VERITAS NetBackup 5340 User manual

Veritas NetBackup™ 5340
Appliance Product
Description

Veritas NetBackup™ 5340 Appliance Product
Description
Last updated: 2017-12-21
Legal Notice
Copyright © 2017 Veritas Technologies LLC. All rights reserved.
Veritas and the Veritas Logo are trademarks or registered trademarks of Veritas Technologies
LLC or its affiliates in the U.S. and other countries. Other names may be trademarks of their
respective owners.
This product may contain third party software for which Veritas is required to provide attribution
to the third party (“Third Party Programs”). Some of the Third Party Programs are available
under open source or free software licenses. The License Agreement accompanying the
Software does not alter any rights or obligations you may have under those open source or
free software licenses. Refer to the third party legal notices document accompanying this
Veritas product or available at:
https://www.veritas.com/about/legal/license-agreements
The product described in this document is distributed under licenses restricting its use, copying,
distribution, and decompilation/reverse engineering. No part of this document may be
reproduced in any form by any means without prior written authorization of Veritas Technologies
LLC and its licensors, if any.
THE DOCUMENTATION IS PROVIDED "AS IS" AND ALL EXPRESS OR IMPLIED
CONDITIONS, REPRESENTATIONS AND WARRANTIES, INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR
NON-INFRINGEMENT, ARE DISCLAIMED, EXCEPT TO THE EXTENT THAT SUCH
DISCLAIMERS ARE HELD TO BE LEGALLY INVALID. VERITAS TECHNOLOGIES LLC
SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES IN
CONNECTION WITH THE FURNISHING, PERFORMANCE, OR USE OF THIS
DOCUMENTATION. THE INFORMATION CONTAINED IN THIS DOCUMENTATION IS
SUBJECT TO CHANGE WITHOUT NOTICE.
The Licensed Software and Documentation are deemed to be commercial computer software
as defined in FAR 12.212 and subject to restricted rights as defined in FAR Section 52.227-19
"Commercial Computer Software - Restricted Rights" and DFARS 227.7202, et seq.
"Commercial Computer Software and Commercial Computer Software Documentation," as
applicable, and any successor regulations, whether delivered by Veritas as on premises or
hosted services. Any use, modification, reproduction release, performance, display or disclosure
of the Licensed Software and Documentation by the U.S. Government shall be solely in
accordance with the terms of this Agreement.
Veritas Technologies LLC
500 E Middlefield Road
Mountain View, CA 94043

http://www.veritas.com
Technical Support
Technical Support maintains support centers globally. All support services will be delivered
in accordance with your support agreement and the then-current enterprise technical support
policies. For information about our support offerings and how to contact Technical Support,
visit our website:
https://www.veritas.com/support
You can manage your Veritas account information at the following URL:
https://my.veritas.com
If you have questions regarding an existing support agreement, please email the support
agreement administration team for your region as follows:
[email protected]Worldwide (except Japan)
[email protected]Japan
Documentation
Make sure that you have the current version of the documentation. Each document displays
the date of the last update on page 2. The latest documentation is available on the Veritas
website:
https://www.veritas.com/content/support/en_US/Document page.html
Documentation feedback
Your feedback is important to us. Suggest improvements or report errors or omissions to the
documentation. Include the document title, document version, chapter title, and section title
of the text on which you are reporting. Send feedback to:
[email protected]
You can also see documentation information or ask a question on the Veritas community site:
http://www.veritas.com/community/
Veritas Services and Operations Readiness Tools (SORT)
Veritas Services and Operations Readiness Tools (SORT) is a website that provides information
and tools to automate and simplify certain time-consuming administrative tasks. Depending
on the product, SORT helps you prepare for installations and upgrades, identify risks in your
datacenters, and improve operational efficiency. To see what services and tools SORT provides
for your product, see the data sheet:
https://sort.veritas.com/data/support/SORT_Data_Sheet.pdf

