Vemmio HUB 100 User manual

WWW.VEMMIO.COM
gateway
MODEL: HUB 100
V1.0
INTRODUCTION
Thank you for choosing Vemmio! We welcome you in our cus-
tomer society. VEMMIO gateway based on Z-Wave technology
is designed for system management and control. It allows the
user to easily monitor room or building from anywhere via a mo-
bile phone or computer.
PACKAGE CONTENTS:
• user manual
• gateway
• 5V adapter
• ethernet cable
• 2 x screws
• 4 x plugs
KEY FEATURES
• controlupto232Z-Wavedevices
• backupbattery:1hour
• externalUSBport
• easyfixmounting
• builtinsiren
• LEDindication
• WiFi
SPECIFICATION
Operating system Linux
Processor MT7620A 580MHz
Memory (RAM) 128 MB DDR2 RAM / 193
MHz
Memory (flash) Internal mini SD 4 GB
Storage Input/Output USB 2.0 x1
Wireless protocol Z-Wave Plus , 2T2R WiFi IEEE
802.11 b/g/n (>17dBm) Data
rate: 300 Mbps Ethernet
Frequency 868.40 MHz
Network range 50m
Operation temperature 0°C ~ 40°C
Power DC 5V 1A adaptor
Backup battery BT N3650
DIMENSIONS
LED INDICATION
SIDE LED INDICATION
TOP COVER LED INDICATION
DESCRIPTIONS
BOTTOM COVER DESCRIPTION
BACK SIDE DESCRIPTION
GATEWAY INSTALLATION
1. Take the gateway out of the box
2. Connect the power to the Gateway
3. Connect Ethernet cable (check Firewall security settings)
4. Wait for the white LED at the top cover to light up indicating
internet access – necessary for system to start operating
5. Go to app.vemmio.com and register
6. After successful login to app.vemmio.com, tutorial will guide
you through further steps
TROUBLESHOOTING
You are not able to register
•checkyourinternetconnection
You are not able to log in
•checkinternetconnection
•clearyouwebbrowser’scacheandtrytologinagain
You do not receive reports
•IstopcoverLEDlitupindicatingaccesstointernet?
YES:
1. Check if you have included at least one sensor
2. Reset the Gateway wit the RESET button
3. Make sure that your Gateway is not exposed to strong elec-
tromagnetic disrupt.
NO:
1. Check you internet connection
2. Eject and insert Etherner plug RJ45 to your router
3. Check your router settings if IP address from DGCP server
has been assigned
WARRANTY
This Limited Warranty applies to physical goods, and only for
physical goods, purchased from Vemmio (the „Physical Goods”).
This Limited Warranty of Vemmio, applies to products manufac-
tured and distributed by Vemmio.
PRODUCTS COVERED AND DURATION OF WARRANTY
Warranty Period: 12 months for business customer and 24
months for individual customer from the date of purchase.
The product purchased shall be free from defects in material
and workmanship from the date of purchase.
This Limited Warranty covers any defects in material or work-
manship under normal use during the Warranty Period.
PRODUCTION STATUS
Each product is manufactured from new parts.
TERMS OF THE WARRANTY
Vemmio warrants that the product you have purchased from
VemmiooraVemmio’sauthorizedresellerisfreefromdefects
in materials and workmanship under normal use during the
warranty period. The warranty period begins on the day of pur-
chase. The warranty extends only to the original purchaser. It
is not transferable to anyone who subsequently purchases the
product from the original purchaser.
During the Warranty Period, Vemmio will repair or replace (at
the sole discretion of Vemmio), at no charge, products or parts
of a product that proves defective. Once the defected product,
during the guarantee period, is returned, it will be repaired or
replaced no later than within 30 days. The warranty period is
extended by the amount of days it has taken to repair or replace
the product.
All used elements changed under the guarantee become the
property of Vemmio. The warranty period for replaced ele-
ments expires on the same date as the original warranty period
1. 2.
Your login
Password
Log in
Forgot your password?
Click here to register
1 2 3
20 characters UID necessary
to register with app.vemmio.com
UID 20 characters are located
either on the Gateway
or on the box
1 – Gateway reset
2 – Ethernet RJ45
3 – WPS
1. Z-Wave LED
- Fast flashing: Exlusion mode
- Slow dimming: Inclusion mode
- Recurring dimming: Z-Wave network normal operation
1
– Power DC 5V
2 – USB port
1
WiFi LED:
- no LED light: Gateway works in a STA mode
- LED lit up: Gateway works in Access Point mode
2 Ethernet LED
- LED lit up: Ethernet connection is not available
- LED flashing: Ethernet to Gateway connection in progress
3 Power LED
- LED lit up: powered on either by mains electricity or backup battery
- no LED light: no mains electricity, no backup battery power
