Veltron VHOE-90 User manual

FAR INFRARED RAYS HEATER
USER’S MANUAL
MODEL: VHOE-90, VHOE-120, VHOE-150, VHOE-180, VHOE-210, VHOE-250/F, VHOE-350/F
 Thank you for purchasing VELTRON Far Infrared Rays heater.
Please read this user’s manual carefully before you operate this heater.
 It is recommended you to put this manual on where the user can fi nd easily.
 It is obligatory that the user read “Notice for Safety“ carefully before using,
and should be aware of this notice whenever using this heater.
 This heater is designed for your country only. If you use it in another country
you have to check the electricity fi rst, and if the electricity condition is same
you can use it.
 Warranty card is enveloped in this manual.
 The contents (features & specifi cations) in this manual are subject to be
changed without notice.

- 2 -
www.veltron-heaters.com
TABLE OF CONTENTS
NOTICE FOR SAFETY ..................................................................3
STRUCTURE & DESCRIPTION .................................................6~7
• STRUTURE & DESCRIPTION FOR MODEL ...............................6
• CONTROLLER ...................................................................................6
• REMOTE CONTROLLER .................................................................7
HOW TO USE ..................................................................................8~10
• OPERATION & STOP .......................................................................8
• TEMPERATURE CONTROL ............................................................9
• SELF DIAGNOSIS FOR THE SAFETY DEVICE ...........................10
CLEANING & MAINTENANCE ..................................................11
DAILY CHECK POINTS & ADJUSTMENT .............................12~13
TROUBLE SHOOTING ................................................................. 14~15
SPECIFICATION & ELECTRICAL WIRING DIAGRAM......16
WARRANTY CARD .......................................................................17

- 3 -
STOVES & CHIMNEYS
NOTICE FOR SAFETY
This is for protecting the user’s safety, and preventing any property damage, please read carefully
and follow the instruction on this manual.
 It is classi ed as “Warning“, and “Caution“ by the contents.
WARNING: In case of misuse, it may cause a serious wounds or death.
CAUTION: In case of misuse, it may cause a slight injury or property damage.
Meaning of symbol
Forbidden Obligatory
WARNING
Use AC 220/230V(50Hz) power supply only,
otherwise.
(it may cause a  re or an electric shock.)
Use the proper form of fuse. Otherwise
(it may cause malfunctioning or a  re.)
In case of cleaning you must take out the plug from
the outlet, wait until the heated furnace is cooled
down suciently.
(Otherwise, it may cause an electric shock or a burn)
Put a plug into the outlet tightly after removing
any dirt on the plug.
(It may cause emitting smoke or a  re by electrical
short.)
It is dangerous to turn OFF this heater by taking
out the power plug.
(It may cause a malfunction or electrical shock.
Please turn OFF using RUN/STOP button.)
Put a plug into the outlet tightly with Earth(-) only.
(It may cause an electric shock)
Do not use a damaged power cord or plug, and a
loose outlet.
(It may cause short,  re, a shock.)
Do not fold the power cord hardly, or put a heavy
material on it.
(It may be damaged on the covering material which
might cause a  re, or an electric shock.)
Do not take out the plug with holding the cord or
by the wet hands.
(It may cause a  re or an electric shock)
Do not place any inammable material near the
heater including curtain, carpet, paper, match,
clothes, etc.
(It is exposed to danger of  re.)
Do not extend the power cord with connecting
another cable in the middle.
(It may cause a  re or an electric shock)
Do not place or use any inammable near the
heater including fuel, gas, thinner, benzene, spray,
solvents, volatile organic compounds, etc.
(It is exposed to danger of  re or explosion.)
 Place this manual noticeably near the heater so that, if necessary, the user can always  nd it easily.

