Veeder-Root TLS-450 Manual instruction

Manual No: 577013-940 ●Revision: F
Screens Manual
TLS-450 Setup and Operation

Notice
Veeder-Root makes no warranty of any kind with regard to this publication, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose.
Veeder-Root shall not be liable for errors contained herein or for incidental or consequential damages in connection with the
furnishing, performance, or use of this publication.
Veeder-Root reserves the right to change system options or features, or the information contained in this publication.
This publication contains proprietary information which is protected by copyright. All rights reserved. No part of this publication
may be modified or translated to another language without the prior written consent of Veeder-Root.
Contact TLS Systems Technical Support for additional troubleshooting information at 800-323-1799.
DAMAGE CLAIMS / LOST EQUIPMENT
Thoroughly examine all components and units as soon as they are received. If any cartons are damaged or missing, write a
complete and detailed description of the damage or shortage on the face of the freight bill. The carrier's agent must verify the
inspection and sign the description. Refuse only the damaged product, not the entire shipment.
Veeder-Root must be notified of any damages and/or shortages within 30 days of receipt of the shipment, as stated in our Terms
and Conditions.
VEEDER-ROOT’S PREFERRED CARRIER
1. Contact Veeder-Root Customer Service at 800-873-3313 with the specific part numbers and quantities that were missing
or received damaged.
2. Fax signed Bill of Lading (BOL) to Veeder-Root Customer Service at 800-234-5350.
3. Veeder-Root will file the claim with the carrier and replace the damaged/missing product at no charge to the customer.
Customer Service will work with production facility to have the replacement product shipped as soon as possible.
CUSTOMER’S PREFERRED CARRIER
1. It is the customer’s responsibility to file a claim with their carrier.
2. Customer may submit a replacement purchase order. Customer is responsible for all charges and freight associated with
replacement order. Customer Service will work with production facility to have the replacement product shipped as soon as
possible.
3. If “lost” equipment is delivered at a later date and is not needed, Veeder-Root will allow a Return to Stock without a restocking
fee.
4. Veeder-Root will NOT be responsible for any compensation when a customer chooses their own carrier.
RETURN SHIPPING
For the parts return procedure, please follow the appropriate instructions in the "General Returned Goods Policy” pages in the
"Policies and Literature" section of the Veeder-Root North American Environmental Products price list. Veeder-Root will not
accept any return product without a Return Goods Authorization (RGA) number clearly printed on the outside of the package.
©Veeder-Root 2011. All rights reserved.

TLS-450 Setup and Operation Screens Manual
iii
Contents
INTRODUCTION ......................................................................................................................................1
Contractor Certification Requirements.................................................................................................1
Related Manuals...................................................................................................................................1
Safety Precautions ...............................................................................................................................1
Safety Warnings...................................................................................................................................2
Front Panel Layout ...................................................................................................................................3
Item 1 - Integral Printer.........................................................................................................................3
Item 2 - System Visual Status LEDs ....................................................................................................3
Item 3 - Touch Screen..........................................................................................................................3
Navigating the Touch Screens..................................................................................................................4
Setup, Operation, Diagnostic Touch Screen Layout............................................................................6
Online Help Touch screen Layout........................................................................................................8
Entering Data............................................................................................................................................9
Changing/Editing Values in a Field......................................................................................................9
Specialty Dialog Keypads...................................................................................................................10
Initial Console Setup Sequence..............................................................................................................14
Initial Startup Procedure.....................................................................................................................14
Startup Display...................................................................................................................................14
Understanding Alarms............................................................................................................................16
What Happens When An Alarm Is Posted?.......................................................................................16
How Do I Silence the Console Beeper and Acknowledge the Alarm?...............................................16
How Do I Learn More About an Alarm and What To Do About It? ....................................................17
Changing Printer Paper..........................................................................................................................20
SETUP SCREENS .................................................................................................................................21
Main Setup..............................................................................................................................................21
Date and Time Setup..............................................................................................................................22
Date & Time Setup - Daylight Savings...............................................................................................22
Date & Time Setup - Date & Time Set....................................................................................................24
Display Setup - Language and Units......................................................................................................25
Display Setup - Date & Time Format......................................................................................................26
Display Setup - Number Format.............................................................................................................27
Display Setup - System Status...............................................................................................................28
Display - All Tanks - All Tanks Tab Advanced Setup.............................................................................30
Display - All Tanks - Fuel Fill Selection ..................................................................................................32
Display Setup - All Sensors Tab Advanced Setup .................................................................................33
Liquid Sensors....................................................................................................................................33
Type A (2-wire CL) Sensors...............................................................................................................34
Type B (3-wire CL) Sensors...............................................................................................................34
Mag Sensors ......................................................................................................................................34
Ground Water Sensors.......................................................................................................................35
Vapor Sensors....................................................................................................................................35
Alarm Condition Icon..........................................................................................................................35
Line Pressure Sensors.......................................................................................................................36
User Defined 1-3 Tabs............................................................................................................................37
Display Setup - User Defined 1 - 3 Tabs............................................................................................37
Headers Setup........................................................................................................................................38
Security - System Security......................................................................................................................40
Device Setup - Probes............................................................................................................................42
Device Setup - Relays............................................................................................................................45
Device Setup - External Inputs...............................................................................................................47
Device Setup - Liquid Sensor.................................................................................................................49
Device Setup - Type A Sensor ...............................................................................................................51
Device Setup - Type B Sensor ...............................................................................................................53
Device Setup - Mag Sensor....................................................................................................................55