Chapter 1 About the NetBackup 5340 Appliance .......................... 6
About the NetBackup 5340 Appliance ................................................ 7
Features and components of the appliance ......................................... 8
Locating the appliance serial number ............................................... 12
About the appliance compute node disk drive configurations ................. 13
About the appliance disk drive LEDs .......................................... 14
About the compute node front panel USB port .................................... 15
About the appliance control panel .................................................... 15
About the System Status LED states .......................................... 17
About the Power button LED states ............................................ 20
About the appliance compute node rear panel .................................... 21
Standard available NetBackup 5340 Appliance PCIe-based I/O
configurations .................................................................. 24
Total NetBackup 5340 Appliance On-board and PCIe-based I/O
ports .............................................................................. 26
NetBackup 5340 Appliance on-board network interface port
locations and speeds ........................................................ 33
Chapter 2 About the Veritas 5U84 Storage Shelves ................... 35
About NetBackup 5340 Appliance storage shelves .............................. 35
Available appliance storage options ........................................... 37
About the Veritas 5U84 Storage Shelf disk drive drawers ................ 39
5U84 Primary Storage Shelf and the 5U84 Expansion Storage
Shelf control panel ............................................................ 50
About the 5U84 Primary Storage Shelf and 5U84 Expansion Storage
Shelf rear components ............................................................ 51
Veritas 5U84 Primary Storage Shelf RAID Controllers .................... 54
Veritas 5U84 Expansion Storage Shelf Expansion I/O modules
..................................................................................... 58
Veritas 5U84 Storage Shelf cooling modules ................................ 61
5U84 Storage Shelf Power Supply Units ..................................... 62
Contents

Chapter 3 NetBackup 5340 Appliance and 5U84 Storage
Shelf cables ................................................................... 64
Power cables ............................................................................... 64
Network cable .............................................................................. 66
Multi-mode fiber optic cable ............................................................ 67
SAS3 cable ................................................................................. 68
Twinaxial copper cables ................................................................. 69
Appendix A Technical specifications, Environmental/Protocol
standards, and Compliance standards ................. 71
NetBackup 5340 compute node technical specifications ....................... 72
Veritas 5U84 Storage Shelf technical specifications ............................. 75
Environmental specifications ........................................................... 78
Protocol standards ........................................................................ 78
Regulatory, compliance, and certification information ........................... 79
Product regulatory compliance .................................................. 80
Product safety compliance ....................................................... 80
Product EMC Compliance - Class A Compliance .......................... 81
Product ecology compliance ..................................................... 81
Certifications / Registrations / Declarations .................................. 82
Electromagnetic compatibility notices ......................................... 82
Index .................................................................................................................... 85
5Contents

About the NetBackup 5340
Appliance
This chapter includes the following topics:
■About the NetBackup 5340 Appliance
■Features and components of the appliance
■Locating the appliance serial number
■About the appliance compute node disk drive configurations
■About the compute node front panel USB port
■About the appliance control panel
■About the appliance compute node rear panel
1
Chapter

About the NetBackup 5340 Appliance
The NetBackup 5340 Appliance is a hardware and software storage system that
can scale up to a total of 1920TB of usable backup capacity. It consists of one 2U
NetBackup 5340 Appliance compute node and one required externally attached
5U84 Primary Storage Shelf for data storage purposes. By itself, the NetBackup
5340 Appliance compute node does not provide internal disk space for data storage.
You can add up to three optional 5U84 Expansion Storage Shelves if you require
additional data storage space.
Note: Total usable backup capacity depends on the hardware configuration you
purchase.
See “Available appliance storage options” on page 37.
Fibre channel (FC) cables connect the NetBackup 5340 Appliance compute node
to the 5U84 Primary Storage Shelf. SAS3 cables connect the 5U84 Primary Storage
Shelf to the optional 5U84 Expansion Storage Shelves.
See “About NetBackup 5340 Appliance storage shelves” on page 35.
High Availability
Veritas also offers a high availability (HA) solution for NetBackup 5340 Appliance
systems. HA provides more efficient operation and improved aggregate performance
for data protection operations. A NetBackup 5340 Appliance HA solution consists
of two connected compute nodes that connect to common storage, and also runs
appliance software version 3.1 or later. Refer to the Veritas NetBackup™ Appliance
7About the NetBackup 5340 Appliance
About the NetBackup 5340 Appliance

