Vega VEGATOR 122 User manual

Operating Instructions
Double channel signal conditioning
instrument for level detection for 8/16 mA
sensors
VEGATOR 122
Document ID: 46108

2
Contents
VEGATOR 122 •
46108-EN-170907
Contents
1 About this document ............................................................................................................... 4
1.1 Function ........................................................................................................................... 4
1.2 Target group ..................................................................................................................... 4
1.3 Symbols used................................................................................................................... 4
2 For your safety ......................................................................................................................... 5
2.1 Authorised personnel ....................................................................................................... 5
2.2 Appropriate use................................................................................................................ 5
2.3 Warning about incorrect use............................................................................................. 5
2.4 General safety instructions............................................................................................... 5
2.5 EU conformity................................................................................................................... 6
2.6 Safety label on the instrument .......................................................................................... 6
2.7 SIL conformity (optional) .................................................................................................. 6
2.8 Installation and operation in the USA and Canada ........................................................... 6
2.9 Safety instructions for Ex areas ........................................................................................ 6
2.10 Environmental instructions ............................................................................................... 6
3 Product description ................................................................................................................. 7
3.1 Conguration.................................................................................................................... 7
3.2 Principle of operation........................................................................................................ 7
3.3 Adjustment ....................................................................................................................... 8
3.4 Packaging, transport and storage..................................................................................... 8
4 Mounting................................................................................................................................... 9
4.1 Mounting instructions ....................................................................................................... 9
5 Connecting to power supply................................................................................................. 10
5.1 Preparing the connection ............................................................................................... 10
5.2 Connection procedure.................................................................................................... 11
5.3 Wiring plan ..................................................................................................................... 12
6 Setup ....................................................................................................................................... 13
6.1 Adjustment system......................................................................................................... 13
6.2 Adjustment elements...................................................................................................... 13
6.3 Function table "Point level" ............................................................................................. 16
6.4 Function table, two-point control..................................................................................... 17
7 Maintenanceandfaultrectication...................................................................................... 19
7.1 Maintenance .................................................................................................................. 19
7.2 Rectify faults................................................................................................................... 19
7.3 How to proceed if a repair is necessary.......................................................................... 20
8 Dismount................................................................................................................................. 21
8.1 Dismounting steps.......................................................................................................... 21
8.2 Disposal ......................................................................................................................... 21
9 Supplement ............................................................................................................................ 22
9.1 Technical data ................................................................................................................ 22
9.2 Dimensions .................................................................................................................... 24
9.3 Industrial property rights................................................................................................. 25
9.4 Trademark ...................................................................................................................... 25

3
Contents
VEGATOR 122 •
46108-EN-170907
Supplementary documentation
Information:
Supplementary documents appropriate to the ordered version come
withthedelivery.Youcanndthemlistedinchapter"Product descrip-
tion".
Editing status: 2017-09-04

4
1 About this document
VEGATOR 122 •
46108-EN-170907
1 About this document
1.1 Function
This operating instructions manual provides all the information you
need for mounting, connection and setup of the instrument. Further-
morethereareimportantinstructionsformaintenance,faultrectica-
tion, the exchange of parts and the safety of the user. Please read this
information before putting the instrument into operation and keep this
manual accessible in the immediate vicinity of the device.
1.2 Target group
This operating instructions manual is directed to trained specialist
personnel.The contents of this manual should be made available to
these personnel and put into practice by them.
1.3 Symbols used
Information, tip, note
This symbol indicates helpful additional information.
Caution: If this warning is ignored, faults or malfunctions can result.
Warning: If this warning is ignored, injury to persons and/or serious
damage to the instrument can result.
Danger: If this warning is ignored, serious injury to persons and/or
destruction of the instrument can result.
Ex applications
This symbol indicates special instructions for Ex applications.
SIL applications
This symbol indicates instructions for functional safety which must be
taken into account particularly for safety-relevant applications.
• List
The dot set in front indicates a list with no implied sequence.
→ Action
This arrow indicates a single action.
1 Sequence of actions
Numbers set in front indicate successive steps in a procedure.
Battery disposal
This symbol indicates special information about the disposal of bat-
teries and accumulators.

