Vega Absolute Smart-MS0101 User manual

www.vega-absolute.ru
MOTION SENSOR
SMART-MS0101
User Manual
Infrared motion sensor Vega Smart-MS0101 is designed
to detect penetration into the protected area. The
sensor alternately operates in two modes: «Guard» and
«Neutral». Sends an alarm signal to the LoRaWAN™
network by the triggering.

Smart-MS0101 / User Manual
2
Revision №03 - 28.09.2018
Document Information
Title
Motion sensor Smart-MS0101
Document type
Manual –Translation from Russian
Document number
V05-MS0101-01
Revision and date
03 - 28.09.2018
This document applies to the following products:
Product name
Type number
Vega Smart
Vega Smart-MS0101
Revision History
Revision
Date
Name
Comments
01
08.12.2017
KEV
Document creation date
02
08.08.2018
KEV
Technical characteristics are added, new part is
added
03
28.09.2018
KEV
Typo at the communication protocol was fixed

Smart-MS0101 / User Manual
3
Revision №03 - 28.09.2018
CONTENTS
INTRODUCTION............................................................................................................................................................................4
1 DESCRIPTION AND OPERATION ............................................................................................................................................5
2 SPECIFICATION ..........................................................................................................................................................................6
3 OPERATION ................................................................................................................................................................................7
Indication ....................................................................................................................................................................................7
Initial startup...............................................................................................................................................................................8
Sensor mounting recommendations ..................................................................................................................................10
Connecting via USB ................................................................................................................................................................11
4 VEGA LORAWAN CONFIGURATOR......................................................................................................................................13
Interface of the application...................................................................................................................................................13
Connection to the device......................................................................................................................................................14
“Device info” tab......................................................................................................................................................................15
“LoRaWAN settings” tab .........................................................................................................................................................16
“Smart-MS0101” tab................................................................................................................................................................21
5 COMMUNICATION PROTOCOL ...........................................................................................................................................22
SMART-MS0101 transmits the following types of packets .............................................................................................22
6 STORAGE AND TRANSPORTATION REQUIREMENTS ......................................................................................................23
7 CONTENT OF THE PACKAGE ................................................................................................................................................24
8 WARRANTY................................................................................................................................................................................25

Smart-MS0101 / User Manual
4
Revision №03 - 28.09.2018
INTRODUCTION
This manual is designated for Vega Smart-MS0101 motion sensor (hereinafter –device,
sensor) manufactured by Vega-Absolute LLC and provides information on powering and
activation procedure, control commands and functions of the device.
This manual is targeted at specialists familiar with installation work fundamentals for
electronic and electrical equipment.
The device shall be installed and adjusted by qualified specialists in order
to ensure proper operation of the device

Smart-MS0101 / User Manual
5
Revision №03 - 28.09.2018
1 DESCRIPTION AND OPERATION
Infrared motion sensor Vega Smart-MS0101 is designed to detect penetration into the
protected area.
The sensor alternately operates in two modes: «Guard» and «Neutral». In the «Guard»
mode, the device sends an alarm message to the LoRaWAN™ network when motion is
detected, after which it switches to the «Neutral» mode for a while. In the «Neutral» mode, the
sensor does not send alarm messages when motion is detected. If the movement in the
protected area has ceased, then the device switches back to the «Guard» mode after a certain
configurable period of time.
Auto-post time interval is setting up by the «Vega LoRaWAN configurator»application
and may vary from 1 to 60 minutes.
Vega Smart-MS0101 can be used to protect premises, buildings and structures, as well as
in Smart Home systems, built on LoRaWAN™ technology.
The sensor is powered by a CR123A 1400 mAh replaceable battery.
The sensor is configured via USB with special software «Vega LoRaWAN configurator».
Information for registering of the device in the LoRaWAN™ network is available via
software «Vega LoRaWAN configurator».

Smart-MS0101 / User Manual
6
Revision №03 - 28.09.2018
2 SPECIFICATION
Main
USB-port
yes
Operating temperatures
-40…+70 °С
Maximum detection range
not less than 15 m
Range of velocities of the intruder
0.3…3 m/s
Sensor mounting height
2.1 m
Angle of the sensor in the vertical plane
6°
Resistance to external light
6500 lux
Built-in temperature sensor
yes
LoRaWAN™
LoRaWAN™ class
A
Quantity of LoRa channels
16
Frequency band
EU-868, RU-868, custom
Activation type
ABP or OTAA
Communication period
1, 6, 12 or 24 hours
Antenna
internal
Sensitivity
-138 dBm
Radio coverage in restrained urban conditions
max 5 km
Radio coverage within line of sight
max 15 km
Power output
up to 100 mW (configurable)
Power
Replaceable battery
CR123A 3V, 1400 mAh
Case
Housing dimensions
35 х 50 х 70 mm
Ingress protection rating
IP41
Vega Smart-MS0101 motion sensor is class A device (LoRaWAN™ classification) and has
the following features:
oADR support (Adaptive Data Rate)
oSending of confirmed packets (configurable)
oExtra communication in case of alarm event
oTwo working modes “Neutral” and “Guard”
oTemperature measurement by the internal temperature sensor
oBattery charge measurment (%)
oSensitivity: up to -138dBm

