Vega Absolute Smart-MS0101 User manual

www.vega-absolute.ru
MOTION SENSOR
SMART-MS0101
User Manual
Infrared motion sensor Vega Smart-MS0101 is designed
to detect penetration into the protected area. The
sensor alternately operates in two modes: «Guard» and
«Neutral». Sends an alarm signal to the LoRaWAN™
network by the triggering.

Smart-MS0101 / User Manual
2
Revision №07 - 03 October 2019
Document Information
Title
Motion sensor Smart-MS0101
Document type
Manual –Translation from Russian
Document number
V05-MS0101-01
Revision and date
08 –03 October 2019
This document applies to the following products:
Product name
Type number
Vega Smart
Vega Smart-MS0101
Revision History
Revision
Date
Name
Comments
01
08.12.2017
KEV
Document creation date
02
08.08.2018
KEV
Technical characteristics are added, new part is added
03
28.09.2018
KEV
Typo at the communication protocol was fixed
04
22.01.2019
KEV
Communication protocol changed, setting via ‘air’
described.
Frequency plans added, specification changed, warranty
changed, configurator updated.
“Marking” part added, “Indication” part changed
05
24.01.2019
KEV
Inaccuracy in communication protocol fixed –packet
type for packets with settings and request of settings
06
17.06.2019
KEV
Inaccuracy in the table of settings fixed –setting 43 is 1-
byte size
07
15.08.2019
KEV
Added new functionality’s description, it’s a sending
message when the device arming
08
03.10.2019
KEV
Fixed an error in the device arming setting, p.27

Smart-MS0101 / User Manual
3
Revision №07 - 03 October 2019
CONTENTS
INTRODUCTION.........................................................................................................................................................................4
1 DESCRIPTION AND OPERATION .........................................................................................................................................5
Device description .................................................................................................................................................................5
Comunication and data collection algorithm ..................................................................................................................6
Functional ................................................................................................................................................................................6
Marking.....................................................................................................................................................................................6
2 SPECIFICATION .......................................................................................................................................................................8
3 OPERATION..............................................................................................................................................................................9
Indication .................................................................................................................................................................................9
Initial startup..........................................................................................................................................................................10
Sensor mounting recommendations ...............................................................................................................................12
Connecting via USB .............................................................................................................................................................13
4 VEGA LORAWAN CONFIGURATOR...................................................................................................................................15
Interface of the application ................................................................................................................................................15
Connection to the device...................................................................................................................................................16
“Device info” tab ...................................................................................................................................................................17
“LoRaWAN settings” tab ......................................................................................................................................................19
“Smart-MS0101” tab.............................................................................................................................................................23
5 COMMUNICATION PROTOCOL ........................................................................................................................................24
SMART-MS0101 transmits the following types of packets ..........................................................................................24
SMART-MS0101 transmits the following types of packets ..........................................................................................26
6 STORAGE AND TRANSPORTATION REQUIREMENTS ...................................................................................................28
7 CONTENT OF THE PACKAGE .............................................................................................................................................29
8 WARRANTY.............................................................................................................................................................................30

Smart-MS0101 / User Manual
4
Revision №07 - 03 October 2019
INTRODUCTION
This manual is designated for Vega Smart-MS0101 motion sensor (hereinafter –device,
sensor) manufactured by Vega-Absolute LLC and provides information on powering and
activation procedure, control commands and functions of the device.
This manual is targeted at specialists familiar with installation work fundamentals for
electronic and electrical equipment.
To provide the stable radio between the gateway and the end device it
is recommend avoiding the device installation in the places which are
barriers for the radio signal getting through like a reinforced floors and
walls, a basement, an underground facilities and wells, a metal case
etc.
The necessary stage for the network deploying including a big quantity
of end devices is a radio planning work with nature experiments