- 4 -
www.veltron-heaters.com
NOTICE FOR SAFETY
WARNING
You must ventilate well while you are using the
heater, and do not use it in the stuy area where
the ventilation is not possible.
(You need to ventilate with fresh air 1~2 times per hour)
(In case of incomplete combustion due to the lack of
oxygen carbon monoxide can be increased to cause an
accident from poisoning.)
It is dangerous to use this heater for a long time in
the closed room or in case there are children or the
old and the weak.
(It is recommended that the user open the windows to
let fresh air in the room if the room is stu y.)
It is dangerous to put your hands or any other thing
into the grill or furnace, or to apply a considerable
shock or force to the heater.
(It is exposed to  re, burn, or electric shock)
Do not place any inammable vinyl or plastic
goods on top of heater, or cover the heater grill
with clothes.
(It is exposed to  re or burn.)
Do not place any electrical item or heavy material
on top of heater.
(It may cause malfunctioning or electrical shock, or if
the heavy material is fallen user can be injured)
Do not touch any of the heated material such as
grill, furnace, etc.
- While the heater is operating or just after extinguish-
ing the grill and furnace are hot, so do not touch any
of those parts (Especially pay attention more to keep
children away from the hot materials)
- It may cause a burn.
Do not move or transport during operation.
(It may cause a  re or a burn)
(In case of moving this heater you must turn OFF take
out power plug before you move it)
It is recommended not to use this heater in the
highly elevated areas.
(Do not use this heater in the areas where is higher
than 1,500m from the sea level.)
(You need frequent ventilation in the areas of 700 ~
1,500m from the sea level.)
(Due to the lack of oxygen, carbon monoxide can be
increased to cause an accident from poisoning.)
Do not use this heater for another purpose other
than heating.
(Do not use this heater for drying clothes because it
may cause a  re.)
(Do not use this heater for keeping pet animal or plants
warm)
Pay attention to avoiding water into the heater
during cleaning.
(It may cause a  re or electric shock)
Do not operate this heater while you are sleeping.
(Due to no ventilation while you are sleeping the room
easily get stu y, and lack of oxygen.)
Do not use this heater on the unstable places.
(Do not use this heater on an inclined surface or a
shaking support.)
(This heater may fall down, which cause a  re or
malfunction.)
 Place this manual noticeably near the heater so that, if necessary, the user can always  nd it easily.

- 5 -
STOVES & CHIMNEYS
NOTICE FOR SAFETY
CAUTION
In case of storing this heater, be sure that you store
it in the dry places indoor instead of hot and humid
environment.
(Otherwise, it gets rusty or goes into trouble)
If the supply cord is damaged, it must be replaced by
the manufacturer or its service agent or simi-larly
qualified person in order to avoid a hazard.
Do not put this heater on unstable surface of ground
such as inclined or bumpy.
(The heater may not work properly.)
Do not put an excessive physical shock to the re-
mote controller, nor disassemble it arbitrarily.
(it arbitrarily.)
You must take out the plug from the outlet, if there
is a flash of lightening or thunder or you don’t use it
for a long time.
(Otherwise, it is exposed to the danger of electrical
shock, short circuit or a fi re.)
Call your local after sales service agent in case the
power cord is damaged.
(Otherwise, it is exposed to the danger of electrical
shock, short circuit or a fi re.)
Do not shower water to the heater directly, nor use
benzene, thinner, alcohol for cleaning.
(Otherwise, it is exposed to the danger of electrical
shock, short circuit or a fi re.)
Do not operate this heater in the place where it gets
wet by the humid such as bathroom.
(It may cause an electrical short circuit or an electrical
shock accident)
TIPS BEFORE INSTALLATION ...
1. Make sure the safety in the place where you wish to use this heater.
* The ground surface and surrounding should be plain and non-flammable, and solid.
* You need to have sufficient space surrounding the heater at least 15cm from the wall and the left & right side, at least 1 m distance from the ceiling and the
front side without any obstacle.
* You need to use exhaust duct in case of operating in small spaces. It is recommended but not required. Take a look at the drawing.
(Recommended Duct specification: 75mm (Diameter) x 5meter long-aluminum duct) (Be sure there must not be rain drops into the exhaust duct end.) (You
must ventilate frequently with fresh air by opening window or fan.)
* You must put an extinguisher beside the heater.
* There must not be direct sun light, excessive heat near the heater.
* After you fix the installation, lock the caster for avoiding unexpected movement.
* Do not use this heater near fabric curtain, carpet or plastic or vinyl curtain which may cover the heater in case of falling down by the wind or by any physical
force, which may cause a fire.
* The heater must not be located immediately below a socket-outlet.
* Positioned so that the plug is accessible.
2. You must use Diesel or kerosene as fuel.
* If you use other fuel, it may cause an excessive soot or trouble of malfunction.
* In case of refueling make sure the heater is turned OFF.
* To be made by the manufacturer or his service agent who should be contacted if there is an oil leakage.
* Regulations concerning the disposal of oil when scrapping the appliance have to be followed.
3. The proper electricity is 220/230V, 50Hz. It will be applied and adjusted as per customer’s request.
You must supply power as per its requirement only once it is adjusted.
How to install the product
* Install the heater in the flat area. If you install the heater in sloped area, combustion furnace
may be damaged by the irregular combustion.
* Install the flue tube for the indoor use. If the flue tube passes through the inflammable
wall, wrap the inside wall more than 3cm with nonflammable insulation.
* Use stainless steel tube (75mm diameter) for the flue tube. Length of tube must be shorter
than 4m and number of bent must not exceed 2.
* If the bent number of flue tube is more than 2 or when the length of tube is longer than 4m,
it may cause incomplete combustion.

