Vent+Cover Baseboard Heater Cover Installation and operating instructions

Baseboard Heater
Covers
WHEN USIN ELECTRICAL APPLIANCES, BASIC PRECAU-
TIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE
THE RISK OF FIRE, ELECTRIC SHOCK, AND INJURY TO
PERSONS, INCLUDIN THE FOLLOWIN :
1. Read all instructions before installing or using the heater cover.
2. Sharp edges and corners may be present on the baseboard cover
panel, When installed correctly any sharp edges will be covered
by the proper endcaps. Please use caution when
installing baseboard covers to avoid injury.
5.This heater cover is hot when in use. To avoid burns, do not let
bare skin touch hot surfaces. Keep combustible materials, such
as furniture, pillows, bedding, papers, clothes, and curtains away
from heater.
3.To prevent a possible fire, do not block air intakes or
exhaust in any manner.
4.Do not insert or allow foreign objects to enter any ventilation or
exhaust opening as this may cause an electric shock or fire, or
damage the heater.
!
WARNIN
ENERAL
This heater cover is designed to provide proper airflow around the finned tube element in residential and commercial baseboar heater
applications. A thermostat is not provided with this cover. Installation or use of this product in any manner not described herein will void the
warranty and could result in injury, damage to property, or permanent damage to cover and/or heater.
Installation & Maintenance Instructions
IMPORTANT INSTRUCTIONS
SAVE THESE INSTRUCTIONS
1-844-567-5050 | ventandcover.com
Standard lengths: Available from 3' to 7' in 12" increments. When two or more
covers occur in a run, a coupler is to be used at joints.

UNPACKIN
Check heater cover to make sure it has not been damaged in shipping.
Do not install or attempt to operate heater if damaged. Return to place
of purchase or file claim with freight carrier.
INSTALLATION INSTRUCTIONS
Minimum Clearance
Cover to Wall: When an open style endcap will not fit due to an
insufficient amount of clearance between the side edge of the
back plate and a perpendicular wall you may require a Zero
Clearance endcap (ZC001). When installed in the same way as a
regular endcap the Zero Clearance endcap is visually
indistinguishable from a normal EC001 endcap.
Furniture: maintain at least 6 inches (152 mm) space
between furniture and heater cover to allow for proper air
flow.
1. Remove existing metal front cover and end caps and
discard. Measure the length of the existing baseboard
heater enclosure (the metal part that is attached to the wall)
from left to right.
2
2. Install new baseboard panel by slipping it over the old wall
plate and push down to secure it in place. The 3/4 inch lip
on the bottom of the cover panel keeps the cover in place-
allowing it stay securly installed.
3. Install the endcaps, make sure to snap into place using the
lip at the bottom of the endcap
4. Slide the endcap to meet the exact end-to-end span you
require.
Vent & Cover
1-844-567-5050
ventandcover.com
Cleaning:You can perform some basic cleaning of the heater
cover. The panel and endcaps may be cleaned using a slightly
damp cloth.
Do not use abrasive cleaners or waxes as these may damage
the finish or leave a residue that will discolor.
Joining Panels: When joining 2 or more baseboard cover
panels together you will require a coupler CP001. The coupler
is used for connecting lengths of panels together seamlessly.
To install the coupler piece simply fit the piece where the two
panels meet and snap in place.
Wall Brackets: OPTIONAL method of installation. Wall brackets
are used when the original covers are less than 7-1/2 Inches tall
or in the event that the original covers have already been
removed. You will need 2 brackets (put one at each end) if the
baseboard heater cover is less than 5 feet long. If you are
purchasing a 5, 6, or 7 foot baseboard heater cover, you will need
3 brackets per unit (put one at each end and one in the middle of
the unit).
The wall brackets come with the no. 7 screw you will need and it
is highly recommend to screw the brackets into a stud.
**NOTE: If the measurementis greater than 7 feet long you
will need to install more than one panel joined with an
optional coupler piece # CP001 (See 'joining panels'
Wall Bracket Coupler
Inside
Corner 90
degrees
Inside/Outside corners: Used when two lengths of baseboard heaters meet at a 90 degree angle.
Inside & Outside Bay Window Corners: Used when two lengths of baseboard heaters meet in a bay window at a 135 degree angle.

3
LIMITED WARRANTY
All products manufactured by Vent and Cover are warranted against defects in workmanship and materials for one year from date of installation. This warranty does
not apply to damage from accident, misuse, or alteration; nor where the connected voltage is more than 5% above the nameplate voltage; nor to products
improperly installed or wired or maintained in violation of the product’s installation instructions.
The customer shall be responsible for all costs incurred in the removal or reinstallation of products, including labor costs, and shipping costs incurred to return products to
Vent and Cover.
THE ABOVE WARRANTIES ARE IN LIEU OF ALL OTHER WARRANTIES EXPRESSED OR IMPLIED, AND ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE WHICH EXCEED THE AFORESAID EXPRESSED WARRANTIES ARE HEREBY DISCLAIMED AND EXCLUDED FROM
THIS A REEMENT. VENT AND COVER SHALL NOT BE LIABLE FOR CONSEQUENTIAL DAMA ES ARISIN WITH RESPECT TO THE PRODUCT, WHETHER
BASED UPON NE LI ENCE, TORT, STRICT LIABILITY, OR CONTRACT.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above exclusion or limitation may not apply to you. This warranty gives
you specific legal rights, and you may also have other rights which vary from state to state.
01/14
ECG39736
HOW TO OBTAIN WARRANTY SERVICE AND
WARRANTY PARTS PLUS ENERAL INFORMATION
1. Warranty Service or Parts
2. Purchase Replacement Parts
3. eneral Product Information
1-844-567-5050
[e-mail]
www.ventandcover.com
Note: When obtaining service always have the following:
1. Model number of the product
2. Date of purchase
3. Part number or description