TLS-450 Setup and Operation Screens Manual
iv
Device Setup - Groundwater Sensor......................................................................................................57
Device Setup - Vapor Sensor.................................................................................................................58
Device Setup - Line Pressure Sensor ....................................................................................................60
Device Setup - LV/MDIM........................................................................................................................61
Tank Setup - General .............................................................................................................................63
Tank Setup - Limits.................................................................................................................................67
Tank Setup - Environmental Tests .........................................................................................................72
Tank Setup - All Tanks ...........................................................................................................................78
Tank Setup - Product..............................................................................................................................81
Report Column Descriptions ..............................................................................................................81
Control Buttons (Right Side of Screen)..............................................................................................81
Tank Setup - Product Mapping...............................................................................................................83
Report Column Descriptions ..............................................................................................................83
Control Buttons (Right Side of Screen)..............................................................................................83
Tank Setup - View All Products..............................................................................................................85
Tank Setup - Chart .................................................................................................................................86
Tank Setup - Manual Calibration............................................................................................................88
Adding a New Manually Calibrated Tank Chart.................................................................................89
Control Buttons (right of screen) ........................................................................................................92
Tank Setup – Tank Charts......................................................................................................................94
Control Buttons (right of screen) ........................................................................................................95
Tank Setup - Siphon Sets.......................................................................................................................96
Tank Setup - AccuChart II ......................................................................................................................98
Pumps and Lines..................................................................................................................................101
PLLD Setup Overview ..........................................................................................................................101
Pumps and Lines Setup - Pumps.........................................................................................................102
Pumps and Lines Setup - Lines............................................................................................................104
Pumps and Lines Setup - All Lines.......................................................................................................106
Line Lockout Schedule - Daily..........................................................................................................106
Line Lockout Schedule - Individual...................................................................................................107
Pumps and Lines Setup - All PLLD ......................................................................................................108
Pumps and Lines Setup - PLLD ...........................................................................................................110
Custom Alarms .....................................................................................................................................114
Custom Alarms Setup - Enable ............................................................................................................114
Custom Alarms Setup - View................................................................................................................115
Report Column Descriptions ............................................................................................................115
Custom Alarms - Setup.........................................................................................................................117
Control Button (on right of screen)...................................................................................................118
Custom Help.........................................................................................................................................119
Custom Help Setup - Enable................................................................................................................119
Custom Help Setup - Alarms................................................................................................................120
Control Buttons (on right of screen) .................................................................................................120
Inventory...............................................................................................................................................121
Inventory Setup - Shift Close Method...................................................................................................121
Inventory Setup - Shift Times ...............................................................................................................123
Inventory Setup - Inventory Report Times............................................................................................124
Delivery.................................................................................................................................................125
Delivery Setup.......................................................................................................................................125
Reconciliation........................................................................................................................................126
Reconciliation Setup - General.............................................................................................................126
Reconciliation Setup - Threshold Alarms .............................................................................................128
Comm ...................................................................................................................................................131
Comm Setup - General.........................................................................................................................131
Console Comm Device Permissible Slots and Configurable Ports..................................................131
Comm Setup Procedure...................................................................................................................133

