Versa Networks CSG300 Series Installation instructions

CSG300 Series Hardware Guide
At a Glance
The Versa Cloud Services Gateway (CSG) 300 series appliances deliver highly secure site-to-site data connectivity to
small businesses and to home offices.
These appliances provide the following features:
• Support for different CPUs and memory sizes:
• Management thernet ports with dual use and dedicated options:
◦ One RJ45 RS-232 console port
◦ One USB 2.0 management port for plugging in external LT or WiFi modems
◦ One copper Gigabit thernet dual-purpose port for data and management
• MDI and MDIX autoswitchable copper Gigabit thernet ports
• Po source support on four thernet ports, with network interface card (NIC) module add-on
• Wireless options:
• CSG350–Two built-in wireless slots
• CSG355 and CSG365–Two LT slots and one dedicated built-in wireless slot
• xternal AC power supply
• Fan for cooling
• Desktop mount, or rack-mountable in a 19” rack (CSG355 and CSG365 only)
CSG300 Appliance Models
The CSG300 appliances are available in the following models:
• CSG350—Compact and optimized appliance for deployment in small branches (up to 75 users) that require
advanced application and cloud intelligence with hierarchical QoS and that provide a cost-effective SD-WAN
solution.
• CSG355–Powerful appliance for deployment in both small- and medium-sized branches that require advanced SD-
Security (NGFW and UTM) along with comprehensive advanced application and cloud-intelligent SD-WAN services
on premises.
• CSG365—High-performance, powerful appliance for deployment at medium-sized branch locations that
require advanced application and cloud-intelligent SD-WAN services and advanced SD-Security (NGFW and UTM).
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
1

Table 1 shows the CPU memory, and storage sizes of the CSG300 appliance models .
Table 1: CSG300 Appliance Models
CSG Appliance Model CPU Memory Storage
CSG350 x86 with 4 cores 4 GB DRAM
(configurable to 16GB) 32 GB
CSG355 x86 with 4 cores 8 GB DRAM 32 GB
CSG365 x86 with 4 cores (higher performance) 8 GB DRAM 64 GB
Chassis Views
The CSG350 appliance is the smallest of the CSG300 appliances. The CSG355 and CSG365 appliances are physically
identical.
CSG350 Appliance
Figure 1 and Figure 2 show the front and rear panels of the CSG350 appliance.
Note: The front panel is the side of the appliance with the SIM slots and two L Ds, for status and power. This is the side
that is visible when you install the appliance in an office environment. The rear panel has the power and reset buttons
and various connectors and ports.
Figure 1: Front Panel of the CSG350 Appliance
Figure 2: Rear Panel of the CSG350 Appliance
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
2

CSG355 and CSG365 Appliances
Figure 3 and Figure 4 show the front and rear panels of the CSG355. The panels for the CSG355 and CSG365
appliances are identical.
Figure 3: Front Panel of the CSG355 Appliance
Figure 4: Rear Panel of the CSG355 Appliance
CSG300 Series Appliance Specifications
A CSG300 series appliance chassis is made of aluminum for optimal heat dissipation. This article lists the chassis and
regulatory compliance specifications for the CSG300 series appliance. It also lists certifications and export control
classification numbers ( CCNs) for the appliance.
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
3

Chassis Specifications
CSG350 Appliance
Table 1 lists the specifications for a CSG350 appliance chassis.
Table 1: CSG350 Series Chassis Specifications
Item Specification
Services and Slot Density
RJ-45 ports 10/100/1000 Mbps 4
xternal USB ports (USB 2.0) 1
RJ-45 serial console port 1
Memory DDR4 CC DRAM 4 GB
Disk 1 SSD default size 32 GB
Power supply 12VDC, 5A
Power Specifications
AC input voltage 100–240 Volts
AC input line frequency 50–60 Hz
Typical power consumption 25 Watts
Chassis Physical Specifications
Chassis height 1.38” (34 mm)
Chassis width 7.87” (200 mm)
Chassis depth 5.91" (152 mm)
Chassis weight 2.75 lb (1.25 kg)
Chassis weight with installation kit: 3.96 lb (1.8 kg) maximum
Package Specifications
Package height 7" (17.78 cm)
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
4