- 6 -
www.veltron-heaters.com
STRUCTURE & DESCRIPTION
STRUCTURE & DESCRIPTION FOR MODEL
CAUTION
 This design may be changed for improvement of efficiency
Exhaust Duck/Safety Grolle
Wheel
Control Panel
Heating Tube
Combustion furnace
Front Safety Grille
Control
Overheating sensor
Fuse
Burner department
Circulation Fan
Conduction Sensor
Fuel Guage
Fuel inlet
Temperature Sensor
Fuel Filter
1. LED DISPLAY
It displays the status of temperature, time, operation,
and error, etc.
2. ON/OFF
3. TEMP SELECT BUTION
To select temperature control mode
4. TIME SELECT BUTION
To select time control mode
5. UP/DOWN
To set or change the temperature or time
6. IR RECEIVER FOR REMOTE CONTROLLER
7. OFF TIMER
To select whether off timer mode is operated or not.

- 7 -
STOVES & CHIMNEYS
- When heater turns o , the moter (to cool heater) is operated.
- It is dangerous to turn OFF this heater by taking out the power plug. It may cause a malfunction or electrical shock.
Please turn OFF using RUN/STOP button.
- If malfunction cause with power down, this case is in a consumer cost.
STRUCTURE & DESCRIPTION
REMOTE CONTROL
1. ON/OFF
When heater tums ON or OFF, you can this button.
2. OFF TIMER
Every time you press this button, heater repeat set-up and cancel.
3. TIME SELECT BUTTON
To select time control mode
4. TEMP SELECT BUTTON
To select temperature control mode
5. UP/ DOWN
To set or change the temperature or time
 Connect power cord of heater with outlet.
 When you connect power plug, current temperature is displayed.
 When you press UP/DOWN button. the desired temperature is displayed.
 You can set the desired temperature between “0-40°C“ (1 °C per a press)
CAUTION

- 8 -
www.veltron-heaters.com
HOW TO USE
OPERATION & STOP
1. CONNECT POWER PLUG (You can see current temperature)
THEN, PRESS ON/OFF BUTTON
(You can check “set tem/time“-the number of right side)
But, if this heater operate in case  rst use from purchase, turn Air
Screw left around three times and then start with pressing “ON/
OFF“ switch. Heater will be turned ON with “beep“ sound, and
automatically operated. Fasten the air screw after 4 seconds.
If “E1“ error is displayed, press “ON/OFF“ switch one more time.
2. SELECT THE DESIRED OPERATION TYPE USING “TEMP or
TIME“ BUTTON.
3. Set the time or temperature by pressing “Temp select button“ or “Time select button“.
- “Temperature“: You can set the desired temperature between “0~40°C“
- “Time“: Set the desired time limit between “10~25min“ (5min per a press)
Tip
• In order to be operated, the setting temperature should be higher than current temperature.
• After power On, the default mode is temperature control mode.
• During the operation if you push On/O button, the heater is stop and the o timer function is cancelled.
Circulation Fan operate in a minute after turning on heater and stop in two minutes after turning o heater.
(This fan is for circulating heat and for cooling heater)
The model equipped “solenoid valve (by-pass device) makes the remaining oil returned to the oil tank. For 10sec. from the time of
burner o , the solenoid valve is operation, which makes remaining oil returned to the oil tank, and by this device, the smell caused
by unburned gas are remarkably shrunk.
Cur Temp
Cur Temp
Set Temp/Time
Set Temp/Time

