Introduction
Contractor Certification Requirements ..............................................................................1
Before You Begin ..............................................................................................................2
Safety Precautions ............................................................................................................2
Precautions Against Static Electricity ................................................................................3
Before Turning Off Power .................................................................................................3
Replacing the Display Door Assembly (P/N 330020-625)......................4
Replacing the Printer Door Assembly (P/N 330020-626)........................6
Replacing the Power Supply (P/N 330020-623)............................................8
Figures
Figure 1. USB/Ethernet board - V-R thumb drive port...............................................3
Figure 2. Front doors.................................................................................................4
Figure 3. Display door cables....................................................................................5
Figure 4. Printer door cables .....................................................................................6
Figure 5. Remove USB cable and CF card ...............................................................8
Figure 6. Remove AC Channel cover........................................................................9
Figure 7. Removing AC Input module .....................................................................10
Figure 8. Removing Power Supply ..........................................................................11
Figure 9. Replacing Power Supply shield over Power Supply board ......................12

1
Introduction
This manual contains instructions for replacing the following TLS-4XX console components:
• Display Door Assembly (P/N 330020-625)
• Printer Door Assembly (P/N 330020-626)
• Power Supply (P/N 330020-623)
This manual does not provide troubleshooting information.
Contractor Certification Requirements
Veeder-Root requires the following minimum training certifications for contractors who will install and setup the
equipment discussed in this manual:
Installer Certification: Contractors holding valid Installer Certification are approved to perform wiring and
conduit routing, equipment mounting, probe and sensor installation, tank and line preparation, and line leak
detector installation.
TLS-350 Technician Certification: Contractors holding valid TLS-350 Technician Certifications are approved to
perform installation checkout, startup, programming and operations training, troubleshooting and servicing for all
Veeder-Root TLS-300 or TLS-350 Series Tank Monitoring Systems, including Line Leak Detection and associated
accessories.
TLS-450 Technician Certification: Contractors holding valid TLS-450 Technician Certifications are approved to
perform installation checkout, startup, programming and operations training, troubleshooting and servicing for all
Veeder-Root TLS-450 Series Tank Monitoring Systems, including Line Leak Detection and associated accessories.
In-Station Diagnostics (ISD) Technician Certification: Contractors holding valid ISD Technician
Certifications are approved to perform installation checkout, startup, programming and operations training,
troubleshooting and servicing for all Veeder-Root In-Station Diagnostics hardware, including ISD-PMC and
Carbon Canister Vapor Polisher.
Warranty Registrations may only be submitted by selected Distributors.

Introduction Before You Begin
2
Before You Begin
Before you begin component replacement, read the following guidelines:
• To avoid electrical shock, be sure AC power to the console is Off when performing the procedures in this
manual.
• Failure to comply with these requirements could result in death, serious personal injury, property loss, or
equipment damage.
Safety Precautions
The following safety symbols may be used throughout this manual to alert you to important safety hazards and
precautions.
ELECTRICITY
High voltage exists in, and is supplied
to, the device. A potential shock hazard
exists.
TURN POWER OFF
Live power to a device creates a
potential shock hazard. Turn Off power
to the device and associated accesso-
ries when servicing the unit.
INJURY
Careless or improper handling of tools
can cause bodily injury.
STATIC SENSITIVE COMPONENTS
Wear grounded anti-static wrist strap
before handling the printed circuit
board.
READ ALL RELATED MANUALS
Knowledge of all related procedures
before you begin work is important.
Read and understand all manuals thor-
oughly. If you do not understand a pro-
cedure, ask someone who does.
WARNING
This system operates on 115 Vac power. Serious injury or death from electrical
shock could occur if the power ON/OFF warnings in this manual are not
heeded.
1. Read and follow all instructions in this manual, including all safety
warnings.
2. Remove rings from hands, metal watch bands and bracelets, and loose
hanging neck jewelry before performing these procedures.
3. Do not modify or use service parts other than those provided by Veeder-
Root.
OFF
OFF

