Vents VUT V mini EC User manual

USER'S MANUAL
VUT V mini EC
VUT H mini EC
HEAT RECOVERY AIR HANDLING UNIT

2
CONTENTS
Introduction
Use
Delivery set
Designation key
Main technical parameters
Safety requirements
Design and operating logic
Mounting and set-up
Condensate drain
Connection to power mains
Unit control
Maintenance
Troubleshooting
Storage and transportation rules
Manufacturer’s warranty
Acceptance certicate
Mounting certicate
Warranty Card
3
3
3
3
4
5
6
7
8
9
10
11
12
12
13
13
13
14

3
VUT mini EC
VUT mini EC
INTRODUCTION
This user’s manual includes technical description, operation, installation and mounting guidelines, technical data for the heat
recovery air handling unit VENTS VUT…mini EC, hereinafter the unit.
The heat recovery unit is designed to save heat energy by means of heat energy utilization and is one of the energy saving components
used in buildings and premises.
The unit is a component unit and is not designed for independent operation.
The unit enables continuous air exchange by means of mechanical ventilation in private residences, oces, hotels, cafes, conference
rooms as well as recovery of the waste heat energy contained in the extract air to warm up the clean supply air.
The unit is rated for continuous operation always connected to power mains.
Unit - 1 item;
Sped controller R-1/010 - 1 item;
User’s manual - 1 item;
Packing box - 1 item.
DESIGNATION KEY
USE
THE UNIT IS NOT INTENDED TO BE USED BY CHILDREN, PHYSICALLY OR MENTALLY DISABLED PERSONS,
PERSONS WITH SENSORY DISORDER, PERSONS WITH NO APPROPRIATE QUALIFICATION.
ANY OPERATIONS WITH THE UNIT MUST BE PERFORMED ONLY BY PROPERLY QUALIFIED PERSONNEL AFTER
THE APPROPRIATE SAFETY BRIEFING.
THE UNIT INSTALLATION SITES MUST PREVENT ACCESS BY UNATTENDED CHILDREN.
DELIVERY SET
Motor type
 - electronically commutated motor
Spigot orientation
V - vertical;
H - horizontal.
Air capacity [m3/h]
200; 300
Unit type
VUT - heat recovery ventilation
VUT   mini 

4
The unit is designed for indoor application with the ambient temperature ranging from +10 °C up to +40 °C and relative humidity
up to 80%.
The unit is classied as a class I electric appliance.
Hazardous parts access and water ingress protection standard:
Unit motors - IP 44;
Unit assembly connected to air ducts - IP 22.
Main overall and connecting dimensions, outer view and technical parameters are shown in g. 1 and tables 1,2.
The unit design is regularly improved, so some models may slightly dier from those ones described in this manual.
TECHNICAL PARAMETERS
Fig. 1. Unit overall dimensions
Table. 1. Unit overall dimensions
Model Dimensions [mm]
ØD B B1 B2 B3 H1 H2 H3 L L1 L2
VUT 200 H mini EC 99 278 200 121 192 431 84 191 699 640 600
VUT 300 H mini EC 124 278 200 139 139 431 89 296 699 640 600
Model Dimensions [mm]
ØD B B1 B2 B3 H H1 L1 L2 L3 L4 L5 L6
VUT 200 V mini EC 99 278 200 109 169 481 431 640 600 73,5 204 396 526,5
VUT 300 V mini EC 124 278 200 100 178 481 431 640 600 74 210 390 526