5
2 For your safety
VEGATOR 122 •
46108-EN-170907
2 For your safety
2.1 Authorised personnel
All operations described in this operating instructions manual must
be carried out only by trained specialist personnel authorised by the
plant operator.
During work on and with the device the required personal protective
equipment must always be worn.
2.2 Appropriate use
VEGATOR 122 is a universal signal conditioning instrument for con-
nection of level switches.
Youcannddetailedinformationabouttheareaofapplicationin
chapter "Product description".
Operational reliability is ensured only if the instrument is properly
usedaccordingtothespecicationsintheoperatinginstructions
manual as well as possible supplementary instructions.
For safety and warranty reasons, any invasive work on the device
beyond that described in the operating instructions manual may be
carried out only by personnel authorised by the manufacturer. Arbi-
traryconversionsormodicationsareexplicitlyforbidden.
2.3 Warning about incorrect use
Inappropriate or incorrect use of the instrument can give rise to
application-specichazards,e.g.vesseloverllordamagetosystem
components through incorrect mounting or adjustment.Thus dam-
age to property, to persons or environmental contamination can be
caused. Also the protective characteristics of the instrument can be
inuenced.
2.4 General safety instructions
This is a state-of-the-art instrument complying with all prevailing
regulations and directives.The instrument must only be operated in a
technicallyawlessandreliablecondition.Theoperatorisresponsi-
ble for the trouble-free operation of the instrument.When measuring
aggressive or corrosive media that can cause a dangerous situation
if the instrument malfunctions, the operator has to implement suitable
measures to make sure the instrument is functioning properly.
During the entire duration of use, the user is obliged to determine the
compliance of the necessary occupational safety measures with the
current valid rules and regulations and also take note of new regula-
tions.
The safety instructions in this operating instructions manual, the na-
tional installation standards as well as the valid safety regulations and
accident prevention rules must be observed by the user.
For safety and warranty reasons, any invasive work on the device
beyond that described in the operating instructions manual may be
carried out only by personnel authorised by the manufacturer. Arbi-

6
2 For your safety
VEGATOR 122 •
46108-EN-170907
traryconversionsormodicationsareexplicitlyforbidden.Forsafety
reasons,onlytheaccessoryspeciedbythemanufacturermustbe
used.
To avoid any danger, the safety approval markings and safety tips on
the device must also be observed and their meaning looked up in this
operating instructions manual.
2.5 EU conformity
ThedevicefullsthelegalrequirementsoftheapplicableEUdirec-
tives.ByaxingtheCEmarking,weconrmtheconformityofthe
instrument with these directives.
YoucanndtheEUconformitydeclarationonourwebsiteunder
www.vega.com/downloads.
2.6 Safety label on the instrument
The safety approval markings and safety tips on the device must be
observed.
2.7 SIL conformity (optional)
InstrumentswithSILoptionfullltherequirementsoffunctionalsafety
accordingtoIEC61508.Youcanndfurtherinformationinthesup-
plied Safety Manual.
2.8 Installation and operation in the USA and
Canada
This information is only valid for USA and Canada. Hence the follow-
ing text is only available in the English language.
Installations in the US shall comply with the relevant requirements of
the National Electrical Code (ANSI/NFPA 70).
Installations in Canada shall comply with the relevant requirements of
the Canadian Electrical Code
2.9 Safety instructions for Ex areas
PleasenotetheEx-specicsafetyinformationforinstallationandop-
eration in Ex areas.These safety instructions are part of the operating
instructions manual and come with the Ex-approved instruments.
2.10 Environmental instructions
Protection of the environment is one of our most important duties.
That is why we have introduced an environment management system
with the goal of continuously improving company environmental pro-
tection.Theenvironmentmanagementsystemiscertiedaccording
to DIN EN ISO 14001.
Pleasehelpusfullthisobligationbyobservingtheenvironmental
instructions in this manual:
• Chapter "Packaging, transport and storage"
• Chapter "Disposal"