Smart-MS0101 / User Manual
5
Revision №07 - 03 October 2019
1 DESCRIPTION AND OPERATION
DEVICE DESCRIPTION
Infrared motion sensor Vega Smart-MS0101 is designed to detect penetration into the
protected area.
The sensor alternately operates in two modes: «Guard» and «Neutral». In the «Guard»
mode, the device sends an alarm message to the LoRaWAN™ network when motion is
detected, after which it switches to the «Neutral» mode for a while. In the «Neutral» mode,
the sensor does not send alarm messages when motion is detected.
If the movement in the protected area has ceased, then the device switches back to the
«Guard» mode after a certain configurable period. There is an option of message sending
when the device switched to the “Guard” mode (configurable through the «Vega LoRaWAN
Configurator»)
The device arming time interval is setting up by the «Vega LoRaWAN Configurator»
application and may vary from 1 to 60 minutes.
Vega Smart-MS0101 can be used to protect premises, buildings and structures, as well
as in Smart Home systems, built on LoRaWAN™ technology.
The sensor is powered by a CR123A 1400 mAh replaceable battery.
The adjustable data transfer period can be from 5 minutes to 24 hours. Data
transferring in random point in time during set period.
The internal clock is set automatically when device connected to the "Vega LoRaWAN
Configurator" via USB.

Smart-MS0101 / User Manual
6
Revision №07 - 03 October 2019
COMUNICATION AND DATA COLLECTION ALGORITHM
The device forming a data packet with a configurable period from 5 minutes to 24
hours. The data saving in device memory and transmitting during the next communication
session with the LoRaWAN network.
If there is no alarm mode, then data transferring in random point in time during set
period. At the next communication session, the device starts sending accumulated packets
with readings, from the earliest to the latest.
When alarm situation appears, the device forming alarm packet and transferring it
immediately.
With the "Confirmed uplinks" option turned on, the device will send the next packet
only after receiving a confirmation of the delivery of the previous one. If such confirmation
has not received after the fulfilled in the settings uplink number of transmissions, device
completes the communication session until the next one according to the schedule. In this
case, the device continues to form packets according to the communication period and store
it in memory. Non-transmitted packets remain in the device memory until the next
communication session.
With the "Confirmed uplinks" option turned off, the device just sends all accumulated
packets to the network in order from the earliest to the latest. There are no checks of package
delivery in this mode. There are no non-transmitted messages in the device memory.
The internal clock is set automatically when device connected to the "Vega LoRaWAN
Configurator" via USB, also adjustable via LoRaWAN.
FUNCTIONAL
Vega Smart-MS0101 motion sensor is class A device (LoRaWAN™ classification) and
has the following features:
oADR support (Adaptive Data Rate)
oSending of confirmed packets (configurable)
oExtra communication in case of alarm event
oMessage sending when the device arming
oTwo working modes “Neutral” and “Guard”
oTemperature measurement by the internal temperature sensor
oBattery charge measurment (%)
oSensitivity: up to -138dBm
MARKING
Device marked with sticker that contain the next information:
oDevice model;

Smart-MS0101 / User Manual
7
Revision №07 - 03 October 2019
oDevEUI;
oMonth and year of manufacture;
oQR-code containing DevEUI for automatized count.
Sticker located in three places –on device case, in factory certificate and on the packing
box.
Besides, there is an additional sticker located on the packing box and contains:
oInformation about firmware version;
oQR-code containing DevEUI and keys for device registration in network via OTAA
method.

Smart-MS0101 / User Manual
8
Revision №07 - 03 October 2019
2 SPECIFICATION
Main
USB-port
mini-USB, type B
Operating temperatures
-40…+70 °С
Maximum detection range
not less than 15 m
Range of velocities of the intruder
0.3…3 m/s
Sensor mounting height
2.1 m
Angle of the sensor in the vertical plane
6°
Resistance to external light
6500 lux
Built-in temperature sensor
yes
LoRaWAN™
AppEui by default
766567616D733031
LoRaWAN™ class
A
Quantity of LoRa channels
16
Frequency plan
RU868, EU868, IN865, AS923, AU915,
KR920, US915, KZ865, custom (EU868
based)
Activation type
ABP or OTAA
Communication period
5, 15, 30 minutes, 1, 6, 12 or 24 hours
Memory amount for storing packets
200 packets
Antenna
internal
Sensitivity
-138 dBm
Radio coverage in restrained urban conditions
max 5 km
Radio coverage within line of sight
max 15 km
Transmitter power by default
25 mW (configurable)
Maximum transmitter power
100 mW
Power
Replaceable battery
CR123A 3V, 1400 mAh
Warranty number of packets sent by the device,
not less
15 000
Case
Housing dimensions
35 х 50 х 70 mm
Ingress protection rating
IP41