- 9 -
STOVES & CHIMNEYS
HOW TO USE
TEMPERATURE CONTROL
1. Push On/O button. 2. By pusing Temperature button, please select Temperature
control mode.
• At that time, Temperature control lamp is lighten.
3. By pushing ““ button, please select desire temperature.
• The setting range: 0~40 °C
• The default value: 25°C
• During the time you push or , the setting temperature is
increased/decreased very fast.
• The range of current temp display –9~50 °C
4. During operaton, the current temp. and setting temp. both
are displayed, and if you push On/O button and make the
operation stop, only current temp. is shown.
5. When the setting temp. is higher 2 °C than current temp.,
it starts operation, and the setting temp. is less than 1 °C
than current temp., the operation is stop.
• Current temp. < Setting temp. … Opeartion (+2°C)
• Current temp. > Setting temp. … Opearation stop (-1°C)
Tip
• The current temp is less than -9°C(16° F), the dispaly of the
temp. is ‘LO’, and more than 50°C(99° F) it dispalys as ‘HI’
(50°C is not same value as 99° F, actually 37°C is same value
as 99° F)
• The setting temperature is increased/decreased 1 °C by
pushing of (/) button, if you push the button more than
for 2sec. the value is increased/decreased 1 °C in 0.2 sec.
• If you push and  button for 5sec. simultaneously, the
unit is converted from °C to °F or from °F to °C (The defaulte
unit is °C)
This mode enables the user set the desired tempera-
ture, and once it is fixed this heater works automati-
cally with running and stop repeatedly to meet this
temperature.
(If power ON and Heater starts operation, the temper-
ature control mode will be operated as default.)

- 10 -
www.veltron-heaters.com
If the following error or trouble signs are displayed on the operation panel
Displayed messages Discription of
troubles Items to check and required actions
E1. No ignition The burner is mis red
- The lack of fuel
- There is Air in the fuel tube (Air Discharge)
- Phototube pollution (Cleaning)
E2. Phototube
(Flame sensor)
Phototube troble
Detrction of residual
 ame
- Unpluged Phototube (→plug), Phototube Trouble (→exchange)
- If the heater is stopped just after ignition, there is re-
sidual  ame (No damage → Re-operation)
E3. Temperature sensor Temperature sensor
trouble
- Check if the temperature sensor connector is loosened.
(Firmly connect the connector if it is loosened)
E4. Overheat sensor Product is overheated
- Check if there are any bump signs inside the burner. (Ask the survice)
- Check if the overheat protector wire is disconnected
(Operate the heater again after connecting the wire)
E5. Slope Tile of heater
- Check if the heater is moved (Tilt may occur when the heater is shaken
or moved. Operate the heater again)
- Inversion switch wire is disconnected (Operate the heater again after
connectong the wire)
E6. Lack of fuel Lack of fuel - Refuel (→ Re-operation)
Hi Temperature
is above 50 °C
- Check if the tempatature sensor is installed inside.
(Install the sensor outside)
- If the troubles E1 - E6 occur, check the causes and take the required action.
If you press the Power Button twice, you may restart the heater
If the troubles persist even after taking the actions as slanted in the below table, ask the survice
Troubles Items to check Required action
All lamps of operation panel
are turned o
- Power failure
- Power plug is unpluged
- Fuse burns out
- Plugning
- Changing Fuse
Lamp si repeatedly turned o
and turned on - Select the time (check the lamp) - Select the temperature
The heather is operated as no
indication of oil stu - Flowmeter wirning is unpluged - Line connection
Something burning smells
during the initial operation - Foreign substances are burnt inside the gasket - To be disappeared after 1 or 2 hours
The fuel smell is unusual
- There is amell when the heater is stoped as soon
as starting
- On oil supply, spilling fuel
- Operate 15’ or more
- Remove spilled oil
Room temperature is higher
than normal one
- Check if the location of temperature sensor
(it may occur if the sensor is installed inside.) - Fix the sensor at the correct position
HOW TO USE
ITEMS TO CHECK BEFORE INFROMING OF TROUBLE

- 11 -
STOVES & CHIMNEYS
To store the heater, cool down the heater and plug out and wrap with plastic cover and keep in the well air- owing place.
- You’d better consume all oil not to remain in.
CAUTION To keep heater in outdoor or humidity place is major cause of problem.
CLEANING & MAINTENANCE
CLEANING & MAINTENANCE
STORING
To pull out the front grille, please
raise a little and pull it out
(Assembly is opposition way.)
In case that you keep the heater for a long time and you want to maintain it in clean status, please power o and cool
down the heater, and pull out the plug as the above picture and clean according to the following instruction.
• Please pull out the front grille by raising it and pull it out to the front.
• Please clean the heating re ection which is in the back side of heater and burner area.
(The burning pipe is coated by ceramic material so careful clean not to damange to the coating.)
 DO NOT DISASSEMBLE THE BURNING PARTS.
• Please wipe out the front controller area with soft wool.
• After  nishing of cleaning, please assemble the front grille to the heater