7
3 Product description
VEGATOR 122 •
46108-EN-170907
3 Product description
3.1 Conguration
The scope of delivery encompasses:
• VEGATOR 122 signal conditioning instrument
• Documentation
– This operating instructions manual
– Ex-specic"Safety instructions" (with Ex version)
– Safety Manual "Functional safety (SIL) acc. to IEC 61508" (with
SIL version)
– Ifnecessary,furthercerticates
Thetypelabelcontainsthemostimportantdataforidenticationand
use of the instrument:
• Instrument type
• Product code
• Approvals
• Technical data
• Serial number of the instrument
• Data matrix code for VEGA Tools app
The type label contains the serial number of the instrument. With it
youcanndthefollowingdataonourhomepage:
• Product code of the instrument (HTML)
• Delivery date (HTML)
• Order-specicinstrumentfeatures(HTML)
• Operating instructions at the time of shipment (PDF)
• Safetyinstructionsandcerticates
Go to "www.vega.com", "Instrument search (serial number)". Enter
the serial number.
Alternatively, you can access the data via your smartphone:
• Download the "VEGA Tools" app from the "Apple App Store" or the
"Google Play Store"
• Scan the Data Matrix code on the type label of the instrument or
• Enter the serial number manually in the app
3.2 Principle of operation
The VEGATOR 122 is a double-channel signal conditioning instru-
ment for level detection with two level switches with 8/16 mA interface.
Simple monitoring and control functions can be realised via the inte-
grated relays.Typical applications are monitoring functions such as
overllanddryrunprotection.Asanalternativetothedouble-channel
level detection, a two-point control can be activated.
The VEGATOR 122 signal conditioning instrument powers connected
sensors and simultaneously processes their measuring signals.
When the medium reaches the switching point of the sensor, the sen-
sor current changes.This is measured and evaluated by VEGATOR
122.The change causes the output relays to switch according to the
set operating mode.
Scope of delivery
T
ype label
Serial number
Application area
Functional principle

8
3 Product description
VEGATOR 122 •
46108-EN-170907
Wide range power supply with a nominal voltage of 24 … 230 V AC,
50/60Hzor24…65VDC.
Detailed information about the power supply can be found in chapter
"Technical data".
3.3 Adjustment
All adjustment elements are located under a hinged front plate.The
operating mode, switch-on pulse monitoring and the switching delay
can be set via a DIL switch block. In addition, the correct function of
the measuring system can be checked by simply pressing a key.
3.4 Packaging, transport and storage
Your instrument was protected by packaging during transport. Its
capacity to handle normal loads during transport is assured by a test
based on ISO 4180.
The packaging of standard instruments consists of environment-
friendly, recyclable cardboard. For special versions, PE foam or PE
foil is also used. Dispose of the packaging material via specialised
recycling companies.
Transport must be carried out in due consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt. Ascertained transit damage or con-
cealed defects must be appropriately dealt with.
Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated, the packages must be stored only under
the following conditions:
• Not in the open
• Dry and dust free
• Not exposed to corrosive media
• Protected against solar radiation
• Avoiding mechanical shock and vibration
• Storage and transport temperature see chapter "Supplement -
Technical data - Ambient conditions"
• Relative humidity 20 … 85 %
With an instrument weight of more than 18 kg (39.68 lbs) suitable and
approved equipment must be used for lifting and carrying.
Voltage supply
Packaging
Transport
Transport inspection
Storage
Storage and transport
temperature
Lifting and carrying