High Availability Reference Guide for information about how to prepare for appliance
HA deployment.
Features and components of the appliance
This section describes the features and components of the NetBackup 5340
Appliance.
Table 1-1 NetBackup 5340 Appliance system specifications
NetBackup 5340 Appliance systemTechnical
Specification
Red Hat Enterprise Linux 7.3Supported operating
system
■Two Intel Xeon 6138 CPUs
■Supports the high-performance processors with low-power
consumption
■Provides high efficiency and performance
Processor
(Performance and
capacity)
2.0 GHz (Turbo: 3.7 GHz)CPU speed
40 (20 per processor)Cores
27.5 MB Cache L3Cache
Base memory capacity: 768GB
Note: Higher memory capacities are capable depending on CPU
population.
Memory type: DDR4 RDIMM
Configuration: 32GB x 24 RDIMM modules
Operating voltage: 1.2V
Configured clock speed: 2666MHz
System memory
AdvancedDisk usable storage capacity: up to 1,920TB
MSDP storage capacity: up to 916TB
See “Available appliance storage options” on page 37.
Usable MSDP and
AdvancedDisk usable
storage capacity (TB)
YesSAS RAID mezzanine
card
8About the NetBackup 5340 Appliance
Features and components of the appliance

Table 1-1 NetBackup 5340 Appliance system specifications (continued)
NetBackup 5340 Appliance systemTechnical
Specification
NoSAS RAID PCIe card
installed in a appliance
compute node PCIe
riser assembly
RAID10 (striping and mirroring) and RAID6 (block level striping
with double distributed parity) are used as follows:
■RAID10: NetBackup 5340 Appliance compute node system
disks
■RAID6: 5U84 Primary Storage Shelf and 5U84 Expansion
Storage Shelf data storage disks
Note: RAID levels are generated using an onboard Intel
RMSHC080 RAID controller that is installed in the NetBackup
5340 Appliance compute node.
RAID levels
4
One required 5U84 Primary Storage Shelf and three optional 5U84
Expansion Storage Shelves
Maximum number of
storage shelves
4
Used to connect the NetBackup 5340
Appliance compute node to the 5U84
Primary Storage Shelf
16Gb Fibre Channel ports
(PCIe-based)
I/O Ports
See “Standard available
NetBackup 5340
Appliance PCIe-based
I/O configurations”
on page 24.
See “Total NetBackup
5340 Appliance
On-board and
PCIe-based I/O ports”
on page 26.
Up to 10, depending on the appliance
I/O configuration
10Gb
Ethernet/iSCSI-capable
ports
(PCIe-based)
Up to eight, depending on the
appliance I/O configuration
8Gb Fibre Channel ports
(PCIe-based)
41Gb Ethernet ports
(on-board)
19" EIA standardRack information
9About the NetBackup 5340 Appliance
Features and components of the appliance

Table 1-1 NetBackup 5340 Appliance system specifications (continued)
NetBackup 5340 Appliance systemTechnical
Specification
Appliance compute node:
■Height: 8.89cm (3.5") (approximately 2U)
■Width: 48.35cm (19")
■Depth: 79.38cm (31.25")
See “NetBackup 5340 compute node technical specifications”
on page 72.
5U84 Primary Storage Shelf / 5U84 Expansion Storage Shelf:
■Height: 21.97cm (8.65") (approximately 5U - shelf, overall)
■Width: 48.26cm (19") (across the mounting flange)
■Length/depth: 91.44cm (36") (from rear of the front flanges to
the rear extremity of the chassis)
Note: The lengths of the Veritas 5U84 Storage Shelves are
longer that what a standard IEC-compliant rack normally
supports. Due to the additional length, the rack-based PDU
hardware may need to be installed on the outside of the rack
to accommodate the storage shelves.
See “ Veritas 5U84 Storage Shelf technical specifications”
on page 75.
Dimensions (IEC rack
compliant)
Appliance compute node: 23.26 kg (51.28 lbs)
5U84 Primary Storage Shelf: 135 kg (298 lbs) with drives; no rail
kit
5U84 Expansion Storage Shelf: 135 kg (298 lbs) with drives; no
rail kit
Maximum weight
Appliance compute node
■300 watts
Each storage shelf
■1000 watts
Typical power
consumption
Appliance compute node
■600 watts
Each storage shelf
■1300 watts
Maximum power
consumption
10About the NetBackup 5340 Appliance
Features and components of the appliance

