VeriSmart EcoHeat C3 User manual
Installationandusermanual
Pleasereadcarefullyandretainforfuturereference
ModelsEcoHeat:
C3,C5,C6,C8,C9,C11,C12
Rev.1_09-07-15 Page 1
TableofContents
1 IMPORTANT:WARNINGS
1.1 GENERALSAFETYCONDITIONS
1.2 SPECIFICSAFETYINSTRUCTIONSFORTHISDEVICE
2 INSTALLATION
3 WALLMOUNTING
4 DIGITALPROGRAMMABLETHERMOSTAT
4.1 Operation
4.2 Screen
4.3 Keypad
4.4 Firstuse
4.4.1 TurningtheradiatorOn/Off
4.4.2 SettingtheTimeandDate
4.5 OperationModes
4.5.1 TimerMode:
4.5.2 ManualComfortMode
4.5.3 AutomaticMode
4.5.4 ECOmode:
4.5.5 FrostProtectionmode:
4.5.6 ProgrammeMode:
4.5.7 USERProgrammesfromU1toU4:
4.5.8 ConsumptionControlMode
5 SpecialFunctions
5.1 Keypadlock:“”
5.2 WindowOpeningFunction
6 SystemSettingsMenu
7 Troubleshooting
8 PresetProgrammes(P1toP9)
Rev.1_09-07-15 Page 2
1IMPORTANT:WARNINGS
Thank you for purchasing this radiator. These appliances
are extremely safe, easy to install and do not require
specific maintenance. They are manufactured from
aluminium, a highly durable and environmentally friendly
material.
Before turning it on for the first time, read these instructions
carefully.Pleasekeepthesesafeforfuturereference.
1.1 GENERALSAFETYCONDITIONS
1. Before connecting the appliance, make sure the mains
voltage is the UK standard 230 Volts and that the
poweroutlethasanefficientearth.
2. Check that the power is sufficient to supply the
appliances. The total draw of the radiators' currents
must not exceed the capacity of the circuit breaker that
protectsthem.
3. This radiator can not be used in rooms with presence of
gasesorotherflammableproducts(glues,etc...).
4. WARNING: To prevent overheating, do not cover the
device.Donotusethedevicetodryclothes.
5. Make sure the power cable or other objects do not
come into contact with the radiator surface while in
operation.
6. To disconnect the radiator from the power supply pull
theplug,neverthecable.
7. If the power cable becomes damaged it must be
replaced by the manufacturer or a suitably qualified
Rev.1_09-07-15 Page 3
trades person. Failure to comply may danger your
safetyandvoidsyourwarranty.
8. Children under the age of three should not be allowed
to touch or play with the radiator and should be
supervisedatalltimes.
9. This device can be used by children under 8 years of
age, as well as by people with reduced physical,
sensory or mental capabilities when suitably supervised
and only when they have been provided the instructions
regarding the use of the device and have understood
the risks that could derive from it. Cleaning must only
becarriedoutbyanappropriateadult.
10. Radiators should always be securely installed onto a
wall especially when installed in childrens’ rooms,
communalareasandlivingrooms.
11. PRECAUTION: Some parts of this product can
reach very high temperatures and cause burns. Pay
special attention when children or vulnerable
peoplearearound.
12. Donotplacethedevicestraightunderapowersocket.
13. Warning: Do not use this heater near baths, showers
or swimming pools. It should not be possible to access
the device's controls from the bath, shower or any other
surface that is in contact with water. (Its use in zones 0
or 1 in bathrooms is totally prohibited: seek advice from
aqualifiedelectrician).
14. For greater safety, this appliance is provided with a
device that interrupts its operation in the case of
overheating.
15. This radiator has been designed exclusively to be fixed
to the wall. For further information on the fixing
systems, consult the section "INSTALLATION AND
WALLMOUNTING"ofthismanual.
Rev.1_09-07-15 Page 4
16. Keep all the packaging elements out of the reach of
children, as they can cause potentially dangerous
situations.
17. Keep these instructions, as well as the guarantee, your
invoice and if possible, the complete packing with all
theelementsinside.
18. Use this device only for domestic / light commercial use
and the tasks for which it has been designed. This
device has not been designed for industrial use. It
must not be used outdoors, in greenhouses or for
animal husbandry. Keep it away from heat, direct
sunlight, humidity and cutting tools. Do not under any
circumstances immerse in water or use this device with
wet hands. In the case of humidity or water in the
device, immediately disconnect the power supply and
donottouchthewetparts.