9
4 Mounting
VEGATOR 122 •
46108-EN-170907
4 Mounting
4.1 Mounting instructions
VEGATOR 122 is designed for carrier rail mounting (top hat rail
35 x 7.5 according to DIN EN 50022/60715). Due to its protection
rating of IP 20, the instrument is suitable for mounting in switching
cabinets.Itcanbemountedhorizontallyandvertically.
Note:
When several instruments are mounted together without space in
between, the ambient temperature at the installation location of the
instrument must not exceed 60 °C. Around the ventilation slots there
must be a distance of at least 2 cm to the next component.
The VEGATOR 122 in Ex version is an associated, intrinsically safe
instrumentandmustnotbeinstalledinhazardousareas.Safeopera-
tion is only ensured if the operating instructions and EU Type Approval
Certicateareobserved.VEGATOR122mustnotbeopened.A
certicationforExZone2isalsoavailableasanoption.
The instrument is suitable for standard ambient conditions acc. to
DIN/EN/IEC/ANSI/ISA/UL/CSA 61010-1.
Makesurethatthedegreeofcontaminationspeciedinchapter
"Technical data" meets the existing ambient conditions.
Ambient conditions

10
5 Connecting to power supply
VEGATOR 122 •
46108-EN-170907
5 Connecting to power supply
5.1 Preparing the connection
Always keep in mind the following safety instructions:
Warning:
Connect only in the complete absence of line voltage.
• Connect only in the complete absence of line voltage
• If overvoltage surges are expected, overvoltage arresters should
be installed
Note:
Install a separating facility for the instrument which is easy to access.
The separating facility must be marked for the instrument (IEC/
EN 61010).
Inhazardousareasyoumusttakenoteoftherespectiveregulations,
conformityandtypeapprovalcerticatesofthesensorsandpower
supply units.
The nominal range of the voltage supply can be 24 … 230 V AC,
50/60Hzor24…65VDC.
Detailed information about the power supply can be found in chapter
"Technical data".
The voltage supply of VEGATOR 122 is connected with standard
cable according to the national installation standards.
The sensors are connected with standard two-wire cable without
screen. If electromagnetic interference is expected which is above the
test values of EN 61326 for industrial areas, screened cable should
be used.
Make sure that the cable used has the required temperature resist-
anceandresafetyformax.occurringambienttemperature
Connect the cable screen on both ends to ground potential. In the
sensor, the screen must be connected directly to the internal ground
terminal.The ground terminal on the outside of the sensor housing
must be connected to the potential equalisation (low impedance).
If potential equalisation currents are expected, the connection on the
processing side must be made via a ceramic capacitor (e. g. 1 nF,
1500 V).The low-frequency potential equalisation currents are thus
suppressed,buttheprotectiveeectagainsthighfrequencyinterfer-
ence signals remains.
Take note of the corresponding installation regulations for Ex applica-
tions. In particular, make sure that no potential equalisation currents
owoverthecablescreen.Incaseofgroundingonbothsidesthis
can be achieved by the use of a capacitor or a separate potential
equalisation.
Safety instructions
Safety instructions
for Ex applications
Voltage supply
Connection cable
Cable screening and
grounding
Connection cable
for Ex applications

11
5 Connecting to power supply
VEGATOR 122 •
46108-EN-170907
5.2 Connection procedure
The pluggable terminals can be removed as needed to allow more
convenient connection.To make the electrical connection, proceed as
follows:
1. Mount the instrument as described in the previous chapter
2. Connect sensor cable 1 to terminal 1/2, and where applicable,
connect the screen
3. Connect sensor cable 2 to terminal 4/5, and where applicable,
connect the screen
4. Connectswitched-opowersupplytoterminal16/17
5. Connect relay 1 to terminal 10/11/12
6. Connect relay 2 to terminal 13/14/15
Theelectricalconnectionisnished.

12
5 Connecting to power supply
VEGATOR 122 •
46108-EN-170907
5.3 Wiring plan
1
2
5
3
4
10 11 12
13 14 15
-+
4 5
-+
1 2
-+
16 17
OPEN
1 Sensor circuit, channel 1 (8/16 mA), max. level with two-point control
2 Sensor circuit, channel 2 (8/16 mA), min. level with two-point control
3 Relay output channel 1
4 Relay output channel 2
5 Voltage supply
Information:
The connection terminals can be detached towards the front, if
necessary. This can be useful when working in tight spaces or when
exchanging an instrument.