5
VUT mini EC
VUT mini EC
Table 2. Technical characteristics
VUT
200 H mini EC
VUT
200 V mini EC
VUT
300 H mini EC
VUT
300 V mini EC
Supply voltage, 50 Hz [V] 1~ 230 1~ 230
Max. fan power [W] 2 items х 105 2 items х 105
Fan current [A] 2 items х 0,9 2 items х 0,9
Total unit power [W] 210 210
Total unit current [A] 1,80 1,80
Max. air capacity [m3/h] 240 345
RPM [min-1] 3550 3570
Noise level 3 m, [dB(A)] 24-45 28-47
Transported air temperature [°C] from -25 up to +60 from -25 up to +60
Casing material Zinc aluminium Zinc aluminium
Insulation 20 mm mineral wool 20 mm mineral wool
Filter: extract/supply panel G4 type panel G4 type
Replaceable lter* SF VUT mini G4 SF VUT mini G4
Summer block* VL VUT mini VL VUT mini
Connected air duct diameter [mm] Ø100 Ø125
Weight [kg] 30 30
Heat recovery eciency up to 85% up to 85%
Heat exchanger type Cross ow Cross ow
Heat exchanger material aluminium aluminium
*extra replaceable lter sets and summer blocks are the specially ordered items and are available upon separate order
SAFETY REQUIREMENTS
Installation and operation of the unit shall be performed in accordance with the present user’s manual as well as the provisions of all
the applicable local and national construction, electrical and technical codes and standards.
The unit is classied as a class I electric appliance.
The unit must be grounded!
Before connecting the unit to power mains make sure that the unit is free of any visible damages or any other foreign objects inside
the casing that can damage the impeller blades.
Mounting and connection of the unit to power mains only by duly qualied electricians with valid electric work permit!
The unit is not rated for operation in an environment that contains toxic or aggressive substances as acids, alkalis, organic solvents,
soot, paint as well as sputtered particles of explosive or aggressive substances. The unit is not rated for use in areas where atmospheric
conditions are determined by sea climate or hot springs.
DISCONNECT THE UNIT FROM POWER SUPPLY PRIOR TO MOUNTING, MAINTENANCE, CONNECTION AND
REPAIR WORKS!
DO NOT!
• DO NOT OPERATE THE UNIT BEYOND THE SPECIFIED TEMPERATURE RANGE OR IN AN AGGRESSIVE AND
EXPLOSIVE MEDIUM!
• DO NOT CONNECT CLOTHES DRYERS OR SIMILAR EQUIPMENT TO THE VENTILATION SYSTEM!
• DO NOT OPERATE THE UNIT IN THE AIR AND DUST MIXTURE MEDIUM!

6
DESIGN AND OPERATING LOGIC
The unit has the following operating logic, g. 2:
Warm stale extract air from the room ows through the air ducts to the unit, where it is ltered, then air ows through the heat
exchanger and is exhausted outside by the extract fan through the air ducts.
Clean cold air from outside is moved by the supply fan to the unit, where from it is directed to the supply lter. Then ltered air ows
through the heat exchanger and moves to the room through the air ducts.
Heat energy of warm extract air is transferred to clean intake fresh air from outside and warms it up. Heat recovery minimizes thermal
energy losses, energy demand and operating costs for air heating accordingly.
The air handling unit construction includes specially designed and sealed service panels for repair and preventing operations. The
terminal block on the side panel incorporates a terminal block. Power and ground cables are connected to the terminal block through
the sealed electric lead-ins.
Fig. 2. Design and operating logic
EXTRACT AIR
SUPPLY AIR
INTAKE AIR
EXHAUST AIR
VUT H mini EC
Supply fan
Extract fan
Heat exchanger
Drain pan
Thermostatic switch
Supply lter
Extract lter
Terminal box
Condensate drain pipe
Supply fan
Heat exchanger
Drain pan
Thermostat switch Condensate drain pipe
Terminal box
Extract lter Supply lter
EXHAUST AIR
INTAKE AIR
EXTRACT AIR
SUPPLY AIR
VUT V mini 
Extract fan

7
VUT mini EC
VUT mini EC
MOUNTING AND SETUP
The unit is designed for suspended mounting by means of the threaded rod xed in the threaded dowel pin. The unit is also suitable
for rigid xation on a horizontal plane, g. 3.
While mounting the unit provide the minimum required access to the unit for maintenance and repair. The required minimum
distances from the unit to the wall is shown in g. 3-5.
Fig. 3. Minimum distance for service access
min 600 mm
Fig. 4. Unit suspended mounting
VUT V .. mini EC
min
400 mm
min 80 mm
VUT H .. mini EC
Unit suspended mounting