TLS-450 Setup and Operation Screens Manual
v
RS-232/RS-485, Internal Modem, Satellite Hughes H-JBox and Satellite S-Sat Comm Devices –
General (page 1)...................................................................................................................................134
Ethernet Comm Devices – General (page 2)...................................................................................136
Ethernet Comm Devices – General (page 3)...................................................................................138
Ethernet Comm Devices – General (page 4)...................................................................................138
Comm Setup - Modem..........................................................................................................................140
EDIM Comm Devices – General (page 1)............................................................................................141
EDIM Comm Devices – General (page 2)........................................................................................142
(EDIM) Comm Setup - DIM...................................................................................................................144
CDIM Comm Devices – General (page 1)............................................................................................145
CDIM Comm Devices – General (page 2)........................................................................................146
Comm Setup - Advanced......................................................................................................................148
RS-232/RS-485, Internal Modem, Satellite Hughes H-JBox, Satellite S-Sat and Ethernet Comm
Devices - Advanced Tab Setups......................................................................................................148
EDIM Advanced Tab Setups............................................................................................................149
CDIM Advanced Tab Setups (page 1).............................................................................................150
CDIM Advanced Tab Setups (page 2).............................................................................................151
Comm Setup - All Comms....................................................................................................................152
Automatic Events..................................................................................................................................153
Automatic Events Setup - Address Book..............................................................................................153
Report Column Descriptions ............................................................................................................153
Control Buttons (on right of screen) .................................................................................................154
Add/Edit Contact Entry - Contacts........................................................................................................155
Control Buttons (lower right of screen).............................................................................................155
Add/Edit Contact Entry - Modem..........................................................................................................156
Control Buttons (lower right of screen).............................................................................................157
Add/Edit Contact Entry - Fax................................................................................................................158
Control Buttons (lower right of screen).............................................................................................159
Add/Edit Contact Entry - TCP/IP...........................................................................................................160
Control Buttons (lower right of screen).............................................................................................161
Add/Edit Contact Entry - Satellite .........................................................................................................162
Control Buttons (lower right of screen).............................................................................................163
Add/Edit Contact Entry - Email.............................................................................................................164
Control Buttons (lower right of screen).............................................................................................164
Automatic Events Setup - Task Log.....................................................................................................165
Report Column Descriptions ............................................................................................................165
Control Buttons (on right of screen) .................................................................................................166
Automatic Events Setup - All Tasks .....................................................................................................167
Report Column Descriptions ............................................................................................................167
Control Buttons (on right of screen) .................................................................................................168
Automatic Events Setup - Device Tasks ..............................................................................................169
Report Column Descriptions ............................................................................................................169
Control Buttons (on right of screen) .................................................................................................170
Automatic Events - Add Tasks - Device ...............................................................................................171
Automatic Events Setup - Print Tasks..................................................................................................172
Report Column Descriptions ............................................................................................................172
Control Buttons (on right of screen) .................................................................................................173
Automatic Events Add Tasks - Print.....................................................................................................174
Automatic Events Setup – Auto Connect Tasks...................................................................................176
Report Column Descriptions ............................................................................................................176
Control Buttons (on right of screen) .................................................................................................177
Automatic Events - Add Tasks - Auto Connect ....................................................................................178
Meter.....................................................................................................................................................180
Meter Setup ..........................................................................................................................................180
Printer Setup - Setup............................................................................................................................181
Printer Setup Screen 1.....................................................................................................................181

TLS-450 Setup and Operation Screens Manual
vi
Printer Setup Screen 2.....................................................................................................................182
Setup a Printer with the Get Printers Button....................................................................................182
Setup a Network Printer with URI Field............................................................................................183
Removing Printers............................................................................................................................183
Printer Setup - Status ...........................................................................................................................184
Printer Setup – Jobs.............................................................................................................................186
REPORTS.............................................................................................................................................187
Active Alarm Report..............................................................................................................................187
Report Column Descriptions ............................................................................................................187
Active Alarm Report Screen Refresh Rate.......................................................................................188
Control Button (on right of screen)...................................................................................................188
Alarm History Report ............................................................................................................................189
Report Column Descriptions ............................................................................................................189
Control Buttons (on right of screen) .................................................................................................190
Priority Alarm History Report................................................................................................................191
Report Column Descriptions ............................................................................................................191
Control Buttons (on right of screen) .................................................................................................192
Non-Priority Alarm History Report ........................................................................................................193
Report Column Descriptions ............................................................................................................193
Control Buttons (on right of screen) .................................................................................................194
Inventory Reports .................................................................................................................................195
Inventory Reports - Current Inventory..................................................................................................195
Report Column Descriptions ............................................................................................................195
Current Inventory Report Screen Refresh Rate...............................................................................196
Inventory Reports - Inventory History...................................................................................................197
Report Column Descriptions ............................................................................................................197
Control Button (on right of screen)...................................................................................................198
Inventory Reports - Shift Inventory.......................................................................................................199
Report Column Descriptions ............................................................................................................199
Environmental Reports.........................................................................................................................201
Environmental Reports - Combined Tank Test ....................................................................................201
Report Column Descriptions ............................................................................................................202
Control Buttons (on right of screen) .................................................................................................202
Regulatory Compliance....................................................................................................................202
Line Leak Report Passed Test Results................................................................................................203
Report Column Descriptions ............................................................................................................203
Control Button (on right of screen)...................................................................................................204
Environmental Reports - Sensor Status...............................................................................................205
Report Column Descriptions ............................................................................................................205
Environmental Reports - Sensor Status History...................................................................................207
Screen Title Bar................................................................................................................................207
Report Column Descriptions ............................................................................................................207
Control Buttons (on right of screen) .................................................................................................208
Delivery Reports ...................................................................................................................................210
Delivery Report - Manual Delivery........................................................................................................210
Report Column Descriptions ............................................................................................................210
Control Buttons (Right Side of Screen)............................................................................................211
Last Delivery Report.............................................................................................................................212
Report Column Descriptions ............................................................................................................213
Delivery History Report.........................................................................................................................214
Report Column Descriptions ............................................................................................................214
Control Button (on right of screen)...................................................................................................215
Delivery Report - Ticketed Delivery Report..........................................................................................216
Control Button (on right of screen)...................................................................................................217
Edit Delivery Ticket...............................................................................................................................218
Control Button (on right of screen)...................................................................................................219