Smart-MS0101 / User Manual
7
Revision №03 - 28.09.2018
3 OPERATION
INDICATION
A double color indicator is located on the front of the sensor case and it flashes red when
detect motion in the protected area but no more than one at 10 seconds.
One more indicator is located on the board and it shown only when cover off and displays
a linking to the network state.
Indicator signal
Meaning
A series of short red flashes
Linking to the network
One long red flash
The device switched to the “Storage” mode
Indicator on the
front of the device
case
Indicator on the
device case
Indicator on the
board

Smart-MS0101 / User Manual
8
Revision №03 - 28.09.2018
INITIAL STARTUP
Motion sensor is powered by the CR123A 3V 1400 mAh replaceable battery. You need to
insert the battery observing the polarity before start.
The sensor supports two activation methods in the LoRaWAN™ network - ABP and OTAA.
Select one of the methods using “Vega LoRaWAN Configurator” application (See part 4).
1. ABP. After pressing the start button, the device immediately starts working in the "Active"
mode.
Вставить
батарейку CR123А
в батарейный
отсек
Нажать кнопку
запуска,
расположенную
на плате

Smart-MS0101 / User Manual
9
Revision №03 - 28.09.2018
2. OTAA. After pressing the start button, the device makes three attempts to connect to
the network within the set frequency band. After the activation request is confirmed by
LoRaWAN™ network, the device sends a signal and switches to the "Active" mode. If all attempts
fail, the sensor switches to the “Storage” mode.
To manually switch the device from the "Active" mode to the "Storage" mode, you can
use the long press of the start button (more than 5 seconds).
Before connecting the device, make sure that its registration data is
entered in the network - Device EUI, Application EUI and Application
Key for OTAA, or Device address, Application session key and Network
session key for ABP

Smart-MS0101 / User Manual
10
Revision №03 - 28.09.2018
SENSOR MOUNTING RECOMMENDATIONS
The sensor must be installed in such a way that the probable penetration paths of the
intruder cross the central axis of the detection zone.
Recommended mounting height of the sensor is 2…2,5 m.
Do not install the sensor near objects that are powerful sources of heat or have the ability
to quickly change their temperature (fireplaces, stoves, air conditioners, radiators, etc.), in places
with strong air currents or the possibility of direct sunlight.
The wall on which the sensor is mounted should not be subjected to strong vibrations.
The presence in the detection zone of objects (curtains, screens, large objects, furniture,
plants, etc.) creates behind them "dead zones", the detection of the offender behind these
objects may not occur.

Smart-MS0101 / User Manual
11
Revision №03 - 28.09.2018
CONNECTING VIA USB
The device Smart-MS0101 can be configured with the "Vega LoRaWAN Configurator"
application (See part 4).
Before connecting the device to the computer for the first time, you must install the driver
for the COM port stsw-stm32102, which can be downloaded from iotvega.com. After running
the executable file VCP_V1.4.0_Setup.exe, the installer window will appear:
micro-USB

Smart-MS0101 / User Manual
12
Revision №03 - 28.09.2018
In this window, you need to click Next, then Install, and then the installation will begin.
When the installation is completed successfully, the following screen appears:
After pressing Finish the driver is ready for operation, - it is possible to connect the
device via USB.

Smart-MS0101 / User Manual
13
Revision №03 - 28.09.2018
4 VEGA LORAWAN CONFIGURATOR
The "Vega LoRaWAN Configurator" application (hereinafter referred to as the
configurator) is intended for setting up the device via USB.
The configurator has two modes of operation - "Simple" and "Expert". In the "Simple"
mode, only basic settings are available. In the "Expert" mode the basic settings, advanced settings
and the ability to check the coverage area of the signal from the gateways are available. Next,
the work of the configurator is considered in the “Expert”mode.
INTERFACE OF THE APPLICATION
The "Vega LoRaWAN Configurator" application does not require the special installation.
When the executable file is launched, the window for working with the application appears (See
Fig. 4.1).
Fig. 4.1. The «Vega LoRaWAN Configurator»application interface.
The menu on the left allows you to switch between the “Simple”and “Expert”modes,
select the device model, connect to the device or disconnect from it, get and apply settings.
The application window contains three tabs –Device info, LoRaWAN™ settings and
device settings.

Smart-MS0101 / User Manual
14
Revision №03 - 28.09.2018
The language selection menu is in the upper right corner.
CONNECTION TO THE DEVICE
For the connection to the device, perform the following steps:
1. Connect the USB cable to the device.
2. Start the "Vega LoRaWAN Configurator" application.
3. Click the "Connect" button in the menu on the left.
The configurator automatically recognizes the type of device, and the device selection
menu becomes inactive.
Fig. 4.2. Connection to the device.
To read the settings from the device, you need to click the "Get settings" button, until this
point the application will display the default settings or from the last connected device.
After making the necessary changes to the settings, you should click the "Apply settings"
button and only then disconnect from the device with the "Disconnect" button.