Smart-MS0101 / User Manual
9
Revision №07 - 03 October 2019
3 OPERATION
INDICATION
A double color indicator is located on the front of the sensor case and it flashes red when
detect motion in the protected area.
One more indicator is located on the board and it shown only when cover off and
displays a linking to the network state.
Indicator on the
front of the device
case
Indicator on the
device case
Indicator on the
board

Smart-MS0101 / User Manual
10
Revision №07 - 03 October 2019
LED signal
Meaning
Series of short flashings
Linking to the network
One long flashing
The device connected to the network
and is in active mode
Three long flashings
Linking to the network is unsuccessful
or the device switched to the
«Storage»mode
In case of connection attempt fail, the device will continue to accumulate
data and will attempt to connect to the network every 6 hours
INITIAL STARTUP
Motion sensor is powered by the CR123A 3V 1400 mAh replaceable battery. You need
to insert the battery observing the polarity before start.
The sensor supports two activation methods in the LoRaWAN™ network - ABP and
OTAA. Select one of the methods using “Vega LoRaWAN Configurator” application (See part 4).
1. ABP. After pressing the start button, the device immediately starts working in the
"Active" mode.
Place the CR123A
battery in the
battery
compartment

Smart-MS0101 / User Manual
11
Revision №07 - 03 October 2019
2. OTAA. After pressing the start button, the device makes three attempts to connect to
the network within the set frequency plan. After the activation request is confirmed by
LoRaWAN™ network, the device sends a signal and switches to the "Active" mode. If all
attempts fail, the sensor will continue to accumulate data and will attempt to connect to the
network every 6 hours.
To manually switch the device from the "Active" mode to the "Storage" mode, you can
use the long press of the start button (more than 5 seconds).
Before connecting the device, make sure that its registration data is
entered in the network - Device EUI, Application EUI and Application
Key for OTAA, or Device address, Application session key and Network
session key for ABP
Press the start
button located on
the board

Smart-MS0101 / User Manual
12
Revision №07 - 03 October 2019
SENSOR MOUNTING RECOMMENDATIONS
The sensor must be installed in such a way that the probable penetration paths of the
intruder cross the central axis of the detection zone.
Recommended mounting height of the sensor is 2…2,5 m.
Do not install the sensor near objects that are powerful sources of heat or having the
ability to quickly change their temperature (fireplaces, stoves, air conditioners, radiators, etc.),
in places with strong air currents or the possibility of direct sunlight.
The wall on which the sensor is mounted should not be subjected to strong vibrations.
The presence in the detection zone of objects (curtains, screens, large objects, furniture,
plants, etc.) creates behind them "dead zones", the detection of the offender behind these
objects may not occur.

Smart-MS0101 / User Manual
13
Revision №07 - 03 October 2019
CONNECTING VIA USB
The device Smart-MS0101 can be configured with the "Vega LoRaWAN Configurator"
application (See part 4).
Before connecting the device to the computer for the first time, you must install the
driver for the COM port stsw-stm32102, which can be downloaded from iotvega.com. After
running the executable file VCP_V1.4.0_Setup.exe, the installer window will appear:
mini-USB

Smart-MS0101 / User Manual
14
Revision №07 - 03 October 2019
In this window, you need to click Next, then Install, and then the installation will begin.
When the installation is completed successfully, the following screen appears:
After pressing Finish the driver is ready for operation, - it is possible to connect the
device via USB.

Smart-MS0101 / User Manual
15
Revision №07 - 03 October 2019
4 VEGA LORAWAN CONFIGURATOR
The "Vega LoRaWAN Configurator" application (hereinafter referred to as the
configurator) is intended for setting up the device via USB.
The configurator has two modes of operation - "Simple" and "Expert". In the "Simple"
mode, only basic settings are available. In the "Expert" mode the basic settings, advanced
settings and the ability to check the coverage area of the signal from the gateways are available.
Next, the work of the configurator is considered in the “Expert”mode.
INTERFACE OF THE APPLICATION
The "Vega LoRaWAN Configurator" application does not require the special installation.
When the executable file is launched, the window for working with the application appears.
The menu on the left allows you to switch between the “Simple”and “Expert”modes,
select the device model, connect to the device or disconnect from it, get and apply settings.
The application window contains three tabs –Device info, LoRaWAN™ settings and
device settings.
The language selection menu is in the upper right corner.