TLS-450 Setup and Operation Screens Manual
vii
Add Delivery Ticket...............................................................................................................................220
Delivery Report - Adjusted Delivery Report..........................................................................................222
Report Column Descriptions ............................................................................................................222
Control Button (on right of screen)...................................................................................................223
BIR Reports ..........................................................................................................................................224
Reconciliation Report - Reconciliation..................................................................................................224
Report Column Descriptions ............................................................................................................225
Control Buttons (on right side of screen)..........................................................................................225
Reconciliation Reports - Book Variance Report...................................................................................228
Report Column Descriptions ............................................................................................................229
Control Buttons (on right side of screen)..........................................................................................229
Reconciliation Reports - Reconciliation Test Report............................................................................231
Report Column Descriptions ............................................................................................................231
Control Buttons (on right side of screen)..........................................................................................232
DIAGNOSTIC SCREENS.....................................................................................................................233
Diagnostics Main Screen......................................................................................................................233
Tank Test Diagnostics..........................................................................................................................234
Tank Test Diagnostics - CSLD Test Status..........................................................................................234
Report Column Descriptions ............................................................................................................234
CSLD Test Status Refresh Rate ......................................................................................................235
Regulatory Compliance....................................................................................................................235
Tank Test Diagnostics - CSLD Rate Table...........................................................................................236
Report Column Descriptions ............................................................................................................236
Control Buttons (right of screen) ......................................................................................................237
Regulatory Compliance....................................................................................................................238
Tank Test Diagnostics - CSLD Monthly................................................................................................239
Report Column Descriptions ............................................................................................................239
CSLD Monthly Report Refresh Rate................................................................................................240
Control Buttons (on right of screen) .................................................................................................240
Regulatory Compliance....................................................................................................................240
Tank Test Diagnostics - SLD Last Test................................................................................................241
Report Column Descriptions ............................................................................................................241
Control Buttons (right of screen) ......................................................................................................242
Regulatory Compliance....................................................................................................................242
Tank Test Diagnostics - SLD In-Progress............................................................................................243
Report Column Descriptions ............................................................................................................243
SLD Test In-Progress Report Refresh Rate.....................................................................................245
Test Control Buttons (on right of screen).........................................................................................245
Regulatory Compliance....................................................................................................................245
Manual Static Leak Detect screen........................................................................................................246
Test Control Buttons (on right of screen).........................................................................................247
Tank Test Diagnostics - SLD History....................................................................................................248
Report Column Descriptions ............................................................................................................248
SLD History Report Refresh Rate....................................................................................................249
Control Buttons (right of screen) ......................................................................................................249
Regulatory Compliance....................................................................................................................249
Pumps and Lines..................................................................................................................................250
PLLD Diagnostics - Manual Test..........................................................................................................250
Report Column Descriptions ............................................................................................................251
PLLD Manual Test - Refresh Rate...................................................................................................251
Test Control Buttons (on right of screen).........................................................................................251
PLLD Diagnostics - PLLD Status..........................................................................................................252
Report Column Descriptions ............................................................................................................252
PLLD Status - Refresh Rate.............................................................................................................253
Control Buttons (right of screen) ......................................................................................................253
PLLD Diagnostics - 3.0 gph (11.3lph) Test Results..............................................................................254