Introduction Precautions Against Static Electricity
3
Precautions Against Static Electricity
Before removing electronic components from their antistatic bags read the following static electricity precautions.
1. Before handling any components, discharge your body's static electric charge by touching a grounded
surface.
2. Do not remove parts from their antistatic bags until you are ready to install them.
3. Do not lay parts on the antistatic bags! Only the insides are antistatic.
4. When handling parts, hold them by their edges and their metal mounting brackets.
5. Avoid touching components or edge connectors that plug into slots.
6. Never slide parts over any surface.
7. Avoid plastic, vinyl, and styrofoam in your work area.
8. Wear the antistatic wrist strap included in your component replacement kit.
9. The antistatic caution icon shown to the left appears in several places in this manual to remind you to wear an
antistatic wrist strap (Part No. 576013-908) when handling static sensitive devices.
Before Turning Off Power
Before powering off the console perform a system backup:
• Insert the V-R Backup thumb drive (P/N 330020-604) in the external USB port on the USB/Ethernet card, P/N
332913-001 (see item 2 in Figure 1).
• Touch the Diagnostics button on the Home Screen and touch the Software Maintenance button to view the
Software Maintenance File Manager tab screen. Touch the Backup button to begin the backup process.
• After the ‘Backup Completed Successfully’ message displays, you can safely remove the V-R Backup thumb
drive.
Figure 1. USB/Ethernet board - V-R thumb drive port
Legend for numbered boxes in Figure 1
954-10.eps
1
2
1. USB/Ethernet module end plate.
2. V-R thumb drive plugged into USB port

4
Replacing the Display Door Assembly (P/N 330020-625)
1. Switch Off power to the console.
2. Open the two front doors of the console as shown in Figure 2
Figure 2. Front doors
Legend for numbered boxes in Figure 2
3. Disconnect grounding braid from the saddle clamp on the inside of the Display door.
4. Disconnect the three cables from the Display door attached to the CPU board touchscreen connector, the
display data connector and the LED/Display connector (see Figure 3).
5. Remove the top and bottom #8 taptite screws in the Display door hinge and remove the door.
6. Get the replacement Display door and line up the holes in the two door hinges with the top and bottom holes
in the console housing and screw in the top and bottom #8 taptite screws. Tighten the two hinge screws.
7. Reconnect the grounding braid to the saddle clamp on the inside of the Display door.
OFF
1 2
1 2
956-1.eps
1. Remove top and bottom #8 taptite screws on right side of left
(Printer) door and swing door to left.
2. Remove top and bottom #8 taptite screws on right side of left
(Display) door and swing door to left.

Replacing the Display Door Assembly (P/N 330020-625) Before Turning Off Power
5
Figure 3. Display door cables
Legend for numbered boxes in Figure 3
8. Reconnect the three cables from the Display door to their connectors on the CPU board (see Figure 3).
9. Close the Display door and insert the right-side top and bottom #8 taptite screws. Tighten the two screws.
10. Close the Printer door and insert the right-side top and bottom #8 taptite screws. Tighten the two screws.
2
543
1
6
1. Top Display door hinge shoulder screw
2. Grounding braid
3. Touchscreen control cable
4. Display data cable
5. LED/Display cable
6. Bottom Display door hinge shoulder screw

6
Replacing the Printer Door Assembly (P/N 330020-626)
1. Switch Off power to the console.
2. Open the left front door of the console as shown in Figure 2.
3. Disconnect grounding braid from the saddle clamp on the inside of the Printer door (see Figure 4).
Figure 4. Printer door cables
Legend for numbered boxes in Figure 4
OFF
1
2
3
4
956-3 eps
5
1. Bottom Printer door hinge shoulder screw
2. USB cable
3. Power cable
4. Grounding braid
5. Top Printer door hinge shoulder screw

Replacing the Printer Door Assembly (P/N 330020-626) Before Turning Off Power
7
4. Disconnect the two cables from the Printer door (see Figure 3).
5. Remove the top and bottom #8 taptite screws in the Printer door hinges and remove the door.
6. Get the replacement Printer door and line up the holes in the two door hinges with the top and bottom holes
in the console housing and screw in the top and bottom #8 taptite screws. Tighten the two hinge screws.
7. Attach the grounding braid to the saddle clamp on the inside of the Printer door (see Figure 4).
8. Connect the USB cable and the power cable to the printer (see Figure 4).

