WELCOMES YOU TO SUGARING WITH THE SAPLING EVAPORATOR
The Vermont Evaporator Company’s Sapling Evaporator is designed for the backyard sugaring enthusiast with
5 to 50+ taps. The Sapling does not require a sugar house, and, with additional purchases, converts to a grill and
a smoker for year-round use!
Although the Sapling is simply designed, it still has the advanced features of more expensive evaporators. The
Sapling is a continuous-flow evaporator, meaning that sap is channeled around the pan using dividers to create a
sugar gradient. This configuration allows syrup to be drawn off and sap to be added without emptying the
pan. The continuous flow is more efficient than preexisting DIY methods, which means more syrup on more
pancakes in less time.
We hope you get many years of enjoyment from your Sapling. Here’s how to start!
Setting up your Sapling
Before you start, be smart! You’re dealing with hot temperatures and a live fire so:
● DO NOT operate your Sapling while intoxicated or under the influence of alcohol or drugs.
● DO NOT install your Sapling near combustible materials.
● DO NOT install your Sapling indoors; DO NOT install in a garage, barn or sugar-shack unless you know
how to do so safely with proper ventilation and fire protection.
● DO NOT attempt to move your Sapling while the unit is hot.
● DO NOT start your Sapling as a grill OR as an evaporator without an insulating layer of sand or ash in the
bottom of the barrel. Failure to place an insulating layer in the bottom of your barrel can result in coals burning
right through the bottom of your barrel.

2
● DO NOT start or run your Sapling as an evaporator without sap or other fluid in the boiling pan; DO NOT
allow your Sapling to cool without sap or other fluid in the pan. You can quickly destroy your pan by doing so.
Assembling your Sapling
What you will need besides your Sapling:
1. A two- or four-foot level;
2. wood shims;
3. sand and/or ashes;
4. baking soda;
5. vegetable or olive oil;
6. an electric drill with a 3/32” bit;
7. a Phillips screwdriver;
8. a thermometer;
9. fire brick and/or some old grill grates (if desired). Consider purchasing Rutland Products Fire Brick
and/or Steel Freak Fire Grate.
To assemble your Sapling:
1. Remove all parts from inside the box. Inside the box, you will have:
• one (1) flue takeoff;
• one (1) 90° elbow;
• one (1) Sapling Stack Bracket;
• two (2) pieces of flue pipe;
• seven (7) self-drilling screws;
• one (1) evaporating pan;
• one (1) ball valve;
• a smidge of pipe tape;
• and, one (1) door, two (2) leg sets and eight (8) each: bolts, nuts, and lock washers.
2. First assemble the leg sets onto the barrel using the predrilled holes and the nuts, bolts and lock washers.
HINT: The easiest way to assemble the legs is as follows. If you have already installed the door,

3
uninstall it. Orient your Sapling “bottom-up,” with the cavity facing down. (It helps to have a
skinny table or workbench or pair of saw horses to do this while steadying the unit.) Align the
holes in each leg set (so that the feet face the rear of the machine) on the corresponding holes on
the barrel and push a bolt through each pair of holes. When all bolts have been inserted, reorient
the unit exit-hole down (door-side up) with the cavity facing you. Install the lock washers and
nuts and tighten!
3. Next, assemble the door onto the barrel by carefully aligning and then gently tapping the pegs on the
door hinge piece into the holes on the plate hinge piece.
4. Center the takeoff to the exit hole in the back of the unit and mark the location of the four predrilled
holes in the takeoff on the barrel with pencil, chalk or a nail. Predrill those holes. Using four of the
screws provided, affix the takeoff to the back of the barrel. The screws are self-tapping, and, when
enough pressure is applied, will eventually tap into the barrel without the need for drilling holes.
However, we highly recommend predrilling the holes for a smooth assembly.
5. Slide the 90° elbow on the flue takeoff affixed to the back of the barrel.
6. Adjust the 90° elbow so that the exit of the elbow is pointed straight up.
7. Looking at your Sapling from the stack-end (the back), position the stack bracket so that the bent end is
flush with the back of the barrel, and the straight end is flush with the elbow above the elbow’s
uppermost adjustable crease (see below). Mark the position of the predrilled hole on the back of the
barrel with pencil, chalk or nail. Predrill a hole in the barrel. Using one of the last two of the screws
provided, affix the stack stabilization bracket to the barrel. Use the last self-tapping screw to affix the
bracket to the side of the elbow (this metal is thinner than the barrel and doesn’t need to be predrilled).
8. Fit a piece of flue pipe onto the elbow exit.
9. Fit the second piece of flue pipe onto the first piece of flue pipe.
10. Place the pan on the unit so that the draw-off is on the front of the left side, as you look at the unit from