TLS-450 Setup and Operation Screens Manual
viii
Report Column Descriptions ............................................................................................................254
Control Buttons (right of screen) ......................................................................................................255
PLLD Diagnostics - Mid-Range Test Results.......................................................................................256
Report Column Descriptions ............................................................................................................256
Control Buttons (right of screen) ......................................................................................................257
PLLD Diagnostics - No-Vent Aborts .....................................................................................................258
Report Column Descriptions ............................................................................................................258
Control Buttons (right of screen) ......................................................................................................259
PLLD Diagnostics - 0.2 gph (0.76 lph) Test Results.............................................................................260
Report Column Descriptions ............................................................................................................260
Control Buttons (right of screen) ......................................................................................................261
PLLD Diagnostics - 0.1 gph (0.38lph) Test Results..............................................................................262
Report Column Descriptions ............................................................................................................262
Control Buttons (right of screen) ......................................................................................................263
Tank......................................................................................................................................................264
Tank Diagnostics - 30 Second Inventory Samples...............................................................................264
Report Column Descriptions ............................................................................................................264
30 Second Inventory Samples Refresh Rate...................................................................................265
Meter.....................................................................................................................................................266
Meter Diagnostics - Meter Events.........................................................................................................266
Control Button (Right side of Screen)...............................................................................................267
Meter Diagnostics - Tank Map..............................................................................................................268
Control Buttons (Right side of screen) .............................................................................................269
Meter Diagnostics - Manual Mapping...................................................................................................271
Report Column Descriptions ............................................................................................................271
Control Buttons (Right side of screen) .............................................................................................272
Reconciliation........................................................................................................................................273
Reconciliation Diagnostics - Status ......................................................................................................273
Report Column Description..............................................................................................................273
Control Buttons (on right side of screen)..........................................................................................274
Reconciliation Diagnostics - Reconciliation..........................................................................................275
Report Column Descriptions ............................................................................................................276
Control Buttons (on right side of screen)..........................................................................................277
Probe ....................................................................................................................................................278
Probe Diagnostics - General.................................................................................................................278
Report Column Descriptions ............................................................................................................278
Probe Diagnostics - General Screen Refresh Rate.........................................................................279
Control Button (right of screen)........................................................................................................279
Probe Diagnostics - Reference Distance..............................................................................................280
Report Column Descriptions ............................................................................................................280
Probe Diagnostics - Reference Distance Screen Refresh Rate ......................................................281
Control Buttons (right of screen) ......................................................................................................281
Probe Diagnostics - Channel................................................................................................................282
Report Description............................................................................................................................282
Probe Diagnostics Channel Refresh Rate .......................................................................................283
Control Button (right of screen)........................................................................................................283
Probe Diagnostics - Mag Options.........................................................................................................284
Report Column Descriptions ............................................................................................................284
Probe Diagnostics - Mag Options Screen Refresh Rate..................................................................285
Control Button (right of screen)........................................................................................................285
Probe Diagnostics - Communication....................................................................................................286
Report Column Descriptions ............................................................................................................286
Probe Diagnostics - Communication Refresh Rate..........................................................................287
Control Button (right of screen)........................................................................................................287
Relays & Inputs.....................................................................................................................................288
Relays and External Inputs Diagnostics - Relays.................................................................................288

TLS-450 Setup and Operation Screens Manual
ix
Column Descriptions ........................................................................................................................289
Control Buttons (right of screen) ......................................................................................................289
Sequential Testing Procedure..........................................................................................................289
Inspection Testing Procedure...........................................................................................................290
Relays and External Inputs Diagnostics - External Inputs....................................................................291
Report Column Descriptions ............................................................................................................291
External Input Diagnostic Screen Refresh Rate...............................................................................292
Control Button (right of screen)........................................................................................................292
Sensor...................................................................................................................................................293
Sensor Diagnostics - Liquid..................................................................................................................293
Report Column Descriptions ............................................................................................................293
Sensor Diagnostics Liquid Sensor Refresh Rate.............................................................................294
Control Button (right of screen)........................................................................................................294
Sensor Diagnostics - Vapor..................................................................................................................295
Report Column Descriptions ............................................................................................................295
Sensor Diagnostics Vapor Sensor Refresh Rate.............................................................................296
Control Button (right of screen)........................................................................................................296
Sensor Diagnostics - Groundwater.......................................................................................................297
Report Column Descriptions ............................................................................................................297
Sensor Diagnostics Groundwater Sensor Refresh Rate..................................................................298
Control Button (right of screen)........................................................................................................298
Sensor Diagnostics - 2-Wire CL ...........................................................................................................299
Report Column Descriptions ............................................................................................................299
Sensor Diagnostics 2-Wire CL Sensor Refresh Rate ......................................................................300
Control Button (right of screen)........................................................................................................300
Sensor Diagnostics - 3-Wire CL ...........................................................................................................301
Report Column Descriptions ............................................................................................................301
Sensor Diagnostics 3-Wire CL Sensor Refresh Rate ......................................................................302
Control Button (right of screen)........................................................................................................302
Mag Sensor...........................................................................................................................................303
Mag Sensor Diagnostics - General.......................................................................................................303
Report Column Descriptions ............................................................................................................303
Mag Sensor Diagnostics - General Screen Refresh Rate ...............................................................304
Control Button (right of screen)........................................................................................................304
Mag Sensor Diagnostics - Comm.........................................................................................................305
Report Column Descriptions ............................................................................................................305
Mag Sensor Diagnostics - Comm Screen Refresh Rate..................................................................306
Control Button (right of screen)........................................................................................................306
Mag Sensor Diagnostics - Constants...................................................................................................307
Report Column Descriptions ............................................................................................................307
Control Buttons (right of screen) ......................................................................................................308
Mag Sensor Diagnostics - Channel......................................................................................................309
Report Description............................................................................................................................309
Mag Sensor Diagnostics - Channel Screen Refresh Rate...............................................................310
Control Buttons (right of screen) ......................................................................................................310
Line Pressure Sensor...........................................................................................................................311
LPR Sensor Diagnostics - General.......................................................................................................311
Report Column Descriptions ............................................................................................................311
Diagnostics - LPR Sensor - General screen refresh rate.................................................................312
Control Buttons (right of screen) ......................................................................................................312
LPR Sensor Diagnostics - Communications.........................................................................................313
Report Column Descriptions ............................................................................................................313
Diagnostics - LPR Sensor - Comm screen refresh rate...................................................................314
Control Buttons (right of screen) ......................................................................................................314
LPR Sensor Diagnostics - Constants...................................................................................................315
Report Column Descriptions ............................................................................................................315

