veise HDWS-772S231M1-10W User manual
DC12V
DC:8-32V
Cable Interface Definition
Monitor Camera
Red Power
Black Ground
Red Power
Black Ground
Brown TIRG1
Blue TIRG2
Applications
720P Digital wireless system
User Manual
Features
★ABS monitor housing endure high temperature.
★7" High Resolution color 1024RGB(H) X 600(V) TFT-LCD.
★ Power input:8V-32V DC.
★Monitor circuit has protector for battery reverse(+/-).
★LED backlight display with constant voltage constant current circuit protection. It can solve
LED working temperature problems (the limit of LED backlight’s current) and prolong life.
★Monitor OSD menu can set each channel camera image in 4 mode NOR/MIR/UP/DOWN;the
priority for each mode; each trigger cable can be set to trigger to any display mode; time delay
setting.
★Two channels digital wireless signal transmission. It supports sub-screen and two screens.
★ 720P Wireless car camera waterproof stainless steel forklift level IP69K.
Monitor menu operation instructions
F
F
F
F
Please perss pair key
on camera side
20
MODE
5
-
+
5
-
+
5
-
+
5
-
+
5
-
+
4
SPLIT3-4 SPLIT234
1 2
SPLIT1-2
H-SPLIT OFF
3
QUAD
ON OFF
ON OFF
NTSC PAL
Display Device Color TFT-LCD
Size 7" Digital Screen
Operation Frequency 2400 ~ 2483.5MHz
Receiving Sensitivity ≤-86dBm(1MHZ QPSK MD300RE)
Resolution 1024×(RGB)×600
View Angle (LR/UD) L/R: 60/70 U/D: 60/70
Contrast Ratio 500:1
2
Luminance(cd/m ) 600
Response Time (ms) 25
Load Dump DC 12+87V/400ms
Operating Temperature -20℃～+60℃
Storage Temperature -30℃～+80℃
operating voltage range Supply DC8V～32V （ 5W Max）
Dimension(L x W x T) (185X122X28mm)
Transmission Power 18dBm with Power control
Camera
720P Wireless waterproof and shockproof digital camera truck
Image Pick-up Device 1/3" Color CMOS
Picture Elements 1280(H)X960(V)
Horizontal Resolution 720P
Minimum illumination 0.1 Lux
View Angle 45°
Waterproof rating IP69K
Shockproof R ating 10G
operating voltage range DC12V
Dimension 127(W) x 37(H) x 24.5(D) mm
Digital wireless system technical Parameters
The system maintenance must be maintained by professionals, please do not open and
improve the system!
The system is only for the safe operation of equipment and not responsible for accidents!
This manual is for reference only. if unknown, or any changes, we will give no notice.
The final interpretation right belongs to the manufacturer
Warning
Line of Sight Range ≤100M
3)Mirror settings:
Set the four states of the CAM1/CAM2 channel image:
Positive image, mirror image, vertical flip image and vertical flip
mirror,Default state: Positive image.
1)Code settings:
Enter the menu, check the code options menu, press the confir
mation button to start the code, display the code.Character
Please perss pair Keyon camera side 20, pair code timeThe
countdown is 20 seconds, the camera is recharged and waited
for 5~10 seconds to display and photograph.The machine conn
ects to the communication and displays the image normally.
2)Image settings:
Enter the menu, select the image settings options menu, press
the confirmation button to enter the image settings:
1.Brightness setting: 0-9 (left / right key adjustment step size)
2.Contrast settings: 0-9 (left / right key adjustment step size)
3.Color settings: 0-9 (left / right key adjustment step size)
4. Volume control: 0-9 (left / right key adjustment step size)
Setting Multi screen
mode setting
On the code Function
settings
Mirror
settings
Automatic
conversion settings
4)Automatic switch mode settings:
1.Set up CAM1/CAM2 channel automatic switching mode to
turn on and off；
2. Set CAM1/CAM2 channel automatic
switching mode time value 5~45,Default state: 5S.
5)Function settings:
1.Switch between NTSC and PAL，Default state:NTSC；
2.Set up the LED screen environment light source mode to
turn on and off；
3.Reversing scale setting: set up CAM2 channel reversing
scale open and close.
6)Multi screen mode display settings:
1. Settings screen can be switched to two-screen display,
open by default.