4
the front.
11. Starting one thread back from the exit, wrap your bit of pipe tape around the draw-off to the right and
wind around until completely used. Screw the ball valve on over the pipe tape. Does your unit look like
the one in our logo? Excellent! You’re done!
Preparing Your Sapling for Use
1. Remove the pan.
2. Using shims and a two- or four-foot level, level your Sapling front to back and side to side.
3. Place a layer of sand and/or ashes in the bottom of your barrel. CAUTION: failure to place an
insulating layer in the bottom of your barrel can result in catastrophic failure – the fire may burn right
through your barrel! For added protection and to increase efficiency, you may also choose to line the
inside of your barrel with fire brick, available at your local hardware store. You may also aid air flow by
putting an old grill grate in the bottom of your barrel.
4. Coat the exterior of the barrel with a thin layer of vegetable or olive oil (apply with a paper-towel or
rag).
5. Replace the pan. Using your level, confirm that your pan is level front to back and side to side.
6. Before you boil your first sap, you’ll want to remove any residual materials from the pan. Here’s how
you do that:
Prepare a solution of 10 gallons of water combined with 2 tablespoons of baking soda.
Fill the pan to 2 or 3 inches with the solution.
Start by building a small fire in the barrel and gradually build to a larger fire. NOTE: We DO
NOT recommend heating your Sapling to over 600 degrees (as measured just above the elbow at
the exit pipe) at any time. You may want to use a magnetic stove thermometer to track your
Sapling’s temperature throughout operation.
Boil the solution for approximately 30 minutes, making sure the solution in the pan remains at
approximately the 2-or 3-inch level by adding more solution, as needed.
7. Check your equipment:
Check to see that there are no leaks at the fittings in the pan.
Assuming you have an even fire underneath, check to see that the pan is boiling evenly.
Open the valve – ensure it works properly.
Check to see that your Sapling is drafting and venting correctly (that the fire has adequate air
intake and that smoke is generally only coming out through the stack).

5
8. Allow the unit to cool and then drain the pan.
9. Rinse the pan thoroughly with clean water and dry.
NOTE: It’s always best to use non-chlorinated water if possible (chlorinated water can eventually cause
corrosion of the pan).
Operating Your Sapling!
CAUTION: NEVER, EVER, EVER fire the Sapling without liquid in the pan (or allow it to cool without
liquid). Otherwise, the operation of the unit is relatively simple! Basically, you add sap at one location and it
travels around the pan, becoming denser as it evaporates, until it gets to the valve. Here are the details:
1. Add 2 inches of sap in the pan. This is about 5 gallons of sap.
2. Start your fire.
3. Get the sap boiling.
4. After the sap has boiled down to half of its volume, gradually add more sap at the back, right corner of
the pan until the sap level is back up to 2 inches. Continue to add sap at this location gradually as needed
to keep the level at 2 inches. Do this for several hours.
5. There are a number of ways to tell if your syrup is “done.” The most sophisticated is to use an
instrument called a syrup hydrometer to measure sugar content. Another is to measure temperature:
syrup boils at about 7 degrees F above the boiling point of water (so, approximately 219 degrees F).
Therefore, when the temperature of the liquid close to the exit valve measures 219 degrees F, you can
draw off syrup (this will take several hours). The syrup should have an amber color and have the
consistency of . . . syrup.
6. Get a clean container and place it under the valve exit.
7. Open the valve and watch your exit temperature.
8. If possible, simultaneously add fresh sap at the introduction location. If not possible, add some before
you draw off and some more after.
9. Continue to draw off syrup until your exit temperature drops below 219°. You will likely get less than a
pint of finished syrup per draw.
10. You may also choose to draw off a bit early into another pot or pan and “finish” on, for example, a
propane burner outside, or on the kitchen stove inside, where it may be easier to control and monitor the
temperature. Do not feel badly about choosing to go this route, especially at the beginning.

6
Finishing on the Sapling requires practice and skill. You will get better at this every year!
11. At the end of your boiling day, draw off about a gallon of the sap closest to being syrup. You can finish
it as described above, or use it the next time you boil for a faster startup.
12. Monitor your evaporator until the boiling stops and the fire has died out.
Some Tips:
Don’t add too much new sap at one time, and try to maintain a constant boil. This will result in a more efficient
process and lighter syrup.
To obtain high, even heat, use dry, mixed (hardwoods and softwoods) wood that is thinly split.
Load often with small amounts of wood to maintain a consistent level of heat.
Think you need more air flow to sustain optimal temperatures? Open the bung on the bottom of the back of the
unit before you fire up next time – that might just help.
Maintaining your Sapling
During Sugaring Season
Clean out some, but not all, of the ashes when the unit has cooled after each boil.
After the Season is Over
Your pan will likely have some deposits/scaling. To clean, use as much of the baking soda-water solution
described above as you need to so that the coating to be removed is covered with water. Simmer the solution for
a minimum of one hour and ideally until you see the deposits dissolve. Let the fire die out and leave the pan
overnight. Brush off the loose scale and rinse the pan. If deposits remain, you may want to repeat the process.
Store your pan in an indoor location (a garage, shed or barn is fine).
The best practice is to clean out the ash and oil the inside of your barrel with vegetable or olive oil when not in
use for extended periods of time, and, unless your Sapling can be stored in a garage or barn, you should cover it
when not in use. Consider purchasing the Sapling Grill Cover for this purpose. If water gets in your barrel, be
sure to dump it out, dry it out, and apply another layer of oil to discourage rust.
Expansion and contraction caused by heating, cooling and exposure to the elements may eventually cause some
cracking and/or flaking in the paint on your Sapling. If you notice this, after the barrel has cooled, sand the area
with 100 grit sandpaper and repaint with Sapling Flat Black Paint, or the equivalent. Or consider purchasing the
Sapling Care Kit, which includes everything you need for maintaining the Sapling!