Item Specification
Package width 16.7" (42.4 cm)
Package depth 12" (30.48 cm)
Package weight 15.4 lb (7 kg)
Operating Conditions
Temperature 0° to 40°C (32° to 104°F) at sea level
Humidity 10% to 85% relative humidity
Altitude Maximum 3000 m (10,000 ft)
Noise level Less than 20 dBA
Storage Conditions
Temperature 20° to 70°C (68° to 158°F) at sea level
Humidity 10% to 85% relative humidity
CSG355 and CSG365 Appliance
Table 2 lists the specifications for the CSG355 and CSG365 appliance chassis.
Table 2: CSG355 and CSG365 Chassis Specifications
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
5

Item Specification
Services and Slot Density
RJ-45 ports 10/100/1000 Mbps 4 + 2
xternal USB ports (USB 2.0) 1
RJ-45 serial console port 1
Memory DDR4 CC DRAM CSG355: 8 GB
CSG365: 8 GB
Disk 1 SSD default size CSG355: 32 GB
CSG365: 64 GB
Power supply 12VDC, 5A
Processor High-performance, 4-core processor
Power Specifications
AC input voltage 100–240 Volts
AC input line frequency 50–60 Hz
Typical power consumption 33 Watts
Chassis Physical Specifications
Chassis height 1.65” (43 mm)
Chassis width 13.8” (370 mm)
Chassis depth 6.7” (172 mm)
Rack height 1 RU
Chassis weight Chassis weight with installation kit: 5.5 lb (2.5 kg) maximum
Package Specifications
Package height 7" (17.78 cm)
Package width 16.7" (42.4 cm)
Package depth 12" (30.48 cm)
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
6

Package weight 15.4 lb (7 kg)
Operating Conditions
Temperature 0° to 40°C (32° to 95°F) at sea level
Humidity 10% to 85% relative humidity
Altitude Maximum 3000 m (10,000 ft)
Noise level Less than 30 dBA
Storage Conditions
Temperature 20° to 70°C (68° to 158°F) at sea level
Humidity 10% to 85% relative humidity
CSG300 Series Appliance SKUs
CSG300 series SKUs have the following format:
model –xxx –yyy
model indicates the CSG300 appliance model number. It can be one of the following:
• CSG350
• CSG355
• CSG365
xxx indicates the number and type of wireless modules. It can be one of the following:
• WLA—1 WiFi module and 1 LT module (North America)
• WLB—1 WiFi module and 1 LT module (APAC)
• 2LA—2 LT modules (North America)
• 2LB—2 LT modules (APAC)
• LA—1 LT module (North America)
• LB—1 LT module (APAC)
• W—1 WiFi Module
yyy indicates the type and number of NIC ports. It can be one of the following:
• 4GP—4 general-purpose NIC ports
• 8GP—8 general-purpose NIC ports
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
7

• T1/ 1—1 T1/ 1 NIC port
• xDSL—1 VDSL NIC port
Regulatory Compliance
Table 3 lists the regulatory compliance specifications for a CSG300 series chassis.
Table 3: CSG300 Series Regulatory Compliance Specifications
Item Specification
Safety CB (I C/ N60950-1 and I C/ N 62368-1)
UL (CSA 22.2 No 62368-1 and UL62368-1)
Security TPM 2.0
Designed to be FIPS 140-2 Level 2 compliant
MC C , FCC Part 15, Class A
nvironmental RoHS
Certifications
A CSG300 series appliance complies with the certificates listed in Table 4.
Table 4: CSG300 Series Certifications
Region Certifications
uropean Union
Safety:
• N 60950-1:2005
• N 62368-1:2014
MC and Radio Frequency (Bluetooth, GPS, and MP (SAR valuation)):
• N 301 489-1 V2.2.3 (2019-11) Class A
• N 301 489-17 V3.1.1 (2017-02)
• Draft N 301 489-52 V1.1.0 (2016-11)
• N 301 893 V2.1.1 (2017-05)
• N 301 893-19 V2.1.1 (2019-04)
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
8

