Vents-us VKP 100 Operating and maintenance instructions

www.ventsus.com
MIU_15,16_VKP,VKPF-01
Bodor Vents, LLC DBA: VENTS-US
11013 Kenwood Road Cincinnati, Ohio 45242
Phone: [phone]
e-mail: [email protected]
INSTALLATION GUIDE
Tools required
Pencil Drill
Ø6 mm
Screwdriver Dowel 4 pcs
NTW 6/35
Screws 4 pcs
4/35
IN-LINE CENTRIFUGAL FAN
VKP 100
VKP 125
VKP 150
VKP 125/125x2
VKP 150/150x2
VKPF 100/100x2
VKPF 125/125x2
MOUNTING
Typical Fan installation

www.ventsus.com
MIU_15,16_VKP,VKPF-01
Bodor Vents, LLC DBA: VENTS-US
11013 Kenwood Road Cincinnati, Ohio 45242
Phone: [phone]
e-mail: [email protected]
The process of fan mounting with the use of a bracket together with four screws and dowels is shown in Fig. 1-4.
1. Mark fastening holes 2. Drill fastening holes
3. Install the casing on the mounting bracket 4. Tighten the screws
The process of ventilation shaft attachment is shown on Pic. 5-6. Air flow direction should match the direction of an arrowhead placed on the fan case.
5. Connect air ducts 6. Fix air ducts with clamps

www.ventsus.com
MIU_15,16_VKP,VKPF-01
Bodor Vents, LLC DBA: VENTS-US
11013 Kenwood Road Cincinnati, Ohio 45242
Phone: [phone]
e-mail: [email protected]
Fan connection
N
L
L
X
QF
~
blue
black
yellow-green
N
brown
5
1
17
16
15
QF
4
3
2
Input: 120 V AC 60 Hz. Fans are designed for continuous operation without
disconnection from network. Wiring diagram is shown on Pic.1.
To connect the fan to the power network it is necessary to:
- shut off the power network (Pic.2);
- remove the cover from the terminal box (Pic.3);
- remove the clamping bar (Pic. 3);
- lay out the cables through the terminal box lug, remove the insulation from
the cables ends for ¼ of an inch (6-7mm) length, connect them to proper
terminals up to the stop of insulation and fix with screws (Pic.4);
- place back the clamping bar, tighten up the lug and install the cover on
the terminal box (Pic.5).

www.ventsus.com
MIU_15,16_VKP,VKPF-01
Bodor Vents, LLC DBA: VENTS-US
11013 Kenwood Road Cincinnati, Ohio 45242
Phone: [phone]
e-mail: [email protected]
Fan connection only for VKPF 125/125х2
N
L
L
X
QF
~
blue
black
yellow-green
N
brown
10
6
17
16
15
QF
9
8
7
Input: 120 V AC 60 Hz. Fans are designed for continuous operation without
disconnection from network. Wiring diagram is shown on Pic.6.
To connect the fan to the power network it is necessary to:
- shut off the power network (Pic.7);
- remove the butterfly screw on the inpection cover and disconnect the
inspection cover from the case (Pic.8);
- remove the insulation from the cables ends for ¼ of an inch (6-7 mm)
length, connect them to proper terminals up to the stop of insulation and fix
with screws (Pic.9);
- fix the inspection cover on the case using the butterfly screw (Pic.10).