8
Replacing the Power Supply (P/N 330020-623)
1. Switch Off power to the console.
2. Open the left front door of the console as shown in Figure 2.
3. Disconnect the USB connector and remove the CF card from the CPU board (see Figure 5).
Figure 5. Remove USB cable and CF card
Legend for numbered boxes in Figure 5
OFF
12
956-4.eps
1. USB cable
2. CF Card

Replacing the Power Supply (P/N 330020-623) Before Turning Off Power
9
4. Remove the two #8 taptite screws from the AC Channel cover and put the cover and screws aside (see
Figure 6).
Figure 6. Remove AC Channel cover
Legend for numbered boxes in Figure 6
956-8.eps
1
2
2
1. AC Channel cover
2. #8 taptite screws (2)

Replacing the Power Supply (P/N 330020-623) Before Turning Off Power
10
5. Remove the three #8 taptite screws in the AC Input module (item 1 in Figure 7).
6. Lift the Power Supply shield up to disengage the two retention snap pins in its right side flange and remove it
from the console (item 2 in Figure 7).
7. Grasp the AC Input module handle (see item 3 in Figure 7) and slowly pull up and away from the power
supply until the AC Input module disconnects from the power supply. Lift the AC Input module out of the
console.
Figure 7. Removing AC Input module
Legend for numbered boxes in Figure 7
956-5.eps
1
3
1
1
2
1. #8 taptite screws (the middle one also secures the Power
Supply shield)
2. Power Supply shield
3. AC Input module handle

Replacing the Power Supply (P/N 330020-623) Before Turning Off Power
11
8. Remove the three #6 taptite screws (item 1 in Figure 8) that secure the Power Supply board to the console
housing.
9. Place fingers under the Power Supply board (at locations indicated by two arrows in Figure 8) and lift the
board up until it is free of the two retention pins (item 3 in Figure 8).
10. Disconnect the printer power cable from the Power Supply board.
11. Lift the board out of the console by its edges since there is still undischarged high voltage in the big
capacitors.
Figure 8. Removing Power Supply
Legend for numbered boxes in Figure 8
956-6.eps
1
5
WARNING!
Shock hazard. Do not
touch underside of
board beneath these
five capacitors.
4
3
2
1. #6 taptite screws
2. J3 - Low voltage relay control connector
3. J2 - AC Input module power connector
4. Two board retention pins.
5. Capacitors
WARNING! These caps can hold a high charge,
do not touch underside of board where these
caps are soldered to board.

Replacing the Power Supply (P/N 330020-623) Before Turning Off Power
12
12. Get the new Power Supply board and lower into console.
13. Attach the printer power supply cable to its connector (J1) on the upper right corner of the replacement Power
Supply board.
14. Lineup the two holes in the Power Supply board (see item 4 in Figure 8) with the two retention pins in the
back of the console housing and push the board down until the pins snap into position.
15. Install the three #6 taptite screws (item 1 in Figure 8) and tighten them.
16. Get the AC Input module. Notice that there are two male connectors on the bottom of the AC Input module
board that plug into two female connectors on the Power Supply board. With the handle (item 3 of Figure 7)
of the AC Input module against the left side of the console housing, line up the two AC Input module bottom
connectors over the two female connectors (items 2 and 3 in Figure 8) on the Power Supply board and push
down on the AC Input module until the connectors are firmly seated.
17. Place the Power Supply shield (item 2 in Figure 7) over the Power Supply board and lower it down onto its
two retention pins (see item 2 in Figure 9) and snap it into place.
18. Install the three #8 taptite screws in the AC Input module (see item 1 in Figure 7).
19. Replace the AC Channel cover and install the two #8 taptite screws (see Figure 6).
Figure 9. Replacing Power Supply shield over Power Supply board
Legend for numbered boxes in Figure 9
956-7.eps
2
1
1. This hole lines up over the middle hole in AC Input Module
bracket
2. The two holes in the right side flange of the Power Supply
shield line up over the retention pins (indicated by two arrows)
in the back of the console housing.

For technical support, sales or
other assistance, please visit:
www.veeder.com