Smart-MS0101 / User Manual
15
Revision №03 - 28.09.2018
“DEVICE INFO” TAB
The "Device info" tab displays information about the device, its current status, and also the
data needed to register the device in the LoRaWAN™ network (Fig. 4.3).
Fig. 4.3. The “Device info” tab.
ABP info - displays the data necessary to register the device in the LoRaWAN™ network
with ABP method (Activation By Personalization).
OTAA info - the data required to register the device in the LoRaWAN™ network with OTAA
method (Over The Air Activation) is displayed.
Regional info (not displayed in the "Simple" mode) - shows the frequencies of the JOIN
channels and the second receiving window. These frequencies can be changed in the
"LoRaWAN™ Settings" tab when selecting a frequency plan.
Device info - the configurator reads information about the device model, its firmware and
automatically corrects the device's time when connected to it.
Update firmware - allows you to select the firmware file from your computer's hard drive
and load it into the device. The device will automatically disconnect from the configurator when

Smart-MS0101 / User Manual
16
Revision №03 - 28.09.2018
the download is complete. The current version of the device firmware can be downloaded from
iotvega.com.
Network info - shows whether the device is connected to the LoRaWAN™ network and
its network address.
Join network button - launch the LoRaWAN™ network connection procedure with the
previously selected ABP or OTAA method. If the device is already connected to the network,
reconnection procedure will occurs.
Link check (not displayed in the "Simple" mode) - when pressed, the device sends a special
signal to the LoRaWAN™ network, in response to which the network informs it of the number
of gateways that received this signal and the signal quality. This button only works when the
device is connected to the network.
Device output (not displayed in the "Simple" mode) - monitoring the device status, all
events in real time are displayed.
“LORAWAN SETTINGS” TAB
The "LoRaWAN Settings" tab allows you to configure various parameters of the LoRa
network (Fig. 4.4).
Fig. 4.4. “LoRaWAN settings” tab.
Region - allows you to select RU-868, EU-868 or specify a custom frequency band.

Smart-MS0101 / User Manual
17
Revision №03 - 28.09.2018
The sensor Smart-MS0101 supports the following frequency bands:
Frequency band
Channel
Frequency
Modulation
EU-868
1
868.1
MultiSF 125 kHz
2
868.3
MultiSF 125 kHz
3
868.5
MultiSF 125 kHz
RX2
869.525
SF12 125 kHz
RU-868
1
864.5
MultiSF 125 kHz
2
864.7
MultiSF 125 kHz
3
864.9
MultiSF 125 kHz
RX2
869.05
SF12 125 kHz
Custom
Set with «Vega LoRaWAN Configurator»application
In the EU_868 and RU_868 frequency bands, only 3 channels are active by default. The
device sends requests for connection to the network on this "join" channels. The remaining
channels that the device should use can be transferred by the LoRaWAN™ network server during
the device activation procedure (only OTAA).
If you select "Custom" in the "Region" field, you must manually specify the frequencies
that the device will use. To do this, click the "Edit" button, the channel frequency editing window
will appear:

Smart-MS0101 / User Manual
18
Revision №03 - 28.09.2018
This frequency band allows you to set up to 16 channels, as well as the frequency and
speed of the second receiving window.
The first three channels and the second receiving window parameters
are mandatory. Without these parameters the custom frequency band
will be considered empty.
Activation type –selecting ABP or OTAA device activation method.
Confirmed uplinks –when you choose "confirmed", the device will retry sending the
packet until it receives the server confirmation, or until the "Uplink number of transmission" is
over (see below).
ADR –this option activates the Adaptive Data Rate algorithm for automatic control of the
data transfer rate from the LoRaWAN™ network side. The higher the quality of the signal
received by the network, the higher the speed will be installed on the device. This option is
recommended only on permanently installed devices.
RX1 offset (not displayed in the "Simple" mode) –specifies the time between end of packet
transmission and first receiving window opening. The second receiving window always opens
after 1 second after the first.

Smart-MS0101 / User Manual
19
Revision №03 - 28.09.2018
Join accept delay 1 (not displayed in the "Simple" mode) –sets the time that the device
will open the first receiving window to receive confirmation for the join request from the
LoRaWAN™ network. The second window always opens after 1 second after the first.
Uplink number of transmission (not displayed in the "Simple" mode) –if the "Confirmed
uplinks" function is disabled, the device will simply send each packet as many times as specified
in this option. If "Confirmed uplinks" is enabled, the device will send packets until it receives a
confirmation or until it sends as many packets as specified in this option.

Smart-MS0101 / User Manual
20
Revision №03 - 28.09.2018
TX power (not displayed in the "Simple" mode) –the device RF transmitter power is
adjusted to this value when sending packets to the LoRaWAN™ network. This option can be
changed by the network server.
TX datarate (not displayed in the "Simple" mode) –the device transmission datarate at
which it will transfer packets to the LoRaWAN™ network. This speed can be changed by the
network server if the ADR algorithm is enabled.
