Replacing a power supply: Veritas Appliance
Document Number: 177
Version: 4.3 (05/04/2020)
Purpose
This document describes the process for replacing a power supply in a Veritas appliance.
Affected appliance models
• 3340 Appliance
• 5240 Appliance
• 5250 Appliance
• 5340/5340 HA Appliance
Electrical Safety
The static discharged by human bodies can damage static-sensitive components on the boards.
When installing and maintaining the equipment, observe appropriate electrostatic safety precautions
to prevent personnel injuries or device damage.
When operating a device in an electrostatic sensitive area, you must take electrostatic-discharge
(ESD)-preventive measures. These include wearing ESD-preventive gloves, an ESD-preventive wrist
strap, and ESD-preventive clothes to avoid personnel injury or device damage.
To prevent damage to the device, pay attention to the following during operations:
• Do not touch devices with bare hands because ESD from the human body may damage the
electrostatically sensitive elements on a board.
• When dealing with the server or any of the internal components, wear an ESD-preventive wrist
strap, ESD-preventive gloves, and ESD-preventive suit.
About replacing an appliance power supply
This document describes how to replace a Veritas Appliance power supply while the appliance is
operating.
1
Veritas Appliance
Hardware Service Procedure

One of the power supplies must be operating at all times. If both power supplies must be removed at
the same time, the shutdown procedure must be performed on the appliance before a power supply
is removed.
The power supplies are numbered 1 and 2 as indicated in below.
This repair can be accomplished with the appliance installed in the rack.
Caution: You must complete a power supply swap within three minutes. Leaving the power supply
slot open for longer than three minutes can result in the appliance overheating and cause other
components to fail.
Requirements
Verify that you have the following items:
• Replacement power supply
• ESD wrist strap
Locating the appliance with the faulty component
Use the following steps to locate the appliance with the faulty component.
To locate the appliance with the faulty component
1Have the customer take you to the unit with the faulty component.
2Verify the appliance compute node serial number. The serial number is located on the rear panel
of the appliance and begins with letters SYM or VTAS.
2
HSP 177: Power Supply Replacement

Removing a faulty power supply
Use the following procedure to remove a faulty power supply.
To remove a faulty power supply
1Verify that the LED on the faulty power supply is amber.
If the LED is green or blinking green, the power supply is working properly. Blinking green indicates
that the power supply is currently being used to power the appliance. If the LED is amber, the
power supply needs to be replaced.
2Put on an ESD-compliant wrist strap or take other ESD-protective measures.
3Check the following to verify that it is safe to remove the power supply before you disconnect the
power:
• The LED on the other power supply is solid green.
• The LED on the target power supply is amber.
4Disconnect the power cable from the faulty power supply only.
3
HSP 177: Power Supply Replacement

Warning: Swap one power supply at a time only. If you need to remove both power supplies,
make sure the appliance is turned off before you proceed.
5Press in and hold the green release lever on the right side of the power supply to release the
module.
6Grasp the handle and pull the power supply out of the slot.
Caution: The power supply may be hot. Be careful when handling the unit.
4
HSP 177: Power Supply Replacement

Installing the replacement power supply
Use the following procedure to install the replacement power supply.
To install the replacement power supply
1Remove the replacement power supply from any wrapping.
2Insert the power supply into a power supply slot.
3Slide the replacement power supply completely into the slot. The power supply release lever
clicks into place when the power supply is properly installed.
4Plug the power cable into the power supply. The LED should come on and turn green.
5