13
6 Setup
VEGATOR 122 •
46108-EN-170907
6 Setup
6.1 Adjustment system
1
2
3
4
Fig. 2: Display and adjustment elements
1 Test keys, channel 1, 2
2 DIL switch block
3 Signal lamps (LEDs)
4 Hinged front cover
6.2 Adjustment elements
Control lamps (LED) in the front plate indicate operation, switching
status and fault signal.
• Green
– Operating control lamp
– Mains voltage on, instrument is operating
• Red
– Fault indicator
– Fault on the sensor circuit due to sensor failure or line break
– The relay deenergises in case of failure
Control lamps

14
6 Setup
VEGATOR 122 •
46108-EN-170907
• Yellow
– Relay control lamp
– Lights with activated (current-carrying) relay status
The adjustment elements are located under a hinged front cover. To
open it, use a small screwdriver in conjunction with the slot on the
upper side of the front cover. To close it, push the cover at bottom and
toprmlyontothefrontcoveruntilyouhearthetworetainingclips
snap in.
The DIL switch block is located behind the front cover.The individual
switches are assigned as follows:
7
8maxmin
CH1CH2
1
2
3
4
5
6
maxmin
0s
0s
0s
0s
+2s
+6s
t
+2s
+6s
t
Fig. 3: DIL switch VEGATOR 122
1 Mode (min./max. adjustment), channel 1
2 Switch-onpulsemonitoringOn/O
3 Switch-on delay 2 seconds
4 Switch-on delay 6 seconds
5 Switch-odelay2seconds
6 Switch-odelay6seconds
7 Two-pointcontrolOn/O
8 Mode (min./max. adjustment), channel 2
The requested operating mode is set with the min./max. switch (min.
detectioni.e.dryrunprotectionormax.detectioni.e.overllprotec-
tion)
• Dry run protection:Relayisswitchedowhenthelevelfalls
below the min. level (safe currentless state), relay is switched on
againwhenthemin.levelisexceeded(switch-onpoint>switch-o
point)
• Overowprotection:Relayisswitchedowhenthemax.levelis
exceeded (safe currentless state), relay is switched on again when
thelevelfallsbelowthemax.level(switch-onpoint<switch-o
point)
Note:
If the connected sensor has an own mode switch, then this switch
must be set to "Max.".
While switching on, the sensors VEGASWING/VEGAVIB/VEGAWAVE
deliveradenedswitchingsequenceinwhichtheswitchingcondi-
tions empty/full/failure are run through.This switching sequence is
Front cover
DIL switch block
Mode (min./max. adjust-
ment)
Switch-on pulse monitor-
ing