- 12 -
www.veltron-heaters.com
 CLEAN OF FLAME SENSOR (Cds)
- If the detection part of CdS is contaminated by soot or other dirt, the performance can be lowered and it may cause a
problem.
- Please take out CdS carefully which is placed in lower part of burner.
- Please clean the detection part of CdS by soft clothes.
- Please be sure CdS is  xed correctly.? (Mark “A“ should be inserted fully.)
 CLEAN OF COMPONENTS
- In case you need to change components, please contact us.
- In case repair or exchange of components, please contact the service center operated by our distributor or head o ce
- Do not try to repair this heater by non-licensed service personnel, because it may cause a worse condition, so please
contact local service center, or distributor that is designated by our company.
DAILY CHECK POINTS & ADJUSTMENT
DAILY CHECK POINTS
Soft
clothes

- 13 -
STOVES & CHIMNEYS
 IN CASE OF SUDDEN STOP DURING OPERATION
- Please check if now is operating in the time control operation.? If so, the heater can be rest for 5min.
- Please check if now the setting temp. is less than the current temp.
- Please check if the heater is stop by pressing On/O switch by remote controller or front controller.
- Please check if the heater is stop by sleep timer function.
- Please check if the heater is stop by auto-self-checking.
 AIR FLOW-OUT
In case that Electric pump so noisy and burner no ignition, main cause of the problem is air  ow into the electric pump
and not distribute oil. If oil is all consumed without remaining in the tank, air can be  ow into inside electric pump.
- The method to ow-out air
 Operate the heater
 When the electric pump operated, turn on the air out ow screw to counter-clockwise. And you wait till air  ow out
and oil start to come out.
 When you see oil start to come out, turn o the air out ow screw to clockwise
(In case much air inside, please repeat same way 2~3times.)
 DETAIL OF BURNER STRUCTURE
- When you contact service person with a problem, please refer the below detail structure of the burner.
DAILY CHECK POINTS & ADJUSTMENT
ADJUSTMENT
FUSE(BLZND)
IGNITER
BURNER MOTER
FLAME SENSOR
(phototube)
AIR SCREW
FUEL INLET
TRANSMIT
PREVENT SENSOR FUEL RETURN HOSE
AIR RELEASE SCREW
ELECTRONIC PUMP
FUEL LINE
AIR SUCTION HOLE
FLOWMETER
OVERHEATING SENSOR

- 14 -
www.veltron-heaters.com
TROUBLE SHOOTING
PROBLEM CAUSE SOLUTION
NO OPERATION
No Power supply? Check the power supply is proper.
(ex. 220/230V a.c. 50Hz)
Check power plug is
disconnected Power plug into the outlet
Is the Fuse short? Replace fuse with new one (250V a.c. 3.15A)
NO FAN MOTOR
OPERATED
“Lack of Fuel“ light ON ? Lack of Fuel
Fill it up with Kerosene or Diesel
Do not mix or use together these two dif-
ferent fuel.
Is set temp. lower than
current temp.? Set the temp as higher than current temp.
Mis re lamp ON? Air in the electric
pump.
Remove the air in the electric pump.
(Refer to page 19)
Overheating Lamp ON?
Under operation
of overheating
prevention
Ventilate with fresh air in the room, and
turn OFF the heater for a while
(Refer to page 16)
Inclination display lamp
ON?
Ground surface is in-
clined or not plain
Replace the heater in plain ground
(Refer to page 16)
Can you see“Er2“ on the
display?
Error on Temperature
sensor
Select Timer control operation from tem-
perature control mode.
(Refer to page 16)
NO IGNITION
ON BURNER
Is fuel  lter stu y? Filter is contaminated
Clean the  lter with compressed air, or re-
place with new one.
(Refer to page 18)
Is air suction valve
adjusted excessively or
too small?
Call after sales service agent.
Voltage is low? In case of low voltage Burner will not work properly, so use a
booster to elevate voltage. (A/S)
Please check below points before you think
trouble has been occurred.
Is Power ON? Is Fuel enough? Is Flame sensor clean?