8
Fig. 5. Unit mounting on a horizontal plane
VUT V .. mini EC VUT H .. mini EC
Un
i
t mount
i
ng on a
h
or
i
zonta
l
p
l
ane
Safety precautions:
The unit is designed for mounting on a rigid and stable structure. Prior to mounting check the technical specications and
the unit weight.
The unit is mounted with anchor bolts. Make sure that a mounting construction has sucient load capacity matching the unit weight.
Otherwise reinforce an installation place by beams, etc. Then insert the threaded rods xed inside the threaded expansion anchors in the
ceiling. If the threaded bolts used for the unit mounting are too short the unit can generate abnormal noise and resonate with the ceiling.
While mounting the unit ensure enough access for the unit servicing and provide an inspection hole for servicing of the
lters, heat exchangers and the fans. Each unit must be serviced by the individual hole. For more details, refer to the outline
drawing, g. 1.
Install M8 anchor bolts. Install an anchor bolt M8 into the xation for the ceiling suspension mount and x it with nuts and washers.
Make sure of no foreign objects (e.g., foil or paper) inside the unit casing before installation.
If the fastening bolts used for the unit mounting are too short, the unit may generate abnormal noise and resonate with the
ceiling.
If the unit connection place to the spiral seam duct is supposed to be the source of abnormal noise, install a exible air duct instead
of the exible one. Normally this measure is enough to troubleshoot the resonance.
Optionally the exible connectors may also be used to prevent resonating.
Access to the unit must be prevented by installing a protecting grille or any other device with the mesh width up to 12.5 mm.
The unit must be connected to sewage system, g.6. Connect the pipe, U-trap (not included in delivery package) and sewage
collection system with metal, plastic or rubber connecting pipes. The pipe slope downwards must be at least 3°. Fill up the system with
water before connecting the unit to the power mains! The U-trap must be lled with water at all times during the unit operation. Make
sure that the water ows freely into the sewage collection system or otherwise condensed water may build up in the unit during the heat
exchanger operation.
The condensate drainage system is designed for normal operation in premises with air temperatures above 0 °C.
If the expected air temperatures are below 0 °C the condensate drainage system must be equipped with heat insulation and pre-
heating facilities.
CONDENSATE DRAINAGE
DO NOT CONNECT SEVERAL DRAIN PIPES FROM SEVERAL AIR HANDLING UNITS TO ONE UTRAP!
DIRECT CONDENSATE OUTSIDE WITHOUT CONNECTION TO DRAIN SYSTEM IS NOT ALLOWED!

9
VUT mini EC
VUT mini EC
Fig. 6. Condensate drainage
Drain pipe
U-trap
Sewage system
1°.. 3°
120 mm
80 mm
CONNECTION TO POWER MAINS
The unit is rated for connection to single-phase ac 230 V / 50 Hz power mains.The connection must be made using durable, insulated
and heat-resistant conductors (cables and wires) with min. cross section 0.75 mm2.
The given conductor sections are for reference only. The conductor section selection shall account for the wire type, maximum
permissible wire heating, insulation, length and installation method.
Use only copper core wires.
The unit must be properly earthed.
Connect the unit to power mains on the terminal block located in the terminal box in compliance with the wiring diagram and
terminal marking, g. 7. Connect all the control and power cables in compliance with the terminal marking!
The terminal marking is shown inside of the terminal box. The unit terminal clamps are marked according to the marking on the
wiring diagram.
Route the wires to the terminal box through the cable gland on the unit side panel to preserve the electrical protection class.
Connect the unit to power mains through the external automatic circuit breaker with magnetic trip integrated into the xed wiring
system with the rated current not below the rated current consumption (above 2.5 A).
THE POWER MAINS CONNECTION SHALL ONLY BE PERFORMED BY QUALIFIED PERSONS AFTER CAREFUL STUDY
OF THE USER’S MANUAL.
THE UNIT IS INTENDED FOR AC MAINS SUPPLYING THE VOLTAGE COMPLIANT WITH THE TECHNICAL
SPECIFICATION CHART.
CHECK THE CABLE FOR CHOKING.
DO NOT SWITCH ON THE UNIT IF THE CABLE IS DAMAGED. NEVER UNPLUG THE UNIT FROM THE SOCKET WITH
WET HAND OR BY HOLDING THE ELECTRIC CABLE.
DISCONNECT THE UNIT FROM POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT!
THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE MANUFACTURER’S LABEL. ANY
TAMPERING WITH THE INTERNAL CONNECTIONS IS PROHIBITED AND WILL VOID THE WARRANTY.