15
6 Setup
VEGATOR 122 •
46108-EN-170907
checked and evaluated when switch-on pulse monitoring is activated.
Ifthisdoesnotcorrespondtothedenitionoriscompleteymissing,
the VEGATOR 122 displays a fault. A function test is only triggered by
pressing the test key. This function test is not carried out automatically
when switching on the VEGATOR 122.
Note:
Whenconnectingsensorswithoutthisdenedswitchingsequence,
the switch-on monitoring must be deactivated.
With these switches you can delay the changeover of the relays by
thesettime.Thiscanbeuseful,e.g.withuctuatingproductsurfaces,
forpreventingunwantedswitchingcommands.Theswitch-on/o
delays can be set independently of each other. If both switches, e.g.
of the switch-on delay, are activated, the times sum up. Delays of 2, 6
or 8 seconds can thus be adjusted.
Information:
Keep in mind that the switching delay of the sensor and signal condi-
tioning instrument accumulate.
The following functionalities can be selected via this switch:
• Single point control (double channel level detection with one sen-
soreachandthesameswitchon/switchopoint)
• Two-pointcontrol(leveldetectionwithtwosensorsanddierent
switchon/switchopoints)
As opposed to single point control, two-point control allows the
switch-onandswitch-opointstobesetatdierentlocations(hyster-
esis).Through the installation or the distance of the two sensors, the
hysteresiscanbedenedindividually.Here,themax.levelmustbe
set to sensor input 1, the min. level to sensor input 2.
Thetwo-pointcontrolisusedforexamplewhenllingandemptying
iscarriedoutviaapump.Thellingofavesselcanbeforexample
switchedonat10%andswitchedoagainat90%.Theoutputofthe
secondchannelbehavesidenticallyliketherstchannelprovidedthe
same mode is set. By changing the mode, the function of the relays
can be inverted.
When level switches VEGASWING/VEGAVIB/VEGAWAVE in two-wire
version are connected, a function test can be carried out.The test key
is recessed behind the front plate of the signal conditioning instru-
ment. Press the test key for at least two seconds with a suitable object
(screwdriver, pen, etc.).
By pushing the test key, the circuit to the sensor is interrupted and a
restart of the sensor is initiated. Through this, the conditions fault sig-
nal, empty and full alarm are simulated.The complete test procedure
takes approx. 5 seconds. After correct function, the red failure LED
should not light and depending on the status of the sensor, the relays
areenergizedordeenergized.
Switch-on/Switch-o
delay
Two-point control
Test key

16
6 Setup
VEGATOR 122 •
46108-EN-170907
If the test result is negative, the red failure LED lights up and the
relaysmustbedeenergized.Inthiscasethewholemeasuringsystem
has to be checked and repaired.
Note:
Keep in mind that downstream connected devices are activated dur-
ing the function test.This allows you to check the correct function of
the measuring system.
6.3 Function table "Point level"
The following table provides an overview of the switching conditions
depending on the set mode and the level.
Note:
The switching conditions in the tables are only valid if the mode
switch on the sensor is set to "Max.".
Sensor Signal conditioning instrument
Level Sensor cur-
rent
LED yellow
(output)
LED red
(fault)
Relay
approx. 8 mA ON
approx. 16 mA OFF
any < 3.6 mA
> 21 mA OFF
Sensor Signal conditioning instrument
Level Sensor cur-
rent
LED yellow
(output)
LED red
(fault)
Relay
approx. 16 mA ON
approx. 8 mA OFF
Overllprotection,point
level
Dry run protection, point
level

17
6 Setup
VEGATOR 122 •
46108-EN-170907
Sensor Signal conditioning instrument
Level Sensor cur-
rent
LED yellow
(output)
LED red
(fault)
Relay
any < 3.6 mA
> 21 mA OFF
6.4 Function table, two-point control
The following charts provide an overview of the switching conditions
depending on the set mode and the level.
Note:
The switching conditions in the tables are only valid if the mode
switch on the sensor is set to "Max.".
Sensor Signal conditioning instrument
Level Sensor cur-
rent
LED yellow
(output)
LED red
(fault)
Relay
approx. 8 mA
approx. 8 mA
ON
approx. 8 mA
approx. 16 mA
ON
approx. 16 mA
approx. 16 mA
OFF
approx. 8 mA
approx. 16 mA
OFF
approx. 8 mA
approx. 8 mA
ON
any < 3.6 mA
> 21 mA OFF
Overllprotection,two-
point control

18
6 Setup
VEGATOR 122 •
46108-EN-170907
Sensor Signal conditioning instrument
Level Sensor cur-
rent
LED yellow
(output)
LED red
(fault)
Relay
approx. 8 mA
approx. 8 mA
OFF
approx. 8 mA
approx. 16 mA
OFF
approx. 16 mA
approx. 16 mA
ON
approx. 8 mA
approx. 16 mA
ON
approx. 8 mA
approx. 8 mA
OFF
any < 3.6 mA
> 21 mA OFF
Dru run protection, two-
point control