19. Do not use accessories that have not been
recommended by the manufacturer, as they could entail
apotentialrisktotheuser,anddamagethedevice.
20. Check the device and the cable regularly. Do not turn
thedeviceonifitisdamaged.
21. Do not attempt to service the device yourself. Contact a
qualifiedtechnician.
22. The guarantee will cease to be valid in the case of
notfollowingtherecommendationsinthismanual.
1.2 SPECIFICSAFETYINSTRUCTIONSFORTHIS
DEVICE
● Thedevicemustremaininaverticalposition.
● Make sure the device is secured at all times. Please
adhere to the installation distances indicated in this
guide
Rev.1_09-07-15 Page 5
● Always install the device so that it cannot enter into
contact with any combustible material such as curtains
ortowels(takeintoaccountthegustsofwind).
● Do not insert any object through the grille or inside the
device.
● Donothanganyobjectinfrontorontopofthedevice.
● To clean the device, consult the instructions in the
"MAINTENANCE" section, because if water enters the
airgrillesitcouldseriouslydamagethedevice.
● The guarantee will not apply if these instructions
havenotbeenobserved.
2INSTALLATION
● Smells or noises could occur for some minutes when first
used. This is normal, and with appropriate ventilation the
smellswilldissipate.
● For greater efficiency, make sure you measure your room
accuratelyandusetheappropriatesizedradiator.
● Runningcostsaredependantonvariablessuchas;
o Insulationlevels
o Externaltemperatures
o Yourelectrictariff
It is your responsibility to meet the running costs of your
heating.
● Fixtheradiatortoafirmwallandmakesureitiswelllevelled.
● If your furniture is too close or obstructing the radiator it will
inhibittheperformance.
● Avoidinstallingthedeviceincorners.
● The radiator must be installed at least 15 cm away from any
combustible material, curtains, furniture, armchairs, etc.
Figure1
Rev.1_09-07-15 Page 6
• WARNING: If this appliance is installed in a bathroom, it
must be installed only within zones 2 or 3, according to the
requirements of the European Low Voltage Electrotechnical
Regulations, Complementary Technical Instruction
ITCBT27. The installation of this appliance within zones 0
or 1 of a bathroom is totally prohibited. Figure 2 below is
only for information purposes, we suggest you contact a
professionalelectrician.
Figure2:
Zone1:AppliancesinSafetyExtra
LowVoltage(SELV).
Zone2:ElectricAppliancesClassII
–IPX4
Zone3:Electricappliances
protectedbyDDR30mA
3WALLMOUNTING
Theradiatorequipmenthas2suspensionsupports.
● Mark the position of the holes using the holes drilling
template.
Rev.1_09-07-15 Page 7
● Make the holes and insert the plugs included in the fixing kit.
Place the support and tighten the screws until the piece is
sufficientlyfixed.
● Hang the device from the safely wallmounted supports and
lastly,screwthesafetypieceasfarasitwillgo.
4DIGITALPROGRAMMABLETHERMOSTAT
The radiator is equipped with a digital, programmable
thermostat.
Operationguide
4.1 Operation
Programming your radiator will optimise its energy consumption
whileincreasingyourcomfort.
Largescreenwithbacklighting.
Weeklyprogrammesetin30min.intervals.
Temporarycancellationfunction.
Holidayorreceptionfunction.
1Configurationmenu(user).
Radiatorconsumptioncontrol.
OpenWindowFunction.
Rev.1_09-07-15 Page 8
Rev.1_09-07-15 Page 9
4.2 Screen
1. Operation Mode. The active operation mode is displayed in
thebox.“ ”
2. Programme Number (P1 to P9), (U1 to U4) or System
SettingsMenu(01to11).“ ”
3. SystemSettingsMenus“ ”
4. KeypadLockActivated“ ”
5. Roomtemperatureindicator.“ ”
6. Typeoftimedisplay(12hAM/PMor24h).
7. Graphicviewoftheprogrammeofthecurrentday.
8. Time,temperatureandSystemSettingsMenusettingarea.
9. Indicatorofdeviceinoperation.“ ”.
10. Help pictogram to create programmes / Status of the
programme in normal mode / Control Menu of the radiator's
consumption.
11. FilPilotefunctionindicatorpictogram.(OnlyFrance)
12. Currentday.
13. Temporary cancellation function activated, or "ITCS" if
flashing.“ ”
14. Window Opening function“ ” (see section 5, System
SettingsMenu07).
Rev.1_09-07-15 Page 10