Region Certifications
• N 300 328 V2.1.1 (2016-11)
• N 301 908-1 V11.1.1 (2016-07)
• N 55032:2015/AC:2016 Class A
• N 55024:2010/A1:2015
• N 55035: 2017
• N 50385:2017
America
Safety:
• UL 62368-1, Second dition.
MI and Wireless:
• FCC 47 CFR Part 15, Subpart B, Class A
• FCC 47 CFR Part 15C, Subpart C (Section 15.247)
Japan
Telecom, Radio, MI:
• JAT —Article 9 and 34
• MIC—ARIB STD-T66 (V3.7)
• VCCI—CISPR 32:2016 Class A
xport Control Information
Table 5 lists the CCN, HTS, and CCATS numbers.
Table 5: ECCN, HTS, and CCATS Numbers
Item ECCN
Number
HTS
Number
CCATS
Number
Versa Use
of Item
MatrixSSL software module 5 002 8542310000 G161333 SSL VPN
Proxy
QuickSec IPsec toolkit used by Versa Analytics, Versa
Director, and Versa Operating SystemTM (VOSTM) device 5D002 8542310000 G161333 IPsec crypto
module
Hardware-based encryption and decryption 5A002U 8542310001 G156910L1 CSG300
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
9

Item ECCN
Number
HTS
Number
CCATS
Number
Versa Use
of Item
series
appliance
Front and Rear Panel Components
This article describes the front and rear panel components of a CSG300 series appliance. For the exact location of
these components on the appliance, see At a Glance.
Front Panel
The front panel of a CSG300 series appliance has two status L Ds.
L Ds
Table 1 lists the L Ds, their colors and states, and the status they indicate.
Table 1: Front Panel LEDs in a CSG300 Series Appliance
LED Color Status
Power Green • Off—Appliance is not powered on.
• Green—Appliance is powered on.
Status Green,
Red
• Off—Appliance hardware is up, but there is a problem with the configuration or software.
• Solid green—Controller connection is up and running, and probes and control plane packets
are being transmitted.
• Blinking green—Controller connection is in the process of being established.
• Solid red—Controller or CA has rejected this appliance, there is a certificate mismatch, or
the appliance is unreachable.
• Blinking red—Controller is unreachable or unresponsive.
Rear Panel
The rear panel of a CSG300 series appliance has six status L Ds, SIM card slots, and power and reset buttons.
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
10

L Ds
The rear panel of a CSG300 series appliance has six L Ds, located in two rows.
Table 2 lists the L Ds, their color and states, and the status they indicate.
Table 2: Rear Panel LEDs in a CSG300 Series Appliance
LED Color Status
Power Green • Off—Appliance is not powered on.
• Green—Appliance is powered on.
Status Green,
Red
• Off—Appliance hardware is up, but there is a problem with the configuration or software.
• Solid green—Controller connection is up and running, and probes and control plane
packets are being transmitted.
• Blinking green—A Controller connection is in the process of being established.
• Solid red—Controller or CA has rejected this appliance, there is a certificate mismatch, or
the appliance is unreachable.
• Blinking red—Controller is unreachable or unresponsive.
Cloud Green,
Red Currently not supported.
Wireless White
• Off—Wireless module is not installed.
• Solid white—Wireless module is up and running.
• Blinking white—Wireless module is booting.
LT White
• Off—LT module not installed or not connected.
• Solid white—LT module is up and running.
• Blinking white—LT module is connecting.
Bluetooth Blue • Off—Bluetooth module is not installed or services are not running.
• Solid blue—Bluetooth service is started and advertised.
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
11

SIM Card Slots
The rear panel of a CSG300 series appliance has two nano-SIM card slots. If you subscribe to a single wireless service,
use the SIM 1 slot to install the LT device. If you subscribe to dual wireless service, use both the SIM 1 and SIM 2 slots
to activate the LT devices.
Note: It is strongly recommended that you use only preactivated SIMs in the SIM card slots.
Power Button
The Power button on the rear panel of a CSG300 series appliance turns the power on and off.
To turn the power on, press and immediately release the Power button when the appliance is off.
To turn the power off, press the Power button when the appliance is on, as follows:
• If you press and immediately release the button, the appliance does a graceful software shutdown that is equivalent
to issuing the shutdown now command from the operating system shell.
• If you press and hold the button for 10 seconds or more, the power for the appliance turns off and the appliance
shuts down.
Reset Button
The Reset button on the rear panel of a CSG300 series appliance resets the appliance. The reset functionality depends
on the number of times you press the button within a span of 30 seconds, as described in Table 3. In between each
press on the reset button, you must pause for a second to register the key presses.
The Reset button is recessed so that it is not accidentally pressed while the appliance is operational.
To press the Reset button, use a sharp, narrow tool.
Table 3: Reset Button Press Behavior
Number
of Presses Behavior
2 Reset the appliance to the factory-default snapshot.
4 Reset the appliance to the branch prestaging configuration.
6 Reset the appliance to the branch staging configuration.
8 Reset the appliance to branch post-staging configuration.
You can reset the appliance to the factory-default configuration by issuing the request system reset CLI command.
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
12