Table 1-1 NetBackup 5340 Appliance system specifications (continued)
NetBackup 5340 Appliance systemTechnical
Specification
4,300 wattsTypical power
consumption with a
maximum of four
external storage shelves
5,800 wattsMaximum power
consumption with a
maximum of four
external storage shelves
Compute node:
■220 VAC at 3.1 A
Each storage shelf:
■200 - 240 VAC at 6.67 A
AC power requirements
Compute node:
■Specification: IEC-60320-C14 to IEC-60320-C13, 15A/250V,
Black, 4ft
The IEC-60320-C14 plugs into a Power Distribution Unit. The
IEC-60320-C13 plugs into an appliance or storage shelf power
supply.
Note: If your power distribution unit is not compatible with the
IEC-60320-C14 plug, Veritas recommends that you purchase
your power cable locally. Make sure the power cable meets or
exceed the indicated power rating.
See “Power cables” on page 64.
Storage shelf:
■Specification: IEC-60320-C20 to IEC-60320-C19, 20A/250V,
Black, 4ft
The IEC-60320-C20 plugs into a Power Distribution Unit (PDU)
on a rack. The IEC-60320-C19 plugs into an appliance or a
storage shelf power supply.
Note: If your power distribution unit is not compatible with the
IEC-60320-C20 plug, Veritas recommends that you purchase
your power cable locally. Make sure the power cable meets or
exceed the indicated power rating.
See “Power cables” on page 64.
AC power cable
11About the NetBackup 5340 Appliance
Features and components of the appliance

Table 1-1 NetBackup 5340 Appliance system specifications (continued)
NetBackup 5340 Appliance systemTechnical
Specification
> 90%Power Factor
Typical:
■14,408 BTU/hour
Maximum:
■19,267 BTU/hour
System cooling
requirement (heat
dissipation)
(Appliance with
maximum storage
shelves attached)
200 – 240 VACOperating voltage
50/60 HzAC Frequency range
Appliance compute node: 90% +
5U84 Primary/Expansion Storage Shelf: 89% +
Power conversion
efficiency
Appliance compute node:
■70 dBA
5U84 Primary/Expansion Storage Shelf:
■82 dBA
Acoustic noise
Locating the appliance serial number
A vertical bar on the rear panel of the appliance compute node contains the serial
number.
12About the NetBackup 5340 Appliance
Locating the appliance serial number

About the appliance compute node disk drive
configurations
The NetBackup 5340 Appliance compute node contains five 2 TB SAS hard disk
drives, which can be accessed from the compute node's front panel. An embedded
RAID controller on the compute node's mainboard is used to configure four of the
five disk drives into two RAID1 mirrored volumes.
The two RAID1 volumes are labeled Volume 0 and Volume 1. The disk drives that
are located in slot 0 and slot 1 are configured as the RAID1, VOLUME0 device.
These disk drives contain the appliance operating system, the operating system
swap file, and the NetBackup application. You can hot-swap one of these disk drives
at a time if a drive becomes problematic. However, you cannot operate the appliance
if both disk drives are removed.
The disk drives in slot 2 and slot 3 are configured as the RAID1, VOLUME1 device.
Volume 1 contains the log files. As with the RAID1, VOLUME0 device, you can
hot-swap one disk drive at a time if a drive becomes problematic. However, you
cannot operate the appliance if both drives are removed.
The appliance uses the disk drive that is located in slot 4 as a hot-spare disk. If a
disk drive in either of the RAID volume experiences a hardware error, the appliance
automatically initiates a RAID rebuild operation. During the rebuild operation, the
appliance dynamically accesses the hot-spare disk from slot 4 and uses it to rebuild
the RAID volume.
Figure 1-1 NetBackup 5340 Appliance compute node front panel disk slot
assignments
10
11
9
6
7
85
4
3
2
1
0
Table 1-2 NetBackup 5340 Appliance compute node front panel disk drive
configurations
Disk drive roleDisk drive
size (TB)
RAID
level
Slot
Operating system boot volume / operating system
swap file / NetBackup application
2 TBRAID10, 1
Log files2 TBRAID12, 3
13About the NetBackup 5340 Appliance
About the appliance compute node disk drive configurations