10
Fig. 7. Wiring diagram
CTR
+10V
GND
N
PE
L
N
PE
X1
L
~230 V/50 Hz
X1 - terminal block for cable connection
R-1/010 speed controller
UNIT CONTROL
Smooth speed control is performed with the R-1/010 speed controller, hereinafter the speed controller, g. 8.
The speed is controlled from minimum to maximum value by rotating the control dial.
Install the speed controller in an easy operated place. The speed controller is pre-wired to the terminal block located in the terminal
block on the unit side panel in compliance with g. 8.
Fig. 8. R-1/010 speed controller and wiring diagram
CTR
+10 V
GND
N
PE
L
X1
A2
CTR
+10 V
GND
1
2
3
4
5
6
R-1/010 speed controller Speed controller wiring diagram
The freeze protection thermostat is installed in the exhaust air duct downstream of the heat exchanger. In case of a freeze danger
the thermostat switches the supply fan o and the heat exchanger is warmed up with warm extract air ow, g. 2. Rotate the thermostat
control dial to set the operation temperature of the thermostat sensor. The thermostat set point is selected individually depending on
the unit operating specics.
The recommended thermostat operating temperature is +3 °C (factory setting).

11
VUT mini EC
VUT mini EC
MAINTENANCE
The unit must undergo technical maintenance 3 to 4 times a year. Maintenance includes general cleaning of the unit and the
following operations:
1. Filter maintenance (3-4 times per year).
Contaminated lters increase air resistance thus impairing supply air delivery into the premises. The lters should be cleaned as they
get dirty, but at least 3-4 times a year. Clean the lter with a vacuum cleaner or replace the worn lter with a new one. For new lters
contact your Seller.
2. Heat exchanger maintenance (once per year).
Even regular technical maintenance may not completely prevent dirt accumulation on the heat exchanger casing. Clean the heat
exchanger on a regular basis to ensure high heat recovery eciency. To clean the heat exchanger remove it from the unit and wash with
warm neutral detergent solution. Re-install the dry heat exchanger into the unit.
Removing of the lters and the heat exchanger is as following:
make sure the unit is disconnected from power mains;
undo two clips that x the front panel to open the unit, g. 9.1. The hinged panel is opened, g. 9.2.
remove the lters, g. 9.3.
remove the heat exchanger, g. 9.4.
3. Fan maintenance (once a year).
Even regular technical maintenance of the lters may not completely prevent dirt accumulation in the fans which reduces the fan
capacity and impairs supply air delivery into the premises. Clean the fans with rugs or a soft brush. Do not use water, aggressive solvents
or sharp objects as they may damage the impeller.
4. Condensate drain check (once a year).
The condensate drain (line) may get clogged by dirt and dust particles contained in the exhaust air. Check the drain line operation by
lling the drain pan under the unit with water, clean the U-trap and the drain line, if necessary.
5. Fresh air supply duct check (twice a year).
The supply duct grille may get clogged with leaves and other objects reducing the unit performance and supply air delivery. Check
the supply duct grill twice a year and clean it as required.
6. Duct system check (every 5 years).
Even regular fullling of all the prescribed above maintenance operations may not completely prevent dirt accumulation in the air
ducts which reduces the unit capacity. The air duct maintenance includes their periodic cleaning or replacement.
7. Maintenance of the exhaust louve shutters and supply diusers (as required).
Remove the disc valves and the louvre shutters and wash those with warm detergent solution. Do not change the positions of the
disc valves and the louvre shutters.
Fig. 9. Unit maintenance
1. 2.
3. 4.