Reset the Appliance to the Factory-Default Configuration from the CLI
You can reset the appliance to the factory-default configuration from the CLI. You can connect to the appliance through
the serial console port or by using SSH.
The factory default reset procedure may take up to 20 minutes to complete. Do not power off the appliance during this
time.
To reset an appliance to the factory default configuration:
1. To connect to the appliance through the serial console port, see Configure a Management Console to Connect to a
CSG300 Series Appliance.
2. Log in to the appliance CLI using the username "admin" and the password "versa123".
Note: To connect to the appliance using SSH, connect your PC to the management port of the appliance. For the
port mapping on the CSG700 series appliance, see Interface Numbering. The management port has the default
static IP address 10.10.10.10/24. Configure the PC IP address to any IP from this segment, for example,
10.10.10.1/24. Open an SSH session to the appliance using its IP address, 10.10.10.10.
3. Issue the following commands to reset the configuration to factory default. If the current software version on the
appliance is the same as that of the factory reset snapshot, the procedure takes about 10 minutes to complete. If
the software versions are different, the procedure takes about 20 minutes to complete. Do not power off the
appliance during the process.
%cli
%request system reset
4. Verify that all Versa services are running by issuing the vsh status command from the Linux bash CLI. The
following is a sample output of this command. If all the services are shown as stopped, issue the vsh start
command from the Linux bash CLI to start them manually.
#vsh status
versa-service is Running, [*] process 6784
versa-infmgr is Running, [-] process 5623
versa-rfd is Running, [-] process 5838
versa-vmod is Running, [-] process 5839
versa-ip2user is Running, [-] process 5844
versa-imgr is Running, [-] process 5848
versa-acctmgrd is Running, [-] process 5845
versa-fltrmgr is Running, [-] process 5648
versa-vstated is Running, [-] process 5625
versa-addrmgrd is Running, [-] process 5857
versa-rt-cli-xfm is Running, [-] process 5798
versa-rtd is Running, [-] process 5827
versa-dhcpd is Running, [-] process 5620
versa-eventd is Running, [-] process 5843
versa-vrrpd is Running, [-] process 5643
versa-dnsd is Running, [-] process 5646
versa-ppmd is Running, [-] process 5793
versa-snmp-xform is Running, [-] process 5800
versa-certd is Running, [-] process 5849
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
13

versa-ntpd is Running, [*] process 5612
versa-dhclient6 is Running, [-] process 5807
versa-redis is Running,[-] process 6927
versa-av-redis is Running, [-] process 5003
versa-spackmgr is Running, [-] process 5832
versa-monit is Running, [*] process 6078
versa-confd is Running, [*] process 4798
versa-fail2ban is Running, [*] process 6093
versa-auditd is Running, [*] process 6116
versa-nodejs is Running, [-] process 5775
5. Power off the appliance.
Additional Information
Factory Default Settings for Branch Devices
The Cloud Services Gateway (CSG) CSG355 and CSG365 appliances offer field configurability using the network
interface card (NIC) slot. This article describes the CSG355 and CSG365 NICs.
NIC Types
Table 1 describes the NICs and the Versa Operating SystemTM (VOSTM) software releases in which the NIC is
supported.
Table 1: CSG355 and CSG365 NIC Support
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
14