Smart-MS0101 / User Manual
16
Revision №07 - 03 October 2019
CONNECTION TO THE DEVICE
For the connection to the device, perform the following steps:
1. Connect the USB cable to the device.
2. Start the "Vega LoRaWAN Configurator" application.
3. Click the "Connect" button in the menu on the left.
The configurator automatically recognizes the type of device, and the device selection
menu becomes inactive.
To read the settings from the device, you need to click the "Get settings" button, until
this point the application will display the default settings or from the last connected device.
After making the necessary changes to the settings, you should click the "Apply settings"
button and only then disconnect from the device with the "Disconnect" button.

Smart-MS0101 / User Manual
17
Revision №07 - 03 October 2019
“DEVICE INFO” TAB
The "Device info" tab displays information about the device, its current status, and also
the data needed to register the device in the LoRaWAN™ network.
ABP info - displays the data necessary to register the device in the LoRaWAN™ network
with ABP method (Activation By Personalization).
OTAA info - the data required to register the device in the LoRaWAN™ network with
OTAA method (Over The Air Activation) is displayed.
Key management (not displayed in the "Simple" mode) - allows you to change the factory
keys to register the device on the network, and reset the keys back to the factory settings.
Device info - the configurator reads information about the device model, its firmware
and automatically corrects the device's time when connected to it.
Update firmware - allows you to select the firmware file from your computer's hard drive
and load it into the device. The device will automatically disconnect from the configurator
when the download is complete. The current version of the device firmware can be
downloaded from iotvega.com.
Network info - shows whether the device is connected to the LoRaWAN™ network and
its network address.
Join network button - launch the LoRaWAN™ network connection procedure with the
previously selected ABP or OTAA method. If the device is already connected to the network,
reconnection procedure will occurs.
Link check (not displayed in the "Simple" mode) - when pressed, the device sends a
special signal to the LoRaWAN™ network, in response to which the network informs it of the

Smart-MS0101 / User Manual
18
Revision №07 - 03 October 2019
number of gateways that received this signal and the signal quality. This button only works
when the device is connected to the network.
Device output (not displayed in the "Simple" mode) - monitoring the device status, all
events in real time are displayed.

Smart-MS0101 / User Manual
19
Revision №07 - 03 October 2019
“LORAWAN SETTINGS” TAB
The "LoRaWAN Settings" tab allows you to configure various parameters of the LoRa
network.
Region - allows you to select one of installed frequency plans or specify a custom
frequency plan. Custom frequency plan is EU-868 based.
In the device frequency plan, only those channels are active by default, on which
sending requests for connection to the network (join channels). The remaining channels (that
the device should use) can be transferring by the LoRaWAN network server during the device
activation procedure (only OTAA).
If you select "Custom" in the "Region" field, you must manually specify the frequencies
that the device will use. To do this, click the "Edit" button, the channel frequency editing
window will appear:

Smart-MS0101 / User Manual
20
Revision №07 - 03 October 2019
This frequency plan allows you to set up to 16 channels, as well as the frequency and
speed of the second receiving window.
The first three channels and the second receiving window parameters
are mandatory. Without these parameters the custom frequency plan
will be considered empty.
Activation type –selecting ABP or OTAA device activation method.
Confirmed uplinks –when you choose "confirmed", the device will retry sending the
packet until it receives the server confirmation, or until the "Uplink number of transmission" is
over (see below).
If you choose to send packets without confirmation, the modem will
not know whether the packet delivered or not
ADR –this option activates the Adaptive Data Rate algorithm for automatic control of
the data transfer rate from the LoRaWAN™ network server side. The higher the quality of the
signal received by the network, the higher the speed will be installed on the device. This option
is recommended only on permanently installed devices.
