Velodyne vTrue User manual

User guide

Box Contents
• vTrue over-ear studio headphones
• 3.5 mm (1/8”) Y-cable connector
• 3.5 mm (1/8”) Y-cable with control module
• 3.5 mm (1/8”) to 6.35 mm (1/4”) stereo adapter
• Carrying pouch
Specications
Driver size: 50 mm
Frequency response: 10 Hz - 20 kHz
Sensitivity: 96 dB/1 kHz/1 mW
Impedance:24Ω
*Designandspecicationsaresubjecttochangewithoutnotice.
1

Warnings, safety & care
• Toreducetheriskofreorelectricshock,donotexposevTrueheadphonestorainormoisture,
anddonotopenorattempttoopenthecontrolmodule,oranypartofvTrueheadphones.
• Keep out of reach of children. Small parts may be a choking hazard. This product is not intended
for use by children under the age of three.
• Excessivesoundpressurefromearphonesandheadphonescancausehearingloss.
• Consultyourphysicianoraudiologistifyouhaveproblemshearing,excessivewaxbuild-uporany
discomfort after use of vTrue headphones.
• Inparticularlydryairconditions,mildtinglingmaybefeltonyourears.Thisisaresultofstatic
electricityaccumulatedinthebodyandnotamalfunctionofvTrueheadphones.Thiseectcanbe
minimizedbywearingclothesmadefromnaturalbers.
• vTrue headphones are assembled in a facility where they could come in contact with chemicals
covered by California’s Proposition 65.
• Ifanydustorearwaxisinsidetheearcup,youmayexperienceadegradationofsoundquality.
• Remove vTrue headphones if they cause any discomfort or pain.
• DonotsubmergeorexposevTrueheadphonestowater.
• Protect your vTrue headphones in the carrying pouch when not in use.
Please listen safely
Fortracsafety,donotusevTrueheadphoneswhiledrivingorcycling.DonotwearvTrueheadphones
while operating machinery. Adhere to local laws regarding the use of headphones.
ListeningwithvTrueheadphonesathighvolumesmayaectyourhearing,includingcausingpermanent
damage. Ringing in your ears or other discomfort can indicate that the volume is too high.
Hearinghealthiscriticaltoenjoymentandthequalityoflife.Protectyourhearingbylisteningwith
your vTrue headphones in a responsible manner that protects your long term hearing health. Velodyne
Acoustics,Inc.isnotresponsibleforhearinglossordamageresultingfromtheuseofthisproduct.
Sound Noise Level (dB) Eect
Normal breathing 10 Just audible
Whisper 30 Very quiet
Normal conversation 50-65 Comfortable hearing levels are under 60 dB
Vacuumcleaner,hair
dryer
70 Intrusive; interferes with telephone conversation
Averagecitytrac 80 Annoying;interfereswithconversation;constantexposuremaycausedamage
Lawnmower,food
blender
85-90 85 dB is the level at which hearing damage (8 hrs) begins
Garbagetruck,cement
mixer
100 Nomorethan15minutesofunprotectedexposurerecommendedforsoundsbetween
90-100 dB
Stereos(over100watts),
thunderclap (near)
110-125 Regularexposuretosoundover100dBofmorethanoneminuteriskspermanent
hearing loss
Jet engines (near) 140 Threshold of pain begins around 125 dB
*Informationobtainedfromhttp://www.nidcd.nih.gov/health/education/teachers/pages/common_sounds.aspx
2
vTrue user guide

How to connect
ToconnectyourvTrueheadphones,plugthestraight3.5mm(1/8”)Y-cableconnectorsintotheportsof
their respective ear cups.
Each connector has a red or blue marking on the body of the connector. Match the connectors with
the corresponding color under the left and right ear cups. The cable with the red marking is for the right
audiochannel,whilethecablewiththeblue marking is for the left audio channel.
Plug the right-angle 3.5 mm (1/8”) connector into the audio output port on your audio device.
Note: Use the included 6.35 mm (1/4”) adapter if your audio equipment uses a 6.35 mm (1/4”) output
port. Use of this adapter with the control module cable eliminates control function.
Wearing vTrue headphones
Located above the inside of each ear cup are markings for right and left audio channels.
Wear the ear cup marked “Right” over your right ear and the one marked “Left” over your left ear. The
control module is located on the cable connecting to the left ear cup.
Always turn down the volume on your audio equipment before wearing vTrue headphones. Once the ear
cupsarecomfortablyseatedoveryouryears,graduallyincreasethevolumetoamoderatesoundlevel.
Cleaning
Ear cups should be cleaned regularly for sanitary reasons and to prolong the life of your ear cups.
Withalightlydampenedcloth,papertowelordisinfectantwipe,thoroughlycleantheearcups.
Use a dry cloth to pat away any remaining moisture.
Adjusting the headband
TheheadbandonthevTrueisadjustabletotdierentheadsizes.
Holdtheheadbandandadjustbypullingontherightandleftearcups.
The right and left ear cups should be centered over the ears.
Do not get the speakers or electronics inside of your headphones
wet. Liquids and heavy moisture can cause damage to the
electronics inside your headphones. Such accidental damages
are not covered under warranty.
3
vTrue user guide