NIC Type and
Model NIC Options Description VOS Support
Gigabit Ethernet
• NIC-4GP
4-port RJ45
copper Po /
Po +
• Supports I 802.3af Type 1 Po and I 802.3at
Type 2 Po + devices over CAT 5e.
• ach port can supply up to 30 W of power, with a
maximum of 60 W for the module.
Releases
21.2.1 and
later
• NIC-4GP-120
W
4-port RJ45
Gigabit thernet
• Supports I 802.3af Type 1 Po and I 802.3at
Type 2 Class 4 Po + devices 802.3at-2009 over CAT
5e.
• ach port can supply up to 30 W of power, with a
maximum of 120 W for the module.
Releases
21.2.1 and
later
ADSL+/VDSL
• NIC-1VA
1 RJ45 port
ADSL+/VDSL,
Annex A
• Single-port ADSL+/VDSL module that supports Annex
A (POTS)
Releases
21.2.1 and
later
• NIC-1VB
1 RJ45 port
ADSL+/VDSL,
Annex B
• Single-port ADSL+/VDSL module that supports Annex
B (ISDN)
Releases
21.2.1 and
later
T1/E1
• NIC-4DS 4-ports RJ45 T1/
1
• Supports T1/ 1 framing
• Supports all common formats
• Supports PPP, HDLC, and Frame Relay encapsulations
Releases
21.2.1 and
later
The CSG355 and CSG365 appliances offer interface modularity, providing four thernet ports that support both Type 1
and Type 2 Po devices. ach port can provide up to 30 W of power, with a maximum of 60 W for the module, for
connecting Po devices such as cameras, access points, and VoIP handsets. The CSG355 and CSG365 appliances
support two types of NICs:
• 1-GB copper Gigabit thernet port
• 1-GB copper Gigabit thernet with Po port
The four thernet ports on the NIC module are labeled Port 6 through Port 9.
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
15

Figure 1 shows the four RJ-45 connectors for the four thernet ports (1-GB copper G port and for the 1-GB Copper G
with Po port).
Figure 1: CSG355 RJ-45 Connectors for 1-GB Copper GE Port with PoE Port
Figure 2 shows the four RJ-45 connectors slots for the 1-GB Copper G combination port.
Figure 2: CSG355 RJ-45 Connectors for 1-GB Copper GE Combination Port
Figure 3 shows the CSG350 series appliance VNI port mapping.
Figure 3: CSG350 RJ-45 Connectors for 1-GB Copper GE Combination Port
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
16

NIC Specifications
Table 2 lists the NIC specifications for a CSG300 series appliance.
Table 2: CSG300 Series NIC Specifications
Item Specification
Item Specification
Typical power consumption 10 Watts
System power input 3.3 VDC @ 3A
Po power adapter input 54 VDC @ 2.78A, 100-240 VAC @ 2A, 50-60 Hz
Physical Specifications
Height 1.54" (39 mm)
Width 3.25" (82.5 mm)
Depth 5.52" (140 mm)
Weight
• NIC-8G 0.33 lb (150 gm)
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
17

Item Specification
• NIC-4GP-120 W 0.44 lb (200 gm)
• NIC-1VA/1VB 0.33 lb (150 gm)
• NIC-4DS 0.44 lb (200 gm)
• NIC-4GF 0.33 lb (150 gm)
Package Specifications
Package height 3.25" (82.55 mm)
Package width 6" (152.4 mm)
Package depth 9" (228.6 mm)
Package weight 0.77 lb (350 gm)
Operating Conditions
Temperature 0 to 40°C (32 to 104°F)
Humidity 10 to 85% relative humidity
Altitude Maximum 3000 m (10000 ft)
Noise level 0 dBm
Storage Conditions
Temperature –20 to 70°C (–4 to 158°F) at sea level
Humidity 10 to 85% relative humidity
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
18