TLS-450 Setup and Operation Screens Manual
x
Control Buttons (right of screen) ......................................................................................................316
LPR Sensor Diagnostics - Channel......................................................................................................317
Report Description............................................................................................................................317
Diagnostics - Line Pressure Sensor - Channel screen refresh rate.................................................318
Control Buttons (right of screen) ......................................................................................................318
AccuChart II..........................................................................................................................................319
AccuChart II Diagnostics - Delivery Instructions...................................................................................319
Report Column Descriptions ............................................................................................................319
AccuChart II Diagnostics - Time Ordered Comparison ........................................................................320
Report Column Descriptions ............................................................................................................320
Control Buttons (Right side of screen) .............................................................................................321
AccuChart II Diagnostics - Histogram Comparison..............................................................................322
Control Buttons (Right side of screen) .............................................................................................322
AccuChart II Diagnostics - Error Plot Comparison ...............................................................................323
Control Buttons (Right side of screen) .............................................................................................323
AccuChart II Diagnostics - Calibration Feedback.................................................................................324
Report Column Descriptions ............................................................................................................324
AccuChart II Diagnostics - Data Sufficiency.........................................................................................326
Control Buttons (Right side of screen) .............................................................................................327
Modules ................................................................................................................................................328
Module Diagnostics - Hardware Configuration.....................................................................................328
Report Column Descriptions ............................................................................................................328
Module Diagnostics - Device Directory.................................................................................................330
Report Column Descriptions ............................................................................................................330
Module Diagnostics - Device Assignments ..........................................................................................331
Report Column Descriptions ............................................................................................................331
Module Diagnostics - Comm.................................................................................................................333
Report Column Descriptions ............................................................................................................333
Control Buttons (right of screen) ......................................................................................................334
Module Diagnostics - Firmware Upgrade.............................................................................................335
Report Column Descriptions ............................................................................................................335
Control Buttons (Right side of screen) .............................................................................................336
Software Maintenance..........................................................................................................................337
Connecting USB Thumb Drive for Software Maintenance Procedures................................................337
Software Maintenance - Backup Restore.............................................................................................340
Backup/Restore Screen Fields and Buttons ....................................................................................340
Software Maintenance - Download.......................................................................................................342
Download Procedure........................................................................................................................342
Download Screen Fields and Buttons..............................................................................................343
Control Buttons (Right Side of Screen)............................................................................................343
Software Maintenance - Install .............................................................................................................344
Installation Procedure.......................................................................................................................344
Install Screen Fields.........................................................................................................................345
Control Button (Right Side of Screen)..............................................................................................345
About.....................................................................................................................................................346
About - System Screen ....................................................................................................................346
SPECIALTY DIALOG SCREENS.........................................................................................................347
Alpha Keypad Dialog............................................................................................................................347
Enhanced Numeric Keypad Dialog.......................................................................................................348
Numeric Keypad Dialog........................................................................................................................349
Report Range Selection Dialogs...........................................................................................................350
PERIODIC MAINTENANCE CHECKLIST............................................................................................351
REFERENCES .....................................................................................................................................355
DIM Information Tables ........................................................................................................................355
Table of Acronyms................................................................................................................................358
Table of Alert Symbols..........................................................................................................................360

TLS-450 Setup and Operation Screens Manual
xi
Table of Device Identifiers....................................................................................................................361
Table of Module Device Identifiers.......................................................................................................362
Table of Standard Abbreviations..........................................................................................................362
Table of Unit Abbreviations...................................................................................................................363
Table of Unit Conversions ....................................................................................................................364
Table of Mag Probe Features...............................................................................................................364

TLS-450 Setup and Operation Screens Manual
1
INTRODUCTION
This manual details currently available setup, operation and diagnostic screens for the TLS-450
Console. Depending on your console type and its installed features, you may only see (and be able to
program) some of the screens and/or fields. Skip over the material in this document that does not apply
to your particular installation. You cannot perform these setup procedures until the console, probes, and
sensors have been installed and configured.
IMPORTANT! READ ALL SECTIONS OF THE INTRODUCTION BEFORE ATTEMPTING ANY
SETUP PROCEDURES.
Contractor Certification Requirements
Veeder-Root requires the following minimum training certifications for contractors who will install and
setup the equipment discussed in this manual:
Installer (Level 1) Certification: Certification: Contractors holding valid Installer Certification are
approved to perform wiring and conduit routing; equipment mounting; probe, sensor and carbon canister
vapor polisher installation; wireless equipment installation; tank and line preparation; and line leak
detector installation.
ATG Technician (Level 2/3 or 4) Certification: Contractors holding valid ATG Technician
Certifications are approved to perform installation checkout, startup, programming and operations
training, system tests, troubleshooting and servicing for all Veeder-Root Series Tank Monitoring Systems,
including Line Leak Detection. In addition, Contractors with the following sub-certification designations are
approved to perform installation checkout, startup, programming, system tests, troubleshooting, service
techniques and operations training on the designated system.
- Wireless 2
- Tall Tank
Warranty Registrations:
Warranty Registrations may only be submitted by selected Distributors.
Related Manuals
•TLS-450 Site Prep Manual (P/N 577013-879 )
•TLS-450 Setup, Operation Screens Manual (P/N 577013-940)
•TLS-450 Quick Help Guide (P/N 577013-969)
•Electronic Line Leak Detectors Application Guide (P/N 577013-465)
•TLS Consoles Point-of-Sale (POS) Application Guide (P/N 577013-401)
Safety Precautions
Safety and Alert Symbols are used throughout the help files to alert you to important system and safety
information. The table below explains symbols you may see when reading the setup and operation
instructions for this equipment.