Table 1-2 NetBackup 5340 Appliance compute node front panel disk drive
configurations (continued)
Disk drive roleDisk drive
size (TB)
RAID
level
Slot
Hot spare2 TB4
No disk drives installed5 - 11
About the appliance disk drive LEDs
Each disk drive module contains two LEDs on the left side of each module. The
LEDs appear as follows:
Figure 1-2 NetBackup 5340 Appliance disk drive module LEDs
Amber Status LED
Green Activity LED
Table 1-3 NetBackup 5340 Appliance disk drive LED status
ConditionLED behaviorDescriptionNumber
No disk drive access and no disk drive
faults
A disk drive fault has occurred
A RAID rebuild is in progress
Off
Solid amber
Blinking amber
Amber Status
LED
1
Power on - the disk drive has spun
down
OffGreen Activity
LED
2
Power on - no disk drive activitySolid green
Power on - the disk drive is processing
a command
or
Power on - the disk drive is spinning
up
Blinking green
14About the NetBackup 5340 Appliance
About the appliance compute node disk drive configurations

Note: Disk drive modules that do not contain disk drives also have LEDs. Although
there is no drive activity going on, some colored lights may still be seen through
the disk modules.
About the compute node front panel USB port
The NetBackup 5340 Appliance compute node front panel includes a USB
2.0-compliant port that supports a data transfer rate of up to 480 Mb/second.
About the appliance control panel
The 5340 Appliance compute node includes a control panel on the right side of the
front panel. System information is shown on this control panel.
Figure 1-3 5340 Appliance control panel
A
B
C
G
F
D
E
15About the NetBackup 5340 Appliance
About the compute node front panel USB port

Table 1-4 5340 Appliance control panel system LED descriptions
DescriptionLabel
The Power button toggles the system on and off.
See “About the Power button LED states”
on page 20.
Power button with integrated
LED
A
The drive activity LED on the front panel indicates
drive activity from the on-board hard disk controllers.
Hard Drive Activity LEDB
The System ID button toggles the integrated ID LED
and the blue server board LED on and off.
The system ID LED identifies the system for
maintenance when it is racked with similar server
systems.
System ID button with
integrated LED
C
The front control panel includes four activity LED
indicators for each on-board network interface
controller (NIC).
■NIC-1 represents network interface controller 1
■NIC-2 represents network interface controller 2
■NIC-3 represents network interface controller 3
■NIC-4 represents network interface controller 4
When network links are detected on the controllers,
the LEDs are activated and remain on. The LEDs
blink when network activity occurs, and the rate at
which they blink is determined by the amount of
network activity that occurs.
Network Activity LEDsD
When it is depressed, the NMI button puts the
appliance in a halt state, issues a non-maskable
interrupt (NMI), and then triggers the non-maskable
interrupt. All server data can be lost.
Veritas recommends that you do not enable NMI by
pressing the NMI button.
NMI button (recessed, tool
required for use)
E
When depressed, the System Cold Reset button
re-boots and re-initializes the appliance.
System Cold Reset Button
(recessed, tool required for
use on non-storage models)
F
16About the NetBackup 5340 Appliance
About the appliance control panel

Table 1-4 5340 Appliance control panel system LED descriptions
(continued)
DescriptionLabel
The System Status LED is bi-color indicator that uses
the colors green and amber to display the current
health of the appliance.
Two locations are provided for you to monitor the
health of the system. You can find the first location
on the front control panel, while the second location
is located on the back edge of the server board. It is
viewable from the rear of the appliance. Both LEDs
show the same state of health.
See “About the System Status LED states”
on page 17.
System Status LEDG
About the System Status LED states
The System Status LED is a bi-color (Green/Amber) indicator that shows the current
health of the system. The appliance provides two locations for this feature. The first
location is on the Front Control Panel, while the second location is on the back edge
of the server board.
Figure 1-4 System Status LED control panel location
System
Status
LED
The following table provides a description of each LED state.
17About the NetBackup 5340 Appliance
About the appliance control panel