19
7Maintenanceandfaultrectication
VEGATOR 122 •
46108-EN-170907
7 Maintenanceandfaultrectication
7.1 Maintenance
If the device is used properly, no special maintenance is required in
normal operation.
7.2 Rectify faults
Maximum reliability is ensured. Nevertheless, faults can occur during
operation.These may be caused by the following, e.g.:
• Measured value from sensor not correct
• Voltage supply
• Interference in the cables
Therstmeasuretobetakenistochecktheinputandoutputsignals.
The procedure is described as follows. In many cases the causes can
bedeterminedthiswayandfaultscanbeeasilyrectied.
Should these measures not be successful, please call in urgent cases
the VEGA service hotline under the phone no. [phone].
Thehotlineismanned7daysaweekround-the-clock.Sinceweoer
this service worldwide, the support is only available in the English
language.The service is free, only standard call charges are incurred.
Depending on the reason for the fault and the measures taken, the
steps described in chapter "Set up" may have to be carried out again.
Cause Rectication
Sensor not connected
correctly •
In Ex systems, make sure that the Ex protection
isnotinuencedbythemeasuringinstruments
used.
•
Measure the current and voltage on the connec-
tion cable to the sensor
•
Faults in the sensor causing a current change to
below 3.6 mA or over 21 mA lead to a fault signal
in the signal conditioning instruments.
•
Theterminalvoltagemustbeinsidethespecied
range.Youcanndthisvoltagerangeintheoper-
ating instructions of the connected sensor.
Sensor delivers no (cor-
rect) switch-on pulse •
Use sensor with switching-on pulse
•
Deactivate switch-on pulse monitoring
Causes of malfunction
Faultrectication
24 hour service hotline
Reaction after fault recti-
cation
Red fault LED lights up

20
7Maintenanceandfaultrectication
VEGATOR 122 •
46108-EN-170907
Cause Rectication
Sensor current < 3.6 mA • Check signal conditioning instrument
•
Check the terminal voltage on the signal condi-
tioning instrument; if it is < 17 V, the signal condi-
tioning instrument is defective -> exchange signal
conditioning instrument or return it for repair
•
If the terminal voltage is > 17 V, disconnect the
sensor cable at the signal conditioning instrument
andreplaceitwitha1kΩresistor.Ifthefault
signal does not disappear, the signal conditioning
instrument is defective -> exchange signal condi-
tioning instrument or return it for repair
•
Check sensor or sensor cable
•
Reconnect the sensor cable to the signal con-
ditiong instrument, disconnect the sensor and
replaceitwitha1kΩresistor.Ifthefaultsignal
does not disappear, then the sensor cable is
broken -> replace the sensor cable
•
If there is no longer a fault signal on the line, the
sensor is defective -> exchange sensor or return
it for repair
Sensor current > 21 mA • Check signal conditioning instrument
•
Disconnect sensor cable and replace it with a
1kΩresistor.Ifthefaultsignaldoesnotdisap-
pear, the signal conditioning instrument is defec-
tive -> exchange signal conditioning instrument or
return it for repair
•
Check sensor or sensor cable
•
Reconnect the sensor cable to the signal con-
ditiong instrument, disconnect the sensor and
replaceitwitha1kΩresistor.Ifthefaultsignal
does not disappear, then the sensor cable is
short-circuited -> eliminate the short-circuit or
replace the sensor cable
•
If there is no longer a fault signal on the line, the
sensor is defective -> exchange sensor or return
it for repair
7.3 How to proceed if a repair is necessary
Youcanndaninstrumentreturnformaswellasdetailedinforma-
tion about the procedure in the download area of our homepage:
www.vega.com.
By doing this you help us carry out the repair quickly and without hav-
ing to call back for needed information.
If a repair is necessary, please proceed as follows:
• Printandlloutoneformperinstrument
• Clean the instrument and pack it damage-proof
• Attach the completed form and, if need be, also a safety data
sheet outside on the packaging
• Please contact the agency serving you to get the address for
thereturnshipment.Youcanndtheagencyonourhomepage
www.vega.com.