12
TROUBLESHOOTING
Table 3
Fault Possible reasons Fault handling
The fan does not
start up during
the unit start-up.
No power supply. Make sure that the unit is properly connected to power mains and make
any corrections, if necessary.
Motor is jammed, the impeller are clogged. Turn the unit o. Troubleshoot the motor jam and the impeller clogging.
Clean the blades. Restart the unit.
Automatic
switch tripping
following the unit
turning on.
Overcurrent resulted from short circuit in the
electric circuit. Turn the unit o. Contact the service centre.
Low air ow.
Low set fan speed. Set higher speed.
The lters, the fans or the heat exchanger are
dirty. Clean or replace the lter, clean the fans and the heat exchanger.
The ventilation system components (air ducts,
diusers, louver shutters, grilles) are clogged or
damaged.
Clean or replace the ventilation system components, such as air ducts,
diusers, louver shutters, grilles.
The air dampers, diusers or the louvre shutters
are closed.
Make sure the air dampers, diusers or the louvre shutters are fully
opened.
High noise,
vibration.
The impeller(s) are soiled. Clean the impeller(s).
The screw connection is too loose. Tighten the fan or casing screw connection against stop.
No anti-vibration dampers. Install anti-vibration rubber mounts.
Water leakage. The drain pipe is clogged, damaged or wrong
mounted.
Clean the drain line, if necessary. Check the drain line slant, inspect the
U-trap and make sure the drain line is equipped with frost protection.
Possible faults and troubleshooting
STORAGE AND TRANSPORTATION RULES
Store the unit in the manufacturer’s original packing box in a dry ventilated premise at the temperatures from +10 °C up to +40 °C.
Storage environment must not contain aggressive vapours and chemical mixtures provoking corrosion, insulation and sealing
deformation.
Use hoist machinery for handling and storage operations to prevent the unit damage. Full the handling requirements applicable
for the applicable freight type.
Transportation with any vehicle type is allowed provided that the unit is protected against mechanical and weather damage. Avoid
any mechanical shocks and strokes during handling operations.

13
VUT mini EC
VUT mini EC
MANUFACTURER’S WARRANTY
The manufacturer hereby warrants normal operation of the unit over the period of 24 months from the retail sale date provided the
user’s observance of the transportation, storage, installation and operation regulations.
In case of no conrmation of the sales date the warranty period is calculated from the manufacturing date.
In case of failures in the unit operation during the warranty period the manufacturer will accept reclamations and complaints from the
owner of the device only after receiving technically sound act with detailed description of the failure.
Unit damage as a result of unauthorized tampering with the circuit diagram is not a warranty case.
For warranty and post-warranty services of the unit please contact the product manufacturer.
In case of warranty claim please submit the present user’s manual with the seller’s stamp, lled connection certicate and warranty
card.
Warranty repair services and post-warranty services are fullled at the manufacturing facility.
WARRANTY CLAIMS ARE ACCEPTED WITH THIS USER’S MANUAL AND FILLED CONNECTION CERTIFICATE ONLY.
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY MECHANICAL OR PHYSICAL DAMAGES RESULTING FROM
THE MANUAL REQUIREMENTS VIOLENCE, THE UNIT MISUSE OR GROSS MECHANICAL EFFECT.
FULFILL THE REQUIREMENTS SET IN THE USER’S MANUAL TO ENSURE PROPER FUNCTIONING OF THE UNIT.
This is to certify that the air handling unit VUT _____ mini EC has been connected to power mains pursuant to the requirements
stated in the present user’s manual by a qualied technician:
ACCEPTANCE CERTIFICATE
CONNECTION CERTIFICATE
The air handling unit with heat recovery VUT _____ mini EC
has been duly certied as serviceable.
The product complies with the requirements according to the EU norms and directives, to the relevant EU-Low Voltage Equipment
Directives, EU-Directives on Electromagnetic Compatibility.
We hereby declare that the following product complies with the essential protection requirements of Electromagnetic Council
Directive 2004/108/EC, 89/336/EEC and Low Voltage Directive 2006/95/EC, 73/23/EEC and CE-marking Directive 93/68/EEC on the
approximation of the laws of the Member States relating to electromagnetic compatibility. This certicate is issued following test
carried out on samples of the product referred to above. Assessment of compliance of the product with the requirements relating to
electromagnetic compatibility was based on the above standards.
Acceptance Inspector’s Stamp Date of manufacture_______________________
Sold by
Name and stamp of trade company
________________________________________________________________________________________________________________
Date of sale_________________________
Company:________________________________________________________________________________________________________
Name___________________________________________________________________________________________________________
Date____________________Signature________________________________________________________________________________
________________________________________________________________________________________________________________
________________________________________________________________________________________________________________

14
WARRANTY CARD
____________________________________________________________________________________________________
____________________________________________________________________________________________________
____________________________________________________________________________________________________
____________________________________________________________________________________________________
____________________________________________________________________________________________________
____________________________________________________________________________________________________
____________________________________________________________________________________________________
__________________________________________________________________________________________
NOTES
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________

15
VUT mini EC
VUT mini EC

2014
V39EN-03
