Velleman VTTEST3 User manual

VTTEST3
GB
1
OPERATION MANUAL
VTTEST3 VOLTAGE TESTER
1.SAFELY RULES
- This tester is designed and tested in accordance with EN publication
61010-1 pollution degree 2 and installation category (Overvoltage
category) III 600V.
- This tester has been tested according to the following EC Directives :
- 89/336/EEC (EMC of Nov., 1992, Electromagnetic compatibility)
EN50081-1 & EN50082-1.
- 73/23/EEC (Product Safety Law of June 11, 1979, Low Voltage Directive
of February 19, 1973).
-This tester is designed for to be indoor use at temperature 5°C to 40°C and
altitude up to 2000m.
- This tester is designed for "TOUCH" testing only. Do not keep continuous
contact with the unit under test for over 10 seconds, especially to high
voltage.
- Test on known live circuits to familiarise yourself with the response from a
live cable.
- Do not use the tester if the tester or the test probes look damaged or if you
suspect that the tester is not operating properly.
- When using the probes, keep your fingers behind the finger guard on the
probes.
- Always ensure probes are dry and do not work with wet hands.
2.INTERNATIONAL SYMBOLS
Important information see manual Ground
AC DC Double insulation

VTTEST3
GB
2
3.OPERATION
3.1 Touch the live (L) terminal with the probe with the "RED" pin head.
3.2 Probe the neutral (N) terminal with the probe with the "BLACK" pin head.
3.3 The neon indicator light will illuminate if the circuit is live and the
VOLTAGE indicators will illuminate to confirm the voltage as follows :
4.MAINTENANCE
This tester is designed to have no serviceable parts and is maintenance free.
Periodically wipe the tester with a soft cloth, do not use abrasives or
solvents. Ensure that no water gets inside the equipment to prevent possible
shorts and damage.
5. WARNING
Consult a qualified electrician if in doubt for application.
One light
= 100 - 120V AC Three lights = 360 - 450V AC
Two lights
= 210 - 250V AC
