reassembly.
CAUTION: Incorrectly connected wires will allow the spotlight to operate normally,
however, when recharge adapters are connected, there will be damage to
the battery and recharge adapters. Double check battery polarity before
reassembly!
7. Replace handle, in one half of the housing body. Make sure wires and connectors
do not touch.
8. Place other half of housing body into position and replace screws (clockwise). Do
not overtighten.
9. Follow steps 13 through 19 for bulb replacement to reassemble reflector, rubber “O”
ring, glass, retaining ring and rubber bezel. Charge the new battery using AC
recharge adapter for a minimum of 18-20 hours initially, then 15 hours thereafter.
SAFE BATTERY DISPOSAL
Contains a maintenance-free, sealed, non-spillable, lead acid battery, which must be
disposed of properly. Recycling is required, contact your local authority for information.
Failure to comply with local, state and federal regulations can result in fines or impris-
onment.
BATTERY DISPOSAL WARNING
• Do not dispose of the battery in fire as this may result in an explosion
• Before disposing of the battery, protect exposed terminals with
heavy-duty electrical tape to prevent shorting (shorting can
result in injury or fire)
• Do not expose battery to fire or intense heat as it may explode
• For more information on recycling this battery, call toll-free
[phone]
8. SPECIFICATIONS
Spotlight Bulb........................................12 volt, H3 series, 100 watt quartz halogen
Battery..................................................Maintenance free, sealed lead acid, 12 volt