LT Modem Module
The CSG300 series LT modem module is a high-performance Cat-6 LT Advanced (LT -A) modem that provides
download speeds up to 300 Mbps and upload speeds up to 50 Mbps. The LT modem supports multiple carriers, and it
has been certified by major global carriers. The appliance has two externally accessible SIM card slots, one for each
embedded LT -A modem. If the appliance is configured with two LT -A modems, each SIM card controls one LT
radio. The appliance also has one USB slot that can be connected to an LT dongle. With two internal modems and one
USB-attached modem, you can deploy up to three simultaneous LT WAN connections.
The LT firmware-driven modem module provides the following capabilities:
• xternally accessible SIM cards that support dual-LT modems.
• Connects to most global carriers' network depending on the SIM card inserted. For example, if the SIM card
inserted is from Carrier A, the modem autodetects the SIM card and connects to Carrier A's network.
• Global navigation satellite system (GNSS) receiver enables tracking and location-based services.
• Stores up to three firmware versions, thereby allowing the modem to switch to other networks.
• Firmware can be upgraded over the air.
• Secure boot provides secure connectivity by preventing unauthorized code on target devices.
The LT modem connections are metered connections, and the Versa software implementation ensures that the LT
service is charged only when needed. Policies and scenarios that determine the use of LT interfaces are set by
network operators and implemented by Versa Operating SystemTM (VOSTM) devices accordingly.
Table 1 lists the supported LT specifications.
Table 1: LTE Specifications
Specification APAC Modem Americas and EMEA Modem
Peak
download/
upload rate
300/50 Mbps 300/50 Mbps
Frequency
bands 4G LT 1, 3, 5, 7, 8, 18, 19, 21, 28, 38, 39, 40, 41 1 through 5, 7, 8, 12, 13, 20, 25, 26, 29, 30, 41
Frequency
bands 3G
WCDMA 1, 5, 6, 8, 9, 19 1, 2, 3, 4, 5, 8
Supported
carrier
aggregation
1 + (8, 18, 19 ,21), 3 + (5, 7, 19, 28), 7 + (5, 7,
28), 19 + 21, 38 + 38, 39 + 39, 40 + 40, 41 + 41
1 + 8, 2 + (2, 5, 12, 13, 29), 3 + (7, 20), 4 + (4, 5,
12, 13, 29), 7 + (7, 20), 12 +30, 5 + 30, 41 + 41
Approvals C , GCF, JRF/JPA, KC, NCC C , FCC, GCF, IC, NCC, PTCRB
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
19

Specification APAC Modem Americas and EMEA Modem
Certified
Carriers KDDI, NTT Docomo, Softbank, Telstra Anatel, AT&T, Bell, Rogers, Sprint, Telus,
Verizon, Vodafone, US Cellular
Location
Solution Standalone, Xtra, SUPL 1.0 and 2.0,
GLONASS, Galileo, BeiDou
Standalone, Xtra, SUPL 1.0 and 2.0, GLONASS,
Galileo, BeiDou
You can order CSG300 series appliances with an optional LT modem module. The LT modem modules have either
one SIM slot or two SIM slots. For modules with one SIM slot, you insert the SIM card into the SIM1 slot, which is on the
back of the appliance. For modules with two SIM slots, you insert a SIM card into each of the two SIM slots, which are
labeled SIM1 and SIM2.
Note: If the appliance has two SIM card slots, use SIM slot 1 and vni-0/100 port for bootstrapping when you upgrade the
software to a later version.
If the appliance is powered off when you insert the SIM card or cards, the LT functionality is activated when you boot
the appliance. If you insert the SIM card or cards into the LT modem module when the appliance is powered on and
operational, you must reboot the appliance to restart the LT modem and LT functionality. To do this, you must power
off the appliance, unplug the power cable, plug the power cable back in, and press the power button. Simply powering
the appliance on and off does not restart the LT modem. Also, pressing the reset button on the appliance or rebooting
the appliance from Versa Director does not restart the LT modem.
mbedded WiFi Module
The CSG350 appliance has two internal wireless slots that can be configured for single LT or dual LT . The CSG355
and CSG365 appliances have three internal wireless slots.
The CSG300 series appliances have one WiFi access point (AP) module. It is a dual-band module that simultaneously
supports 2.4 GHz, for longer distances, and 5 GHz, for faster throughput. It provides the following WiFi capabilities:
• WiFi radios preconfigured for operation at 2.4 GHz or 5.0 GHz
• Supports DFS frequency bands, enabled by default, thereby providing more frequency bands for 5-GHz radio
• Supports 802.11ac Wave 2 standard and 2x2:2 Multi-User Multiple Input Multiple Output (MU-MIMO) for more
efficient transmission to multiple clients
• Built-in support for WiFi mesh capabilities
• Bluetooth for ZTP and smartphone applications
• Supports I 802.11a, 802.11b, 802.11g, 802.11n, and 802.11ac protocols
• Supports channel bandwidths of 20 MHz, 40 MHz, and 80 MHz
• Supports channel bonding with channel bandwidths of 5 MHz, 10 MHz, 20 MHz, and 40 MHz
• Background scanning automatically selects the best and cleanest channel
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui…
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
20