TLS-450 Setup and Operation Screens Manual
2
Symbol
Definition
ELECTRICITY
High voltage exists in, and is supplied to, the device. A potential shock
hazard exists.
EXPLOSIVE
Fuels and their vapors are extremely explosive if ignited.
FLAMMABLE
Fuels and their vapors are extremely flammable.
TURN POWER OFF
Live power to a device creates a potential shock hazard. Turn Off power
to the device and associated accessories when servicing the unit.
WARNING
Heed the adjacent instructions to avoid equipment damage or personal
injury.
READ ALL RELATED MANUALS
Knowledge of all related procedures before you begin work is important.
Read and understand all manuals thoroughly. If you do not understand a
procedure, ask someone who does.
Safety Warnings
This system operates near highly combustible fuel storage tanks. Leaking tanks
can create serious environmental and health hazards.
If you have not been trained in proper service procedures and hazards involved,
refer all service to a qualified Veeder-Root Service Representative.
ATTEMPTING TO SERVICE TANK MONITORS AND EQUIPMENT WITHOUT
PROPER TRAINING CAN CAUSE DAMAGE TO PROPERTY, ENVIRONMENT,
RESULTING IN PERSONAL INJURY OR DEATH.
Improper programming and operation may result in equipment self-test failures
and submersible pump shutdowns. It is the owner's responsibility to:
1. Ensure that this equipment is properly programmed.
2. Promptly investigate any alarm conditions.
3. Operate this equipment in accordance with the instructions in this document.

TLS-450 Setup and Operation Screens Manual
3
Front Panel Layout
The TLS-450 Console front panel components are shown below:
Item 1 - Integral Printer
The integral printer is mounted in the left hand door of the console. The printer uses only V-R thermal
roll paper (P/N 514100-456) and it must be installed correctly so the thermal sensitive side faces the
print head. A red stripe will appear on the paper when it is time to change the roll.
Item 2 - System Visual Status LEDs
The check symbol is beneath a green LED. When the green LED is lit, there are no alarms active
(normal)
The exclamation symbol is beneath a yellow LED. When the yellow LED is lit, there is at least one
warning (minor) active.
The X symbol is beneath a red LED. When the red LED is lit, there is at least one alarm (major)
active.
Item 3 - Touch Screen
The TLS-450 graphical user interface is a touch sensitive screen providing quick access to operational
reports, setup parameters, diagnostic information for all configured devices (tanks, sensors, etc.) and
Online Help.

TLS-450 Setup and Operation Screens Manual
4
Navigating the Touch Screens
After power up, the TLS-450 displays the System Status - All Tanks (Home) screen (see figure below)
which contains system information and access to setup, reports, and diagnostics screens as defined in
the legend below the figure.
Area/Touch
Button
Action/Description
1
Date and Time area displays System Time and Date. Format for time and date is
configurable in the system setup area. This area is dynamic and will redraw to
update the date and time display twice per second.
2
Alarm Report button - When an alarm occurs, this button will flash and the console
beeper will activate. Touch this button once to display the Active Alarms Report
screen. Once the Active Alarms Report screen displays, review the alarm list, then
touch this button a second time to acknowledge the alarm(s), turn off the flashing
System Status box and silence the beeper.
Touch the Alarm Report button at any time to access all alarm reports:
- Active Alarms Report
- Alarm History Report - All Alarms
- Alarm History Report - Priority Alarms
- Alarm History Report - Non-Priority Alarms
3
System Status Box - The System Status box displays system alarm, warning and
notice messages. If there are no active or inactive alarms, the system status