- 15 -
STOVES & CHIMNEYS
TROUBLE SHOOTING
PROBLEM CAUSE SOLUTION
IMMEDIATE
STOP JUST
AFTER IGNITION
“Lack of Fuel“ light ON? Running out of fuel Fill up the fuel.
Check if the fuel is Diesel
or kerosene
It may cause less per-
formance & trouble
Drain the existing fuel, and  ll with Diesel
or kerosene only.
Water or any other
impurities on fuel?
It may cause less per-
formance & trouble Replace the fuel with good quality one.
Is  ame sensor located
well?
In di erent position, it
causes an error. Place the sensor in original location.
Is  ame sensor dirty? Error because of soot
or dirt Call after sales service agent.
Noise in fuel pump? Excessive air in the
pump and nozzle. Remove the air in the electric pump.
EXCESSIVE
SOOT IS
GENERATED
Check if the fuel is Diesel
or kerosene
It may cause less per-
formance & trouble
Drain the existing fuel, and  ll with Diesel
or kerosene only.
Water or any other
impurities on fuel?
It may cause less per-
formance & trouble Replace the fuel with good quality one.
Is air suction valve
adjusted excessively or
too small?
Error on Temperature
sensor Call after sales service agent.
Is tube clogged? Smoke may  ow
backward
Clean the tube by removing soot inside of
tube, or replace with new one.
NOISE IN
BURNER
Is Fuel  lter stu y?
Dirty  lter with
impurities and
contamination.
Clean or replace with new one
Noise in fuel pump? Excessive air in the
pump and nozzle. Remove the air in the electric pump.

- 16 -
www.veltron-heaters.com
SPECIFICATION &
ELECTRICAL WIRING DIAGRAM
Model VHOE-90* VHOE-120* VHOE-150 VHOE-180 VHOE-210 VHOE-250/F** VHOE-350/F**
Fuel Diesel Diesel Diesel Diesel Diesel Diesel Diesel
Heating Output
(kcal/h) 9,000 13,000 15,000 18,000 21,000 25,000 35,000
Calori c power (kW) 10.4 14.0 17.4 20.9 24.4 29.0 40.7
Fuel Consumption (l/h) 1.0 1.2 1.5 1.9 2.1 2.3 2.8
Heating Area 36–53m² 55–88m² 66–133m² 86–196m² 135–237m² 166–280m² 231–330m²
Electric Power
Consumption 50W 50W 50W 65W 65W 115W 120 W
Size (WxDxH) 870 x 280
x 800
940 x 320
x 1020
1290 x 320
x 1020
1290 x 320
x 1190
1290 x 320
x 1190
1340 x 350
x 1510
1370 x 400
x 1800
Weight 42kg 45kg 60kg 63kg 63kg 90kg 116 kg
Used Heating Heating Heating Heating Heating Heating Heating
Power Supply 220V /
50Hz AC
220V /
50Hz AC
220V /
50Hz AC
220V /
50Hz AC
220V /
50Hz AC
220V /
50Hz AC
230 V / 50
Hz AC
Tank Capacity 25 L 30L 45L 45L 45L 80 L 90 L
* pre-heater system
** With Fan
Somke Pipe
(in case of Using)
90mm 100mm 100mm 100mm 100mm 100mm 100mm
Black
Black Black
Black
BR
White
Green
AC 220 V Overheating
Sensor
Conduction
Switch
Flowmeter Temperature
Sensor
Green GreenYellow
Yellow
Brown
Brown
Yellow Black 2P Gray 2P
Red
Flame Sensor
Ignition Trans
Fan Motor
Electronic Lamp

- 17 -
STOVES & CHIMNEYS
WARRANTY CARD
This VELTRON far infrared rays heater gives you more reliable performance and comfortableness, and durabil-
ity the more you use it, because it is produced under the strict quality assuarance system including various
inspection during production and after production and reliance test, etc.
In case you encounter any problem, please contact the local service agent, or a distributor.
If the problem is occurred due to the production failure, or natural malfunctioning, we will o er you free
repair service under our warranty clause.
GENERAL
1. Warranty period is 24 months after purchasing date.
- If the problem is occurred by the mistake or misuse of the customer, we charge a repair cost even if it is
within warranty period.
2. This warranty card is valid within your country.
3. Please keep this warranty card for better service in case of trouble.
4. Please contact your local distributor or after sales service agent.
5. Please  ll out this form after purchase.
DESCRIPTION VELTRON Far Infrared Rays Heater
MODEL VHOE-90 / VHOE-120 / VHOE-150 / VHOE-180 / VHOE-210 / VHOE-250 / VHOE-350
DATE OF PURCHASE PRODUCT
WARRANTY PERIOD ( ) Months PRICE €
DISTRIBUTOR NAME OF COMPANY
TELEPHONE NO.
CUSTOMER
NAME
ADDRESS
TELEPHONE NO.
Official representative:
Veltron International Ltd
Tel.: [phone]
E-mail address: [e-mail]
Address: Pärnu mnt.139/11, Tallinn, Estonia
Manufacture: Made in Korea