Using the playback, volume, & phone functions
ThecontrolmoduleonthevTrueY-cablehasplayback,volume,andphonecontrolssoyoucanow
betweenlisteningtomusic,watchingvideo,andtalkingonthephonewhenconnectedtodevicesthat
support these features.
Volume up
Answer / end call
Track forward / backward
Play / pause
Volume down
Music & video functions Button press sequence
Increase or decrease volume Press + / -
Switch between pause & play Press&releasecenterbuttonx1
Nextsongorvideochapter Press&releasecenterbuttonx2
Start of song or video chapter Press&releasecenterbuttonx3
Previous song or video chapter Press&releasecenterbuttonx3,thenx3again
Scan forward in song or video Press&releasecenterbuttonx1,thenpress&
hold center button
Scan backward in song or video Quicklypress&releasecenterbuttonx2,then
press & hold center button
Phone functions Button press sequence
Answer or end call Press&releasecenterbuttonx1
Decline incoming call Press&holdcenterbuttonfortwoseconds,then
release
Put call on hold & answer new call or switch
between calls
Press&releasecenterbuttonx1
End call & answer incoming call Press&holdcenterbuttonfortwoseconds,then
release
Important:Playback,volume,
and phone control functionality
varies by media device.
4
vTrue user guide

Product recycling
ProducingvTrueheadphonesrequiredtheextractionanduseofnaturalresources,andtheymaycontain
hazardoussubstances.DonotdisposeofvTrueheadphoneswithyourotherhouseholdwaste.Instead,
take them to a designated collection point for the recycling of electronic equipment. The separate
collection and recycling of your electronic waste equipment at the time of disposal will help to conserve
natural resources and ensure that it is recycled in a manner that protects human health and the
environment.Forinformationaboutwhereyoucandropoyourwasteequipmentforrecycling,contact
your local city government or your household waste disposal service.
vTrue user guide
5

6
vTrue user guide
Limited Warranty (U.S. Only)
VelodyneAcoustics,Inc.(“Velodyne”)warrantsthisproductforaperiodofone(1)yearfromthedateofpurchaseagainstdefectsinmaterials
andworkmanshipandagreestorepairor,atVelodyne’soptionreplacewithalikeorcomparablemodel,anydefectiveunitwithoutcharge.
•This warranty is void if any repairs or service covered by the terms of this warranty are made to this product by anyone other
than a Velodyne factory authorized service representative.
•Thiswarrantyisvoidifthisproductisdamagedduetoadefectinthedevicetowhichitwasconnected,suchasabatteryleak
or electrical fault.
•Velodyneisnotresponsiblefordamagecausedbyordinarywearandtear,cosmeticdamage,incorrectconnection,accidents,
abuse,misuse,negligence,naturalorpersonaldisasterorunauthorizedmodication.
•ThiswarrantyislimitedtoproductspurchasedfromauthorizedVelodynedealersandnalizedwithinauthorizeddealerlocations.
•Proof of purchase is required. A proof of purchase is a receipt with the product and date of purchase listed from an authorized
dealer.
•This warranty is void if this product is sold or transferred to another party.
To obtain service
Informationregardingservicemaybeobtainedfromthedealerfromwhomyoupurchasedtheunit,orbycontactingVelodynecustomer
service. Warranty service must be performed by a Velodyne factory authorized service representative within the warranty period set forth
above.Shipmentofdefective unitstoVelodyne forrepairorreplacementwillbeatthecustomer’sownriskandexpense.Velodynewill
assumereturnshippingcostforallunitsrepairedorreplacedunderwarrantyforUSshippingaddresses,andforunitsthatweredirectly
purchased and shipped from Velodyne.
Customer service contact information:
Toll free number: 855-219-4717
Technical support: 408-465-2851
Email: [email protected]
*International warranty information - Please contact your local dealer for information on internationaly warranty.