Table 1-5 System Status LED states
DescriptionCriticalityStateColor
■System is power off (AC and/or DC)
■System is in EuP Lot6 Off Mode
■System is in S5 Soft-Off State
Not readyOff - The
system is not
operating
No
color
Indicates that the system is running (in S0 State)
and its status is “Healthy”. The system is not
exhibiting any errors. AC power is present and
BMC has booted and manageability functionality
is up and running.
HealthySolid on (SO)Green
System degraded:
■Redundant loss, such as power supply or
fan. Applies only if the associated platform
sub-system has redundancy capabilities.
■Fan warning or failure when the number of
fully operational fans is more than minimum
number needed to cool the system.
■Non-critical threshold crossed: Temperature
(including HSBP temp), voltage, input power
to power supply, output current for main
power rail from power supply and Processor
Thermal Control (Therm Ctrl) sensors.
■Power supply predictive failure occurred while
redundant power supply configuration was
present.
■Unable to use all of the installed memory (one
or more DIMMs failed/disabled but functional
memory remains available).
■Battery failure.
■BMC executing in uBoot. (Indicated by
Chassis ID blinking at 3Hz). System in
degraded state (no manageability). BMC
uBoot is running but has not transferred
control to the BMC Linux. Server will be in
this state 6-8 seconds after BMC reset while
it pulls the Linux image into flash.
Degraded
The system is
operating in a
degraded state
although still
functional.
or
The system is
operating in a
redundant state
but with an
impending failure
warning.
~1 Hz blinkGreen
18About the NetBackup 5340 Appliance
About the appliance control panel

Table 1-5 System Status LED states (continued)
DescriptionCriticalityStateColor
System degraded (continued):
■BMC booting Linux. (Indicated by Chassis ID
solid ON). System in degraded state (no
manageability). Control has been passed
from BMC uBoot to BMC Linux itself. It will
be in this state for 10-20 seconds.
■BMC Watchdog has reset the BMC.
■Power unit sensor offset for configuration
error is asserted.
■Hard disk drive HSC is off-line or degraded.
Degraded
(continued)
~1 Hz blinkGreen
Non-fatal - However, the system is likely to fail:
■Critical threshold crossed – Voltage,
temperature (including HSBP temp), input
power to power supply, output current for
main power rail from power supply and
PROCHOT (Therm Ctrl) sensors.
■VRD Hot asserted
■Minimum number of fans to cool the system
not present or failed
■Hard drive fault
■Power Unit Redundancy sensor – Insufficient
resources offset (indicates not enough power
supplies present)
■Correctable memory error threshold has been
reached for a failing DIMM when the system
is operating in a non-redundant mode.
Non-critical
The system is
operating in a
degraded state
with an
impending failure
warning.
However, the
system is still
functioning.
~1 Hz blinkAmber
Fatal alarm – system has failed or shutdown:
■CPU CATERR signal asserted
■MSID mismatch detected (CATERR also
asserts for this case)
■CPU1 is missing
■CPU Thermal Trip
■No power – power fault
■DIMM failure when there is only one DIMM
present; no other good DIMM memory
present
■Runtime memory uncorrectable error in
non-redundant mode.
Critical,
non-recoverable
– System is
halted
Solid onAmber
19About the NetBackup 5340 Appliance
About the appliance control panel

Table 1-5 System Status LED states (continued)
DescriptionCriticalityStateColor
■Uncorrectable Runtime memory error in
non-redundant mode
■DIMM Thermal Trip or equivalent
■CPU ERR2 signal is asserted
■BMC/Video memory test failed (Chassis ID
shows blue/solid-on for this condition)
■SBB Thermal Trip or equivalent
■240VA fault
■Both uBoot BMC FW images are bad
(Chassis ID shows blue/solid-on for this
condition)
■Fatal Error in processor initialization:
■Processor family not identical
■Processor model not identical
■Processor core/thread counts not identical
■Processor cache size not identical
■Unable to synchronize processor
frequency
■Unable to synchronize QPI link frequency
Critical,
non-recoverable
– System is
halted
Solid onAmber
About the Power button LED states
The Power button is located on the NetBackup 5340 Appliance control panel. It is
used to turn the appliance on or off.
Figure 1-5 Power button control panel location
Power/Sleep
button
The following table provides a description of each power state.
20About the NetBackup 5340 Appliance
About the appliance control panel