TLS-450 Setup and Operation Screens Manual
5
Area/Touch
Button
Action/Description
message "All Functions Normal" is displayed. When an alarm occurs, the System
Status box will flash and display the alarm, warning or notice message. Once the
alarms have been acknowledged, the System Status box will no longer flash. The
alarm message will continue to display in the System Status box until the cause of
the alarm has been corrected. When more than one alarm is active, the alarm labels
will continuously scroll in the System Status box until they have been corrected.
4
Help button - Touching the Help button displays the console's online help topic for
the screen being viewed.
Touch the Table of Contents button in the upper left corner of the help screen
to open the online help table of contents in which you can navigate to any online
help topic.
5
Print button - Touching the Print button will print the contents of the data view area
to the printer designated as the default printer in Printer Setup. Nothing will print if
the view is empty or printing is not relevant to that screen. If the system has no
printer this button will be disabled.
6
Line-Feed button - Touching the Line Feed button will advance the printer paper
about one inch (25mm).
7
Home button - Touching the Home button returns you to the System Status - All
Tanks screen shown in the figure above.
8
Back button - Touching the Back button displays the previously viewed screen.
9
Setup button - Touching the Setup button displays the main System Setup Screen.
10
Diagnostic button - Touching the Diagnostic button displays the main Diagnostic
Screen.
11
Shift Close button - Touching the Shift Close button displays the Shift Close dialog
box in which you can choose to close the current shift for one or all tanks.
12
Scroll Up button - Touch the Scroll Up button to scroll upward through the contents
of the Data View area in batches that will fit in the data view area of the display. It
will be Enabled/Disabled based on Records or Data available for display.
13
Scroll Down button - Touch the Scroll Down scroll button to scroll downward
through the contents of the Data View area in Batches that will fit in the data view
area of the display. It will be Enabled/Disabled based on Records or Data available
for display.
14
Scroll Right button - When the number of data report columns or bottom row device
buttons is greater than can be shown at once, touch this button to scroll right to
access off-screen data/devices. This button will be disabled unless necessary.
15
Scroll Left button - When the number of data report columns or bottom row device
buttons is greater than can be shown at once, touch this button to scroll left to
access off-screen data/devices. This button will be disabled unless necessary.
16
BIR Report button - Touching this button accesses the following Reconciliation
Reports:
- Reconciliation Report
- Book Variance Report
- Reconciliation Test Report
17
Environmental Report button - Touching this button accesses the following
Environmental Reports:
- Combined Tank Test Report
- Static Leak Test Report
- Line Leak Test Report
- Sensor Status Report
- Sensor History Report

TLS-450 Setup and Operation Screens Manual
6
Area/Touch
Button
Action/Description
18
Delivery Report button - Touching this button accesses the following Delivery
Reports:
- Manual Delivery Report
- Adjusted Delivery Report
- Ticketed Delivery Report
19
Inventory Report button - Touching this button accesses the following Inventory
Reports:
- Current Inventory Report
- Inventory History Report
- Shift Inventory Report
- Shift Inventory History Report
20
Tab Screen buttons - Touching any of the Tab Screen buttons displays the related
screen:
- All Tanks current status screen
- All Sensors current status screen
- User Defined 1, 2, 3 (user configured) status screens
21
Title Bar - The title bar area will always be present and will provide text to help
identify the current screen in the Data View area. Information related to the name of
the screen, selected tab screen name, and specific device or object being displayed
will be present. The right side of the title bar contains additional title
information. Often this is the name or label of a selected item.
22
Data View area - The Data View area displays the requested report, setup fields,
etc.
Setup, Operation, Diagnostic Touch Screen Layout
The top button row of all console screens is shown below. The Date/time box on the left and the touch
buttons to the right are present across all screens.
When you are viewing Setup or Diagnostic screens, the buttons below the data view area will represent
the configured or active (communicating) devices (see example below for Tank Setup). You touch a
device's button and then access setup parameters or diagnostic information for that device (Tank 3 is
selected in the example below).

TLS-450 Setup and Operation Screens Manual
7
The data area displays the information associated with any selected setup, report or diagnostic screen.
Tabs at the top of the data area (All Tanks, All Sensors, User Defined 1, etc. in the diagram below), if
present, provide access to related data screens when touched.

TLS-450 Setup and Operation Screens Manual
8
Online Help Touch screen Layout
Touching the help (?) button at the top of any Setup, Report (Operation) or Diagnostic screen displays
the online help topic for that screen.
The help screen layout is shown below:
Item 1 - Online Help Table of Contents button
Touch this button to display the online help table of contents. When in the table of contents you can
scroll through it and select any topic for display.
Item 2 - Edit Help button
If this feature is enabled, you can touch this button to view/add your own text to the default text for any
selected help topic. Custom entered text will display at the top of the topic's default text. If this feature
is disabled, the Edit Help button will not be visible.
Item 3 - Print button
Touch this button to print the selected help topic on the optional console printer.
Item 4 - Close Help button
Touch this button to close the online help screen and return to the previously viewed console screen.

TLS-450 Setup and Operation Screens Manual
9
Entering Data
You enter setup parameters, confirm/cancel setup field entries, select reports, etc., using any one of a
variety of touch buttons, drop-down lists and specialty dialog boxes that are easy to understand and
use.
Changing/Editing Values in a Field
When you make an entry or change to a field on a screen, an asterisk (*) is displayed on the currently
viewed tab and beside the edited field (see star highlights in example below):
Touch the Check button to accept your entry/change or touch the Cancel button to undo
your entry/change.
If you try and leave the screen after editing a field, but before saving your change, a Save dialog box
will display, forcing you to either save or cancel your edit before leaving the screen.
